Dynabrade 52224 Important Operating, Maintenance And Safety Instructions

Model:
52224 – 6mm Collet, 15,000 RPM
52225 – 6mm Collet, 18,000 RPM
52226 – 6mm Collet, 20,000 RPM
52227 – 6mm Collet, 20,000 RPM*
52288 – 1/4" Collet, 15,000 RPM
52289 – 1/4" Collet, 18,000 RPM
52290 – 1/4" Collet, 20,000 RPM
52291 – 1/4" Collet, 20,000 RPM*
(*Includes 53163 Side Handle)
WARNING
!
1 T 2
34 N•m
Index Key
No. Part # Description
1 Collet Assembly
50010 1/4"
50015 6mm
2 Exhaust Cover
01734 15,000 RPM
01738 18,000 RPM
01748 20,000 RPM
3 01744 Silencer
4 01007 Bearing
5 01121 Shim (3/pkg.)
6 01008 Plate
7 50767 Guide Pin (2)
8 01010 Spacer
9 01028 Cylinder
10 55021 Rotor
11 01185 Blade (4/Pkg.)
12 01743 Bearing Plate
13 02649 Bearing
14 01739 Motor Housing
15 01437 Plug
16 01548 Gasket
17 01461 Lock Nut
18 01558 Collar
19 01448 Throttle Lever
01462 Safety Throttle Lever
20 12132 Pin
21 95558 Retaining Ring
22 Housing (See Chart)
23 01449 Valve Stem
24 95730 O-Ring
25 01024 O-Ring
26 01469 Speed Regulator Assy.
27 01464 Seal
28 01472 Tip Valve
29 01468 Spring
30 01494 Inlet Bushing
31 50033 Hanger
See inside for Important Operating, Maintenance and Safety Instructions.
.7Hp/7˚/Short Shank/Front Exhaust
Always operate, inspect and maintain this tool in accordance with the Safety Code for portable air tools
(ANSI B186.1) and any other applicable safety codes and regulations. Please refer to Dynabrade's
Warning/Safety Operating Instructions for more complete safety information.
3 4 5 6 8
7
O
Oil: O
A Adhesive: A
Torque: N•m x 8.85 = In. - lbs.
T
A 22
8
Right Hand Threads
Valve Body
01622 – Model 52224
01623 – Model 52225
01624 – Model 52226
01625 – Model 52227
02139 – Model 52288
02140 – Model 52289
02141 – Model 52290
02141 – Model 52291
9 10
O
11
1
KEY
= Air Lube
1
= Loctite #567
8
19
21
27
23
24
25
26
Parts Page Reorder No. PD02•19
Effective April, 2002
Supersedes PD96•72
Die Grinder
Machine and Motor Parts
12 13 14
A
7
8
Left Hand Threads
T
45 N•m
T
23 N•m
20
A
O
8 1
28 29 30
31
15
16
17
18
