Model 754
INSET LIVE FUEL EFFECT GAS FIRE
Fitted with an
Artura
(GC No. 32-032-59)
We trust that this guide gives
sufficient details to enable this
appliance to be operated and
maintained satisfactorily. However, if
further information is required, our
Baxi Fires Division Technical
Helpline will be pleased to help.
Telephone 08706 061 065 (National
call rates apply in the United
Kingdom).
In the Republic of Ireland
Telephone 0044 8706 061 065.
This guide is intended to help you care
for your Baxi Fires Division gas fire.
Please read thoroughly before using
and keep for future reference.
This guide to be left with the owner
©
Baxi Heating U.K. Limited 2007.
OWNER GUIDE
fascia
5113454/03

Advertisement

loading
Need help?

Need help?

Do you have a question about the 754 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Baxi Fires Division 754

Summary of Contents for Baxi Fires Division 754

  • Page 1 In the Republic of Ireland Telephone 0044 8706 061 065. This guide is intended to help you care for your Baxi Fires Division gas fire. Please read thoroughly before using and keep for future reference. This guide to be left with the owner ©...
  • Page 2 Warning: Any person who does any unauthorised act in relation to a copyright work may be liable to criminal prosecution and civil claims for damages. Baxi Fires Division, Erdington, Birmingham B24 9QP www.firesandstoves.co.uk Because our policy is one of constant development and improvement, details may vary slightly from those given in this publication ©...
  • Page 3 BS EN ISO 9001 quality system accepted by the British Standards Institute. The Highest Standards Baxi Fires Division is a member of the Society of British Gas Industries which works to ensure high standards of safety, quality and performance. Careful Installation Baxi Fires Division is a CORGI registered company.

  • Page 4: Table Of Contents

    OWNER GUIDE LIST OF CONTENTS Section Page SAFETY GAS CONSUMPTION APPLIANCE DIMENSIONS OPERATING YOUR FIRE The Oxysafe flame sensing and flue blockage safety system. To light the fire. Lighting with a taper. To turn off. CLEANING YOUR FIRE Fascia parts. Ceramic fuel effect.

  • Page 5: Safety

    OWNER GUIDE SAFETY IF YOU SMELL GAS DON’T SMOKE. EXTINGUISH ALL NAKED FLAMES. DON’T TURN ELECTRICAL SWITCHES ON OR OFF. TURN OFF THE GAS SUPPLY AT THE METER. OPEN DOORS AND WINDOWS TO GET RID OF THE GAS. IMMEDIATELY CALL THE GAS EMERGENCY SERVICE FROM A NEIGHBOURS PHONE - SEE YOUR LOCAL TELEPHONE DIRECTORY.

  • Page 6: Gas Consumption

    Don’t attempt to clean or service the fire until it has been switched off and allowed to cool completely. GAS CONSUMPTION Model 754 Artura Has a maximum natural gas input of 5.1kW (Gross) Has a maximum natural gas output of 2.6kW Has a minimum natural gas input of 3.0kW (Gross)

  • Page 7: Appliance Dimensions

    OWNER GUIDE APPLIANCE DIMENSIONS Dimension Description (mm) Appliance height Appliance width Appliance depth into room Minimum mandatory clearance to combustible surfaces projecting beyond the front of appliance. Recommended clearance to non-combustible surfaces for access purposes. Figure 1. Appliance dimensions and clearances (Fascia may differ from that shown) ©...

  • Page 8: Operating Your Fire

    OWNER GUIDE OPERATING YOUR FIRE PLEASE NOTE When operating your fire for the first time, some vapours may be given off which may cause a slight odour and could possibly set off any smoke alarms in the immediate vicinity. These vapours are quite normal with new appliances. They are totally harmless and will disappear after a few hours use.

  • Page 9: Lighting With A Taper

    OWNER GUIDE When the pilot is alight and stable, partially depress the knob and turn to “LOW”. The pilot should then light the main burner at its low setting. There may be a delay of up to four seconds between the pilot lighting and ignition of the gas at the main burner.

  • Page 10: To Turn Off.

    OWNER GUIDE To turn off. To turn the main burner off but leave the pilot alight, partially depress the knob and turn to PILOT/IGN. To turn the fire fully off, partially depress the knob and turn to OFF. Wait at least three minutes before relighting. While cooling, the fuel effect may make some crackling noises.

  • Page 11: Burner

    OWNER GUIDE Burner. Remove any deposits of soot or other foreign matter from the solid areas of the burner with a dry soft brush. Be careful not to brush any particles into the open holes. Remove any particles from the holes with a vacuum cleaner fitted with a soft brush attachment. Do not poke wire, etc.

  • Page 12: Servicing

    OWNER GUIDE Servicing. In the United Kingdom servicing can be carried out either by a Baxi Fires Division service engineer or a CORGI registered installer. If you require your fire to be serviced, please contact Baxi Fires Division Service on 08706 090 081 and quote the following details;...
