Mitsubishi Electric Air-conditioner Network System
Central Controller
Model: G-50A
Before using the controller, please read this Instruction Book carefully to ensure
correct operation. Store this Instruction Book in a location that is easy to find.
Contents
Safety ...................................................
1.
.......................................
2.
3.
................................................
3-1
3-2
.......................................
4.
4-1
4-2
4-2-1
4-2-2
4-3
4-4
4-5
5.
..........................................
5-1
5-2
5-3
5-4
5-5
5-6
5-7
5-8
5-9
6.
..........................................
6-1
6-2
7.
7-1
7-2
Instruction Book
.................................
..............................
...............
...........................
............
.........
..............................
....................................
........................
............
.....................
..............................
...............
............
........................
.................................
...........................
............
...............
..................
..............................
.....................
.....................
.....................
.....................
1
2
4
4
8
10
11
12
12
16
19
23
24
25
25
25
26
27
29
31
34
35
35
36
36
37
38
38
39
40
42

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi Electric G-50A

Summary of Contents for Mitsubishi Electric G-50A

  • Page 1: Table Of Contents

    Mitsubishi Electric Air-conditioner Network System Central Controller Model: G-50A ON/OFF CENTRAL CONTROLLER G-50A Before using the controller, please read this Instruction Book carefully to ensure correct operation. Store this Instruction Book in a location that is easy to find. Instruction Book Contents Safety ……………………………………………...
