Location Of Controls And Components; Board Location - Haier Dx-Ltdvd19-09 Service Manual

a. When the power supply cord or plug is damaged or frayed.
b. If liquid has been spilled, or objects have been fallen into the unit.
c. If the unit has been exposed to rain or water.
d. If the unit does not operate normally by following the operating instructions. Adjust only those
controls that are covered by the operating instructions, as improper adjustment of other controls
may result in damage and will often require extensive work by a qualified technician to restore
the unit to its normal operation.
e. If the unit has been dropped or damaged in any way.
f. When the unit exhibits a distinct change in performance; this indicates a need for service.
15) Heat --- The product should be situated away heat source such as radiators, heat registers,
stoves, or other products (Including amplifiers) that product heat.
16) Overloading ---Do not overload wall outlets and extension cord as this can result in a risk of fire
or electric shock.

3. LOCATION OF CONTROLS AND COMPONENTS

3.1. Board Location

No. Parts number
A Board
B Board
C Board
Description
Power Board
6
