Havahart 5145 Instruction Manual

washer between probes and strap. Hand tighten as far as you can. If needed,
use pliers or wrench to go one turn further. Do not over tighten. The vibration
probe should be installed by hand.
Always use rubber insulators to keep probes tight and provide insulation during
damp conditions. The rubber insulators are necessary to maintain the waterproofing.
Position the collar high up on your pet's neck underneath the chin, with probes
facing upward touching the pet's skin. Adjust collar to fit snug but not tight. You
should be able to slide one finger between the pet's coat and the collar. The
correct fit is very important because most training failures are caused by the
probes not making direct contact with the skin. Remove collar, trim excess, and
melt end using a small flame to prevent fraying. Remember, for growing dogs,
check collar size weekly and adjust when necessary. Allow enough nylon for the
collar to grow with your dog. Never leave the collar on for more than 12
consecutive hours a day.
F. CHANGING THE RECEIVER COLLAR CORRECTION LEVEL
The collar's stimulation level can be checked or changed at any time.To check
the current stimulation level, begin with the unit turned on. Push and hold the
power button. The light will come on, and then go off. Release the button. The
unit will then blink the number of times to signify the setting level.
To change the stimulation level, turn the unit on. After about one minute, push
and hold the power button until the light goes off. Then push the button the
number of times for the desired level (1-5). Observe that the LED blinks each
time you push the button. You are done. Continue to observe the LED. After five
seconds it will blink once and then follow with rapid blinks indicating the level
you have set it. For example, if you have set it to Level 3 by pushing the button
three times then five seconds after you stopped pushing the LED will come on
once, go out and then blink rapidly three times. This indicates the correction level
has been changed to Level 3. At this point the LED will revert in seconds to
blinking to indicate the battery mode.
G. USE AND TRAINING
Refer to your 5140/5132 Instruction Manual and Training Guide for further information.
F. TROUBLESHOOTING
Refer to your 5140/5132 Instruction Manual and Training Guide for further information,
visit www.havahart.com or call 1(800) 800-1819, ext. 450 from 8 am – 7 pm EST.
4
