Mitek Loudespeaker C803AT70 Dimensions

Mitek Corporation

MITEK PART # / DRAWING #
C803AT70
Research & Development
1601 Jack McKay Boulevard

Ennis, TX. 75119

TITLE
SPK 8 IN COAX T7/5W
Fax: (972)875-8416
Phone: (972)875-8413
THIS DRAWING AND DATA EMBODY PROPRIETARY
DESIGNS AND INFORMATION WHICH IS THE
DRAWN BY SCALE
K. WAYMON
CONFIDENTIAL PROPERTY OF MITEK CORPORATION.
NONE OF WHICH SHALL BE COPIED, REPRODUCED,
DISCLOSED TO OTHERS, PROPOSED OR USED IN DATE CHK'D BY
4/11/00
DRAWN
WHOLE OR IN PART, FOR ANY PURPOSE WITHOUT
EXPRESS WRITTEN PERMISSION OF A DULY
ENG. APPROVAL Q.C. APPROVAL
AUTHORIZED AGENT OF MITEK CORPORATION.
B. MARLIN
THIS DRAWING IS SUBJECT TO RECALL BY MITEK
CORPORATION AT ANY TIME. IT IS BEING
ENG. DATE Q.C. DATE
SUBMITTED IN CONFIDENCE AND PATENT RIGHTS
APPROVED APPROVED
ARE RESERVED BY MITEK CORPORATION. 10/17/03
8.07
MAT'L REV ECO#
N/A
A 5495
DRAWN IN
B E4364
SOLIDWORKS
C E4520

SHEET #

1 1
OF
TOLERANCES
FINISH
SCALE : 1:2
UNITS INCH
NONE
.03
X.XX
W. HENDERSON
.015
X.XXX
1
MFG. APPROVAL ANGLUAR
J. ALMAND G. LAW
1/64
FRACTIONAL
.005
HOLES
MFG. DATE SIZE REV
B
APPROVED C
1/13/04 11/14/04
ASME Y14.5M-1994
DESCRIPTION BY DATE
DWG. CREATED KW 4/11/00
MDH 6/20/03
ADDED 419006, MADE SINGLE PART PRINT, DWG# WAS 30-10774
113557 WAS 187489, 112895 WAS 419006 KI 10/17/03
0
LAST USED: RETIRED: None
2.88
APRV.
BM
ITEM NO. QTY. PART NO.
BM
1 1 368081
2 1 366415
3 1 112895
4 1 200297
5 2 113557

NOTES:

1. ROUTE PRIMARY WIRES THRU CORD CLAMP (#3).
5
4
3
2
1
DESCRIPTION
LABEL 3 IN RD BLANK BCKPLT
SPKR ASSY C803A COAX
CLAMP, 1/4 CORD NYLON
TRANS, 70V 5,2,1,.5W 1/2 X 5/8
SCW, # 8 X .375 STABWHHX ZP
