- Page 1 CAT5 AV Splitter User Guide Audio & Video Splitter 5UM40066 - V1 8/01...
-
Page 2: Table Of Contents
Table of Contents Introduction The CAT5 AV Splitter Features Overview Installing the AV Splitter system Connecting the Central unit Connecting the remote units Operating the AV Splitter system Adjusting the screen picture The Long Range Remote unit – Adjusting the brightness Adjusting the volume Technical Specifications... -
Page 3: Introduction
I n t r o d u c t i o n Minicom Advanced Systems Ltd (Minicom) is a leading manufacturer of KVM switches for multiple server control. Minicom also manufactures interactive systems for Computer Equipped Learning Environments. It is also the world leader in the development and deployment of cutting edge CAT5 technology. -
Page 4: Features
Features • Pure hardware Plug and Play • Two Remote models to choose from • Compatible with all major brands of Sound cards • Cascadable • Supports high resolution monitors (1280x1024) • Transmits audio and video signals along CAT5 cable •... -
Page 5: Overview
Overview The AV Splitter system consists of: A Central unit – either a 2 or 4 port model Plus the following: • VGA cable • Stereo Plug cable • Power adapter - either 110V or 220V • Power cord Remote or Remote Long Range units Plus the following: •... - Page 6 Monitor Remote unit 9 VAC PICTURE MONITOR TO CENTRAL UNIT Monitor Remote unit 9 VAC PICTURE MONITOR TO CENTRAL UNIT Monitor Remote unit Remote unit 9 VAC PICTURE MONITOR TO CENTRAL UNIT Monitor Remote unit 9 VAC PICTURE MONITOR TO CENTRAL UNIT Figure 1 The AV Splitter system configuration Speakers AUDIO OUT...
-
Page 7: Installing The Av Splitter System
I n s t a l l i n g t h e AV S p l i t t e r s ys t e m Before installing the system do the following: • Place cables away from fluorescent lights, air conditioners, and machines that are likely to generate electrical noise. - Page 8 Connect the following to both models of the Central unit back panel: • Monitor’s cable • VGA cable • CAT5 cables • Speakers (optional) • Stereo Plug cable • Power adapter Figure 3 below illustrates the back panel connections of the 4-port model.
- Page 9 HDD15M to Local Monitor port 9 VAC DIN4M to Power port Power To wall socket adapter Power cord Keyboard Figure 3 The Central unit back panel connections RJ-45M to Remote units 1-4 Monitor CAT5 cables RJ-45M to ports 1-4 TO REMOTE UNIT LOCAL MONITOR VIDEO IN HDD15F to...
-
Page 10: Connecting The Remote Units
Connecting the remote units Connect the following to each remote unit’s back panel: • Monitor’s cable • CAT5 cable • Speakers • Power adapter Figure 4 below illustrates the Remote unit and Remote Long range unit back panel connections. Note! The Remote Long Range unit also has a brightness adjuster (not illustrated in figure 4). - Page 11 9 VAC DIN4M to Power port Power To wall socket adapter Power cord Figure 4 The Remote unit back panel connections Monitor HDD15M to Monitor port PICTURE MONITOR TO CENTRAL UNIT Aux Out plug to Audio Out port RJ-45M to Central unit CAT5 cable RJ-45M to...
-
Page 12: Operating The Av Splitter System
O p e r a t i n g t h e AV S p l i t t e r s ys t e m To prepare the system for operation: Connect the AV Splitter system. Switch on the computer. Switch on the AV Splitter units. -
Page 13: Adjusting The Volume
Adjusting the volume Use the Windows volume control to adjust the volume of all Remote units simultaneously. Or adjust the individual speakers at each remote unit. -
Page 14: Technical Specifications
Te c h n i c a l S p e c i f i c a t i o n s Resolution Dimensions Weight Power supply Operating temperature Storage temperature Screens Up to 1280 x 1024 - 75 Hz Central unit 30mm x 78mm x 224mm Remote unit... - Page 15 Video Signal: Analog Signal Red Green Video Interface Blue 0.7Vp-p/75 Sync: Horizontal: Vertical: Impedance: Horizontal frequency: Vertical frequency: Frequency response V in V out max Ω positive TTL Compatible Sync. positive/negative Sync. positive/negative 75 Ohms 30-100 KHz 43-100 KHz Audio specs 20Hz –...
- Page 16 +1 888 486 2154 Tel: +1 908 486 2100 Fax: +1 908 486 7788 Web site - www.minicom.com German Europe Minicom Advanced Systems GmbH Zurich, Switzerland Tel: +41 1 455 6220 Fax: +41 1 455 6225 Customer service - minicom@minicom.com...
