TITLE
MILWAUKEE ELECTRIC TOOL CORP.
Wire
Wire
Origin or
No.
Gauge
Color
1
Blue
Cord
2
Brown
Cord
3
White
Field
4
Black
Field
5
White
Field
6
White
Field
Green/Yellow
7
Cord
WIRING INSTRUCTIONS
DYMODRILL and SWITCH BOX
13135 WEST LISBON RD. BROOKFIELD, WIS.
WIRING SPECIFICATIONS
Length
Terminals, Connectors and 1 or 2 End Wire Preparation
70mm
As received, apply with #8.
70mm
As received, apply with #9.
-----
As received.
-----
As received.
-----
Strip 5mm for T1.
-----
Strip 5mm for T1.
-----
Strip 5mm for T1.
BULLETIN
58-03-0020
DATE
Feb. 2011
NOTE:
All leads must be held to ± 1/8".
All lead lengths are before stripping.
TERMINAL DESCRIPTION
Code
Part No.
T1
23-74-0840
CONNECTOR DESCRIPTION
Qnty.
3
Drwg. 2
