Meyer Sound High-Power Loudspeaker MSL-2A Specification Sheet

MSL-2A
The MSL-2A is a high-powered, wide-
coverage loudspeaker for professional
sound reinforcement applications. Specifi-
cally designed for touring reinforcement,
the accurate, rugged MSL-2A is a biampli-
fied system consisting of a proprietary 15-
inch low-frequency driver in a vented en-
closure, and a 70-degree high-frequency
horn with 2-inch (throat diameter) driver.
The MSL-2A's drivers provide excep-
tional efficiency and power handling, with
low distortion for maximum clarity.
High Power
Loudspeaker
— 12
–
–
— 9
–
–
— 6
–
–
— 3
–
–
— 0
Inches
The sturdy, multi-ply hardwood enclo-
sure with textured finish is designed to
withstand road abuse. The MSL-2A comes
with handles and, optionally, aircraft-style
rigging pan fittings or nut plates.
The MSL-2A requires a high-quality
professional stereo power amplifier capable
of delivering up to 600 watts per channel
continuously into 8 ohms, with a signal
voltage gain of 10dB (minimum) to 32dB
(maximum).
Features
Efficient high power
Arrayable
Wide horizontal coverage
Flat frequency response
Rugged and reliable
Applications
Touring reinforcement
Live music clubs
Theatre PA systems
Side fill in concert reinforcement
High powered announcing
Music playback in discos
Meyer Sound Laboratories, Inc.
2832 San Pablo Avenue
Berkeley, CA 94702
(510) 486-1166
FAX (510) 486-8356
