Building Automation Industrial Automation Systems Product Information Switching, Control and Communication – SIMPLY ea y The easy400, 600, 800 control relays Bildgrösse 210 x 118,5 mm Logo 17 x 17 mm Think future. Switch to green. -
Page 2: Start Up And Control
The easy Family Start up and control – SIMPLY ea y The new control relay, easy800, combines virtually all the performance features of a PLC with the handling convenience of easy. Together with the easy400 and easy600, it forms a cohesive system with uniform accessories, software and operation, designed for intelligent solutions in machine and instrument control or in building services. - Page 3 Logic links instead of wiring Circuit diagrams form the basis for all electrical applications. Conventionally, the resulting circuits are implemented by wiring of switching and control devices. With the easy control relay, this is done quite simply using keystrokes or the convenient easy-soft software at the PC, for making the logic connections.
- Page 4 Using easy ea y Showing Your Business in a Favourable Light Lighting for shop windows: • Automatic daylight- and clock-controlled switching of lighting and external advertising shows products in a “favourable light”. • Lighting can be activated in the event of an alarm or at random.
- Page 5 Using easy ea y Helps Industry Save Costs HGV cooling system: • Operating temperature range -25 °C to +55 °C of all the easy devices enables them to be used directly in outdoor installations, on vehicles, etc. • easy is particularly cost efficient: it can do without the keypad and display window and then costs less.
- Page 6 Networking easy With Built-in NET – Communication simplified The easy800 control relays can be simply and economically networked with one another by means of the built-in NET network interface. Up to eight easy800 units can communicate with one another via this interface at a distance of up to 1000 m, irrespective of whether the individual device is processing its own program or being used merely as a remote input/output module.
- Page 7 in Automatic ea y Interaction – With Fieldbus Connection to the Production Process Commanding, indicating, monitoring and control at Bit level Even for straightforward sequences, such as in production processes, the bus connection is worthwhile. The actuator- sensor interface, AS-i for short, can supply 31 stations simultaneously with up to 248 binary instructions.
- Page 8 easy Expansion Local and Remote Expansion - Simply ea y The expandable basic units of the easy600 and easy800 series permit local or remote expansion of inputs/outputs. Combining them with EASY 618-AC-RE, EASY618-DC-RE or EASY620-DC-TE expansion modules produces a unit with 24 inputs and up to 16 outputs.
- Page 9 easy Wiring “Wiring” by Keystroke – Inputting Circuit Configuration and Parameters Directly Enter contact ”I1“ Enter contact ”I2“ Each of the eight selection buttons has its own specific function. The OK button activates the selected function. The four cursor keys, up, down, left and right, allow the user to make his selection from the actions to be taken.
- Page 10 easy Selection EASY 412-AC-RC EASY 412-DC-TCX EASY 412-DA-RC 400 Series Basic Units Supply voltage 12 V DC 115/240 V AC 115/240 V AC 24 V DC 24 V DC 115/240 V AC 115/240 V AC Heat dissipation 5 VA Inputs, digital Inputs, analog –...
- Page 11 easy Inputting ea y -Soft – The Convenient Way to Input the Circuit Configuration easy-soft makes programming particularly simple for the user. The graphics editor shows the desired representation of the circuit diagram directly. Selection menus and drag- and drop functions facilitate logic connections. Simply select and connect contacts and coils, all at the click of a mouse button –...
- Page 12 Moeller addresses world-wide: www.moeller.net/address Moeller GmbH Industrial Automation Hein-Moeller-Str. 7 -11 D-53115 Bonn E-Mail: info @ moeller.net Internet: www.moeller.net © 2002 by Moeller GmbH Subject to alterations W2528-7519GB MDS/DM Printed in the Federal Republic of Germany (03/02) Article No.: 259331 Xtra Combinations is the new world of automation from Moeller.
