Mitsubishi Electric FL6900U Specification Sheet

Input and Output Terminals
1 REMOTE IN and OUT terminals
1 2 3 4 5
2 LAN terminal
3 SERIAL terminal (D-Sub 9pin)
4 USB (COMPUTER) terminal
5 COMPUTER / COMPONENT VIDEO
DVI-D (HDCP) terminal (DVI-D 24pin)
6 COMPUTER / COMPONENT VIDEO IN 1
terminals (R/P , G/Y, B/P , H/HV, V) (BNC)
R B
7 Main power switch O : OFF I : ON
8 Power jack
9
AUDIO IN 1 terminal (Mini jack)
The AUDIO IN 1 terminal is used for
both COMPUTER 1 and DVI input.
10 AUDIO IN 2 terminal (Mini jack)
11
COMPUTER / COMPONENT VIDEO
IN 2 terminal (Mini D-Sub 15pin)
12 MONITOR OUT terminal
(Mini D-Sub 15pin)
13 AUDIO OUT terminal (Mini jack)
7 8 9 10 11 12 13 14
14 VIDEO IN and audio input terminals
15 S-VIDEO IN and audio input terminals
Optional Lenses Line-UP
OL-X500FR ( F )
OL-X500SZ OL-X500LZ OL-X500TZ
( Short Throw ( Long Throw ( Tele Throw ( Rear Projection Short Throw
Zoom Lens ) Zoom Lens ) Zoom Lens ) Fix Lens with Front Cabinet )
* For those who already have OL-X500FR, a front cabinet CA-XL6600(FR) is necessary for use.
Dimensions (unit: mm)
31.5 143 127 50
172.6 20
273
10
48.5 10
443(With terminal cover)
371(Without terminal cover) terminal
433
cover
131.5
84
287
40.5
40.5 307 316
To find out more about the FL6900U and other projectors, visit us at
L-188-8-C8159-A KY 0810 Printed in Japan(MDOC)
Specifications
Model FL6900U
Display technology 1.1" 3-LCD
Resolution 1920 x 1080 (Total 2,073,600 pixels)
Brightness 4000 lm
Contrast ratio 1000:1 (on/off)
Projection lens f=51-64mm, F1.8-2.1
Throw ratio 2.01 - 2.56
Offset axis 10 : 0 (default) with variable H + V powered lens shift (excluding OL-X500FR)
Zoom / Focus Motorized Zoom & Focus
Picture size 60" - 250" (100"=4.5 - 5.7m)
220W (Shut Off Time 4000Hrs) with Low mode,
Source lamp
275W (Shut Off Time 2000Hrs) with Standard mode
Computer Resolution ; 640 x 400 (Expand) - 1920 x 1080 (Real) -
compatibility 1600 x 1200 (Compress) Sync on Green available
6
NTSC / NTSC 4.43 / PAL (including PAL-M, N) / SECAM / PAL-60,
Component Video ; 480i/p (525i/p), 576i/p (625i/p), 720p (750p 50/60Hz),
Video compatibility
1080i (1125i 50/60Hz),1080p (1125p 50/60Hz), (1080i (1250i 50Hz) is not available)
SCART (RGB + 1V sync, only Mini D-Sub 15pin Terminal)
PC ; 5 BNC x 1, Mini D-Sub 15pin x 1, DVI-D(with HDCP) x 1,
Input terminals PC Audio ; Stereo mini jack ( 3.5mm) x 2
Video ; RCA x 1 or BNC x 1, S-VIDEO (4pin) x 1 or S-VIDEO Y/C (BNC), Video Audio ; RCA (L/R) x 2
Output terminals RGB ; Min D-Sub 15 pin x 1, Audio ; Stereo mini jack ( 3.5mm) x 1 (Variable Out)
LAN (RJ-45) ; x 1 (Projector control), RS-232C ; D-Sub 9pin x 1 (Direct command is available.),
Communication
USB ; x 1 (for Mouse Cursor Control), Wired remote (IN) ; x 1 ( 3.5mm Stereo mini jack ),
terminals
Wired remote (OUT) ; x 1 ( 3.5mm Stereo mini jack )
Audio speaker 10 W Mono
Dimensions (W x H x D) 443 x 207 x 434 mm / 17.4 x 8.1 x 17.1 inch (Including Detachable Terminal Cover)
15
Weight 9.8kg / 21.6lbs (Excluding Detachable Terminal Cover)
Power supply AC100 - 240V, 50/60Hz
* SXGA, XGA and SVGA are registered trademarks of IBM Corporation.
* All brand names and product names are trademarks, registered trademarks or trade names of their respective holders.
Projection Distance with Optional Lenses
OL-X500SZ OL-X500LZ OL-X500TZ
Shortest Longest Shortest Longest Shortest
Screen Size
(Wide) (Tele) (Wide) (Tele) (Wide)
(inch)
inch m inch m inch m inch m inch m
60 74 1.9 90 2.3 - - - - - -
80 100 2.5 121 3.1 173 4.4 244 6.2 256 6.5
100 125 3.2 152 3.9 220 5.6 307 7.8 319 8.1
150 189 4.8 229 5.8 331 8.4 465 11.8 484 12.3
200 253 6.4 305 7.8 445 11.3 622 15.8 646 16.4
250 317 8.1 - - 555 14.1 780 19.8 811 20.6
Screen Size and Projection Distance
Refer to the following table to determine the screen size and projection distance.
Front projection
Front projection, ceiling mounting
W1 W W1 W1
L
Screen Size Projection distance (L)
Diagonal size Height (H) Width (W) Shortest (Wide) Longest (Tele)
inch cm inch cm inch cm inch m inch m inch
104
60 152 29 75 52 133 2.6 133 3.4
80 203 39 100 70 177 140 3.5 178 4.5
100 254 49 125 87 221 175 4.5 223 5.7
150 381 74 187 131 332 264 6.7 336 8.5
200 508 98 249 174 443 354 9.0 449 11.4
7
250 635 123 311 218 553 443 11.2 - -
58
* The above figures are approximate and may be slightly different from the actual measurements.
Specifications subject to change without notice.
MULTIMEDIA DATA/VIDEO PROJECTORS
OL-X500FR
Longest
(Tele)
inch m
inch m
- - 43 1.1
386 9.8 59 1.5
484 12.3 75 1.9
728 18.5 114 2.9
972 24.7 - -
1217 30.9 - -
W W1
L
Image power that will change business styles.
Lens movable range
H1 H2 W1
cm inch cm inch cm
15 38 4 10 3 7
20 51 5 13 4 9
25 63 7 17 4 11
37 94 10 25 7 17
49 125 13 34 9 22
62 156 17 42 11 28
New publication, effective Oct. 2008
The debut of the FL6900U. Full HD anytime, anywhere.
