INSTALLATION INSTRUCTIONS FOR PART 99-5719
METRA. THE WORLD'S BEST KITS.™
1-800-221-0932
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
metraonline.com
INSTALLATION INSTRUCTIONS FOR PART 99-5719
APPLICATIONS
FORD TAURUS
2004 - 2007
99-5719
KIT FEATURES
• ISO & DIN Head Unit Provision w/ Pocket
• DDIN Head unit provisions
• Integrated auto climate controls and display
• Integrated passenger airbag light
• Painted Scratch Resistant Matte Black
KIT COMPONENTS
• A) Radio Housing • B) ISO Brackets • C) ISO Trim Plate • D) Pocket
• E) DDIN Brackets • F) DDIN Trim Plate • G) In-Car Temp Sensor Housing • H) Harness Extension
B
C
A
F
TOOLS REQUIRED
• Radio Removal Tool (Metra Part #86-5618) • Phillips Screwdriver
• Panel Removal Tool • Socket Set • Cutting Tool or File • T10 Torx Screwdirver
METRA. THE WORLD'S BEST KITS.™
1-800-221-0932
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
E
D
H
G
metraonline.com
