Metra Electronics LC-GMRC-LAN-01 Installation Instructions

LC-GMRC-LAN-01
* IMPORTANT WARNING
THIS PRODUCT INCLUDES INSTRUCTIONS FOR INSTALLATION WHICH
MUST BE CAREFULLY FOLLOWED. THE INSTRUCTIONS ARE WORDED
IN SUCH A MANNER TO ASSUME THAT THE INSTALLER IS CAPABLE
OF COMPLETING THESE TYPE OF ELECTRONIC INSTALLATIONS.
IF YOU ARE UNCLEAR AS TO WHAT YOU ARE INSTRUCTED TO DO OR
BELIEVE THAT YOU DO NOT UNDERSTAND THE INSTRUCTIONS SO AS TO
PROPERLY AND SAFELY COMPLETE THE INSTALLATION YOU SHOULD
CONSULT A TECHNICIAN WHO DOES HAVE THIS KNOWLEDGE AND
UNDERSTANDING. FAILURE TO FOLLOW THESE INSTRUCTIONS
CAREFULLY AND TO INSTALL THE INTERFACE AS DESCRIBED COULD
CAUSE HARM TO THE VEHICLE OR TO SAFETY SYSTEMS ON THE
VEHICLE. INTERFERENCE WITH CERTAIN SAFETY SYSTEMS COULD
CAUSE HARM TO PERSONS AS WELL. IF YOU HAVE ANY QUESTIONS
IN THIS REGARD PLEASE CALL THE HELP LINE OR THE METRA AT
1-800-221-0932 FOR ASSISTANCE.
1
LC-GMRC-LAN-01
5
Rev. 02-03-09
1-800-221-0932 www.axxessinterface.com
©Copyright 2009 Metra Electronics Corporation
GM LAN DATA BUS INTERFACE
LC-GMRC-LAN-01
* READ IMPORTANT WARNING ON PAGE 1
BEFORE ATTEMPTING ANY INSTALLATION
The LC-GMRC-LAN-01 is designed to be used in non-
amplified GM vehicles or in vehicles that the OEM
amplifier has been bypassed; Onstar is not retained in
either case. The LC-GMRC-LAN-01 retains all the facto-
ry warning chimes that would be lost when the OEM
radio is removed. It will also provide a 3 amp 12 volt
switched accessory for proper radio operation, and
retain the R.A.P. (Retained Accessory Power) feature if
equipped.
SEE INSIDE FOR APPLICATIONS
INTERFACE COMPONENTS
INSTLC-GMRC-LAN-01
1-800-221-0932
©Copyright 2009 Metra Electronics Corporation
INSTALLATION
INSTRUCTIONS
• Interface
• Harness
www.axxessinterface.com
