Metrologic FocusBT MS1633 Specification Sheet

FocusBT is the hand-held area
®
imager that surpasses all wireless
2D scanners by combining Bluetooth
connectivity with aggressive
FirstFlash scan performance.
®
Perfect for solving retail and supply-chain
management applications, this omnidirectional
scanner combines the freedom of Bluetooth
V1.2 mobility with many qualities already found
in the popular Focus MS1690.
Regardless of orientation, FocusBT's FirstFlash
technology decodes all standard bar codes in
a single flash, including 1D, 2D, GSI DataBar
PDF417, microPDF, EAN/UCC Composite,
Matrix and Postal Codes.
FocusBT features Metrologic's patented Code-
Gate and RangeGate technology. CodeGate
® ®
technology zeros in on the required code and
Features
• FirstFlash
• Omnidirectional scanning
• Removable Li-ion battery pack
• USB Bluetooth dongle
• PowerSave modes/Power switch
then completes data transmission with the push
of a button.
®
With RangeGate, FocusBT scans and stores
hundreds of bar codes when outside host
system communication range. When the con-
nection is re-established, the stored scans are
automatically downloaded to the host.
For image-capture applications, FocusBT
combines a high-resolution CMOS sensor with
a powerful processor which enables a wide
array of outputs.
In addition to automatic infrared object detec-
tion, FocusBT comes equipped with several
,
TM
power-save modes, a USB Bluetooth dongle
and two rechargeable lithium-ion batteries.
Each battery provides 12 hours of scanning or
approximately 9,000 scans per charge.
www.metrologic.com/MS1633
Benefits
Increases productivity by scanning nearly every standard bar code on
first LED flash
Eliminates need to orientate imager to bar code
Easily remove and replace battery packs without using tools
Cable-free dongle simultaneously enables Bluetooth compatibility for host
system and up to 7 other Bluetooth devices
Both conserve battery life and extend uptime
FocusBT
MS1633
®
