HOW TO BUILD
YOUR
PLYFLY GO-KART!
For Ages 12+
PlyFly Go‑Kart Instruction Guide • 2015 Release

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the plyfly and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Flatworks plyfly

  • Page 1 HOW TO BUILD YOUR PLYFLY GO-KART! For Ages 12+ PlyFly Go‑Kart Instruction Guide • 2015 Release...
  • Page 2 Thank you We hope you’re as excited to get started on your new adventure as we are to be working on the FLATWORKS. Enjoy your new Plyfly Go‑Kart! Check back soon and see what else we make! the Flatworks Crew, &...
  • Page 3 Steven Hynes Cam McCulloch K Brotman Alan Miyasaki Dennis Cox Stephan Schnitker Chris DePerro Chris Patton Family Woo Joe Barton Marcus Leef Liam Newman Tyra Hammett Mohit No Regrets Nathan Pelsor Sam Bell Ray Colwell Douglas Dayton Emily H. Henry E. Sam Bowling Andrew Marc Carl Moulton...

  • Page 4: Table Of Contents

    What's Inside? 1 Exploring the kit 8 Pedal Assemblies Warnings and safety Plywood sheet reference Handling and storage Recommended tools Why Wood? Required hardware Good to know Required wooden parts What’s in the kit? Assembling the gas & the brake pedals Unpacking the boxes 9 Frame Assembly 2 Getting Started...

  • Page 5: Exploring The Kit

    Exploring the kit Introduction Each Plyfly Go-Kart kit arrives in 3 boxes. Review the contents of each box to ensure you have all the necessary parts to begin building your next adventure!

  • Page 6: Warnings And Safety

    Warnings and safety Handling and storage Riding karts can be dangerous. • The kart is heavy. Please use caution and prudence and follow the • Use at least two people to lift or move it. guidelines below. • Some surfaces may be hot after use, handle with •...

  • Page 7: Why Wood

    What’s in the kit? Sure, steel karts are fun and strong, but they require a large Each Plyfly Go-Kart kit arrives in 3 boxes. Box 1 is a flat box number of specialized tools to build, repair or modify. Tools with the wooden structural parts.

  • Page 8: Unpacking The Boxes

    Unpacking the boxes Each box should have the following components. Box 1 contents 2.5 HP 4.0 HP 4.0 HP 4.0 HP 4.0 HP SINGLE WHEEL SINGLE WHEEL SINGLE WHEEL LIVE AXLE LIVE AXLE № DESCRIPTION 10” WHEELS 10” WHEELS 12” WHEELS 10”...
  • Page 9 10” WHEELS 10” WHEELS 12” WHEELS 10” WHEELS 12” WHEELS DESCRIPTION Plyfly Packaged Hardware Kit Sealed kit of go ‑kart hardware Clutch #35 Chain, 11 Tooth Pulley for 5/8” shaft 2.5 HP Model ― ― ― ― Clutch #35 Chain, 12 Tooth Pulley for 3/4” shaft 4.0 HP Model ―...

  • Page 10: Getting Started

    Getting Started Introduction Preparing for a Plyfly Go-Kart build, you will need to cut out each structural wooden part from the plywood sheets. The more time spent trimming tabs cleanly will save a lot of sanding time.

  • Page 11: Getting Started

    Orbital sander Sandpaper Jigsaw or Reciprocating saw (optional) For more information on What’s in the kit?, see page 3. PlyFly Go‑Kart Instruction Guide • 2015 Release...

  • Page 12: Seat Assembly

    Seat Assembly Assembly Introduction Before beginning this assembly, be sure to chisel out and sand parts 22 ‑ 33. These 12 components are required to fully assemble the go‑kart seat...

  • Page 13: Plywood Sheet Reference

    Electric driver Required hardware № DESCRIPTION REFERENCE Sheet 3 ‒ Parts 22‑23 3/4” Plywood Sheet ‒ Parts 25‑27 32 Spax Screw #8, 1‑1/2” L PN 12519 Sheet 4 ‒ Parts 28‑31 1/4” Plywood Sheet PlyFly Go‑Kart Instruction Guide • 2015 Release...

  • Page 14: Required Wooden Parts

    PLYWOOD SHEET 3 Note If you received a 1/4” plywood sheet that is finished on one side and you intend to paint the Plyfly go-kart seat; reverse the wooden parts 28-33 (so the unfinished side is outward facing and ready to receive paint).

  • Page 15: Assembling The Seat

    Note the location and orientation of the part 32. 14. Repeat step 13 with part 30 on the opposite side. 15. Secure parts 30‑31 to seat frame using screws. ‒ Use 4 screws. ‒ Total of 4 locations. PlyFly Go‑Kart Instruction Guide • 2015 Release...

  • Page 16: Steering Column Assembly

    Steering Column Assembly Introduction Before beginning this assembly, be sure to chisel out and sand parts 19‑20. These 3 components are required to fully assemble the steering shaft.

  • Page 17: Plywood Sheet Reference

    #8, 1‑1/2” L PN 12519 Required wooden parts DESCRIPTION REFERENCE 5 21 Part 19 Steering Column Shaft PLYWOOD SHEET 2 Part 20 Steering Pinion PLYWOOD SHEET 1 Part 21 Steering Wheel PLYWOOD SHEET 2 PlyFly Go‑Kart Instruction Guide • 2015 Release...

  • Page 18: Assembling The Steering Shaft

    Assembling the steering shaft INSTRUCTIONS 1. Press bushings into each side of part 20. 6. Secure the parts using screws. ‒ Use 2 screws on part 20 Note there are 2 bushings, 1 bushing per side. ‒ Total of 2 locations. 7.

  • Page 19: Steering Rack Assembly

    Steering Rack Assembly Introduction Before beginning this assembly, be sure to pre‑cut and sand parts 9 ‑ 12. These 4 components are required to fully assemble the go‑kart steering rack.

  • Page 20: Plywood Sheet Reference

    Plywood sheet reference Recommended tools DESCRIPTION REFERENCE DESCRIPTION REFERENCE Sheet 1 ‒ Parts 9‑10 3/4” Plywood Sheet Dead blow hammer or mallet Hammer Screwdriver Sheet 2 ‒ Parts 11‑12 Electric driver 3/4” Plywood Sheet Required hardware № DESCRIPTION REFERENCE Spax Screw #8, 1‑1/2”...

  • Page 21: Required Wooden Parts

    Note the part 12 orientation – the gear teeth should point in the same direction. Bracket PLYWOOD SHEET 2 4. Secure part 12 to the assembly using screws. ‒ Use 2 screws. ‒ Total of 2 locations. PlyFly Go‑Kart Instruction Guide • 2015 Release...

  • Page 22: Fixed Steering Column Assembly

    Fixed Steering Column Assembly Introduction Before beginning this assembly, be sure to pre‑cut and sand parts 13 ‑ 18. These 6 components are required to fully assemble the go-kart fixed steering column.

  • Page 23: Plywood Sheet Reference

    Dead blow hammer or mallet Hammer Required hardware № DESCRIPTION REFERENCE Sheet 2 ‒ Parts 14‑18 3/4” Plywood Sheet Small Tee Nut Zinc Plated, 5/16”‑18 PN 12510 12 Spax Screw #8, 1‑1/2” L PN 12519 PlyFly Go‑Kart Instruction Guide • 2015 Release...

  • Page 24: Required Wooden Parts

    Assembling the steering column Required wooden parts DESCRIPTION REFERENCE INSTRUCTIONS 1. Press t ee nuts into parts 15 & 18 Note the orientation of part 15. Part 13 Steering Column Left PLYWOOD SHEET 1 Note the orientation of part 18. Part 14 2.

  • Page 25: Steering Spindle Assemblies

    Steering Spindle Assemblies Introduction Before beginning this assembly, be sure to chisel out and sand parts 1‑8. These 8 components are required to fully assemble 2 steering spindle. Each assembly contains 4 parts.

  • Page 26: Plywood Sheet Reference

    Plywood sheet reference Recommended tools DESCRIPTION REFERENCE DESCRIPTION REFERENCE ‒ Part 1 Sheet 1 ‒ Parts 3‑4 3/4” Plywood Sheet ‒ Parts 6‑8 Dead blow hammer or mallet Hammer Electric Driver Sheet 2 ‒ Part 2 3/4” Plywood Sheet ‒ Part 5 Required hardware №...

  • Page 27: Required Wooden Parts

    Part 5 Steering Spindle Bottom Left PLYWOOD SHEET 2 Part 6 Steering Spindle Bottom Right PLYWOOD SHEET 1 Part 7 Steering Spindle Top PLYWOOD SHEET 1 Part 8 Steering Spindle Top PLYWOOD SHEET 1 PlyFly Go‑Kart Instruction Guide • 2015 Release...

  • Page 28: Assembling The Left & Right Steering Spindles

    Assembling the left & right steering spindles INSTRUCTIONS 1. Press bushings into parts 1‑2, 5‑6, & 7‑8 7. Using a mallet, cap the parts 1, 3, 5 with part 7. 8. Using a mallet, cap the parts 2, 4, 6 with part 8. Note the orientation of part 1 &...

  • Page 29: Pedal Assemblies

    Pedal Assemblies Introduction Before beginning this assembly, be sure to chisel out and sand parts 34 ‑ 39. These 6 components are required to fully assemble the go‑kart gas and brake pedals. Each assembly contains 3 parts.

  • Page 30: Plywood Sheet Reference

    Plywood sheet reference Recommended tools DESCRIPTION REFERENCE DESCRIPTION REFERENCE ‒ Parts 34 Sheet 1 3/4” Plywood Sheet ‒ Parts 36‑39 Dead blow hammer or mallet Hammer Electric Driver Sheet 3 ‒ Parts 35 3/4” Plywood Sheet Required hardware № DESCRIPTION REFERENCE Plastic Bushing Flanged, 1/4”...

  • Page 31: Required Wooden Parts

    Note part location and orientation of parts 36-37. Be sure to square the parts. 5. Secure parts 35, 38 & 39 using screws. ‒ Use 2 screws per part & per side. ‒ Total of 4 locations, 4 screws. PlyFly Go‑Kart Instruction Guide • 2015 Release...

  • Page 32: Frame Assembly

    Frame Assembly Introduction Before beginning this assembly, be sure to chisel out and sand parts 40‑55. These 11 components and assemblies1‑3 are required to fully assemble the go‑kart frame.

  • Page 33: Plywood Sheet Reference

    1/4” Plywood Sheet ‒ Part 50 ‒ Parts 44‑46 ‒ Part 51 Sheet 2 Sheet 4 ‒ Part 48 ‒ Part 53‑54 3/4” Plywood Sheet 1/4” Plywood Sheet ‒ Part 52 ‒ Part 55 PlyFly Go‑Kart Instruction Guide • 2015 Release...

  • Page 34: Recommended Tools

    Recommended tools Required assemblies DESCRIPTION REFERENCE DESCRIPTION REFERENCE Dead blow Hammer or mallet Steering rack Assembly Hammer Parts 9‑12 Electric Driver Screwdriver Fixed steering column Assembly Parts 13‑18 Required hardware № DESCRIPTION REFERENCE Drawer Slide Hardware included, 10” L PN 12508 Steering column Assembly Large Metal Bushing...

  • Page 35: Required Wooden Parts

    Front‑end Bottom PLYWOOD SHEET 2 Part 52 Frame Gusset PLYWOOD SHEET 2 Part 45 Front‑end Top PLYWOOD SHEET 2 Part 46 Frame Rail Bracket PLYWOOD SHEET 2 Part 47 Sprocket Guard PLYWOOD SHEET 3 PlyFly Go‑Kart Instruction Guide • 2015 Release...

  • Page 36: Assembling The Frame

    Assembling the frame INSTRUCTIONS 1. To begin this assembly 5. Press the large tee nuts into ‒ Start at Step 2 if you have a ‒ Part 42‑43 SINGLE WHEEL KIT ‒ Start at Step 4 if you have a ‒...
  • Page 37 Note the letter L should face part 41, away from the centerline of the go-kart. ‒ Total 4 locations 15. Test the drawer slide fit by moving the slide back and forth. ‒ Be sure there are no interferences between any screw head and the slide. PlyFly Go‑Kart Instruction Guide • 2015 Release...
  • Page 38 20. Repeat steps 18 and 19 using 25. Secure part 44 to the assembly using screws. ‒ Part 42 ‒ There is a purposeful gap in alignment to allow part 51 to sit flush with the assembly. ‒ Part 43 ‒...
  • Page 39 37. Install the 3 mounted bearings Note the orientation, location and position of each mounted bearing. 33. Secure part 52 using screws. ‒ Use 2 screws. ‒ Total of 2 locations. PlyFly Go‑Kart Instruction Guide • 2015 Release...
  • Page 40 38. Using a mallet, tap part 51 into place. 39. Secure part 51 to the assembly using 21 screws. ‒ Total of 21 locations, 21 screws. 40. Flip assembly right side up. 41. Lay part 50, with the small tee nuts facing upwards, into place.

  • Page 41: Putting The Go-Kart Together

    Putting the go-kart together Introduction Before beginning this final assembly, be sure to have assemblies 1‑7 completed. These 8 assemblies are required to fully assemble the go‑kart. This chapter contains 10 individual procedural parts to successfully complete the full go‑kart assembly.

  • Page 42: Overview Of The Recommended Tools

    Overview of the recommended tools Overview of the required hardware DESCRIPTION REFERENCE № DESCRIPTION REFERENCE PART 1 Dead blow Hammer 1 Sprocket or mallet 5/8” bore diameter 60 Tooth, #35 Chain PN 12522 1 Drive Shaft Hammer Steel, Keyed, 5/8” D, 18” L SINGLE WHEEL KIT PN 12580 1 Drive Shaft Electric Driver...
  • Page 43 1 Throttle Return Clip 1 Red Throttle Cable 4.0 HP MODEL Brake conduit, 5’ L PN 12561 PN 12527 8 Sheetmetal Screw 1 Green Throttle Cable Galvanized, #6 Gas conduit, 6’ L PN 12551 PN 12528 PlyFly Go‑Kart Instruction Guide • 2015 Release...
  • Page 44 12553 1 Lock washer 1 T‑Handle 5/16” ID Quick Release Pin 12542 1 Clutch Key 1 Flag 3/16”, 1/2” L Plyfly flag PN 12557 12535 2 Set Screw PART 10 Clutch PN 12563 20 Spax Screw 1 #8, 1‑1/2” L...

  • Page 45: Overview Of The Required But Not Provided

    Fairing Front PLYWOOD SHEET 4 PARTS 34, 36‑37 Brake Pedal Assembly PARTS 35, 38‑39 Left Spindle Assembly PARTS 1, 3, 5, 7 Right Spindle Assembly PARTS 2, 4, 6, 8 Frame Assembly PARTS 21‑28 PlyFly Go‑Kart Instruction Guide • 2015 Release...
  • Page 46 Required hardware Chapter 10 № DESCRIPTION REFERENCE Sprocket 5/8” bore diameter P ART 60 Tooth, #35 Chain PN 12522 Recommended tools Drive Shaft DESCRIPTION REFERENCE Steel, Keyed, 5/8” D, 18” L SINGLE WHEEL KIT PN 12580 Dead blow Hammer or mallet Drive Shaft Steel, Keyed, 5/8”...

  • Page 47: Part 1 Install The Rear Axle

    42. Note the drive shaft extends equal distances on both sides of the assembly. 9. Ensure all the hardware on mounted bearings are fully tightened PlyFly Go‑Kart Instruction Guide • 2015 Release...

  • Page 48: Part 2 Install The Brake Caliper

    Part 2 Install the brake caliper Chapter 10 The brakes will initially be installed and then adjusted. INSTRUCTIONS 1. Insert the socket head cap screws with an oversized flat washer through the holes located on part 43, P ART ‒ Use 1 socket head cap screw with 1 oversized flat washers per location.

  • Page 49: Part 3 Install The Steering Column Assembly

    3/8” D, 2‑1/4” L, 5/16”‑18 PN 12514 3. To secure, tighten both the shoulder screws Required assemblies ‒ Total 2 locations. DESCRIPTION REFERENCE Steering rack Assembly Parts 9‑12 Steering Column Assembly PARTS 19‑21 PlyFly Go‑Kart Instruction Guide • 2015 Release...

  • Page 50: Part 4 Install The Steering Spindles

    Part 4 Install the steering spindles Chapter 10 INSTRUCTIONS 1. Slide the steering rack all the way to the right. 7 with the bolt facing out. 2. Insert P ART 7 are completely seated ‒ Check that the bushings on before installing.

  • Page 51: Part 5 Install The Gas & Brake Pedals

    Parts 35, 38‑39 5. Using a hammer, tap into place. 6. Test the alignment of each pedal assembly. ‒ Each pedal should be able to move freely and independently (some drag is expected). PlyFly Go‑Kart Instruction Guide • 2015 Release...
  • Page 52 Reference Assemblies Chapter 10 DESCRIPTION REFERENCE P ART Fixed steering column Assembly Recommended tools PARTS 13‑18 DESCRIPTION REFERENCE Needle Nose Pliers Gas Pedal Assembly Parts 34, 36‑37 Allen Wrench Brake Pedal Assembly Socket Wrench Parts 35, 38‑39 Required Assemblies Frame Assembly №...

  • Page 53: Part 6 Install The Gas & Brake Cables

    ‒ through the hole located on the left side of part 17. Note the location and direction of the red cable. Be sure to seat the red cable in the notches located on part 19 of PlyFly Go‑Kart Instruction Guide • 2015 Release...
  • Page 54 6. Continue to run green cable on the right side of 11. Feed the brake control cable through a washer into the the go‑kart fitting located on the brake. ‒ Through the cable ties located on Note path of the brake control cable through the brake caliper. ‒...
  • Page 55 1/16” D, throttle & brake control cable Parts 34, 36‑37 PN 12525 1 Throttle cable clamp PN 12537 1 Extension Spring Black‑Oxide, Precision PN 12560 Frame Assembly 1 Throttle Return Clip PARTS 21‑28 4.0 HP MODEL PN 12561 PlyFly Go‑Kart Instruction Guide • 2015 Release...

  • Page 56: Part 7 Install The Engine And Drive Train

    Part 7 Install the engine and drive train Required hardware The engine arrives with no oil, no configuration is required. № DESCRIPTION REFERENCE INSTRUCTION 8 Sheetmetal Screw Galvanized, #6 1. Stand the engine on part 50 located on PN 12551 aligning the engine mounting holes to the tee nut pattern (installed previously) appropriate for the engine model.
  • Page 57 ‒ Be sure to align the keyway on the clutch with the keyway on the drive shaft. Note the orientation of clutch; the small sprocket should face the engine. PlyFly Go‑Kart Instruction Guide • 2015 Release...
  • Page 58 11. Insert 1/2” clutch key through the center of the clutch. 15. Connect the chain by sliding the posts of the master link into the holes located at the ends of the chain. 12. Using an Allen wrench tighten the set screws. Note the order of the assembled hardware.
  • Page 59 25. Thread the green cable into the right side of the engine. 28. Install the extension spring, by hooking one end to the Note the location of the green cable. hole located on the throttle linkage. Note the location of the extension spring. PlyFly Go‑Kart Instruction Guide • 2015 Release...
  • Page 60 29. Using pliers, hook the other end of the extension spring to 32. Continue to feed the throttle control cable all the way the throttle return clip. through to Note the location of the extension spring. Note the location of the throttle control cable. 33.

  • Page 61: Part 8 Install The Wheel Assemblies

    16. Secure the axle to the driven wheel using the shaft collar. 12593 SINGLE WHEEL KIT ‒ Use a socket wrench to tighten the locknut; while holding the locknut on alternate side with wrench. 3/16” square, 1”L PN 12539 PlyFly Go‑Kart Instruction Guide • 2015 Release...

  • Page 62: Part 9 Install The Seat Assembly

    41 located on the right side of the go‑kart. 12542 6. Insert the flag through holes located on the back right side of Seat Assembly and the go‑kart frame. Flag Note the location of the flag holes. Plyfly flag 12535 Required assemblies DESCRIPTION REFERENCE Seat Assembly PARTS 22‑33...

  • Page 63: Part 10 Install The Fairings

    ‒ Use 6 screws. unfinished side is facing outward and ready to receive paint). For more information on Visual reference of the plywood sheets, see page 61. ‒ Total of 6 locations FINISHED!! TIME TO RIDE!! PlyFly Go‑Kart Instruction Guide • 2015 Release...

  • Page 64: Master List

    Master List...

  • Page 65: Visual Reference Of The Plywood Sheets

    Note If you received a 1/4” plywood sheet that is finished on one side and you intend to paint the Plyfly go-kart seat or fairings; reverse wooden parts 28-33 and parts 53-55 (so the unfinished side is outward facing and ready to receive paint).

  • Page 66: List Of The Wooden Parts

    List of the wooden parts List of the wooden parts reference image reference image DESCRIPTION DESCRIPTION Part 1 Part 9 Steering Spindle Outer Spacer Steering rack Bracket PLYWOOD SHEET 1 PLYWOOD SHEET 1 Part 2 Part 10 Steering Spindle Outer Spacer Steering rack Bracket PLYWOOD SHEET 2 PLYWOOD SHEET 1...
  • Page 67 Part 31 Seat Side Right Seat Thigh Bolster Right ‒ gas tank side PLYWOOD SHEET 4 PLYWOOD SHEET 3 Part 24 Part 32 Seat Crossbar Seat Back PLYWOOD SHEET 1 PLYWOOD SHEET 4 PlyFly Go‑Kart Instruction Guide • 2015 Release...
  • Page 68 List of the wooden parts List of the wooden parts reference image reference image DESCRIPTION DESCRIPTION Part 41 Frame Rail Inner Right Part 33 PLYWOOD SHEET 1 Seat Bottom PLYWOOD SHEET 4 Part 42 Frame Rail Outer Left Part 34 PLYWOOD SHEET 1 Brake Pedal PLYWOOD SHEET 1...
  • Page 69 Floor Panel PLYWOOD SHEET 4 Part 52 Frame Gusset PLYWOOD SHEET 2 Part 53 Fairing Left PLYWOOD SHEET 4 Part 54 Fairing Right PLYWOOD SHEET 4 Part 55 Fairing Front PLYWOOD SHEET 4 PlyFly Go‑Kart Instruction Guide • 2015 Release...

  • Page 70: List Of The Wooden Assemblies

    Note If you received a 1/4” plywood sheet that is finished on one side and you intend to paint the Plyfly go-kart seat or fairings; reverse wooden parts 28-33 and parts 53-55 (so the unfinished side is outward facing and ready to receive paint). For a complete list of wooden parts, go to “List of the wooden parts”...

  • Page 71: List Of The Tools Needed

    Dead blow Hammer Metric Allen Wrench or mallet included with mounted bearing Sandpaper Socket Wrench Orbital Sander Wrench (optional) Jigsaw or Needle Nose Pliers Reciprocating Saw (optional) Electric Driver Impact Driver (optional) PlyFly Go‑Kart Instruction Guide • 2015 Release...

  • Page 72: List Of Loose Contents

    List of loose contents 2.5 HP 4.0 HP 4.0 HP 4.0 HP 4.0 HP SINGLE WHEEL SINGLE WHEEL SINGLE WHEEL LIVE AXLE LIVE AXLE № KIT DESCRIPTION 10” WHEELS 10” WHEELS 12” WHEELS 10” WHEELS 12” WHEELS Clutch 12576 #35 Chain, 11 Tooth Pulley for 5/8” D ―...
  • Page 73 10” D Wheels 12591 ― ― Undriven wheel 12” D Wheels 12592 ― ― ― Rear driven wheel 12” D Wheels 12593 ― ― ― Undriven wheel Flatworks Flag 12535 Plyfly safety flag PlyFly Go‑Kart Instruction Guide • 2015 Release...

  • Page 74: List Of The Packaged Contents

    List of the packaged contents 2.5 HP 4.0 HP 4.0 HP 4.0 HP 4.0 HP SINGLE WHEEL SINGLE WHEEL SINGLE WHEEL LIVE AXLE LIVE AXLE № KIT DESCRIPTION 10” WHEELS 10” WHEELS 12” WHEELS 10” WHEELS 12” WHEELS Large Metal Bushing 12504 Flanged, 3/4”...
  • Page 75 3/16”, 1/2” L Throttle Return Clip 12561 ― 4.0 HP MODEL Button Head Cap Screw 12562 ― 5/16”‑24, 3/4” L Set Screw 12563 Clutch Pan head 12564 M6, 12 mm L ― 4.0 HP MODEL PlyFly Go‑Kart Instruction Guide • 2015 Release...

  • Page 76: Legal

    Legal...

  • Page 77: Legal

    (all collectively hereinafter referred to as “I” or “me” or “my”, In the event of a medical emergency, I hereby authorize Flatworks and as the case may be), in consideration of being permitted to use and...

  • Page 78: Terms & Conditions

    Terms & Conditions...

  • Page 79: Terms & Conditions Of Purchase And Use

    RISK AND RELEASES), WAIVERS, INDEMNIFICATION PROVISIONS, malfunction from whatever cause, or any other negligence or fault of Flatworks, User, for himself or herself, and for anyone acting on his or her LIMITATIONS OF LIABILITY, LIMITED WARRANTIES, A COVENANT NOT behalf, further agree to hold harmless, defend, and indemnify Flatworks...
