- Page 1 Owner’s Guide Mitsubishi Plasma Display PD-5030 & PD-6130 ® Technically Anything is Possible...
-
Page 3: Read Before Operating Equipment
IMPORTANT SAFETY INSTRUCTIONS (PD-5030/PD-6130) Read before operating equipment 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this plasma display near water. 6. Clean only with a dry cloth. -
Page 4: Important Information
Refer all service to authorized Mitsubishi Service Centers. Caution PD-5030 and PD-6130 are for use with the following optional accessories. Use with other optional accessories is capable of resulting in instability causing possible injury. Manufacturer’s... - Page 5 *ORBITER - Uneven phosphor aging/burn-in reduction feature. To minimize the risk of uneven phosphor aging/burn-in when displaying still images, the Mitsubishi PD-5030 and PD-6130 offers a built-in feature known as ORBITER. The ORBITER feature intermittently shifts the screen image horizontally and vertically in small increments. This intermittent screen movement is usually not evident in full motion video.
- Page 6 WARNING: Do not leave stationary or letterbox images on-screen for extended periods of time. Mix types of pictures shown. Uneven phosphor aging is NOT covered by your warranty. The normal use of a TV should include a mixture of TV picture types.
-
Page 7: Cleaning Safeguards
Cleaning Safeguards Plasma Display Screen & Cabinet Please follow the cleaning safeguards listed below to prevent damage to your Plasma Display and retain this document for future reference. IMPORTANT: No Abrasives! DO NOT use any kind of abrasive cloth or cleaner or ammonia on the Plasma Display’s screen or cabinet. -
Page 8: Contents Of The Package
Introduction Introduction to the PD-5030/ PD-6130 Plasma Monitors Mitsubishi’s PD-5030/PD-6130 plasma displays are a seamless blend of cutting-edge visual technology and sophisticated design. The monitor’s sleek techno-art lines blend in well with your environment. The displays crisp, vivid image quality will transform data from any graphic medium from PCs to DVD players into art. -
Page 9: Table Of Contents
Source Information Menu ... 34 Checking the frequencies, polarities of input signals, and resolution ... 34 RS-232C Control ... 35 Troubleshooting ... 36 Technical Specifications PD-5030 ... 38 Technical Specifications PD-6130 ... 39 Table of Signals Supported ... 40 Warranty ... 41... -
Page 10: How To Attach Options To The Plasma Monitor
How to Attach Options to the Plasma Monitor You can attach your optional mounts or stand to the plasma monitor in one of the following two ways: * While it is upright. (See Drawing A) * As it is laid down with the screen face down (See Drawing B). Lay the protective sheet, which was wrapped around the monitor when it was packaged, beneath the screen surface so as not to scratch the screen face. -
Page 11: Part Names And Function
Part Names and Function Front View LEFT/ - MENU/ENTER DOWN VOLUME RIGHT/+ INPUT/ EXIT MENU/ENTER VOLUME q POWER Turns the monitor’s power on and off. w REMOTE SENSOR WINDOW Receives the signals from the remote control. e POWER/STANDBY indicator When the power is on ... Lights green. When the power is in the standby mode ... -
Page 12: Rear View/ Terminal Board
Rear View/ Terminal Board A AC IN Connect the included power cord here. B EXT SPEAKER L and R Connect speakers (optional) here. Maintain the correct polarity. Connect the (positive) speaker wire to the EXT SPEAKER terminal and the speaker wire to the EXT SPEAKER terminal on both LEFT and RIGHT channels. -
Page 13: Remote Control
Remote Control POWER ON STANDBY RGB/PC DVD/HD VIDEO MENU/ ENTER ADJUST EXIT POINTER ZOOM VOLUME MUTE FORMAT INFO SLEEP AUTO POSITION RM-PDP2 q POWER ON/STANDBY Switches the power on/standby. (This does not operate when POWER/STANDBY indicator of the main unit is off.) w RGB/PC Press this button to select RGB/PC as the source. -
Page 14: Battery Installation And Replacement
!5 AUTO POSITION Available for PC Inputs Only. Press this button to automatically adjust the size and position of the current screen resolution. !6 Remote control signal transmitter Transmits the remote control signals. !7 Remote Jack Insert the plug of the remote cable here when using the supplied remote control in the wired condition. -
Page 15: Using The Wired Remote Control Mode
Using the wired remote control mode Connect one end of the remote cable to the remote control’s REMOTE JACK and the other end to the “REMOTE IN” terminal on the monitor. When the cable is connected, the mode automatically switches to wired remote control. When the wired remote control mode is used, the remote control can be operated even if no batteries are installed. -
Page 16: Installation
Installation VIDEO 1- 3 VCR or Laser Disc Player To video inputs on the plasma monitor Document Camera DVD Player IBM VGA or Compatibles Macintosh or Compatibles (Desk top type) Monitor adapter for Macintosh (not included) To Mini D-Sub 15 pin connector on the plasma monitor Mitsubishi HD Receiver/Controller (i.e. -
Page 17: Connecting Your Pc Or Macintosh Computer
Connecting Your PC or Macintosh Computer Connecting your PC or Macintosh computer to your plasma monitor will enable you to display your computer’s screen image for an impressive presentation. The plasma monitor supports the signals described on page 40. To connect a PC, Macintosh or compatible graphics adapter, simply: 1. -
Page 18: Monitorlink Connections
MonitorLink™ Connections MonitorLink and MonitorLink Control 1. Connect a MonitorLink cable from the Mitsubishi Receiver/Controller back panel to the plasma monitor back panel. 2. Connect the L (left) and R (right) audio cables from the Mitsubishi Receiver/Controller to AUDIO LEFT and AUDIO RIGHT on the MonitorLink section of the plasma monitor back panel. -
Page 19: Loop Out
Loop Out • Connect signal cables and remote cables as shown below. Video signal BNC connector RCA phono plug VIDEO Signal Remote control Note: 1. The VIDEO1 and RGB1 terminals can be used for either INPUT or OUTPUT. When LOOP OUT is ON, do not connect an OUTPUT signal from another unit, that will place an extraordinary load on the other unit and may damage it. -
Page 20: Basic Operations
Basic Operations POWER 1. Plug the power cord into an active AC power outlet. 2. Press the Power button located underneath the right side of the front panel. The monitor’s POWER/STANDBY indicator turns green and the plasma display is on. OFF: Press the Power button (underneath the front panel) to turn off the display. -
Page 21: Sleep/Off Timer
SLEEP/OFF TIMER To set the off timer: The off timer can be set to turn the power off after 30, 60, 90 or 120 minutes. 1. Press the SLEEP button to start the timer at 30 minutes. 2. Press the SLEEP button to the desired time. 3. -
Page 22: Available On-Screen Format Sizes
Format Sizes Format Operation (manual) With this function, you can select one of six screen sizes. When viewing videos or digital video discs 1. Press the FORMAT button on the remote control. 2. Within 3 seconds ... Press the FORMAT button again. The screen size switches as follows: →... -
Page 23: Format Operation With Computer Signals
Format Operation with Computer Signals Switch to the wide screen mode to expand the 4 : 3 image to fill the entire screen. 1. Press the FORMAT button on the remote control. 2. Within 3 seconds ... Press the FORMAT button again. The screen size switches as follows: →... -
Page 24: On-Screen Menu (Osm) Controls
On-Screen Menu (OSM) Controls Menu Operations The following describes how to use the menus and the selected items. In the explanation, the menu section is shown close up. 1. Press the MENU/ENTER button on the remote control to display the MAIN MENU. MAIN MENU VIDEO SETTINGS AUDIO SETTINGS... -
Page 25: Video Settings Menu
VIDEO Settings Menu Adjusting the picture The contrast, brightness, sharpness, color and tint can be adjusted as desired. Example: Adjusting the contrast 1. On the MAIN MENU, select “VIDEO SETTINGS”, then press the MENU/ENTER button. The “VIDEO SETTINGS” screen appears. 2. -
Page 26: Reducing Noise In The Picture
Reducing noise in the picture Use these settings if the picture has noise due to poor reception or when playing video tapes with poor picture quality. Example: Setting “NR-3” 1. On the MAIN MENU, select “VIDEO SETTINGS”, then press the MENU/ENTER button. The “VIDEO SETTINGS”... -
Page 27: Changing The Gamma Curve
7. Adjust the white balance using the GAIN RED * If neither the button is pressed within 5 seconds, the current setting is stored into memory and the previous screen reappears. Information Adjusting the white balance GAIN R/G/B ... White balance adjustment for signal level BIAS R/G/B ... -
Page 28: Colorview
ColorView™ Use this procedure to adjust hue and color density for red, green, blue, yellow, magenta and cyan. You can accentuate the green color of trees, the blue of the sky, etc. Example: Adjusting the blue 1. On the MAIN MENU, select “VIDEO SETTINGS”, then press the MENU/ENTER button. -
Page 29: Selecting The Input Of The Audio Connectors
Setting the allocation of the audio connectors Setting the AUDIO 1, 2, and 3 connectors to the desired input. Example: Setting “AUDIO INPUT1” to “VIDEO 2” 1. On the MAIN MENU, select “AUDIO SETTINGS”, then press the MENU/ENTER button. The “AUDIO SETTINGS” screen appears. 2. -
Page 30: Option1 Settings Menu
Information When “AUTO PICTURE” is “OFF” MONITOR SETTINGS ASPECT MODE STANDARD V-POSITION H-POSITION V-HEIGHT H-WIDTH AUTO PICTURE FINE PICTURE PICTURE ADJ. SEL. EXIT ADJ. When Auto Picture is off, the Fine Picture and the Picture ADJ. items are displayed so that you can adjust them. -
Page 31: Setting The Bnc Connectors
Setting the BNC connectors Select whether to set the input of the 5 BNC connectors to RGB or component. Example: Set the BNC INPUT mode to “COMP.” 1. On the MAIN MENU, select “OPTION1”, then press the MENU/ENTER button. The “OPTION1” screen appears. 2. -
Page 32: Setting High Definition Images To The Suitable Screen Size
Information RGB SELECT modes One of these 6 modes must be selected in order to display the following signals correctly. AUTO ... Select the suitable mode for the specifications of input signals as listed in the table “Table of Signals Supported”... -
Page 33: Resetting To The Default Values
Resetting to the default values Use this operation to restore all the settings (PICTURE, AUDIO, IMAGE ADJUST, OPTION1~3, etc) to the factory default values. 1. On the MAIN MENU, select “OPTION1”, then press the MENU/ENTER button. The “OPTION1” screen appears. 2. -
Page 34: Power/Standby Indicator
POWER/STANDBY indicator Power POWER/ Power Description management STANDBY management mode indicator operating status Green Not activated. Horizontal and vertical synchronizing signals are present from the computer. Activated. Horizontal vertical synchronizing signals are not sent from the computer. Setting the picture to suit the movie The film image is automatically discriminated and projected in an image mode suited to the picture. -
Page 35: Orbiter
ORBITER ORBITER - Uneven phosphor aging/burn-in reduction feature. To minimize the risk of uneven phosphor aging/ burn-in when displaying still images, the Mitsubishi PD- 5030 and PD-6130 offers a built-in feature known as ORBITER. The ORBITER feature intermittently shifts the screen image horizontally and vertically in small increments. -
Page 36: Setting The Time For Inverse
Information INVERSE Settings ON ... The picture is displayed alternately between positive image and negative image. You can set the time by pressing the MENU/ ENTER button while “ON” is set. OFF ... Inverse mode does not function. WHITE ...The entire screen turns white. You can set the time by pressing the MENU/ ENTER button while “ON”... -
Page 37: Soft Focus
SOFT FOCUS Reduces edges and softens the image. Example: Setting “SOFT FOCUS” to “2” 1. On the MAIN MENU, select “OPTION2”, then press the MENU/ENTER button. The “OPTION2” screen appears. 2. Use the ▲ and ▼ buttons to select “LONG LIFE”, then press the MENU/ENTER button. -
Page 38: Setting The Signal And Black Level For Dvi Signal
Information S1/S2 settings AUTO ...Adjusts the screen size automatically according to the S1/S2 video signal. OFF ... Turns the S1/S2 function off. Restoring the factory default settings Select “ALL RESET” under the OPTION1 menu. Note that this also restores other settings to the factory defaults. -
Page 39: Option3 Settings Menu
Option3 Settings Menu Using the timer This function sets the monitor to turn ON/OFF automatically at a set time. 1. On the MAIN MENU, select “OPTION3”, then press the MENU/ENTER button. The “OPTION3” screen appears. 2. Use the ▲ and ▼ buttons to select “TIMER”, then press the MENU/ENTER button. -
Page 40: Setting The Power On Mode
PROGRAM TIMER This sets the day and time at which the power will be switched ON/OFF as well as the input mode. Example: Setting so that the power will be switched on at 8:30 A.M., Monday, displaying RGB2 source, and switched off at 10:30 A.M. Perform Steps 1-2 of Using the TIMER, then... -
Page 41: Enabling/Disabling The Front Panel Controls
Information PWR. ON MODE settings LAST ... Last mode (the mode that was last selected at the time the power was switched off). VIDEO1, 2, 3 ... VIDEO input mode. RGB1, 2, MONLINK .. RGB input mode. HD/DVD1, 2 ... HD/DVD input mode. Restoring the factory default settings Select “ALL RESET”... -
Page 42: Loop Out Setting
Loop Out setting When this feature is set to ON, the received signal will be looped out. Example: Setting “ON” 1. On the MAIN MENU, select “OPTION3”, then press the MENU/ENTER button. The “OPTION3” screen appears. 2. Use the ▲ and ▼ buttons to select “LOOP OUT”. 3. -
Page 43: Language Settings Menu
Language Settings Menu Setting the language for the menus The menu display can be set to one of seven languages: English, German, French, Swedish, Italian, Spanish or Chinese. Example: Setting the menu display to “DEUTSCH” 1. On the MAIN MENU (NEXT PAGE), select “LANGUAGE”, then press the MENU/ENTER button. -
Page 44: Rs-232C Control
RS-232C Control Application These specifications cover the communications control of the plasma monitor by external equipment. Connections Connections are made as described below. External equipment e.g., Personal computer Display Connector on the plasma monitor side: MONITORLINK CONTROL/RS-232C connector. Use a crossed (reverse) cable. Type of connector: D-Sub 9-pin male Pin No. -
Page 45: Troubleshooting
Troubleshooting If the picture quality is poor or there is some other problem, check the adjustments, operations, etc., before requesting service. Symptom Picture moves intermittently around the screen. Mechanical sound is heard. The unit emits a crackling sound. Picture is disturbed. Sound is noisy. - Page 46 *1 Overheat protector If the monitor becomes too hot, the overheat protector will be activated and the monitor will be turned off. If this happens, turn off the power to the monitor and unplug the power cord. If the room where the monitor is installed is particularly hot, move the monitor to a cooler location and wait for the monitor to cool for 60 minutes.
-
Page 47: Technical Specifications Pd-5030
Specifications: PD-5030 Screen Size 43.5"(H) 24.5"(V) inches 1106(H) 622(V) mm diagonal 50" Aspect Ratio 16 : 9 Resolution 1365(H) 768(V) pixels Pixel Pitch 0.032"(H) 0.032"(V) inches 0.81(H) 0.81(V) mm Color Reproduction 256 levels, 16,770,000 colors Signals Synchronization Range Horizontal : 15.5 to 110 kHz (automatic : step scan) Vertical : 50.0 to 120 Hz... -
Page 48: Technical Specifications Pd-6130
Specifications: PD-6130 Screen Size 53.2"(H) 29.9"(V) inches 1351(H) 760(V) mm diagonal 61" Aspect Ratio 16 : 9 Resolution 1365(H) 768(V) pixels Pixel Pitch 0.039"(H) 0.039"(V) inches 0.99(H) 0.99(V) mm Color Reproduction 256 levels, 16,770,000 colors Signals Synchronization Range Horizontal : 15.5 to 110 kHz (automatic : step scan) Vertical : 50.0 to 120 Hz (automatic : step scan) -
Page 49: Table Of Signals Supported
Table of Signals Supported Supported resolution • When the screen mode is NARROW, each signal is converted to a 1024 dots 768 lines signal. (Except for * • When the screen mode is TRUE, the picture is displayed in the original resolution. •... -
Page 50: Warranty
*1 Only when using a graphic accelerator board that is capable of displaying 852 480. *2 This signal is converted to a 1024 dots *3 The picture is displayed in the original resolution. *4 The aspect ratio is 5:4. This signal is converted to a 960 dots 768 lines signal. *5 Normally the RGB select mode suite for the input signals is set automatically. - Page 51 Mitsubishi Plasma Display Panel Limited Warranty MITSUBISHI DIGITAL ELECTRONICS AMERICA, INC. (“MDEA”) warrants to the original purchaser of this Plasma Display Panel that if purchased from an authorized MITSUBISHI Audio/Video Dealer, should it prove defective by reason of improper workmanship and/or material: a.
-
Page 52: Declaration Of Conformity
FCC Rules. Mitsubishi Digital Electronics America 9351 Jeronimo Road Irvine, CA 92618 (949) 465-6000 Plasma Display Class B Peripheral PD-5030/PD-6130 Mitsubishi Digital Electronics America 9351 Jeronimo Road Irvine, CA 92618 Printed in USA 7S900055...
