- Page 1 Door Access Control with the VoIP interface NISTA DEVICES GmbH 2013 © All Rights Reserved Release 1.4...
- Page 2 NISTA DEVICES GmbH 2013 © All Rights Reserved IP Door Phones IP39-4X Quick Installation Guide Document Release: 1.04 Release Date: 18-Jun-15...
- Page 3 Nista Devices GmbH is strictly prohibited. Nista Devices GmbH reserves the right to modify the hardware and software described herein without prior notice. However, changes made to the hardware or software described do not necessarily render this publication invalid.
-
Page 4: Table Of Contents
NISTA DEVICES GmbH 2013 © All Rights Reserved Table of Contents Introduction ................................5 List of Available Models ............................ 5 The IP Door Phone kit contents ..........................5 Installation .................................. 6 Physical installation ............................6 IP Door Phone installation ..........................6 Access to WEB Programming ........................... -
Page 5: Introduction
NISTA DEVICES GmbH 2013 © All Rights Reserved 1 Introduction To avoid damage to the Door Phone, the external power supply and POE Ethernet connection should be disconnected from mains prior to connecting wires to the Door Phone unit. The External Power Supply does not included in standard IP394X... -
Page 6: Installation
NISTA DEVICES GmbH 2013 © All Rights Reserved 3 Installation 3.1 Physical installation The Door phone can be mounted on the wall by using installation bracket provided with the unit. To install the IP Door Phone Unit on the wall: Open the IP Door Phone case by rotating the secret screw from the bottom side of the unit. - Page 7 NISTA DEVICES GmbH 2013 © All Rights Reserved The wiring connector has screw connector type terminals. In order to attach a wire, you must insert the stripped end of the wire into the appropriate wiring connector socket and tighten the terminal screw. This will bring together the wire connection.
- Page 8 NISTA DEVICES GmbH 2013 © All Rights Reserved 5. Attach the Door phone into the installation bracket. 6. Check the LAN network cable is inserted into the ‘Ethernet’ RJ-45 socket and that if PoE is deployed the unit powers up.
-
Page 9: Access To Web Programming
NISTA DEVICES GmbH 2013 © All Rights Reserved Connector’s PINs Description Door status detector. SEN 1/2 (Sensor 1/2*) Also can be used as external Switch button connection (Chapter Error! eference source not found.). Note: The short circuit closer type External... - Page 10 NISTA DEVICES GmbH 2013 © All Rights Reserved Go to Control Panel Open ‘Network and Sharing Center’ Click on ‘Change adapter settings’ Mouse right click on active Ethernet connection and chose ‘Properties’...
- Page 11 NISTA DEVICES GmbH 2013 © All Rights Reserved In LAN properties window select ‘Internet Protocol Version 4 (TCP/IPv4) option and click on ‘Properties’ button Select 'Use the following IP address:' and insert IP Address and Subnet mask as shown on the...
- Page 12 NISTA DEVICES GmbH 2013 © All Rights Reserved Press ‘OK’ to accept settings Launch Internet browser and type 10.10.10.6 in address bar. 4. Log in to the Nista web GUI using the appropriate user’s credentials IP 394X provides different management levels for WEB-Management: Administrator and User ...
- Page 13 NISTA DEVICES GmbH 2013 © All Rights Reserved Note: 1. The default IP Door Phone IP address is 10.10.10.6 and it is configured as ‘Static’ IP Address. 2. The default web-programming Administrator credentials are: User name: ‘admin’ – For Administrator management level and ‘user’ – for User management level ...
- Page 14 NISTA DEVICES GmbH 2013 © All Rights Reserved Configure the rest of parameters by using the IP Door Phone User’s manual document...
-
Page 15: Reset Device To Factory Default Configuration
NISTA DEVICES GmbH 2013 © All Rights Reserved 5 Reset device to Factory Default Configuration IP Door phone can be reset to its Factory default configuration by using following actions: 1. Via WEB-Management interface ( See Chapter 7.8 in User Manual document) 2.
