INSTALLATION INSTRUCTIONS FOR PART 99-9302
APPLICATIONS
BMW
Mini Cooper/Cooper S 2002-2007
99-9302
KIT FEATURES
• Mounting bracket
KIT COMPONENTS
A) Mounting Bracket
A
TOOLS REQUIRED:
Small Flat Blade Screwdriver/ Panel Removal Tool
• Phillips Screwdriver • T-33 Torx Driver
1-800-221-0932
www.metraonline.com
© COPYRIGHT 2004-07 METRA ELECTRONICS CORPORATION
Advertisement
Related Manuals for Metra Electronics 99-9302
Summary of Contents for Metra Electronics 99-9302
- Page 1 INSTALLATION INSTRUCTIONS FOR PART 99-9302 APPLICATIONS Mini Cooper/Cooper S 2002-2007 99-9302 KIT FEATURES • Mounting bracket KIT COMPONENTS A) Mounting Bracket TOOLS REQUIRED: Small Flat Blade Screwdriver/ Panel Removal Tool • Phillips Screwdriver • T-33 Torx Driver 1-800-221-0932 www.metraonline.com © COPYRIGHT 2004-07 METRA ELECTRONICS CORPORATION...
