Summary of Contents for Mitsubishi Electric PK20
- Page 1 LED Projector MODEL PK20 User Manual This User Manual is important to you. Please read it before using your projector. EN-1...
- Page 2 EN-2...
- Page 3 The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing)
- Page 4 Equipment, ANSI/NFPA 75. When using the projector in Europe: COMPLIANCE NOTICE This Projector complies with the requirements of the EC Directive 89/336/EEC “EMC Directive” as amended by Directive 92/31/EEC and 93/68/EEC, and 73/23/EEC “Low Voltage Directive” as amended by Directive 93/68/ EEC.
-
Page 5: Table Of Contents
Using the SD card viewer...29 Image adjustment...34 Troubleshooting...36 Maintenance...40 Indicators...41 Specifications...43 Declaration of Conformity Model Number : PK20 Trade Name : MITSUBISHI ELECTRIC Responsible party : Mitsubishi Digital Electronics America, Inc. 9351 Jeronimo Road, Irvine, CA 92618 U.S.A Telephone number : +1-(949) 465-6000 This device complies with Part 15 of the FCC Rules. -
Page 6: Important Safeguards
7. Water and moisture Do not use this projector near water or in contact with water. EN-6 8. Accessories Do not place this projector on an unstable cart, stand, tripod, bracket or table. - Page 7 Never push objects of any kind through openings of this projector as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the projector, adaptor or battery. 14. Servicing Do not attempt to service this projector yourself.
- Page 8 If the projector is dropped and the cabinet is damaged, unplug the projector and contact your dealer for inspection. It may lead to fire if you keep using the damaged projector. Do not face the projection lens to the sun.
- Page 9 Place the projector on a solid, vibration-free surface. Otherwise it may fall, causing serious injury or damage. Do not stand the projector on a table’s end. It may fall, causing serious injury or damage. Do not place the projector near air-conditioning unit or heater to avoid the air outlet and inlet grilles from being exposed to hot air.
-
Page 10: Overview
Overview 1 Focus ring 2 Control panel 3 Terminal cover 4 Terminal board 5 Air outlet grille 6 Lens 7 Remote control sensor (Rear side only) 8 Air inlet grille EN-10 Control panel 1 LAMP indicator 2 POWER indicator 3 CHARGE indicator 4 Four directional buttons following function: : AUTO POSITION... -
Page 11: Power Supply
Using the optional battery The projector must be used with specified Lithium-ion rechargeable battery (BT-PK20R). Charge the battery before using the projector for the first time use. You may also use the projector when charging the battery. About the battery wear Display time with battery (BRIGHTNESS MODE is set to HIGH): 1.5 hours. - Page 12 We recommend that you full charge the battery all the time. Important: Be sure to remove the battery pack before placing the projector into the carrying bag. Otherwise, it can lead to fire. Warning: Do not change the battery except this method. It may cause battery exploding.
- Page 13 Condition LAMP (Green) Stand-by. When the lamp is on. When the projector is off, the charger works as a fast charging mode. It takes approximately 4 hours to complete charging. When the projector is on, the charger works as a slow charging mode. It takes approximately 8 hours to complete charging.
-
Page 14: Remote Control
Remote control 1 Power button 2 Four directional buttons 3 Enter button 4 Menu button 5 Volume buttton 6 Keystone button 7 Hi-Bright button 8 Computer button 9 Video button 1 0 Viewer button 1 1 Still button 1 2 Unplug button 1 3 Mute button 1 4 Auto button EN-14... - Page 15 The projector will not function if there are objects between the remote control and the remote sensor on the projector or if strong light falls on the remote sensor. A weak battery will also prevent the projector from operating.
-
Page 16: Installation
Image size varies depending on the distance between the screen and the projector. Front projection L : Between the screen and the front edge of the projector A : Height of the projected image under the horizontal line Optical offset:... -
Page 17: Using The Tripod
Using the tripod Mount the projector onto a tripod as shown in the illustration. Important: After attaching the tripod plate onto the projector, be sure that the adjustable rubber foot is properly tighten. Do not place the tripod on inclined or unstable surfaces. -
Page 18: Basic Connections
Important: Make sure that the connected device is turned off before starting connection. Plug in the AC adapter of the projector and the connected devices firmly. When unplugging, hold and pull the plug. Do not pull the cord. When the projector and the connected devices are located too close to each other, the projected image may be affected by their interference. -
Page 19: For Macintosh
If your Macintosh has no video port, a monitor output adapter is required. Contact your dealer for further information. Some Macintoshes require a MAC adapter for the RGB cable for connection with this projector. Contact your dealer for further information. COMPUTER IN... -
Page 20: Preparation
The POWER indicator lights red when using the AC adapter. Warning: Do not look into the lens directly when the projector is Use 100-240 V AC 50/60 Hz to prevent fire or electric shock. Do not place any objects on the AC adapter and power cord or do not place the projector near heat sources to prevent damage to the power cord. - Page 21 Important: When the keystone adjustment is carried out, the adjustment value is indicated. Note that this value doesn’t mean a projection angle. The allowable range of the adjustment value in the keystone adjustment varies depending on the installation conditions. When the keystone adjustment takes effect, the resolution decreases. In addition, stripes may appear or straight lines may bend in images with complicated patterns.
-
Page 22: Basic Operation
On the control panel EN-22 Power-on 1. Turn on the device connected to the projector first. 2. Plug the AC adapter in both the projector and the wall outlet. The POWER indicator lights up. The CHARGE indicator lights up when the projector connects with a not fully charged optional battery. - Page 23 The air outlet fan rotates faster as the temperature around the projector rises. Power-off Use the following procedure to turn off the projector. Do not turn off the projector by unplugging the power cord while the lamp is on. Unplugging while the lamp is on degrades the lamp’s performance and causes failure in the projector.
-
Page 24: On The Remote Control
Once the keystone control bar appears on the screen, and adjust... -
Page 25: Menu Operation
Menu operation AUTO SOURCE -25 - +25 -25 - +25 * 1: Not active when connect with VGA signal and SD card * 2: Not active when connect with Video signal and SD card * 3: Not active when connect with Component signal * 4: Range -15 - +15 for 4:3 aspect ratio;... - Page 26 1 IMAGE BRIGHTNESS MODE... Use to select the brightness mode. • The white color looks greenish so that LED lights out become maximum, when the brightness mode is set to high. • During the high brightness mode, color temperature is not selectable.
- Page 27 • The projector is in the stand-by mode when the lamp AUTO POWER OFF... Use to set the time elapsed before the projector enters the stand-by mode when there is no signal input from the source.
- Page 28 RESET ALL... Use to reset the menu settings (except LANGUAGE and SIGNAL menus). 4 SIGNAL In this menu the setting value is not saved after turning off the projector. This menu is prepared just for temporary use when Auto position does not work correctly for the current provided signal.
-
Page 29: Using The Sd Card Viewer
This projector enables you to read JPEG and MPEG files from the SD card and show the images on a screen. This can be used to give a presentation and/or present a slide show without using a computer. Important: The input method cannot be changed with the button on the main unit during the [VIEWER] input display. - Page 30 If the file size is larger than the 4MB, the image can not be playback. SVGA (480 000 pixel, 800 x 600 dot) is the native resolution of the projector. When you use the images files downloaded from the website, and the resolution is different from the SVGA resolution, the projector will resize those signal inputs for SVGA projection.
- Page 31 JPEG file Displaying thumbnails 1. Insert an SD card to the SD card slot on this projector. 2. Select an SD viewer. If the [AUTO START] is set to [ON], press the Viewer button on the remote controller or the COMPUTER button on the main unit.
- Page 32 3-1. Displaying JPEG images Display thumbnails in the thumbnails screen. Move the red frame using the button. The image changes and a slide appears. To open a folder, move the red frame to the target folder and press the ENTER button. You can move to a folder located 3 levels lower in the same method.
- Page 33 3-3. Playing an MPEG format Select a movie file you want to see from the thumbnail display and press the ENTER button in the same way as displaying a JPEG image. Press the ENTER button to stop the MPEG display and return to the thumbnail display. The thumbnail display will also return automatically when the MPEG display is over.
-
Page 34: Image Adjustment
Adjust SHARPNESS in the IMAGE menu. Press the Adjustment of the image from the computer This projector adjusts the format of the video signal supplied from the computer. However, sometimes images are not projected correctly owing to the type of the computer used. When the image from the computer isn’t projected correctly, press the AUTO button. - Page 35 To move the image vertically: Adjust VERT. POSITION in the SIGNAL menu. Press the the image downward. When the image flickers: Adjust FINE SYNC. in the SIGNAL menu. Simple adjustment method 1. Select HORIZ. POSITION in the SIGNAL menu. 2. Press the button to adjust the horizontal start position (or the left side of the image).
-
Page 36: Troubleshooting
2. Plug the power cord into the wall outlet or attach the battery. 3. Press the POWER button. Check that the battery or power cord connected with the projector correctly. Connect the power cord to the projector. Plug the power cord into a wall outlet. - Page 37 Adjust the projector and the screen so that they are perpendicular to each other. This symptom is normal for a DLP projector and is not a malfunction. (A very small number of pixels may stay lit or out, but such sympton is not a malfunction. Pixels of 99.99% or more are effective.)
- Page 38 This is caused by the computer being used. Contact the manufacturer of your computer. Match the output resolution of your computer with the resolution of the projector. For the method to change the output resolution of the computer, contact the manufacturer of your computer.
- Page 39 No sound come out from the projector speaker. Cause and solution This air comes out as a result of cooling the inside of the projector. This isn’t a product malfunction. The microcomputers inside the projector may be wrongly operating because of noise.
-
Page 40: Maintenance
Cleaning of the projector and the ventilation slots Use a soft cloth to clean the projector and the ventilation grilles. When the grilles become dirty, wipe them with a soft cloth dampened with diluted mild detergent, and then wipe them with a dry cloth. -
Page 41: Indicators
Indicators This projector has three indicators, each of which shows the operation condition of the projector. The following offer solutions to possible problems. If these problem persist, turn the projector off and consult your appliance dealer. Normal condition (AC Adaptor only) - Page 42 Normal condition (Battery only) LAMP (Green) Abnormal condition LAMP (Red) Flashing x 1 Flashing x 2 Flashing x3 EN-42 CHARGE (Red) POWER (Red) CHARGE (Red) POWER (Red) Off x 1 (Flashing) Off x 3 (Flashing) Off x 4 (Flashing) CONDITION System ON System standby Low Battery (System turned off)
-
Page 43: Specifications
72.8 inch + 72.8 inch (1.85m + 1.85m) Temperature, humidity +41°F (+5°C) - +95°F (+35°C), maximum 85% (performance guaranteed) The specifications and outside appearance of the projector are subject to change without prior notice. 640 x 480 800 x 600 1024 x 768... - Page 44 Dimensional drawings (unit : mm) 25.7mm 123.0 mm 123.0 mm EN-44...
- Page 45 What’s included in the box 1 Soft Carrying Bag 1 CD ROM (User manual) 1 Quick Reference Guide 1 Composite Video Cable 1 Remote Control (with battery) 1 Tripod 1 AC Adaptor 1 Power Cord for US for EU for UK It depends on different countries or areas, only 1 type of power cord is included.
- Page 46 Specification of RGB signals in each computer mode of the projector Signal mode Resolution (H x V) VGA 60 640 x 350 VGA 85 640 x 350 VGA mode3 640 x 480 640 x 480 VGA VESA 72 640 x 480...
- Page 47 1920 x1080 Important: Some computers aren’t compatible with the projector. The projector’s maximum resolution is 800 x 600 pixels. It may not display images of higher resolutions than 800 x 600 correctly. Images with SYNC on G (Green) signal may jitter.
- Page 48 MITSUBISHI Projector Contact Information North America MESCA (Mitsubishi Electric Sales Canada Inc.) http://www.mitsubishielectric.ca Information Technologies Group, 4299 14th Avenue, Markham, Ontario L3R 0J2, Canada Sales & Technical Inquiries Phone : +1-(800) 450-6487 : +1-(905) 475-7958 E-mail : projectors@mitsubishielectric.ca Customer Care E-mail : support@mitsubishielectric.ca...
- Page 49 Sales & Technical Inquiries Phone : +39-(0)39-60531 : +39-(0)39-6053214 E-mail : info.projector@it.mee.com MEU-NL (Mitsubishi Electric Europe B.V. Benelux Branch) http://www.mitsubishi.nl/LCD/ProdFrame.html Nijverheidsweg 23A, 3641 RP Mijdrecht, The Netherlands Sales Inquiries Phone : +31-297-282461 : +31-297-283936 E-mail : info@mitsubishi.nl Technical Inquiries Phone : +31-297-282461 : +31-297-283936 E-mail : info@mitsubishi.nl...
- Page 50 Sales Inquiries Phone : +86(21) 5211-0882-3002 : +86(21) 5211-0576 Technical Inquiries Phone : +86(21) 5211-0882-3020 : +86(21) 5211-0576 HONG KONG (Mitsubishi Electric Ryoden Air-Conditioning & Visual Information Systems (HongKong) Ltd.) 7th Floor, Manulife Tower, 169 Electric Road, North Point, Hong Kong Sales Inquiries Phone : +852-2510-1505 : +852-2510-0463...
- Page 51 Sales Inquiries Phone : +65-6473-2308 : +65-6475-9503 E-mail : Peripherals@asia.meap.com Technical Inquiries Phone : +65-6470-2666 : +65-6475-9503 STC (Setsuyo Astec Corporation Seoul Branch) 4F, Dongseo Game Channel Bldg,660-11 Deungchon- Dong,Kangseo-Ku, Seoul, Korea Sales & Technical Inquiries Phone : +82-(0)2-2657-9841~3 : +82-(0)2-2657-9900 MALAYSIA (Antah Melco Sales &...
- Page 52 Manufactured by Mitsubishi Electric Corporation 1 Zusho Baba, Nagaokakyo-City, Kyoto Japan MITSUBISHI ELECTRIC CORPORATION EN-52...
