KWorld 730 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
EPG Program Reservation
There are 10 program timers to bring up reminder for a
reserved program. 20 seconds before the start of the
reserved program, a pop-up window will remind viewer.
If no further instruction, box will switch to the reserved
program. Each timer has 3 modes – Once, Daily,
Weekly.
20
DVB-T 730
User's Manual
Kworld Computer Co. Ltd.
Http://www.kworld.com.tw

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 730 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KWorld 730

Summary of Contents for KWorld 730

  • Page 1 20 seconds before the start of the User’s Manual reserved program, a pop-up window will remind viewer. If no further instruction, box will switch to the reserved program. Each timer has 3 modes – Once, Daily, Weekly. Kworld Computer Co. Ltd. Http://www.kworld.com.tw...
  • Page 2 5.4 EPG Use the EPG key from remote control can display the Electronic Program Guide (EPG). There are two presentation modes for the EPG. In EPG, there are 10 program timers to provide reminder when a program is coming. Move the focus to a program and press “OK”, you can see more detailed program description.

  • Page 3: Table Of Contents

    Delete by Program Name INDEX Delete a program from available channel program list. CHAPTER 1 INTRODUCTION............1 1.1 I ................1 NTRODUCTION 1.2 A ................. 1 CCESSORIES CHAPTER 2 HARDWARE INSTALLATION ........2 2.1 PC C ................2 ONNECTION 2.2 TV C ................
  • Page 4 Delete by Network Name This is to delete a network frequency from the list. All the programs from that frequency will be removed. System will search the network every 4:30AM in the background when box is in standby mode.

  • Page 5: Chapter 1 Introduction

    5.3 Advanced Options Chapter 1 Introduction 1.1 Introduction This is a DVB-T 730 for free-to-air (FTA) terrestrial digital TV broadcasting. You can enjoy the DVD quality video and audio for free. It supports Teletext, 8-day Electronic Program Guide (EPG) and DVB subtitle. Through the EPG, you can set up to 10 program timers to remind you the important programs.

  • Page 6: Chapter 2 Hardware Installation

    DVB-T 730 can provide VGA, S-Video and composite outputs to PC monitor, TV and VCR. It can also pass through PC signal (VGA and audio) when DVB-T 730 is in standby mode. Please follow the connection steps and diagram below to connect receiver to PC or TV.

  • Page 7: Tv Connection

    pan and scan on If the video is 4:3 aspect ratio, a 16:9TV the video will fill the screen and maintain the aspect ration in a wide screen 16:9 TV. The top and bottom part of the video will be cut. ignore on a 16:9 If the video is 4:3 aspect ratio, the video will fill the screen in a...
  • Page 8 S-Video input. Use the AV cable (White and Red plugs) to connect box L-Audio-R output (White and Red jacks at front panel) and TV audio input for AV or S-Video source. Plug the power adapter to the “12V DC IN”. Video Mode Select the video output Aspect Ratio according the TV aspect ratio.

  • Page 9: Chapter 3 Operation

    (GREEN LED is on). NOTE: When DVB-T 730 is powered on and stay at standby mode, it will re-direct the PC video and audio to monitor and speaker. After the operation, the DVB-T video and audio will be sent out.

  • Page 10: Chapter 4 Remote Control

    Reorder Channels Chapter 4 Remote Control This is to change the channel sequence. Use the remote direction keypad (LEFT/RIGHT/UP/DOWN) to select the channel, press OK keypad to confirm selection, then use the direction keypads to select the new position and press OK to insert.
  • Page 11 GREEN 1. List favorite channels 2. Function keys YELLOW BLUE Up or CH+ Down or CH- Left or VOL- Right or VOL+ Available Channels Exit menu or Go to upper EXIT List all found channels. You may see the channel signal level menu power level and signal quality here.

  • Page 12: Chapter 5 Osd Menu Operation

    Chapter 5 OSD Menu Operation 5.1 Setup Channels If “User defined” is selected, a specific frequency (KHz) and bandwidth (6/7/8MHz) can be entered to search programs. Auto Search Scan all available channels according the “Country” setting in “Box Installation”. Edit Favorite Channels There are four favorite groups –...
