Summary of Contents for Hyundai HYHT36Li
-
Page 2: Table Of Contents
CONTENTS o’s Page N Section Description 1. GETTING TO KNOW YOUR MACHINE 3 – 4 2. SAFETY REQUIREMENTS 3. SAFETY REGULATIONS 4 – 6 4. ELECTRIC HEDGE TRIMMER 6 – 8 5. MACHINE PARTS 6. OPERATING INSTRUCTIONS 10 – 14 7. -
Page 3: Getting To Know Your Machine
1. GETTING TO KNOW YOUR MACHINE 1.1. How to read the manual. 1.1.1. Certain paragraphs in the manual contain particularly significant information and are marked with various levels of highlighting with the following meaning: Non- observance Indicates a hazard NOTE or Non-observance Read Manual will result in the... -
Page 4: Safety Requirements
1.4.2. Improper use of the machine will invalidate the warranty, relieve the manufacturer from all liabilities, and the user will consequently be liable for all and any damage or injury to himself or others. 2. SAFETY REQUIREMENTS. 2.1. Your machine must be used carefully. 2.1.1. - Page 5 3.1. GENERAL POWER TOOL SAFETY 3.1.1. Work area safety. 3.1.1.1. Keep work area clean and well lit. Cluttered or dark areas invite accidents. 3.1.1.2. Do not operate power tools in explosive atmospheres’, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
-
Page 6: Electric Hedge Trimmer
3.1.4.4. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users. 3.1.4.5. Maintain power tools. - Page 7 use the machine. Local regulations can restrict the age of the user. The machine must never be used by more than one person. 4.3. Never use the machine; 4.3.1. When people, especially children or pets are in the vicinity; 4.3.2. If the user is tired or unwell, or has taken medicine, drugs, alcohol or any substances which may slow his reflexes and compromise his judgment judgement;...
- Page 8 4.8. User instructions for Batteries. 4.8.1. General precautions. 4.8.1.1. The battery must never be opened. 4.8.1.2. Never throw used batteries into a fire EXPLOSION RISK! 4.8.1.3. Connect the battery charger to power sockets carrying the voltage indicated on the manufacturer’s rating plate. 4.8.1.4.
-
Page 9: Machine Parts
5. MACHINE PARTS 1. Power unit. 2. Cutting device (blade). 3. Front guard. 4. Front handgrip. 5. Rear handgrip. 6. Blade protection. 7. Trigger switch. 8. Safety switch. 9. Battery (Battery). 10. Battery charger Page 9 Rev 2... -
Page 10: Operating Instructions
6. OPERATING INSTRUCTIONS The figures mentioned in the text of this manual are found on page 9. 6.1. Machine assembly. 6.1.1. Disposal of the packaging should be done in accordance with the local regulations in force. 6.1.2. For safety and transportation reasons, the lithium ion battery (if supplied) is delivered separately from the machine and partially charged. - Page 11 6.3. Charging the battery. Check that the socket mains voltage is the same as that indicated on the battery charger plate. 6.3.1. Remove the battery from the machine, 6.3.2. To recharge the battery, 6.3.2.1. Connect the battery charger (1) to a mains power socket; a green power light (3) will come on indicating there is voltage.
- Page 12 6.5. Managing the battery. 6.5.1. The battery must be kept in environments where the temperature is not in the range of 0°C +45°C. If the machine is stored in places where the temperature could exceed those limits, please remove the battery and keep it in a suitable place. 6.5.2.
- Page 13 6.7.2.5. Damage of the hearing, if no protection of the ears is carried. 6.7.3. Keep in mind that the operator or user is responsible for accidents or hazards occurring to other people or their property. 6.7.4. Always wear suitable clothing when using the machine. Your dealer can provide you with all the information on the most suitable accident-prevention devices to guarantee your safety.
-
Page 14: Maintenance
6.8.1. The battery is fitted with a protection system which prevents it from running completely flat. 6.8.2. The power tool will automatically switch OFF when the battery is flat. If this happens, it must be promptly recharged. 6.9. Working techniques. 6.9.1. - Page 15 7.3. Maintenance and sharpening of the Blade. Periodically check that the blades are not bent or damaged and that the fixed comb on the blade is intact. 7.3.1. Adjustment of the distance between blades is not necessary, as this is predetermined by the manufacturer.
-
Page 16: Troubleshooting
(no red led Charger. on). Defective battery charger Replace with original spare part. 9. SPECIFICATION HYHT36Li Hedge Trimmer Battery charger supply vac/hz 230/50 Battery type Samsung Lithium ion Battery voltage vdc Battery capacity Ah... - Page 17 nearest domestic waste collection service. 10.3. Reduce – Reuse - Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. Page 17 Rev 2...
-
Page 18: Contact Details
10.4. When the product is no longer required, it must be disposed of in a manner which is compatible with the environment. 11. GENPOWER CONTACT DETAILS 11.1. Postal address; Genpower Limited, Isaac Way, Pembroke Dock, Pembrokeshire, SA72 4RW, UK. 11.2. Telephone contact number;... -
Page 19: Declarations Of Conformity
12. DECLARATIONS OF CONFORMITY 12.1. Genpower Ltd confirms that this Hyundai product conform to the following CE Directives; 12.1.1. 2006/42/EC Machinery Directive 12.1.2. 2004/108/EC EMC Directive 12.1.3. 2000/14/EC, Amended by 2005/88/EC (as amended) Page 19 Rev 2... - Page 20 GENPOWER LTD Isaac Way, London Road Pembroke Dock, UNITED KINGDOM, SA72 4RW T: +44 (0) 1646 687 880 F: +44 (0) 1646 686 198 E: info@hyundaipowerequipment.co.uk www.hyundaipowerequipment.co.uk...
