USER MANUAL
ENGLISH
Thank you very much for choosing the iiyama
LCD monitor.
We recommend that you take a few minutes to
r e a d c a r e f u l l y t h r o u g h t h i s b r i e f b u t
comprehensive manual before installing and
switching on the monitor. Please keep this
manual in a safe place for your future
reference.
Advertisement
Table of Contents
Related Manuals for Iiyama Pro Lite E511S
Summary of Contents for Iiyama Pro Lite E511S
-
Page 1: User Manual
USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to r e a d c a r e f u l l y t h r o u g h t h i s b r i e f b u t comprehensive manual before installing and switching on the monitor. - Page 2 Congratulations! The display you have just purchased carries the TCO’03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the impact on our natural environment.
-
Page 3: Why Do We Have Environmentally Labelled Computers
Congratulations! You have just purchased a TCO’99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products. -
Page 4: Environmental Requirements
Environmental requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of flame retardant substances. -
Page 5: Fcc Declaration Of Conformity
To meet the FCC requirements, you should use a signal cable with ferrite core at both ends. CAUTION Changes or modifications not expressly approved by iiyama could void the users authority to operate the device under FCC compliance regulations. CANADIAN DEPARTMENT OF COMMUNICATIONS COMPLIANCE... -
Page 6: Table Of Contents
TABLE OF CONTENTS FOR YOUR SAFETY ................1 SAFETY PRECAUTIONS ..............1 SPECIAL NOTES ON LCD MONITORS ..........3 CUSTOMER SERVICE ..............3 CLEANING ..................3 BEFORE YOU OPERATE THE MONITOR ..........4 FEATURES ..................4 CHECKING THE CONTENTS OF THE PACKAGE ......4 OPTIONAL PARTS ................ -
Page 7: For Your Safety
STOP OPERATING THE MONITOR WHEN YOU SENSE TROUBLE If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the monitor and contact your dealer or iiyama service center immediately. Further use may be dangerous and can cause fire or electric shock. -
Page 8: Installation Location
CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fire, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located. -
Page 9: Special Notes On Lcd Monitors
Power Switch for hours. Contact your dealer or iiyama service center for the backlight replacement when the screen is dark, flickering or not lighting up. Never attempt to replace it by yourself. -
Page 10: Before You Operate The Monitor
BEFORE YOU OPERATE THE MONITOR FEATURES 51cm (20.1") TFT Color LCD Monitor Supports Resolutions up to 1600 × 1200 High Contrast 400:1 / High Brightness 250cd/m /Quick Response Time 16ms 17.8mm Narrow Bezel & Slim Design Multi-Color Control Supports sRGB International Standard Gamma Control Clear Display for Moving Pictures &... -
Page 11: Checking The Contents Of The Package
Optional parts as below are available for your LCD monitor. Please contact your local iiyama dealer or regional iiyama office for more details. The Protection Sheet may be attached to the LCD panel surface to protect it from stains or scratches. -
Page 12: Controls And Connectors
CONTROLS AND CONNECTORS <Front> <Back> A Power Switch / Power Indicator (POWER) Green: Normal operation (ProLite E511S) NOTE Blue: Normal operation (ProLite E511S-B / ProLite E511S-S) Orange: Power Management The monitor enters into power management mode which reduces the power consumption to less than 5W when receiving no horizontal and/or vertical sync signal. -
Page 13: Connecting Your Monitor
The cable supplied with the monitor is for a standard 15 pin D-Sub connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office. For connection to Macintosh computers, contact your local iiyama dealer or regional iiyama office for a suitable adaptor. -
Page 14: Computer Setting
Change to the desired signal timing listed on page 24: COMPLIANT TIMING. Windows 95/98/2000/Me/XP Plug & Play The iiyama LCD monitor complies with DDC1/2B of VESA standard. The Plug & Play function runs on Windows 95/98/2000/Me/XP by connecting the monitor to DDC1/2B compliant computer with the Signal Cable supplied. -
Page 15: Adjusting The Viewing Angle
ADJUSTING THE VIEWING ANGLE For optimal viewing it is recommended to look at the full face of the monitor. Hold the stand so that the monitor does not topple when you change the monitor’s angle. You are able to adjust the monitor’s angle up to 26 degrees upward,3 degrees download. -
Page 16: Operating The Monitor
OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 24. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 18 for SCREEN ADJUSTMENTS. -
Page 17: Adjustment Menu Contents
ADJUSTMENT MENU CONTENTS Analog Input Menu : 1 (Analog) Menu:1 1600 × 1200 H: 74.35 KHz V: 59.48 Hz Adjustment Item Problem / Option Button to Press Too dark Brightness * Direct Too bright Too dull Contrast Direct Too intense Clock * To correct flickering text or lines Phase *... - Page 18 Menu : 2 M e n u : 2 (Analog) 1600 × 1200 H: 74.35 KHz V: 59.48 Hz Adjustment Item Problem / Option Button to Press Return to Menu. Auto Set-up * Adjust Clock, Phase, V-Position and H-Position automatically. Direct The Auto Set-up is not performed when the Setting...
- Page 19 Menu : 2 (Analog) Adjustment Item Problem / Option Normal Gamma Mode1 High contrast Dark Mode2 Normal Economy Mode Mode1 Brightness of back-light is reduced. Direct Mode2 Brightness of back-light is reduced more than Mode1. NOTE is displayed while Economy Mode is active. The picture is displayed at the optimum resolution.
- Page 20 Menu : 3 Menu:3 (Analog) 1600 × 1200 H: 74.35 KHz V: 59.48 Hz Adjustment Item Problem / Option Button to Press Too soft Volume Direct Too loud NOTE is displayed while Mute is active. 1 2 3 4 5 OSD Position You can move the OSD display area to any one of the following 5 positions...
-
Page 21: Digital Input
Digital Input Menu : 1 M e n u : 1 (Digital) 1600 × 1200 H: 74.35 KHz V: 59.48 Hz Adjustment Item Problem / Option Button to Press Too dark Brightness * Direct Too bright Too dull Contrast Direct Too intense Cold Bluish white... - Page 22 Menu : 1 (Digital) Adjustment Item Problem / Option Normal Economy Mode Mode1 Brightness of back-light is reduced. Direct Mode2 Brightness of back-light is reduced more than Mode1. NOTE is displayed while Economy Mode is active. The picture is displayed at the optimum resolution. Full Screen Stretch the picture and keep the screen size ratio.
-
Page 23: Menu 2 Digital
Menu : 2 M e n u : 2 (Digital) 1600 × 1200 H: 74.35 KHz V: 59.48 Hz Adjustment Item Problem / Option Button to Press Too soft Volume Direct Too loud NOTE is displayed while Mute is active. 1 2 3 4 5 OSD Position You can move the OSD display area... -
Page 24: Screen Adjustments
SCREEN ADJUSTMENTS Adjust the image by following the procedure below to get the desired picture when selecting Analog input. The screen adjustments described in this manual are designed to set image position and minimize flicker or blur for the particular computer in use. The monitor is designed to provide the best performance at resolution of 1600 ×... - Page 25 Press the Auto Button (Auto Set-up) C C C C C D D D D D Adjust the image manually by following procedure below when the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Set-up.
-
Page 26: Power Management Feature
H H H H H Select “Brightness” in the Adjustment Program and adjust the Brightness and Contrast so that all 16 levels of gray in the grayscale pattern are visible. Click on “FINISH” to close the Adjustment Program. POWER MANAGEMENT FEATURE The power management feature of this product complies with every power saving requirement of ®... -
Page 27: Trouble Shooting
2. Consult the following items if you cannot find an appropriate adjustment item in OPERATING THE MONITOR or if the problem persists. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem... - Page 28 Problem Check No sound. The audio equipment (computer etc.) is ON. The Audio Cable is properly connected. The Volume is turned up. The Mute is OFF. The audio output level of the audio equipment is within the specification of the monitor. The sound is too The audio output level of the audio equipment is within the specification of the monitor.
-
Page 29: Appendix
APPENDIX SPECIFICATIONS LCD Panel Driving system a-Si TFT Active Matrix Size Diagonal: 51cm / 20.1" Pixel pitch 0.255mm H × 0.255mm V Brightness 250cd/m (Typical) Contrast ratio 400 : 1 (Typical) Viewable angle Right / Left / Up / Down: 88 degrees each (Typical) Response time 16ms (Black, white, black) Display Colors... -
Page 30: Dimensions
DIMENSIONS 446mm/17.6" 70mm/2.8" 410.5mm/16.2" COMPLIANT TIMING Vertical Horizontal Video Mode Dot Clock Frequency Frequency 31.469kHz 59.940Hz 25.175MHz 640×480 37.861kHz 72.809Hz 31.500MHz 37.500kHz 75.000Hz 31.500MHz 43.269kHz 85.008Hz 36.000MHz 35.156kHz 56.250Hz 36.000MHz 37.879kHz 40.000MHz 60.317Hz VESA 48.077kHz 72.188Hz 50.000MHz SVGA 800×600 46.875kHz 75.000Hz 49.500MHz 53.674.kHz... -
Page 31: Connector Pin Assignment
CONNECTOR PIN ASSIGNMENT D-Sub mini 15pin Input Signal Input Signal Connector Red video Ground Green video / Sync on green Blue video Reserved port Reserved port Data line (SDA)* Ground H-Sync/HV-Sync Red video ground V-Sync Green video ground Clock line (SCL)* Blue video ground * Compliant to VESA DDC.
