- Page 1 Atlas Copco Instruction Manual Instruction Manual for Atlas Copco WEDA Dewatering Pump English WEDA 30 all options WEDA 40...
- Page 3 Instruction Manual for Atlas Copco WEDA Dewatering Pump WEDA 30 WEDA 40 Original Printed matter N° 9822 1686 00-0 ATLAS COPCO - PORTABLE ENERGY DIVISION www.atlascopco.com 12/2013...
- Page 4 Neglecting maintenance or making changes to the setup of the machine can result in major hazards. While every effort has been made to ensure that the information in this manual is correct, Atlas Copco does not assume responsibility for possible errors.
-
Page 5: Table Of Contents
Table of contents Preface Operating instructions......13 Transport ............ 13 Please read the following instructions carefully before starting to use your pump. Safety precautions ........7 Starting ............13 Introduction ..........7 Stopping ............. 13 It is a solid, safe and reliable machine, built according to the latest technology. - Page 6 - 6 -...
-
Page 7: Safety Precautions
To be read attentively and acted accordingly before operating, performing maintenance or repairing the unit. INTRODUCTION PICTOGRAMS AND SYMBOLS The policy of Atlas Copco is to provide the users of Take the necessary steps to keep unauthorized This manual contains safety instructions that, when their equipment with safe, reliable and efficient persons away from the unit and eliminate all possible not observed, can lead to dangerous situations. -
Page 8: Authorised Personnel
In principle all Not observing the safety instructions may lead to repair on Atlas Copco equipment. maintenance has to be performed on a non-energised personal injury, damage to the equipment and pump. -
Page 9: Unintended Use
UNINTENDED USE DATA PLATE The reliability of the pump is only guaranteed when it Reference Name is used according the specifications in this manual. The limits as indicated are not to be exceeded under Serial number any circumstances. Pump type Do not use the pump to transport water for human consumption, for water well pumping or for Protection class... -
Page 10: General Description
IMPELLER The design with outer jacket for cooling and motor protector keeps the pump running safely under The WEDA 30 and 40 pumps are equipped with a various conditions. The double mechanical seal runs high chrome steel impeller. in an oil bath and assures a long life time. -
Page 11: Options
Options FLOAT SWITCH MOTOR PROTECTION PLUG To protect the motor against over current it is strongly recommended to use an external motor protector (option only for pumps with 400V - 3ph motor). The external motor protector can be ordered separately. It combines the on/off switch and the overload protection in one device, thus creating optimal operating comfort and protection for the pump. -
Page 12: Zinc Anodes
ZINC ANODES LOW SUCTION COLLAR DISCHARGES Discharge Part number 3” Hose standard with 1 clamp 470W203562 3” BSP - thread 470W203484 3” NPT - thread 470W203570 4” Hose standard with 1 clamp 470W203564 4” BSP - thread 470W203482 4” NPT - thread 470W203572 3”... -
Page 13: Operating Instructions
Operating instructions TRANSPORT In case the motor stops due to overload or a blocked Always use the handle to lift the pump. impeller, first pull the plug out of the socket before Never use the power cable to lift or removing the pump from the pump site to check for transport the pump. -
Page 14: Maintenance
Check cable gland Check pipes, valves Check float switch / Level sensor NVB function Check external damage, loose parts For maintenance kits and spare parts please refer to the Atlas Copco Spare parts list 9822 1666 00. - 14 -... -
Page 15: External Damage, Loose Parts
EXTERNAL DAMAGE, LOOSE PARTS IMPELLER Make sure that all screws, bolts and nuts are tight. Inspect the impeller by removing the strainer and Check the condition of the pump lifting handle and wear plate. Replace the impeller if it is damaged or replace if damaged or worn. -
Page 16: Troubleshooting
Troubleshooting Problem Cause Action Pump will not run 1. Fuse blown or circuit breaker tripped 1. Replace fuse or reset circuit breaker 2. Broken cable 2. Replace cable 3. Power failure 3. Restore power supply 4. Impeller jammed 4. Clean impeller 5. -
Page 17: Technical Details
Technical details Unit WEDA 30 WEDA 40 Discharge, smooth and threaded BSP inch 3” 3” inch 4” 4” Weight Max solids handling Cable length Max submersed depth Impeller type centrifugal impeller centrifugal impeller Impeller material high chrome steel high chrome steel... -
Page 18: Dimensions
DIMENSIONS MOTOR DATA (50Hz) Voltage Max. power consumption Max. current A WEDA 30 230V/1ph 12.0 230V/3ph 400V/3ph 500V/3ph WEDA 40 230V/3ph 10.0 400V/3ph 500V/3ph (60Hz) Voltage Max. power consumption Max. current A Dimensions WEDA WEDA WEDA in mm WEDA 30 230V/1ph 11.5... -
Page 19: Wiring Diagram
WIRING DIAGRAM 470W214834-1 470W214836-1 Δ Δ WEDA 30 - 110V/1ph/50Hz WEDA 30 - 230V/3ph/50Hz WEDA 40 - 230V/3ph/50Hz Δ Δ WEDA 30 - 110V/1ph/60Hz WEDA 30 - 230V/3ph/60Hz WEDA 40 - 230V/3ph/60Hz Δ Δ WEDA 30 - 230V/1ph/50Hz WEDA 30 -... - Page 20 Reference Name Phase inverter Overcurrent relay 470W214835-1 On/Off switch WEDA 30 - Y 400V/3ph/50Hz WEDA 40 - Y 400V/3ph/50Hz Phase control WEDA 30 - Y 440-460V/3ph/60Hz WEDA 40 - Y 440-460V/3ph/60Hz WEDA 30 - Y 380V/3ph/60Hz WEDA 40 - Y 380V/3ph/60Hz...
-
Page 21: Flow Characteristics
2:30L-400V-3~ 2:30L-400V-3~ 1:30L-230V-1~ 1:30L-230V-1~ 3:30N-230V-1~ 4:30N-400V-3~ 80 100 120 140 160 180 200 220 240 260 280 300 320 340 1000 1200 1400 Flow (USGPM) Flow (l/min) WEDA 30 - 50 Hz WEDA 30 - 60 Hz - 21 -... - Page 22 Power Electrical WEDA 40 Power Electrical WEDA 40 1000 1200 1400 Flow (l/min) Flow (USGPM) Performance Curve WEDA 40 Performance Curve WEDA 40 1:40N-460V-3-60 1:40L-400V-3~ 1000 1200 1400 Flow (l/min) Flow (USGPM) WEDA 40 - 50 Hz WEDA 40 - 60 Hz - 22 -...
-
Page 23: Spare Parts
OIL SPECIFICATION For spare parts see spare parts list: Oil capacity: 0.25 L 9822 1666 00 - ASL WEDA 30 Oil: partnr. 1605 2254 00 (2 L) 9822 1666 00 - ASL WEDA 40 Oil: partnr. 1605 2255 00 (0.5 L) -
Page 24: Warranty
In the event of a warranty claim please contact your operating lifetime drain and dispose of all fluids of local dealer or the nearest authorized Atlas Copco Recycling and disposal policies are part of the according the applicable local disposal regulations. -
Page 25: Declaration Of Conformity
Gesch ftsf hrer : Mindener Strasse 29 Fax: +49 (0)5731 1801-66 Piet Leys D-32547 Bad Oeynhausen Email info@atlascopco.com Ust.-Id.-Nr. DE 154065482 Germany Amtsgericht Bad Oeynhausen HR B 2642 www.atlascopco.com For info, please contact your local Atlas Copco representative p.1(6) - 25 -... - Page 26 Notes - 26 -...
- Page 28 www.atlascopco.com...
