Mitsubishi Electric DX-TL2500U Installation And Operation Manual

Mitsubishi digital electronics dvr user manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DIGITAL RECORDER
INSTALLATION AND
OPERATION MANUAL
MODEL
DX-TL2500U
THIS INSTRUCTION MANUAL IS IMPORTANT TO YOU. PLEASE READ IT BEFORE USING YOUR DIGITAL RECORDER.
1

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi Electric DX-TL2500U

Summary of Contents for Mitsubishi Electric DX-TL2500U

  • Page 1 DIGITAL RECORDER INSTALLATION AND OPERATION MANUAL MODEL DX-TL2500U THIS INSTRUCTION MANUAL IS IMPORTANT TO YOU. PLEASE READ IT BEFORE USING YOUR DIGITAL RECORDER.
  • Page 2 WARNING: REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT USE THIS (POLARIZED) PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.
  • Page 3 AVERTISSEMENT: La flèche symbolisant l’éclair dans un triangle équilateral a pour objet de tirer l’attention de l’utilisateur sur le fait, qu’il y a des “tensions dangereuses” non-isolées à l’intérieur de l’enceinte du produit qui peuvent être suffisamment importantes pour conduire au risque d’électrocution.

  • Page 4: Important Safeguards

    Important safeguards PLEASE READ ALL THESE INSTRUCTIONS REGARDING YOUR RECORDER AND RETAIN FOR FUTURE REFERENCE. FOLLOW ALL WARNINGS AND INSTRUCTIONS MARKED ON THE RECORDER. 1. Read Instructions All the safety and operating instructions should be read before the appliance is operated. 2.
  • Page 5 16. Servicing Do not attempt to service this product yourself as opening or removing covers may expose you to dan- gerous voltage or other hazards. Refer all servicing to qualified service personnel. 17. Damage requiring Service Unplug this product from the wall outlet and refer serv- icing to qualified service personnel under the follow- ing conditions: (a) When the power-supply cord or plug is dam-...

  • Page 6: Caution And Care

    Caution and care HEAVY OBJECTS SHOULD NEVER BE PLACED ON THE UNIT (E.G., TV) NEVER TOUCH OR INSERT ANY OBJECT INSIDE THE UNIT Touching the inside of the cabinet or inserting foreign objects of any kind not only creates a safety hazard but can also cause extensive damage.
  • Page 7 WARNING: The supplied power cord is used for 120V only. Never connect to any outlet or power supply having a different voltage or frequency. There may be cases when the unit’s built-in MOTION DETECTION function does not operate properly due to external condition or video input signal or other factors. The user will not be indemnified for problems (e.g., recording failure or playback failure) that occur with either the unit or a connected device during operation.

  • Page 8: Features

    Features Built-in duplex 16 channel multiplexer • The screen mode can be switched on the monitor such as single screen, split4, split9 and split16 screen and sequential screen, split4 sequential screen and split9 sequential screen. ( see page 41) • The unit is equipped with the 2 type-output connector to display the different mode split screen on the each of different monitors.
  • Page 9 Ease of use • Auto set-up By selecting only the recording period of 24, 96 or 168 hrs. and 14 or 30 days, the unit assigns automatically recording interval and picture grade for all channels and other menu settings are set to the default. ( pages 21, 22) •...

  • Page 10: Table Of Contents

    Contents Important safeguards ... 4,5 Caution and care ... 6,7 Features ... 8,9 Contents ... 10,11 Flowchart ... 12,13 Flowchart for connection and settings ... 12,13 Major operations and their functions ... 14-18 Front View ... 14 Front View (Inside of the door) ... 15,16 Inserting/Ejecting Compact Flash Card ...
  • Page 11 ALARM NOTIFICATION SETTING ... 60,61 CAMERA CONTROL ... 61 INFORMATION/SERVICE ... 61-63 HDD INFORMATION/ARCHIVE/COPY INFORMATION/CFC INFORMATION ... 61,62 WARNING LOG LIST ... 62 RESET TO FACTORY SETTINGS ... 63 DATA CLEAR ... 63 PASSWORD ... 63-65 SIMPLE LOCK ... 63 PASSWORD LOCK ...

  • Page 12: Flowchart

    Flowchart Flowchart for connection and settings Installation example : This is an example operational flowchart of the following : making connections at the rear of the terminal ; setting HDD mode to PARTITION ; making default settings ; making an Alarm recording with Timer mode ; searching recorded data with ALARM LIST SEARCH ;...
  • Page 13 Changing the multiplexer function • Changing the split4 , split9 and split16 screen settings. See “ SPLIT4 SCREEN SETTING”, page 42, “ SPLIT9 SCREEN SETTING”, page 43 and “ SPLIT16 SCREEN SETTING”, page 43. • Changing the sequence setting. See “ SEQUENCE SETTING”, pages 43, 44. Setting other various functions •...

  • Page 14: Major Operations And Their Functions

    Major operations and their functions Front View DIGITAL RECORDER DX - TL 2500 SPLIT/ SEQUENCE ZOOM OUTPUT B TIMER 1. ZOOM button Pressing this button once during single screen dis- play, the screen is magnified by 100%. In the same way, pressing the button twice magnifies the screen by 200% and pressing the button three times magni- fies the screen by 400%.

  • Page 15: Front View (Inside Of The Door)

    Front View (Inside of the door) DIGITAL RECORDER DX - TL 2500 SPLIT/ SEQUENCE ZOOM OUTPUT B TIMER PRE ALARM M-DET POWER TIMER VIDEO OUT AUDIO OUT 23 24 17. WARNING RESET button This button is used to clear on-screen warning dis- play data.

  • Page 16: Inserting/Ejecting Compact Flash Card

    Major operations and their functions (continued) Front View (Inside of the door) (continued) DIGITAL RECORDER DX - TL 2500 SPLIT/ SEQUENCE ZOOM OUTPUT B TIMER POWER TIMER VIDEO OUT AUDIO OUT 23 24 29. EJECT button Use this button to remove media from externally con- nected devices.

  • Page 17: Rear View

    Rear View MAIN AC IN VIDEO RS-485/ RS-422 1. MAIN switch This is the main power switch. When using this unit, set this switch to ON. Otherwise, the unit cannot be turned ON using the POWER button on the front of the unit. 2.

  • Page 18: Connections

    Connections Connecting to CCTV camera, monitor, sensor To OUTPUT A VIDEO or OUTPUT A S(Y/C) connector CAUTION Connecting a coaxial transmission camera wrong may damage the input terminal. Be careful. CAMERA #1 To CAMERA IN 1 connector Up to 16 cameras MAIN AC IN VIDEO...

  • Page 19: Call Out Output Terminal

    ALARM IN ALARM SWITCH Connecting peripheral recording devices Connecting peripheral recording devices to the DVR unit through its SCSI interface (SCSI2 half-pitch 50-pin), stor- age space can be increased and archive and copying func- tions can be performed. Please consult with your retailer for information regarding which peripheral recording de- vices can be used.

  • Page 20: Alarm Recording Connection

    (1TB = 1000 x 1000 x 1000 x 1000 bytes.) AUTO SET UP AUTO SET UP is displayed and done when the DVR is turned on for the first time (out of box). Only when the unit is turned on for the first time, the AUTO SET UP screen is displayed automatically.

  • Page 21: Auto Set Up

    AUTO SET UP (continued) 8. Turn the SHUTTLE ring clockwise. • The <AUTO RECORD SETTING> screen appears. • The period of the record can be set. • Setting of AUTO RECORD SETTING ( default : “24H” ) “24H”, “48H”, “72H”, “96H”, “120H”, “144H”, “1WEEK”, “2WEEK”, “3WEEK”, “1MONTH”, “2MONTH”, “3MONTH”, “4MONTH”, “5MONTH”, “6MONTH”, “1YEAR”...

  • Page 22: Id4•Id5

    Initial settings (continued) HDD SETTING The HDD SETTING can be set to MIRRORING (simultane- ous recording to the internal HDD and peripheral recording device HDD as a pair), and PARTITION (an independent partition that can be set within the total HDD memory specifi- cally for ALARM RECORDING).

  • Page 23: Ethernet Connector

    Major operations and their functions (continued) Rear View (continued) MAIN AC IN REC terminal Input terminal to start recording. Not available dur- ing timer recording. EMERGENCY terminal Input terminal initiating EMERGENCY recording mode. MODE OUT 1 ~ MODE OUT 5 terminals Output terminal to indicate the unit’s current mode.

  • Page 24: Basic Operations

    Basic Operations Multiplexer functions Buttons on the front of the unit can be used to perform some of the multiplexer functions. Multiplexer buttons 2. SPLIT/SEQUENCE buttons 1. Camera number buttons (1 to 16) SPLIT/ SEQUENCE ZOOM 3. ZOOM button 1. Camera number buttons (1 to 16) Video images of cameras connected to CAMERA IN ter- minals 1 to 16 on the rear of the unit are displayed.

  • Page 25: To Return To The Normal Screen From A Menu Screen

    <TIME DATE/DISPLAY SETTINGS> TIME DATE ADJUST >>DISPLAY MODE CLOCK LOCATION SETTING CAMERA DISPLAY CAMERA TITLE/MEMO SETTING DUPLEX MODE DISPLAY <MODE 3> 01-01-2003 WED 00:00:00 15P 99% A00001 To return to the normal screen from a menu screen The procedure to return to the normal screen after com- pleting menu screen settings using the JOG dial/SHUT- TLE ring is detailed below.

  • Page 26: Time Date Adjust

    Basic Operations (continued) <TIME DATE ADJUST> DAYLIGHT SAVING >>MONTH YEAR TIME 6. Turn the JOG dial clockwise to move the cursor (>>) to “DAY”. When turning the JOG dial clockwise, the cursor (>>) moves down. When turning counterclockwise, the cursor (>>) moves up. 7.

  • Page 27: Basic Manual Recording

    Basic manual recording Information on normal recording is provided bolow. Before starting recording, recording settings must be checked. After checking the settings of “HDD REPEAT REC MAIN”, “HDD REPEAT REC SUB” in the <HDD SETTINGS> screen ( see page 53), the REC mode settings are made.

  • Page 28: Basic Playback

    Basic Operations (continued) The menu screen will not be cleared even when pressing the SET UP button when the setting item is flashing. 6. Turn the JOG dial to select “0.25P” and turn the SHUTTLE ring clockwise. • Setting is confirmed and flashing stops. <RECORD SETTING>...

  • Page 29: Basic Search

    3. To pause playback, press the PAUSE button. • To resume playback, press the PAUSE button again or press the PLAY button. 4. To stop playback, press the STOP button. • During HDD playback/pause, playback will start the next time from the paused position. •...

  • Page 30: Language Selection

    Basic Operations (continued) 11. When the setting is complete, turn the SHUTTLE ring counterclockwise. • The display returns to the <TIME DATE SEARCH> screen and the cursor appears on the left of the search date. 12. Turn the JOG dial to select “EXECUTE(FORWARD)” and turn the SHUTTLE ring clockwise.

  • Page 31: Menu Functions

    Menu functions MENU SETTING You can set the basic settings for this unit in the MENU SETTING. Refer to pages shown below for details. During playback, recording, pre-alarm recording stand-by mode you cannot change setting of some MENUs. SET UP MAIN MENU SUB MENU (3) <SEQUENCE SETTING>...
  • Page 32 Menu functions (continued) SET UP MAIN MENU SUB MENU (2) <REC MODE A> ~ <REC MODE D> Pages 52 •••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• SUB MENU (1) SUB MENU (2) <MOTION DETECTION SETTINGS> <DETECTION MASK SETTING> Pages 45, 46 <TEST MODE> <ALARM SETTING> 1/2 <RECORD SETTINGS>...
  • Page 33 SET UP MAIN MENU SUB MENU (1) <INITIAL SET UP/INFORMATION> Pages 53-65 •••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• Operations SUB MENU (2) <HDD SETTINGS> Pages 53, 54 SUB MENU (3) <CALL OUT SETTINGS> <REAR TERMINAL SETTINGS> Pages 56-58 <COMMUNICATION PORT SETTINGS> <RS-232C> Pages 58-61 < ETHERNET >...
  • Page 34 Menu functions (continued) SET UP SUB MENU (1) MAIN MENU #2. Appears when “PARTITION” is set on the screen. #3. Appears when “ARCHIVE•COPY” is set to ID4•ID5 on the screen. #4. Appears when “HDD” is set to ID4•ID5 on the screen. ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••...
  • Page 35 SET UP MAIN MENU REC/STOP + POWER button <INITIALIZATION> Pages 22, 23, 82-84 •••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• Operations SUB MENU (1) SUB MENU (2) <INITIAL SET UP/INFORMATION> <INFORMATION/SERVICE> 1/2 Pages 53-65 SUB MENU (2) SUB MENU (3) <PASSWORD> Pages 63-65 <PASSWORD SETTING> <PASSWORD SETTING> <LANGUAGE SELECTION>...

  • Page 36: Copy Menu

    Menu functions (continued) COPY MENU MAIN MENU <COPY> <COPY> SEARCH SELECTION MENU MAIN MENU <TIME DATE SEARCH> <INDEX SEARCH> <ALARM INDEX SEARCH> <ALARM SKIP SEARCH> <ALARM LIST SEARCH> •••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• Pages 80, 81 <RESTORE> <RESTORE> SEARCH SEARCH Pages 29, 30 SEARCH Pages 76, 77 SEARCH Pages 76, 77...

  • Page 37: Time Date/Display Settings

    <TIME DATE/DISPLAY SETTINGS> TIME DATE ADJUST See pages 25, 26. DISPLAY MODE Display format of the date and current time can be set. Setting ( default : “1” ) “1” : Displays the month/day/year, current time. “2” : Displays the month/day/year, day of week, cur- rent time, playback interval (single screen playback only).

  • Page 38: Camera Title/Memo Setting

    <TIME DATE/DISPLAY SETTINGS> (continued) The <CAMERA TITLE/MEMO SETTING> screen consists of 2 pages. The second page is displayed by turning the JOG dial to move the cursor to “NEXT PAGE”, and turn the SHUTTLE ring clockwise. <CAMERA TITLE/MEMO SETTING> 1/2 <CAMERA TITLE/MEMO SETTING>...

  • Page 39: Duplex Mode Display

    DUPLEX MODE DISPLAY Operation conditions such as PLAYBACK, COPY, REC and ALARM REC (ALARM is displayed in red during emergency recording), etc., can be displayed on the up- per or lower portions of the screen. Setting ( default : “BOTTOM” ) “BOTTOM”...

  • Page 40: Mpx Display Settings

    <MPX DISPLAY SETTINGS> The multiplexer function of this unit allows the connected camera video to be displayed using SPLIT4, SPLIT9 and SPLIT16 screens. It is also possible to set the order of the camera number displayed. Basic operations of the multi- plexer can also be found on Multiplexer function related button operations/operation table...

  • Page 41: The Function Of The Split/Sequence Button, Zoom Button, And Camera Number Buttons

    The function of the SPLIT/SEQUENCE button, ZOOM button, and camera number buttons The screen of cameras with no video input signal will appear blue. Furthermore, the screen of cameras set to “OFF” for COVERT CAMERA SETTING will appear black ( SPLIT/ ZOOM Display...

  • Page 42: Mpx Display Settings

    <MPX DISPLAY SETTINGS> (continued) MPX DISPLAY SETTINGS Multiplexer setting of the <OUTPUT A> and <OUTPUT B> are referenced below. SPLIT/SEQUENCE SPLIT/SEQUENCE allows selection of display modes. Setting ( default : “ALL” ) “ALL” : Displays all split screens of 4, 9, and 16. “SHORT”...

  • Page 43: Split9 Screen Setting

    SPLIT9 SCREEN SETTING For the SPLIT9 SCREEN SETTING, 2 types of SPLIT9 screen types (a, d) can be set. 1. Press the SET UP button <SETTINGS> “OUTPUT A” (“OUTPUT B”) in the <MPX DISPLAY SETTINGS> screen and turn the SHUTTLE ring clockwise. •...

  • Page 44: Sequence Setting

    <MPX DISPLAY SETTINGS> (continued) <SEQUENCE SETTING> 2/2 The <SEQUENCE SETTING> screen consists of 2 pages. The second page is displayed when turn- ing the JOG dial to move the cursor to “NEXT PAGE”, and turn the SHUTTLE ring clockwise. 3. Select the desired display order ( SHUTTLE ring clockwise twice.

  • Page 45: Motion Detection Settings

    <MOTION DETECTION SETTINGS> In this menu, the conditions of the motion detection func- tion for normal recording and alarm recording, which is started when detecting motion within the video of the con- nected camera, are set. SELECTION CAMERA NUMBER The camera for motion detection setting is selected. Each camera settings can be made seperate.

  • Page 46: Sensitivity

    <MOTION DETECTION SETTINGS> (continued) SENSITIVITY The sensitivity of detection for changes in the active video data is set. The sensitivity setting is divided into the 5 lev- els of brightness. Setting ( default : “HIGH • • < < < LOW” ) “HIGH •...

  • Page 47: Record Settings

    <RECORD SETTINGS> Settings concerning normal recording and alarm recording This unit allows per camera independent settings for nor- mal recording and alarm recording. By this, more detailed settings are possible such as changing the recording inter- vals of the camera inputting the alarm signals while main- taining the normal recording settings of normal cameras.

  • Page 48: Pre Alarm Rec

    <RECORD SETTINGS> (continued) <RECORD SETTING> 1/2 Camera selection during alarm recording <RECORD SETTING> GRADE A-PPS 1.875P STD 1.875P STD 1.875P STD 1.875P STD 1.875P STD 1.875P STD 1.875P STD 1.875P STD 1.875P STD NEXT PAGE SHUTTLE<<:BACK <RECORD SETTING> 2/2 <RECORD SETTING> GRADE A-PPS >>...

  • Page 49: Alarm Rec Duration

    ALARM MOITON DET REC ARCHIVE OVERWRITE >> ARCHIVE MEDIA AUTO EJECT When the DVR archive media is full, the unit stops archiving and ejects the ARCHIVE media au- tomatically. This setting appears when “ARCHIVE• COPY” is selected on “ID4•ID5” of the <INITIALIZATION>...

  • Page 50: Timer Program Settings

    <TIMER PROGRAM SETTINGS> TIMER PROGRAM SETTINGS Up to 3 operation patterns can be set in advance. By indi- vidually setting the camera, recording intervals and re- cording picture quality for normal recording/alarm record- ing to REC MODE A ~ D, settings can be changed in- stantly by simple switching selections.
  • Page 51 5. Check to see that the cursor is to the left of program number “1” and turn the SHUTTLE ring clockwise twice. • The “DW” display reverses in color when the SHUTTLE ring is turned for the first time. When the ring is turned for the second time, the background turns red and flashes.

  • Page 52: Holiday Setting

    <TIMER PROGRAM SETTINGS> (continued) HOLIDAY SETTING Holidays throughout the year can be set in advance. <HOLIDAY SETTING> --/-- --/-- --/-- --/-- --/-- --/-- --/-- --/-- --/-- --/-- --/-- --/-- --/-- --/-- --/-- MONTH/DAY 1. Press the SET UP button } <SETTINGS> } Select “HOLIDAY SETTING”...

  • Page 53: Initial Set Up/Information

    <INITIAL SET UP/INFORMATION> HDD SETTINGS HDD REPEAT REC MAIN/ HDD REPEAT REC SUB Operation when HDD (Hard Disk Drive) space is full. <HDD SETTINGS> >>HDD REPEAT REC MAIN HDD REPEAT REC SUB HDD REPEAT PLAY IM-CHECK PLAY SEQUENTIAL PLAY FIFO OVERWRITE MODE ARCHIVE SOURCE HDD ARCHIVE START POSITION RESET #1.Appears when “ARCHIVE•COPY”...

  • Page 54: Im-Check Play

    When performing complex playback operations with the SHUTTLE ring (one picture at a time), dur- ing alteration check, the “IMAGE MODIFIED” warn- ing may appear. Use the DVR’s normal playback mode if this occurs. SEQUENTIAL PLAY It is possible to make a copy of the recorded video to an analogue video recorder, etc..

  • Page 55: Archive Source Hdd

    3. Select “ON” by turning the JOG, and turn the SHUTTLE ring clockwise. • The setting is made, and the display stops flashing. If a power failure occurs during archive, the ar- chive will not restart automatically after the power is restored.

  • Page 56: Audio Recording

    <INITIAL SET UP/INFORMATION> (continued) AUDIO RECORDING This unit can record audio in one channel along with the video. When recording audio, the continuous recording time is less than when recording only video. <INITIAL SET UP/INFORMATION> HDD SETTINGS >>AUDIO RECORDING REAR TERMINAL SETTINGS COMMUNICATION PORT SETTINGS CAMERA CONTROL INFORMATION/SERVICE...

  • Page 57: Key Sound

    <REAR TERMINAL SETTINGS> MODE OUT 1 MODE OUT 2 MODE OUT 3 MODE OUT 4 MODE OUT 5 >>KEY SOUND BUZZER REMAIN HDD CALL OUT SETTINGS EMERGENCY REC DURATION 1. Press the SET UP button } <SETTINGS> } <INITIAL SET UP/INFORMATION>...

  • Page 58: Call Out Settings

    <INITIAL SET UP/INFORMATION> (continued) CALL OUT SETTINGS The CALL OUT settings are used with the rear CALL OUT terminals outputting a signal to notify of a specified condition. CALL OUT SETTINGS use photo-coupler output to decrease the amount of malfunctions due to writing . See page 19 “CALL OUT Output terminal”...

  • Page 59: Mode

    • SETTINGS RS-232C settings can be made when setting “MODE” above to “REMOTE A”, “REMOTE B” or “REMOTE C”. Set the settings for the RS-232C of the DVR and PC the same. Setting of “TRANSMISSION MODE” ( default : “9600” ) “1200”, “2400”, “4800”, “9600”, “19200”...

  • Page 60: E-Mail Address

    • E-MAIL ADDRESS The setting of “SMTP SERVER”, “RECORDER ID” and “USER ADDRESS” is referenced below. The DVR’s DX-PC25 software is required to input “SMTP SERVER”, “RECORDER ID” and “USER AD- DRESS”. Please refer to the instruction manual of the software.

  • Page 61: Camera Control

    Setting of “ALARM SENS” ( default : “OFF” ) “ON” : When alarm terminal is activated, the DVR trans- mits the status information to connected PC. E-mail is sent to address displayed on “USER ADDRESS” of the <E-MAIL ADDRESS> screen.

  • Page 62: Warning Log List

    <INITIAL SET UP/INFORMATION> (continued) 1-1. (To check HDD RECORD data • • • ) Press the SET UP button } <SETTINGS> } <INITIAL SET UP/INFORMATION> } Select “HDD INFORMATION” in the <INFORMATION/SERVICE> screen, and turn the SHUTTLE ring clockwise. • The <HDD INFORMATION> screen is displayed. <HDD INFORMATION>...

  • Page 63: Information/Service

    RESET TO FACTORY SETTINGS All of the unit’s menu screen are reset to factory settings. 1. Press the SET UP button } <SETTINGS> } <INITIAL SET UP/INFORMATION> } Select “RESET TO FACTORY SETTINGS” in the <INFORMATION/SERVICE> screen. Turn the SHUTTLE ring clockwise. •...
  • Page 64 <INITIAL SET UP/INFORMATION> (continued) 4) Unlock the PASSWORD LOCK of level 2. • The PASSWORD LOCK of level 3 will be active. When The PASSWORD LOCK of level 3 is active, all operations are active except the SET UP button and ALARM INTERRUPT button.

  • Page 65: Language Selection

    5. Input the 4 digits of the PASSWORD by pressing the camera number buttons or the ZOOM button. • The cursor moves to the left side of the setting “2”. When the PASSWORD LOCK of level 1 and 2 are set, if you unlock level 1 the PASSWORD LOCK of level 2 will still be active.

  • Page 66: Quick Settings

    <QUICK SETTINGS> QUICK SETTINGS This unit can save or load Menu settings stored on the Compact Flash Card. During execution of menu quick settings, other op- erations are not accepted. To update menu settings of this unit To read/alter menu settings stored on the Compact Flash Card using the unit, synchronize the HDD setting to that of the unit the menu settings were copied to.

  • Page 67: Operation Examples

    Operation examples Operation example 1 This example illustrates the procedure for switching be- tween cameras according to time and day, when different numbers of cameras are allocated to RECORD SETTINGS A and B for normal recording in Timer record mode. For loading of camera video, of recording operation to the number of cameras and recording interval settings”, page 98.

  • Page 68: Operation Example 1

    Operation examples (continued) <RECORD SETTING B> 2/2 <RECORD SETTING B> ALARM GRADE A-PPS >> ------ STD ------ STD ------ STD ------ STD SUPER ------ STD SUPER ------ STD SUPER ------ STD PRE ALARM REC SHUTTLE<<:BACK <ESTD REC> 7) <TIMER PROGRAM> screen setting ( 50, 51).

  • Page 69: Operation Example 2

    5) <RECORD SETTING A> screen setting ( 52). • Camera number “ ” ~ “ ”. • PPS, GRADE : Set desired interval and picture quality for each camera. • A-PPS : “- - - - - -”. <RECORD SETTING A> 1/2 <RECORD SETTING A>...
  • Page 70 Operation examples (continued) 5) <REC MODE C> screen setting ( • MOTION DET REC : “ALARM” <REC MODE C> ALARM SETTING RECORD SETTING >>MOTION DET REC 6) <ALARM SETTING C> screen setting ( • All cameras ( “ ” ~ “ ”...

  • Page 71: Operation Example 4

    11) <TIMER PROGRAM> screen setting ( 50, 51). • SPL : “MON - FRI”. • PROGRAM NO.1 : “SPL”, “08:00”, “15:00”, “C”, “ON”. • PROGRAM NO.2 : “SPL”, “15:00”, “08:00”, “D”, “ON”. • PROGRAM NO.3 : “SAT”, “08:00”, “08:00”, “D”, “ON”. •...

  • Page 72: Various Recordings

    Various recordings PRE ALARM RECORDINGS During alarm recording, recording can be started a few seconds before the ALARM IN terminal is grounded or motion is detected. For details concerning pre-alarm recording set- tings, see “Recording mode settings A ~ D for normal recording/alarm recording”...

  • Page 73: Various Playback Functions

    Various playback functions Playing still frames 1. Press the PAUSE button during playback. • The unit switches to still frame playback. Press the button again to resume playback. • If a camera number (1 ~ 16) button is pressed during single screen still frame playback, the video of the camera number button pressed will be displayed by searching forward.

  • Page 74: Monitor Display Settings And Playback Operation

    Various playback functions (continued) 2-2. Press the REV. PLAY (REVERSE PLAYBACK) button. • The playback interval is changed to a slower setting (30P, 15P, and so on) each time the button is pressed. Audio cannot be played back when changing the playback interval.

  • Page 75: Various Search

    Various search This unit supports a variety of search functions which will allow you to quickly access the desired video. SEARCH SELECTION The search screen appears when the SEARCH button is pressed. When pressed again, the “SEARCH SELECTION” screen appears. This screen is to select playback device, search type, camera number and start and end time.

  • Page 76: Time Date Search

    Various search (continued) TIME DATE SEARCH See pages 29, 30. INDEX SEARCH/ALARM INDEX SEARCH With this unit, index signals are automatically written to the HDD at the start of each recording. It is possible to search these signals and playback start- ing at such index points.

  • Page 77: Alarm Skip Search

    To change the desired camera number to the single screen dis- play during still-frame playback in SPLIT16 display, press the SEARCH button to clear the search setting screen and press the desired cam- era number button. Search may not perform properly at times depending on the re- corded condition of the index signals.

  • Page 78: Alarm List Search

    Various search (continued) ALARM LIST SEARCH This unit stores the start time of alarm recording and emer- gency recording in the alarm list when such recording be- gins. It is also possible to index search the desired time (or the closest time) from the list of alarm recording (emer- gency recording) start times stored in the alarm list.

  • Page 79: Start/End Search

    START/END SEARCH It is possible to search the recording starting/ending point of the device (media) selected by pressing the PLAY DE- VICE button in <TIMER DATE SEARCH>, <INDEX SEARCH> and <ALARM INDEX SEARCH> for playback. 1. Press the SEARCH button. •...

  • Page 80: Making Copy/Restore

    Making Copy/Restore Making Copy/Restore Data in MAIN HDD or SUB HDD can be copied to a COPY device or Compact Flash Card. Data in ARCHIVE/COPY devices or Compact Flash Cards can be restored to MAIN HDD. Setting “MAIN HDD } CFC” : The data recorded on MAIN HDD is copied to Compact Flash Card.

  • Page 81: Copying From Unit To Videotape

    6. To stop copying, press the STOP button of this unit. After stopping playback, stop the recording on the analogue video cassette recorder. Video recorded on VCR will be exactly as dis- played on the playback screen of the DVR.

  • Page 82: Other Convenient Functions

    Other convenient functions Power failure compensation circuit The unit is equipped with an internal power failure com- pensation circuit. When the unit has been charged for 48 hours (full), the date, time, timer record settings, and menu settings are kept up to 1 month without power. The accuracy of the time will decline if the power plug is not connected to the wall outlet for and extensive pe- riod.

  • Page 83: Mirroring

    Points to be aware of regarding MIRROR mode • “MIRRORING” mode only uses the internal HDD, and peripheral recording device HDD’s. “MIRRORING” mode combinations are shown right. Combinations not shown are not possible. Pair 4 re- quires HDD’s to be connected to ID4•ID5, and “HDD” to be selected on “ID4•ID5”.

  • Page 84: Partition/Partition Size

    Other convenient functions (continued) PARTITION/PARTITION SIZE PARTITION mode only uses the internal HDD, and pe- ripheral recording device HDD’s. PARTITION mode des- ignates the area inside the HDD that is specified as each HDD’s sub-device capacity for Alarm recording. This independent partition inside the HDD allows to keep the data of alarm recording.

  • Page 85: Covert Camera Setting

    COVERT CAMERA SETTING The video of the specified camera number can be set to not be displayed regardless of the presence of video signals. Setting ( default : “ON” ) “ON”, “OFF” COVERT CAMERA SETTING trouble, warning in- dicator will not appear on the screen. If “WARNING” is set in BUZZER setting the BUZZER sounds and the unit registers this error in the WARNING LOG LIST, CALL OUT signal is emitted.

  • Page 86: Communications By Web Browser

    Start up the Microsoft Internet Explorer and log in. ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 1. Start up the Microsoft Internet Explorer and enter the IP address of the DVR. • The “[Authentication]” screen will appear. 2-1. (When logging in • • • ) First, enter the “userID” and then enter the “password”. When shipped from the factory, the userID for the full-rights user is “root”, and the password is “admin000”, the userID for the...

  • Page 87: Welcome

    3-2. Select “[Back to Authentication]” and either left-click or press ENTER. • The “[Authentication]” screen will appear. 3-3. Follow the steps in step 2-1 and enter the correct “userID” and “password”. 4-1. (If you do not want to log in • • • ) Select “If you don’t want to log in, click here to exit.”...

  • Page 88: Playback

    Communications by Web Browser (continued) <Explanation of functions> STOP : Stops the retrieval of an image. : Starts (or restarts) the retrieval of an image. Display : For selecting either the display or non-display of a camera number. Layout : For selecting from the 6 types of display patterns.

  • Page 89: Time Search

    : During playback or searching, press to stop playback for still frame. Device : Selects the HDD for playback and search. ( default : MAIN ) SUB when DVR is partitioned. • The following search functions can be selected in sin- gle-screen display.

  • Page 90: Log Out

    Communications by Web Browser (continued) <User authorization> Live Monitor : Allows acquisition of live images. It is a mandatory to register. Play Mode : Allows acquisition of recorded im ages. Playmode, control from one user. All Camera : Allows the acquisition of images from a covert camera.

  • Page 91: Welcome

    2-1. (To change the logged in user • • • ) In the “Log in ( or log in as a different user ):” settings, execute step 2-1 and 2-2 in “ AUTHENTICATION” and change the logged in user. • The logged in user is changed and the “Welcome” screen appears.

  • Page 92: Recording Time Table

    Recording time table Continuous recording time table HDD continuous recording time (for 240GB drive) Displays the estimated recordable time (when recording on a 240GB HDD). The following table shows estimated recordable time when operating with 2 cameras and the recording interval is set at a constant PPS rate given at the top of the column. •...

  • Page 93: Compact Flash Card Continuous

    Compact Flash Card continuous recording time (for 64MB) Displays the estimated recordable time (when recording on a 64MB Compact Flash Card). • Without Audio recording GRADE SUPER HIGH 1m10s BASIC 1m30s LONG • With Audio recording <Audio recording using 12.8KHz PCM sampling is possible.> GRADE SUPER HIGH...

  • Page 94: Troubleshooting

    Troubleshooting If problems with the unit persist even after you’ve followed the suggestions below, please disconnect the power cord and contact the retailer from whom you purchased the unit. Description of problem The unit will not turn on. Power is on, but the unit will not operate.
  • Page 95 Description of problem The copy device/archive device dose not respond. The unit will not perform the motion detection function. The unit will not respond to PC control. There is a camera number with a blue screen during split screen display. Button operation is not working.

  • Page 96: Warnings And Call Out Output

    Warnings and CALL OUT output Warnings and their appropriate countermeasures #1 Options in the CALL OUT options column: • Selectable : CALL OUT output can be selected/de-selected on the menu. • Fixed : a CALL OUT signal is emitted without prior selection of this function using the menu. •...
  • Page 97 Status Warning Display IMAGE MODIFIED • Video data that has been altered was played back. SYSTEM ERROR • System error has REC/ occurred. SYSTEM ERROR PLAY/ SYSTEM ERROR COPY/ SYSTEM ERROR REST/ SYSTEM ERROR ARCHIVE/ SYSTEM ERROR REC/RW • Error has occurred during writing of data to COPY/RW REST/RW...

  • Page 98: Glossary

    Glossary Glossary • I/O terminals Terms used for referring to both input and output. • RS-232C Connection standard used for handling data between de- vices such as a PC, modem, etc. A standard when con- necting a PC and modem. The upper limit for the commu- nication speed of this standard is 115.2kbps and the maxi- mum transfer distance is 15m.

  • Page 99: Specifications

    Specifications Rated Power Supply: Rated Input: Color System: Operating Temperature: Relative Humidity: Altitude: Dimensions: Weight: Recording System Sampling Data Compression Compression Unit Resolution Recording Device Video Input: Monitor Output: Throughout Output: Audio Input: Audio Output: Microphone Input: Timer Program: Memory Backup: CONNECTORS ALARM IN(1-16) Input: CLOCK ADJ Input:...
  • Page 100 872C276A0 PRINTED IN JAPAN...
