  • Page 1: Table Of Contents

    SPORTSART C520R RECUMBENT BIKE INTRODUCTION IMPORTANT SAFETY PRECAUTIONS Warning... Caution... ASSEMBLING YOUR BIKE Hardware Kit Contents... Assembly - Seat Support Covers... Assembly - Seat Back-Part 1... Assembly - Seat Back-Part 2... Assembly - Seat Back-Part 3... Assembly - Seat Back Adjust Handle... Assembly - Screw Inserts...
  • Page 2 GUIDELINES FOR EXERCISE MAINTENANCE Clearing User Settings... TROUBLESHOOTING Error Messages... INTERNAL SETTINGS Metric/American standard units... Time... Distance... Display Main Program IC Version... WIRING SCHEMATIC...
  • Page 3: Sportsart C520R Recumbent Bike

    SPORTSART C520R RECUMBENT BIKE INTRODUCTION Congratulations on your purchase of one of the finest pieces of exercise equipment on the market today, the SportsArt C520R Recumbent Bike. Constructed of high quality materials and designed for years of trouble-free usage, the C520R is built to become an integral part of your fitness regimen.
  • Page 4: Important Safety Precautions

    IMPORTANT SAFETY PRECAUTIONS Your SportsArt bike was designed and built for optimum safety. However, certain precautions apply whenever you use your bike. Please read the entire manual before assembly and operation. Please read and observe the following safety guidelines: ‧ Keep this owner's manual for future use and reference.
  • Page 5: Caution

    ‧ Do not use accessories that are not specifically recommended by the manufacturer as these might cause injuries or cause the unit to fail. ‧ Allow sufficient space on both sides of the bike for users to mount and to dismount the unit. ‧...
  • Page 6: Assembling Your Cycle

    ASSEMBLING YOUR CYCLE Before assembling your bike, make sure that you have all of the following items. 1. Gas spring 2. Body 3. Hardware kit 4. Pedestal and display 5. Pedestal collar 6. Handlebar 7. Rear foot cover Note: Some screws and washers are secured in the frame. Remove them before trying to assemble the exercise bike.
  • Page 7: Hardware Kit Contents

    Hardware Kit Contents 1. Open double end wrench, 1 pc 2. L-shaped Allen wrench (M5), 1 pc 3. L-shaped Allen wrench (M6), 1 pc 4. L-shaped Allen wrench (M4), 1 pc 5. Screwdriver handle (green), 1 pc 6. Double-ended screwdriver stem, 1 pc 7.
  • Page 8: Assembly - Seat Back-Part 1

    Assembly - Seat Back - Part I Assembly - Seat Back - Part 2 1. Remove the pin and R clip at position A. 2. Insert end B of the gas spring into bracket A. 3. Secure the gas spring with the pin and R clip.
  • Page 9: Assembly - Seat Back-Part 2

    Assembly - Seat Back - Part 3 Assembly - Seat Back Adjust Handle 1. Remove the R clip and gas spring at location C. 2. Lift the seat back to position D. 3. Insert the pin and R clip to secure the seat back.
  • Page 10: Assembly - Screw Inserts

    Assembly - Screw Inserts Assembly - Pedestal 1. Press the screw inserts into the frame. Note: Screw inserts are in the hardware kit. 1. Put the pedestal collar in place. 3. After connecting the data cable, insert the pedestal into the unit frame. Secure screw/washer set B, then secure set A and set C.
  • Page 11: Assembly - Seat/Pedal Proximity

    Assembly - Seat/Pedal Proximity The seat position on C520R can be adjusted to suit people with different leg lengths. The seat position can be altered in two ways: An automatic gas spring moves the seat within a set range; and the placement of the gas spring's connection to the frame changes the range of movement.
  • Page 12: Assembly Seat Pedal Proximity (Continued)

    Assembly Seat Pedal Proximity (Continued) Connection Point Adjustment (Continued) Then, move the shock to the front hole and secure it. Please refer to the instructions and diagrams below. a. Remove the screw and washer. b. Tap out the bushing. c. Move the end of the gas spring to the front hole.
  • Page 13: Assembly Seat Positioning

    Assembly Seat Positioning 1. Locate the handle in position E. Hold up handle F as shown. Do not release the handle. 2. The gas spring will push the seat up so that the handlebar and lower covers can be installed. Release the handle after the seat stops moving.
  • Page 14: Assembly - Handlebar

    Assembly - Handlebar Assembly - Cup Holder 1. Insert the handlebar between the seat back and the gas spring as indicated below. Note: You cannot slide the handlebar in straight. You must tilt and move it to fit it in. 2.
  • Page 15: Assembly - Rear Foot Cover

    Assembly - Rear Foot Cover Assembly - Horizontal Covers 1. Put the rear foot cover in place. 2. Loosely secure each screw. After all screws are in place, tighten them down. 1. Put left and right horizontal covers in place. 2.
  • Page 16: Assembly - Seat Support Covers

    Assembly - Seat Support Covers Assembly - Seat Bottom 1. Put front and back seat support covers in place. Front- w ith hole Back- N o hole 2. Loosely secure each screw. After all screws are in place, tighten them down. Secure the seat bottom as shown.
  • Page 17: Assembly - Pedals

    Assembly - Pedals Assembly - Levelers Pedals are marked left or right. Put pedals on the appropriate side. The bike's left/right sides are the same as the user's left/right sides. N o t e : t h e l e f t p e d a l s c r e w s i n counterclockwise.
  • Page 18: Seat Angle Adjustment

    Seat Adjustments Up/Down Adjustment Sit on the seat. Pull up lever A. Adjust the seat position until it suits you. (Push against the pedals to move back, or pull the handle to move forward.) Then release the lever. Seat Back Adjustment Sit on the seat.
  • Page 19: Understanding The C520R Display Console Display Illustration

    UNDERSTANDING THE C520R DISPLAY CONSOLE Display Illustration 65% HR Target Dot matrix screen- shows workout profile 80% HR Heart rate Target Active body area Scan indicator Feedback window Program Keys...
  • Page 20: Specifications

    Specifications ˙ WORKOUT LEVEL - Resistance range: 1 ~ 20 ˙ ~ TIME - Time range: 00 99:59; Time setting range: 5:00 ~ 99:00. (After 99:00, 0 appears) ˙ DISTANCE - 0.1-9999 Km/Mile ˙ ~ CALORIES - 0 9999 K-CAL ˙...
  • Page 21 Key Function Overview - CHANGE Press the CHANGE key while exercising to view a different row of workout feedback. Active feedback indicator LEDs light up. Top row: WORKOUT LEVEL, CALORIES, TIME, RPM. Bottom row: DISTANCE, CAL/HR, WATTS, SPEED. In scan mode, feedback LEDs flash, and a different row of feedback information is displayed every six seconds.
  • Page 22: Getting Started

    GETTING STARTED The "startup banner screen" appears on the display after you press the START key or the QUICK START key, or if you start pedaling (over 30 RPM). The startup banner shows the message "SPORTSARTC520." Once the startup banner appears, there are two ways to start your workout.
  • Page 23: Setting Up Personal User Id

    To operate the bike through the START mode and set up a user ID, follow the instructions below. When the start up banner appears, press the START key. The display shows the previously used USER ID and accumulated workout statistics. Every six seconds one of the following boxes appears.
  • Page 24 - 2. Weight The WT indicator flashes. KG or LB lights up. KG indicates metric mode, which has a preset value of 75 KG. LB indicates US mode, which has a preset value of 165 LB. Press Then press the ENTER key to confirm your choice and proceed to the select a workout program.
  • Page 25: Workout Programs

    WORKOUT PROGRAMS Workout programs include TRACK, HILL, RANDOM, INTERVAL, and two cardio programs (WEIGHT LOSS and CARDIO). The ZONE TRAINER program turns any program into a cardio program. TRACK One lap is 400 meters (0.25 mile). The user can manually adjust resistance and stride.
  • Page 26: Zone Trainer

    ˙ The weight loss program maintains a heart rate at 65% of your maximum heart rate. The weight loss conditioning formula is (220 AGE) x 65%. ˙ The cardio conditioning program maintains a heart rate at 80% of your maximum heart rate. The cardio conditioning formula is (220 AGE) x 80%. At any time during a heart rate control program, if the user's heart rate is not detected, the following message appears: "NO HEART RATE READING, PLEASE CHECK TRANSMITTER".
  • Page 27: Cool Down

    COOL DOWN In an exercise program, when the workout time has expired, "ACCU DATA" appears on the display. Accumulated data, including time, distance, calorie expenditure, average heart rate appear. Then "COOL DOWN" appears on the display as the unit enters a two-minute cool down period. When the unit counts down to "0:00", PROGRAM indicators flash, and the "SELECT PROGRAM"...
  • Page 28: Maintenance

    MAINTENANCE The Sports Art C520R requires little maintenance but regular cleaning is recommended to keep your bike at peak performance. Before your workout, use a dry cloth to clean the surface of the display. NOTE: NEVER POUR LIQUIDS ON THE DISPLAY. To clean plastic parts, use a mild detergent, and make sure the unit is completely dry before operating it.
  • Page 29: Troubleshooting Error Messages

    TROUBLESHOOTING Error Messages There are no error messages on this bike. INTERNAL SETTINGS Internal settings determine basic operating conditions, for example, units of measure. To access internal settings, at the startup banner hold the CHANGE key for three seconds. Then follow the steps below to see and change internal settings.
  • Page 30: Distance

    Distance The total accumulated distance appears in the feedback window. The unit of distance is either in miles or kilometers, depending on the speed setting selected previously. Press the ENTER key to confirm your choice and to proceed to the next setting. You may also press the STOP key to leave this setting.
  • Page 31: Wiring Schematic

    Wiring Schematic: Receiver board Battery chargert Generating set An clectromagnet Your Authorized SPORTS ART Distributor C520R CON2 C520R CTL Board CON1 CON3 CON1 Transmit board CON4 CON3 CON2 C520 DRIVER BOARD Speed Sensor Battery...
