MJF-212A : High-Power Stage Monitor
The Meyer Sound MJF-212A is a self-
powered stage monitor
designed to meet critical requirements
in professional applications. Exhibiting
flat amplitude and phase responses, full-
range bandwidth, and exceptional impulse
response, the MJF-212A far exceeds the
capabilities of conventional stage monitors
while offering the simplicity of setup and
operation provided by
systems.
The MJF-212A monitor's phase-corrected
frequency range of 55 Hz to 18 kHz
enables accurate reproduction of both
vocals and instruments with high gain
before feedback, and provides excellent
intelligibility at high output levels with low
distortion and no coloration added to the
signal. The MJF-212A is also engineered
to have exceptional
headroom, which can be helpful in some
features & benefits
High peak power ensures excellent
transient response
Flat frequency and phase responses
afford high levels of gain before
feedback
applications such as the extreme low-
loudspeaker frequency demands of high-level drum
monitoring. The face of the low-profile
cabinet slopes at 40 degrees from the stage
to permit optimal placement relative to the
talent, while its medium-Q horn provides
even coverage in both the horizontal and
vertical planes.
self-powered
The loudspeaker's high-frequency section
comprises a 4-inch diaphragm compression
driver coupled to a symmetrical (50 degrees
horizontal by 50 degrees vertical) constant
directivity horn. A pair of high-power
12-inch neodymium magnet cone drivers
with 4-inch voice coils, mounted in an
optimally vented enclosure, reproduces
low frequencies.
Each driver is powered by one channel of
low-frequency
a three-channel class AB/H amplifier that
employs complementary power MOSFET
Low profile preserves sightlines
Symmetrical, medium-Q pattern
provides even coverage
Dimensions 27.07" w x 16.11" h x 23.00" d
(688 mm x 409 mm x 584 mm)
Weight 108 lbs (49 kg)
Enclosure Premium birch plywood
Finish Black textured
Powder-coated hex-stamped steel,
Protective Grille
black mesh screen
Female XLR input with male XLR loop output or
Audio Input
VEAM all-in-one connector
PowerCon
AC Power Connector
all-in-one connector
output stages to provide total burst output
of 1275 watts (2 x 500 watts, 1 x 275 watts),
2550 watts total peak. The MJF-212A
incorporates Meyer Sound's Intelligent AC™
system for automatic voltage selection, EMI
filtering, soft current turn-on, and surge
suppression.
The cabinet is constructed from premium
birch plywood and coated with a durable,
textured black finish. A metal grille lined with
acoustical black mesh protects the drivers.
The rugged MJF-212A includes plastic skids
on the bottom of the unit to prevent damage
to the enclosure or stage floor.
The MJF-212A can be integrated into Meyer
Sound's RMS™ remote monitoring system
with the addition of an optional module.
RMS is a Windows-based computer applica-
tion for monitoring the full range of ampli-
fier and limiter operating parameters.
applications
Main vocal monitor
High-output drum or keyboard monitor
Sidefill monitor for small- to medium-scale
applications
UL T R A S E R IE S
with looping output or VEAM
®
