SPECIFICATIONS

Model Name
Capacity
Power source
Power input
Current
Temperature set range Remote controller
Airflow direction
Fan Type x Quantity
External static press
Motor type
Motor output
Driving mechanism
Airflow rate(Low-Mid-High)
Airflow rate(Low-Mid-High)
Airflow rate(Low-Mid-High)
External finish
External dimension
H x W x D
Net weight
Wiring Min.size of wire
Amperage of wire breaker
Refrigerant Liquid R410A
piping diameter
Gas R410A
Drain piping diameter
Sound level (Low-Mid-High)
(measured in anechoic room)
Insulation material
Air filter
Refrigerant control device
Protection devices
Heat exchanger
Varistor
Terminal block
Power outlet
Document
Standard
Accessory
attachment
Remark
Note 1.Cooling/Heating capacity indicates the maximum value at operation under the following condition.
<Cooling> Indoor: 80 ˚ FD.B. / 67 ˚ FW.B. (26.7 ˚ CD.B. / 19.4 ˚ CW.B.) Outdoor:95 ˚ FD.B. (35 ˚ CD.B. )
<Heating> Indoor:70 ˚ FD.B. (21.1 ˚ CD.B.) Outdoor:47 ˚ FD.B. / 43 ˚ FW.B. (8.3 ˚ CD.B. / 6.1 ˚ CW.B.)
Pipe length: 24-9/16ft (7.5m)
2.Power consumption. Run current at 0.060[in.WG] (15Pa) (external static pressure)
3.Cooling capacity value at 1:1system
Heating capacity value at 1:1system
PEA-A12AA4
Cooling
BTU/h 12000
208/230V (60Hz)
kW
0.07
A
0.57
˚ F( ˚ C)
67 to 86 (19 to 30)
-
Sirocco fan x 2
in.WG(Pa)
0.02-0.06-0.14-0.20 (5-15-35-50)
DC brushless motor
kW 0.096
Direct-driven
7.0-9.0-11.0
3
m /min
247-317-388
CFM
L/S 116-150-183
Galvanized
mm
200 x 990 x 700
In. 7-7/8 x 39 x 27-9/16
kg
22
in.(mm)
1/8 (1.6)
A
15
in.(mm)
ø1/4 (ø6.35) Flare
in.(mm)
ø1/2 (ø12.7) Flare
in.(mm)
O.D. 1-1/4 (32)
dB<A> 23-28-33
Polystyrene foam, Polyethylene foam, Urethane foam
PP Honeycomb fabric (washable)
-
Fuse (250V 6.3A)
Cross fin (Aluminum fin and copper tube)
ERZV10D471
To outdoor unit : 3P To wired remote controller : 2P
A
10
Installation Manual, Instruction Book
Drain hose (flexible joint)
Height difference: 0ft (0m)
3
Heating Cooling
- 18000
208/230V (60Hz)
- 0.09
- 0.74
- 67 to 86 (19 to 30)
0.02-0.06-0.14-0.20 (5-15-35-50)
DC brushless motor
200 x 1190 x 700
7-7/8 x 46-7/8 x 27-9/16
ø1/4 (ø6.35) Flare
ø1/2 (ø12.7) Flare
Polystyrene foam, Polyethylene foam, Urethane foam
PP Honeycomb fabric (washable)
Fuse (250V 6.3A)
Cross fin (Aluminum fin and copper tube)
To outdoor unit : 3P To wired remote controller : 2P
Installation Manual, Instruction Book
Drain hose (flexible joint)
PEA-A18AA4
Heating
19000
0.07
0.63
63 to 83 (17 to 28)
-
Sirocco fan x 4
0.096
Direct-driven
12.0-15.0-18.0
423-529-635
200-250-300
Galvanized
28
1/8 (1.6)
15
O.D. 1-1/4 (32)
30-34-38
-
ERZV10D471
20
