EXAMPLE:
00
Component Parts (Small #) Are Included
0
When Ordering The Assembly (Large #).
FIG.
PART NO.
DESCRIPTION OF PART
1
06-82-9220
Pan Hd. Slt. T-20 PT Screw
2
06-82-9279
Pan Hd. Slt. T-20 PT Screw
3
10-15-0180
Warning Label
4
14-38-0655
Front Housing Assembly
5
14-50-0171
12 Volt Motor Assembly
6
23-66-2310
Switch
7
31-15-0470
Handle Cover
8
31-51-0110
Switch Mount - Left
9
31-51-0120
Switch Mount - Right
10
42-14-0410
Baffle
11
43-62-1110
Reversing Shuttle
12
---------------
12 Volt Battery - Select From Catalog (1)
13
45-06-0640
Seal
14
42-06-0130
Anvil Assembly
15
48-03-3630
Drive Adapter
16
02-04-1510
Ball Bearing
17
38-50-0030
Ram Spindle
18
02-02-1205
7/32" Steel Ball
19
45-88-0110
Washer
20
40-50-0140
Spring
21
02-80-0140
Thrust Bearing
22
44-82-0060
Ram
SERVICE PARTS LIST
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
CORDLESS 12 VOLT IMPACT DRIVER
9057-1
CATALOG NO.
NO.REQ.
STARTING
SERIAL NO.
FIG.
PART NO.
23
32-62-0060
(2)
24
06-65-0040
(2)
25
34-40-4420
(1)
(1)
26
45-88-8705
(1)
27
43-34-0750
(1)
28
34-40-0210
29
34-60-0620
(1)
12-20-1165
(1)
10-15-1130
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(2)
(1)
(1)
(1)
13135 W. LISBON RD., BROOKFIELD, WI 53005
(1)
BULLETIN NO.
54-26-1650
REVISED BULLETIN
WIRING INSTRUCTION
854A
58-01-1615
DESCRIPTION OF PART
Planet Gear
Pin
O-Ring
Washer
Spring Flange
O-Ring
Retaining Ring
Service Nameplate Kit
Logo Label
MILWAUKEE ELECTRIC TOOL CORPORATION
DATE
Feb. 2003
NO.REQ.
(3)
(3)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
Drwg. 1
