• Hot! do not touch! the glass and
surfaces of this appliance will be hot
during operation and will retain heat
for a while after shutting off the appli-
ance. severe burns may result.
• carefully supervise children in the
same room as appliance.
• if small children are present in the home, it is
recommended that this appliance be fitted with
a screen door or screen panel kit. see Pages
13 & 14 for ordering information.
WarninG: iF tHe inForMation in tHis ManuaL
is not FoLLoWed eXactLY, a Fire or eXpLo-
sion MaY resuLt causinG propertY daMaGe,
personaL inJurY or Loss oF LiFe.
do not store or use gasoline or other flammable
vapors or liquids in the vicinity of this or any
other appliance.
WHat to do iF You sMeLL Gas:
• do not light any appliance.
• do not touch any electrical switch; do not
use any phone in your building.
• immediately call your gas supplier from a
neighbor's phone. Follow your gas supplier's
instructions.
• if your gas supplier cannot be reached, call
the fire department.
installation and service must be performed by
a qualified installer, service agency or the gas
supplier
.
US
A French manual is available upon request. Order P/N 875,028CF
Ce manuel d'installation est disponible en francais, simplement en
faire la demande. Numéro de la pièce 875,028CF
WarninGs
otL report no. 116-F-31-5
care and operation
instructions
DIRECT VENT MERIT
LMDV-33/35/40 SERIES
direct-Vent Gas FirepLace Heaters
p/n 875,028M
reV. e 02/2008
MODELS
Millivolt Models
LMdVt-3328cnM
LMdV-3530cnM
LMdVt-3328cpM
LMdV-3530cpM
LMdVr-3328cnM
LMdV-4035cnM
LMdVr-3328cpM
LMdV-4035cpM
instaLLer: Leave this manual with the appliance.
consuMer: retain this manual for future reference.
aVertisseMent: assureZ-Vous de Bien
suiVre Les instructions donnÉ dans cette
notice pour rÉduire au MiniMuM Le risQue
d'incendie ou pour ÉViter tout doMMaGe
MatÉrieL, toute BLessure ou La Mort.
pour Votre sÉcuritÉ: ne pas entreposer ni
utiliser d'essence ni d'autre vapeurs ou liquides
inflammables dans le voisinage de cet appareil ou
de tout autre appareil.
pour Votre sÉcuritÉ: Que faire si vous sentez
une odeur de gaz:
• ne pas tenter d'allumer d'appareil.
• ne touchez à aucun interrupteur. ne pas vous
servir des téléphones se trouvant dans le bati-
ment où vous vous trouvez.
• evacuez la piéce, le bâtiment ou la zone.
• appelez immédiatement votre fournisseur de
gaz depuis un voisin. suivez les instructions
du fournisseur.
• si vous ne pouvez rejoindre le fournisseur de
gaz, appelez le service dos incendies.
L'installation et service doit être exécuté par un
qualifié installeur, agence de service ou le fournis-
seur de gaz.
™
Electronic Models
LMdVt-3328cne
LMdVr-3328cne
LMdV-3530cne
LMdV-4035cne
Advertisement
Table of Contents
Related Manuals for Lennox Hearth Products LMDVT-3328CNM
Summary of Contents for Lennox Hearth Products LMDVT-3328CNM
- Page 1 DIRECT VENT MERIT LMDV-33/35/40 SERIES direct-Vent Gas FirepLace Heaters p/n 875,028M reV. e 02/2008 MODELS Millivolt Models LMdVt-3328cnM LMdV-3530cnM LMdVt-3328cpM LMdV-3530cpM LMdVr-3328cnM LMdV-4035cnM LMdVr-3328cpM LMdV-4035cpM instaLLer: Leave this manual with the appliance. consuMer: retain this manual for future reference.
-
Page 2: Table Of Contents
Millivolt models come standard with the manu- ally-modulated gas valve; flame appearance and heat output can be controlled at the gas valve. The BTU Input for millivolt models is shown in Tables 1 & 2: input (Btu) Mannually-Modulated Gas Valves (millivolt models) naturaL Gas Models input rate (Btu/Hr) LMdVt-3328cnM 17,500 high LMdVr-3328cnM 11,700 low 20,000 high LMdV-3530cnM 12,800 low 27,000 high LMdV-4035cnM 18,500 low Table 1 input (Btu) Mannually-Modulated Gas... -
Page 3: Gas Controls/Control Compartment Access
Gas pressure - Tables 4, 5 and 6 show the appliances' gas pressure requirements. inlet Gas supply pressure (all models) Fuel # Minimum Maximum 5.0" Wc 10.5" Wc natural Gas (1.24 kpa) (2.61 kpa) 11.0" Wc 13.0" Wc propane (2.74 kpa) (3.23 kpa) Table 4 Manifold Gas supply pressure (millivolt models) Fuel #... -
Page 4: Variable Flame Adjustment
Millivolt appliances - Appliances with Millivolt systems will be fitted with the gas control valve shown in Figures 4 or 5. electronic appliances - Appliances with electronic systems will be fitted with the electronic valve shown in Figure 3. Millivolt appliances - To light millivolt appli- ances refer to the detailed lighting instructions found on Pages 18 & 19 . Millivolt appliance lighting instructions may also be found on the pull out lighting instruction labels attached to the gas control valve. -
Page 5: Maintenance
3. Keep the lower control compartment clean by vacuuming or brushing at least twice a year. More frequent cleaning may be required due to excessive lint from carpeting, bedding materials, pet hair, etc. it is very important that the control compartments, burners and circulating air passageways of the appliance are kept clean. 4. Always turn off gas to the pilot (millivolt appliances) and let the appliance cool down before cleaning. Before re-lighting, refer to the lighting instructions in this manual. Lighting instructions may also be found on the pull out lighting instruction labels attached to the gas control valve. -
Page 6: Front Glass Enclosure Panel, Removal And Installation
Front Glass enclosure panel, removal and installation WarninG do not operate appliance with the glass front removed, cracked or broken. replacement of the glass should be done by a licensed or qualified service technician. WarninG do not attempt to substitute the materials used on this door, or replace cracked or broken glass with any materials other than... -
Page 7: Install Vermiculite, Volcanic Stone
instaLL VerMicuLite, VoLcanic stone, GLoWinG eMBers and LoGs 1. Remove the front glass enclosure panel (see Removing Glass Enclosure Panels on this page). 2. Carefully remove the old logs, embers volcanic stone and vermiculite from the firebox. Handle logs carefully to prevent breakage. 3. -
Page 8: Log Placement Instructions
ModeL LMdV-3328 & LMdV-3530 Log placement instructions LoG set catalog number * item description Log, rear Log, Left Log, Left center Log, right center Log, right * Item "letters" above correspond to photos install the embers, Vermiculite, Volcanic stone and Logs in the order shown here (1 through 6) and per the instructions on Page 7. - Page 9 ModeL LMdV-4035 Log placement instructions LoG set catalog number H3365 * item description Log, rear Log, Left Log, center Log, center Front Log, right * Item "letters" above correspond to photos install the embers, Vermiculite, Volcanic stone and Logs in the order shown here (1 through 6) and per the instructions on Page 7.
-
Page 10: Burner Flame Adjustments
Burner adJustMents (QuaLiFied tecHnicians onLY) Flame appearance and sooting Proper flame appearance is a flame which is blue at the base and becomes yellowish-orange in the body of the flame. When the appliance is first lit, the entire flame may be blue and will gradually turn yellowish-orange during the first 15 minutes of operation. If after a short period the flame stays lowered blue, or if the flame is orange with evidence of sooting (black tip), the air shutter opening may need to be adjusted. If the air shutter openings closed too far, sooting may develop. Sooting is indicated by black puffs developing at the tips of very long orange flames. Sooting results in black deposits forming on the logs, appliance inside surfaces and on exterior surfaces adjacent to the vent termination. Soot- ing is caused by incomplete combustion in the flames and lack of combustion air entering the air shutter opening. To achieve a warm yellow- ish-orange flame with an orange body that does not soot, the shutter opening must be adjusted between these two extremes. air shutter adjustment Guidelines • If there is smoke or soot present, first check the log set positioning to ensure that the flames are not impinging on any of the logs. -
Page 11: Millivolt Appliance Checkout
caution carbon will be produced if the air shutter is closed too much. any damage due to carboning result- ing from improperly setting the air shutter is not covered under the warranty. Burner air shutter adjustment adjustment set-screw adjustment rod up (Fully open position) Burner tube air shutter... -
Page 12: Wiring Diagrams
WirinG diaGraMs Wiring diagrams are provided here for refer- ence purposes only. This information is also provided on schematics attached directly to the appliance on a pullout panel located within the control compartment. caution Label all wires prior to discon- nection when servicing con- trols. Wiring errors can cause improper and dangerous appli- ance operation. Millivolt Wiring diagram schematic representation only if any of the original wire as supplied must be replaced, it must be replaced with type aWM 105 c - 18 gage wire. -
Page 13: Accessory Components
Cat. Model Ship. Ship. Weight Volumn H3313 LMdVt-3328cnM 95 lb. 13.08 cu. ft. H3314 LMdVt-3328cpM 95 lb. 13.08 cu. ft. H3315 LMdVr-3328cnM 95 lb. 13.08 cu. ft. H3316 LMdVr-3328cpM 95 lb. 13.08 cu. ft. H3317 LMdVt-3328cne 95 lb. - Page 14 accessorY coMponents Barrier screen panel Kit This easy to install optional screen panel installs over the standard glass enclosure panel and provides a bar- rier to prevent direct contact with the hot glass surface. These screen panels cannot be used in conjunction with the arch door kits or door frame kits. screen panel Kits cat. no. Model no. Models Where used LMdVt-3328 98L04 HG33 LMdVr-3328 26M48 HG35M LMdV-3530 26M49 HG40M LMdV-4035 (ref. Form # 750,101M) decorative arch screen panel Kit This easy to install optional screen panel installs over the standard glass enclosure panel and provides a bar- rier to prevent direct contact with the hot glass surface. These screen panels cannot be used in conjunction with the arch door kits or door frame kits.
- Page 15 accessorY coMponents Forced air Blower Kits cat. Model no. description 80L84 FBK-100 Blower, standard (single speed) 80L85 FBK-200 Blower, Variable speed (w/wall-mounted switch) 80L86 FBK-250 Blower, Variable speed (w/unit-mounted switch) 94L89 FBK-100-36 Blower, standard, 36 pack 94L90 FBK-200-36 Blower Kit - Variable speed with Wall switch 36 pack H0543 FBK-250-36...
- Page 16 accessorY coMponents touch-up paint Kit Repair of minor scratches and discoloration of the appliance charcoal painted surfaces may be accom- plished with the touch-up paint kit. touch-up paint Kits (all models) cat. no. Model no. description 90L74 tpK-c touch-up paint (charcoal) (TPK-C ref. Form # 504,216M) Termination Shroud Deluxe Termination Guard Square Termination Guard termination Guard Kits (all models) cat. no. Model no. description H5820 4.5HtsK...
- Page 17 accessorY coMponents tall style View doors - These decorative screen doors are offered in four attractive finishes and fit on the face of the appliance over the glass doorframe to prevent direct contact with the hot glass surface. The screens prevent direct contact with the hot glass surface. These doors replace the bottom louver assembly and cover the control compartment which elongates the appearance of the height of the fireplace face. style View tall arch pane screen door Kits cat# Model description H3525 tapd35c 35”, charcoal H3527 tapd35sp 35”, satin pewter H3529 tapd40c 40”, charcoal...
-
Page 18: For Your Safety Read Before Lighting
LiGHtinG instructions – HoneYWeLL and sit MiLLiVoLt Gas VaLVe WarninG: iF You do not FoLLoW tHese instructions eXactLY, a Fire or eXpLosion MaY resuLt causinG propertY daMaGe, personaL inJurY or Loss oF LiFe. a. This appliance has a pilot which must be lighted with a piezo igniter. When lighting the pilot, follow these instructions exactly. B. BeFore operatinG smell all around the appliance area for gas. Be sure to smell next to the floor because some gas is heavier than air and will settle on the floor. - Page 19 INSTRUCTIONS D’ALLUMAGE – VANNE GAZ MILLIVOLT HONEYWELL ET SIT POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE AVERTISSEMENT : SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS À LA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE. A.
-
Page 20: Lighting Instructions - Electronic
WarninG: iF You do not FoLLoW tHese instructions eXactLY, a Fire or eXpLosion MaY resuLt causinG propertY daMaGe, personaL inJurY or Loss oF LiFe. a. When lighting the appliance, follow these instructions exactly. B. BEFORE OPERATING smell all around the appliance area for gas. Be sure to smell next to the floor because some gas is heavier than air and will settle on the floor. WHat to do iF You sMeLL Gas • Extinguish any open flame. • Open windows. • Do not light any appliance. - Page 21 INSTRUCTIONS D’ALLUMAGE — ELECTRONIC POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE AVERTISSEMENT: SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS À LA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE. A.
-
Page 22: Maintenance Schedule
Maintenance scHeduLe annually (Before the onset of the Burning Season) Maintenance tasK Inspecting/Cleaning Burner, Logs and Controls Check Flame Patterns and Flame Height Inspecting/Cleaning Pilot and Burner Checking Vent System Appliance Checkout Replacing Rockwool Ember Materials periodically (After the Burning Season) Maintenance tasK Cleaning Firebox Interior Check Flame Patterns and Flame Height Checking Vent System Cleaning Front Glass Enclosure Panel accoMpLisHinG person Qualified Service Technician Inspect valve and ensure it is properly operating. Check piping for leaks. Vacuum the control compartment, fireplace logs and burner area. Qualified Service Technician Refer to Figure 10 (LMDV-3328 & LMDV-3530) or Figure 11 (LMDV-4035) on Page 10 and verify the flame pattern and height displayed by the appliance conforms to the picture. Flames must not impinge on the logs. Ensure flames are steady (not... -
Page 23: Troubleshooting Guide - Millivolt
trouBLesHootinG Note: Before troubleshooting the gas control system, Ensure external gas shut off valve, located at gas supply inlet, (and wall switch, iff applicable), is in the “ON” position. Important: Valve system troubleshooting should only be accomplished by a qualified service technician. TROUBLESHOOTING GUIDE - MILLIVOLT GAS CONTROL SYSTEM sYMptoM 1. Spark igniter will not light pilot after... - Page 24 trouBLesHootinG procedure - eLectronic iGnition sYsteM start • turn off Gas supply. • ensure Valve switch is in on position. • disconnect control Harness. • set thermostat to call For Heat. insert a end View of control Harness connector 24 Volt 24 Volt Hot common 24 Volt...
- Page 25 note: tHis paGe intentionaLLY LeFt BLanK. note: diaGraMs & iLLustrations are not to scaLe.
-
Page 26: Replacement Parts List
repLaceMent parts List item # description Hood Louver assembly, top, charcoal *Louver assembly, Bottom, charcoal enclosure, Glass Front (complete) nameplate, Lennox Latch Log set (complete) Burner assembly orifice, Main Burner - natural Gas orifice, Main Burner - propane Gas Bag of Glowing embers (rockwool) Bag of decorative Volcanic stone Bag of Vermiculite Gas Line Flexible connector... -
Page 27: Replacement Parts
repLaceMent parts LMdV-4035 LMdVt-3328 & LMdVr-3530 note: diaGraMs & iLLustrations are not to scaLe. note: tHis paGe intentionaLLY LeFt BLanK. note: diaGraMs & iLLustrations are not to scaLe. - Page 28 Lennox Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult your local distributor for fireplace code information. Printed in U.S.A. © 2005 by LENNOX HEARTH PRODUCTS p/n 875,028M reV. e 02/2008 1110 West Taft Avenue • Orange, CA 92865 note: diaGraMs & iLLustrations are not to scaLe.
