DIGITAL COLOR PRINTER
MODEL
CP900DW
OPERATION MANUAL
FEED&CUT
THIS OPERATION MANUAL IS IMPORTANT
TO YOU.
PLEASE READ IT BEFORE USING YOUR
DIGITAL COLOR PRINTER.
This digital color printer complies with the requirements of the EC
Directive 89/336/EEC, 73/23/EEC, 93/42/EEC and 93/68/EEC.
The electro-magnetic susceptibility has been chosen at a level that
gains proper operation in residential areas, on business and light
industrial premises and on small-scale enterprises, inside as well as
outside of the buildings. All places of operation are characterised by
their connection to the public low voltage power supply system.
RESET
COPY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CP900DW and is the answer not in the manual?

Questions and answers

Related Manuals for Mitsubishi CP900DW

Summary of Contents for Mitsubishi CP900DW

  • Page 1 TO YOU. PLEASE READ IT BEFORE USING YOUR DIGITAL COLOR PRINTER. This digital color printer complies with the requirements of the EC Directive 89/336/EEC, 73/23/EEC, 93/42/EEC and 93/68/EEC. The electro-magnetic susceptibility has been chosen at a level that gains proper operation in residential areas, on business and light industrial premises and on small-scale enterprises, inside as well as outside of the buildings.

  • Page 2: Medical Equipment

    INFORMATION This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. MEDICAL EQUIPMENT WITH RESPECT TO ELECTRIC SHOCK, FIRE AND MECHANICAL HAZARDS ONLY IN ACCORDANCE WITH UL 2601-1 AND CAN/CSA C22.2 NO.
  • Page 3 CAUTION: DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute the risk of electric shock.

  • Page 4: Table Of Contents

    Installation of print paper ... 11-13 Installation of ink sheet ... 13-15 Usage and storage of paper sheet set ... 15 Installing printer driver ... 16 Indication on the front panel & countermeasures ... 17 Before calling for service ... 18...

  • Page 5: Safety Precautions

    Contact your dealer about having the printer checked and serviced. NEVER INSERT ANY OBJECT INTO THE UNIT Nothing other than supplies for this printer should ever be inserted into the printer. Other items can cause a safety hazard and extensive damage to the mechanism and electronics.

  • Page 6: Installation Locations

    UNSUITABLE LOCATIONS Avoid installing the printer in unstable locations with high vibration or in hot-springs areas where hydrogen sulfide and acidic ions are likely to be generated. PLACES WITH HIGH HUMIDITY AND DUST Do not place the unit in locations with high humidity and dust, as this can cause extensive damage.

  • Page 7: Safety Checks

    SAFETY PRECAUTIONS CONNECTING DEVICES Read thoroughly the Safety Notices, Cautions and “Operating Precautions” of the instruction booklets for the other devices connected with the unit. CAUTION ON RELOCATING When transporting the unit, make sure it is not likely to be subjected to impacts. This can be a primary cause for damage. Before moving the unit, make sure to disconnect the power cord from the power outlet, and the cables from the connected devices.

  • Page 8: Special Features

    SPECIAL FEATURES SPECIAL FEATURES 2 PRINT SIZES ARE AVAILABLE DEPENDING ON INK SHEET 2 printing sizes, L size (max.110 x 162 mm) and S size (max.110 x 105 mm), are selectable. HIGH SPEED PRINTING Printing speed is approx. 12 seconds (in S size print). LARGE CAPACITY PRINT MEDIA S size media has a maximum of 200 prints per roll.

  • Page 9: Unpacking

    4 4 4 4 4 Unwrap the packing. 2 2 2 2 2 CONTENTS Make sure to check the supplied contents on the cushion. Ink cassette Operation manual Printer driver (1 floppy disk) UNPACKING Power cords (2) Spacers (4) Screws (4)

  • Page 10: Features And Functions

    FEATURES & FUNCTIONS 1 2345 1 1 1 1 1 POWER BUTTON(INDICATOR) Press to turn on power. Press again to turn off power. When the power is turned on, the indicator illuminates. 2 2 2 2 2 ALARM INDICATOR When this unit is overheated, this lamp flashes. When other errors occur, the LED is steady.

  • Page 11: Features And Functions

    FEATURES & FUNCTIONS 1 1 1 1 1 REMOTE TERMINAL Terminal connection for service remote only. This terminal is to be used by qualified service personnel only. 2 2 2 2 2 MODE SWITCHES Used to set the various functions of this unit. See page 3 3 3 3 3 USB CABLE CLAMPER Use this clamper so that the USB port is not disconnected.

  • Page 12: Connections

    CONNECTION WITH USB INTERFACE 2 2 2 2 2 CONNECTING WITH PC Connect this unit with a personal computer as following example. To USB port Personal computer To USB port 8 7 6 5 4 3 2 1 REMOTE Printer AC LINE...

  • Page 13: Setting Mode Switches

    Even if the printed paper remains at the print outlet, PAPER indicator remains turned off and this unit does not stop printing. Automatic feed&cut mode This will cause the printer to perform an automatic feed and cut after installation of the paper and ink sheet. Manual feed&cut mode...

  • Page 14: Before Operation

    BEFORE OPERATION Before printing, 1. Unlock the printing mechanism. (See below) 2. Install the print paper and ink cassette. (pages 11-15) PAPER SHEET SET Make sure to use the following types of paper sheet and ink sheet set. 2 2 2 2 2 PAPER SHEET SET Product name Ink sheet size...
  • Page 15 BEFORE OPERATION 2 2 2 2 2 Set the other side of roller without gear. 3 3 3 3 3 Remove the seal, and insert the edge of the print paper right below the roller cover with arrow marks towards the front panel. Make sure to insert the paper straight.

  • Page 16: Installation Of Ink Sheet

    2 2 2 2 2 INSTALLING THE INK SHEET Load the ink sheet roll to the ink cassette before inserting the ink cassette into the printer. 1 1 1 1 1 Insert the ink sheet rollers gear into the holes of the ink cassette.
  • Page 17 2 2 2 2 2 Insert the ink cassette with the ink sheet into its compartment. Put the ink cassette into the printer drawer as shown (with handle) as shown right. When exchanging the ink cassette, remove it by holding the handle. (See page 19.)

  • Page 18: Usage And Storage Of Paper Sheet Set

    Take the print paper one by one after completing printing. Pull out the tray completely when using it. If you fail to do so, paper jamming may occur. Put the tray back after printing. USAGE AND STORAGE OF PAPER SHEET SET BEFORE PRINTING •...

  • Page 19: Installing Printer Driver

    Applies for Microsoft CPD900N0 Applies for Microsoft Refer to the “Read me” for installing the printer driver in the floppy disk supplied with this unit. 2 2 2 2 2 How to open the ReadMe file 1 1 1 1 1 Install the floppy disk in the floppy disk drive on your PC.

  • Page 20: Troubleshooting

    TROUBLESHOOTING INDICATION ON THE FRONT PANEL & COUNTERNEASURES If for some reason printing is not possible or error occurs during printing, the indicators on the front panel will be lit. In this case, follow the procedure described below. ALARM SHEET PAPER DATA Paper is used up.

  • Page 21: Before Calling For Service

    TROUBLESHOOTING BEFORE CALLING FOR SERVICE Use the following troubleshooting chart to try to resolve any apparent defect in operation. If you are unable to resolve the problem, unplug the power cord and contact your dealer. Symptom No power (when POWER lamp does not illuminate) The image is not printed.

  • Page 22: Overcoming Paper Jams

    1 1 1 1 1 Press OPEN button to pull out the printing mechanism. When it is not working, reset the power. Then try to press OPEN button again. 2 2 2 2 2 Remove the ink cassette with ink sheet. 3 3 3 3 3 Remove the print paper as shown right.

  • Page 23: Cleaning

    CLEANING Cleaning as indicated below will help maintain stable printer operation and extend the printer’s life. Preparations Alcohol (isopropyl alcohol) Tissue paper (Fold in half about 4 times, and use the folded side to clean.) Cotton buds Cleaning kit (Option)* Other : Cleaner pen (Option)* *Please ask the dealer about options.

  • Page 24: Spec & Options

    Outside dimensions 280(W) x 150(H) x 400(D) mm Weight 11kg Accessories Power cords (2), Ink cassette (1), Operation manual (1), Printer driver (1 floppy disk), Spacer (4), Screw(4) 2 2 2 2 2 PAPER SHEET SET Product name Ink sheet size...
  • Page 25 MITSUBISHI DIGITAL ELECTRONICS AMERICA, INC. 9351 Jeronimo Road, Irvine, CA 92618, U.S.A. Phone 949-465-6000 Mitsubishi Electric Europe B.V. UK Branch Travellers Lane, Hatfield, Herts. AL10 8XB, England, U.K. Phone (0) 1707 276100 German Branch Gothaer Strasse 8, 40880 Ratingen ; Postfach 1548, 40835 Ratingen ; Germany Phone (2102) 486-9250 French Branch 25, Boulevard des Bouvets - 92741 NANTERRE cedex...
