Safe Operation Practices • Set Up • Controls • Operation • Maintenance • Specifications • Warranty
O
'
M
peratOr
s
anual
Hydrostatic Stand-On Self-Propelled Spreader/Sprayer
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Printed In USA
Form No. 769-04150
(April 19, 2010)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cub Cadet 125 lb Spreader & 10 Gallon Sprayer
Summary of Contents for Cub Cadet 125 lb Spreader & 10 Gallon Sprayer
- Page 1 READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL BEFORE ATTEMPTING TO OPERATE THIS MACHINE. FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY. CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 Printed In USA Form No. 769-04150...
-
Page 2: Table Of Contents
Choose from the options below: ◊ Visit us on the web at www.cubcadet.com ◊ Locate your nearest Cub Cadet Dealer at (877) 282-8684 ◊ Write us at Cub Cadet LLC • P.O. Box 361131 • Cleveland, OH • 44136-0019... -
Page 3: Safe Operation Practices
Important Safe Operation Practices WARNING: This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury. - Page 4 General Always have proper footing on slopes and hill sides and never operate when conditions are slippery. Be very careful Sometimes, it is not possible to reduce a hazard by eliminating on wet grass. it, substituting a less hazardous process or product, making Always keep both hands on the handles.
- Page 5 Note: Select equipment that is NIOSH tested and approved. Protective equipment, appropriate for the task and hazards • Go across slopes, not up and down. that an employee could be potentially exposed to, shall be • Remove obstacles such as rocks, limbs, etc. provided by the employer.
- Page 6 Use only an approved gasoline container. After striking a foreign object, stop the engine, disconnect the spark plug wire(s) and ground against the engine. Never fill containers inside a vehicle or on a truck Thoroughly inspect the machine for any damage. Repair or trailer bed with a plastic liner.
-
Page 7: Safety Symbols
Safety Symbols This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate. Symbol Description READ THE OPERATOR’S MANUAL(S) Read, understand, and follow all instructions in the manual(s) before attempting to assemble and operate DANGER —... - Page 8 2 — i ectiOn MpOrtant peratiOn ractices...
-
Page 9: Set Up
Set-Up Initial Adjustments Gas and Oil Fill-up WARNING! WARNING! Before performing any adjustments, Use extreme care when handling disconnect the spark plug wire to prevent the gasoline. Gasoline is extremely flammable and the engine from accidentally starting. vapors are explosive. Never fuel machine indoors or while the engine is hot or running. -
Page 10: Control & Features
Controls and Features Hopper Shut-Off Spreader 3rd Hole Spreader Side Spreader Switch Deflector Ignition Switch Right-Hand Nozzle Valve Sprayer Switch Forward Ground Reverse Ground Speed Control Speed Control Speed Control Lever (Application-Transport) Figure 4-1 Spreader-sprayer controls and features are illustrated in Fig 4-1 and described on the following pages. WARNING! Read and follow all safety rules and instructions in this manual, including the entire Operation section, before attempting to operate this machine. - Page 11 Pressure Gauge Ground Speed Control Levers (Forward & Reverse) Mounted in the pressure regulator housing next to the battery, Located on the right side of the control panel is the forward the pressure gauge indicates the pressure in the output lines to speed control lever.
- Page 12 Hour Meter and Tachometer Parking Brake Located at the upper left edge of the control panel. When the The mechanical disc brake is activated by the lever in the foot machine is running the tachometer displays engine rpm. When platform area. See Fig. 4-4. Press down on the lever to engage the machine is off it displays time of operation.
-
Page 13: Operation
Operation WARNING!: Practice operating the machine and as you gain Make certain you thoroughly confidence, move the ground speed selector lever to the understand all of the safety precautions before you transport position. Operate the machine in the application attempt to operate this machine. position until you are comfortable and confident with the controls. - Page 14 Using the Sprayer Empty the spreader after each use. Wash the spreader thoroughly and allow it to dry. Keep the impeller clean. Press the sprayer switch to the “ON” position. Lubricate all moving parts. See “Lubrication” in the Determine your spray path. Maintenance section.
- Page 15 TO ACHIEVE THE CORRECT PRODUCT APPLICATION RATE: TO USE THE CALIBRATION GAUGES: The approximate spreader settings printed on any The Calibration Gauges provide a series of “steps”, numbered product label should only be used as the initial setting for in 1/32-inch increments, that will allow you to “fine-tune” the calibration.
- Page 16 Spreader and Sprayer Application Rates The spreader-sprayer operates at an average system pressure of 45 lb/in . The 20 amp charging system provides adequate electrical power for the spreader, sprayer, or both together. With the system pressures and spray tips listed below, the effective spray width will be 9 feet and the output will be as indicated for 45 lb/in Sprayer Application Rate for Pressure and Travel Speed 4 mph...
-
Page 17: Maintenance
Maintenance & Adjustments Battery WARNING! Before performing any maintenance disconnect the spark plug wire to prevent the CALIFORNIA PROPOSITION 65 WARNING engine from accidentally starting. Battery posts, terminals, and related accessories contain lead and lead compounds, chemicals known General Recommendations to the State of California to cause cancer and reproductive harm. - Page 18 Lubrication Changing the Pump Drive Belt WARNING! At the top of the engine base, remove the guard covering Before lubricating, repairing, or the transmission fan/pulley. inspecting, always set parking brake, stop engine and remove key to prevent unintended starting. Access engine drive pulley, idler pulley and belt from the left hand side of the unit.
-
Page 19: Maintenance Schedule
Maintenance Schedule Before Every Every Every Every Prior Each use 10 Hours 25 Hours 100 Hours 300 Hours to Storing Clean the machine and allow to dry Check Engine Oil Level Check Air Filter for Dirty, Loose or Damaged Parts Check the fuel level Clean the cooling-air intake Clean Battery Terminals... -
Page 20: Troubleshooting
Troubleshooting Problem Cause Remedy Engine Fails to start Spark plug boot disconnected. Connect wire to spark boot. Fuel tank empty or stale fuel. Fill tank with clean, fresh gasoline. Engine not primed (if equipped with primer). Prime engine as instructed in the Operation section. -
Page 21: Specifications
Specifications Note: Specifications subject to change without notice. Specifications: Model: 125 lb Spreader & 10 gallon Sprayer Engine Mfg: Kawasaki 6.5* Type: 4 Cycle Single Cylinder Starter: Electric (Recoil Back-Up) Air Cleaner: Dual Element Dry Lube: Pressurized Fuel Capacity: 2 Quarts Charging System: 20 Amp Generator &... - Page 22 CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT YOUR WARRANTY RIGHTS AND OBLIGATIONS The California Air Resources Board and MTD Consumer Group Inc are pleased to explain the evaporative emission control system warranty on your 2008 lawn mower. In California, new lawn mowers must be designed, built and equipped to meet the State’s stringent anti-smog standards. MTD Consumer Group Inc must warrant the EECS on your lawn mower for the period of time listed below provided there has been no abuse, neglect or improper maintenance of your lawn mower.
- Page 23 WARRANTED PARTS: The repair or replacement of any warranted part otherwise eligible for warranty coverage may be excluded from such warranty coverage if MTD Consumer Group Inc demonstrates that the lawn mower has been abused, neglected, or improperly maintained, and that such abuse, neglect, or improper maintenance was the direct cause of the need for repair or replacement of the part.
-
Page 24: Warranty
Without limiting the foregoing, this limited warranty does not provide coverage in the following cases: The limited warranty set forth below is given by Cub Cadet LLC with respect to new merchandise purchased or leased and used in the a. Routine maintenance items such as lubricants, filters, blade...
