Econotig
Light Industrial Applications
Farm
Ranch
Hobby
Quick
Specs
The Power of Blue
Upgraded circuitry gives you finer TIG output
adjustment with the remote foot or fingertip
control. If you need more output while using
the remote control, simply increase the
setting of the front panel amperage control.
AC output for superior aluminum welding
and DC output for mild and stainless steel.
Four-position polarity
and range selector
switch offers two AC
current ranges, DC
electrode (–) for TIG,
and DC electrode (+)
for Stick.
Special arc starting
circuitry eliminates
high- frequency starts.
Built-in arc assist starter
for DC TIG.
Built-in arc assist stabilizer
for AC TIG on aluminum.
Process switch automatically
sets machine for TIG or Stick.
Unique "flow-through" shielding
gas TIG torch connection allows
removal of torch without tools.
®
Processes
TIG (GTAW)
Stick (SMAW)
Input Power
1-Phase Power
.
®
Complete
Package!
Power source is warranted for 3 years, parts and labor.
Original main power rectified parts are warranted for 5 years.
Miller Electric Mfg. Co.
An Illinois Tool Works Company
1635 West Spencer Street
Appleton, WI 54914 USA
Rated Output at 20% Duty Cycle
TIG: 150 A at 15 VDC, 150 A at 15 VAC
Stick: 130 A at 25 VDC, 150 A at 25 VAC
Amperage Range
TIG: 50 –165
Stick: 35 –165
Max. Open-Circuit Voltage
Weight
140 lb (64 kg)
Just supply Argon gas,
stick electrodes, filler rod,
gloves and helmet and
you are ready to weld!
International Headquarters
Phone: 920-735-4505
USA FAX: 920-735-4134
Canadian FAX: 920-735-4169
International FAX: 920-735-4125
Issued April 2003 • Index No. AD/1.2
Arc Welding
Power Source
AC High
AC Low
DC
20–50
30–160
20–50
25–130
78
Comes Complete With:
Power source with primary cord
(plug provided on 230 V model)
DB1712RDI TIG torch with backcap,
ceramic gas cup, 3/32 in (2.4 mm)
collet and collet body, and 2%
thoriated tungsten
International-style quick-connect torch
12 ft (3.7 m) work cable and clamp
Stick electrode holder with 15 ft
(4.6 m) cable
RFCS-14 foot-operated remote
control with 20 ft (6 m) cord
Gas regulator, flowmeter and
12-1/2 ft (3.8 m) shielding gas hose
"How-To" DVD (in English and
Spanish)
Preset automatic postflow timer protects
tungsten tip, workpiece and torch.
Automatic high temperature shutdown.
Web Site
www.MillerWelds.com
