INSTALLATION INSTRUCTIONS FOR PART 95-7953
APPLICATIONS
Suzuki Grand Vitara
2006-2010
95-7953
B
C
A
WIRING AND ANTENNA CONNECTIONS (Sold Separately)
Wiring Harness:
• 70-1721 - Honda/Acura harness 1998-up
Antenna Adapter:
• Not required
www.metraonline.com
1-800-221-0932
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
