MSL-10A
The Meyer Sound MSL-10A is an
extremely high-power, high-performance
loudspeaker system designed for large-scale
music reinforcement and public address
applications.
The MSL-10A System comprises an all-
horn, integral full-range loudspeaker
cabinet constructed as a 30-degree
arrayable section, and a 19" electronics
rack (on wheels) housing the M-10A
Control Electronics Unit, three MS 10
Power Amplifiers and an Interface Unit.
High Power
Loudspeaker
System
The minimum standard MSL-10A
configuration comprises two loudspeaker
cabinets, each with its own electronics
rack. Additional MSL-10A cabinets may be
employed as modular 30-degree building
blocks to increase the coverage and
acoustical power of the system, providing
extensive flexibility to meet specific
application requirements.
Features
Extremely High Power
Exceptional Clarity
Point Source Arraying
Weatherproof Hardware
Long-Term Reliability
Applications
Paging and Announcing
Outdoor Sports Arenas
Stadiums
Racetracks
Large-Scale Touring
Concert Reinforcement
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Meyer Sound Loudspeaker MSL-10A
Summary of Contents for Meyer Sound Loudspeaker MSL-10A
- Page 1 MSL-10A The Meyer Sound MSL-10A is an extremely high-power, high-performance loudspeaker system designed for large-scale music reinforcement and public address applications. The MSL-10A System comprises an all- horn, integral full-range loudspeaker cabinet constructed as a 30-degree arrayable section, and a 19" electronics...
- Page 2 MSL-10A Loudspeaker Fork lift brackets (top & bottom) High frequency horns Low frequency horns Reflex port and enclosure ventilation High frequency driver service access Speaker connector Serial number plate Low frequency driver service access Front View Rigging points Hatch handle Environmental power indicator Environmental power...
- Page 3 The MSL-10A Loudspeaker cabinet is fortified for long-term reliability in outdoor installations, and is thoroughly inspected at several stages during assembly. Con- structed of high-grade Finnish birch hardwood, the enclosure is resin-impreg- nated in critical areas, bonded with structural epoxy adhesive, and coated with a finish that tolerates cabinet swelling without cracking.
- Page 4 Arraying and Rigging The MSL-10A loudspeaker is designed to function as a modular building block capable of being arrayed in multiples to satisfy a wide range of acoustical power and coverage requirements. Configured as a tightly controlled 30-degree section, the MSL-10A cabinet features a trapezoidal con- struction which forms curved arrays.
- Page 5 Long-Throw Arrays To increase the effective throw of the system, MSL-10A cabinets may be arrayed one atop another with high horns together, as shown in the illustration at the right. Spacer/ Spacer/ Hanger Use of Spacer/Hanger Bar to Couple Cabinets Vertically 113"...
- Page 6 • Modular amplifier rack includes control electron- ics, amplifiers and interconnection panel for easy interface with speaker system • Input/Output unit provides power switch and circuit breaker for entire system; protection and power distribution to the CEU, amplifiers, and loud- speaker;...
- Page 7 M-10A Control Electronics Unit Input Type Output Type Maximum Input/Output Level Unbalanced Balanced Hum and Noise Dynamic Range Electronic Crossover Frequency Driver Protection Circuits Low Frequency High Frequency Indicators Controls Connectors Input Loop Out Hi and Lo Output Sense AC Interfacing and Protection The MSL-10A Rack System requires a single-phase AC voltage source wired between the øX and øY terminals of the...
- Page 8 Meyer Sound Laboratories has devoted itself to designing, manufacturing, and refining com- ponents that deliver superb sonic reproduction. Every part of every component is designed and built to exacting specifications and undergoes rigorous, comprehensive testing in the laboratories. Research remains an integral, driving force behind all production.
