INSTALLATION INSTRUCTIONS FOR PART 99-9103
APPLICATIONS
Audi A4 2001-2007
WITH THE CONCERT RADIO
99-9103
KIT FEATURES
• DIN Head Unit Provisions
KIT COMPONENTS
A) Radio Housing
A
TOOLS REQUIRED:
86-9001 Head Unit Removal Keys • Flat Blade Screwdriver
1-800-221-0932
www.metraonline.com
© COPYRIGHT 2004-2009 METRA ELECTRONICS CORPORATION
Advertisement
Related Manuals for Metra Electronics 99-9103
Summary of Contents for Metra Electronics 99-9103
- Page 1 INSTALLATION INSTRUCTIONS FOR PART 99-9103 APPLICATIONS Audi A4 2001-2007 WITH THE CONCERT RADIO 99-9103 KIT FEATURES • DIN Head Unit Provisions KIT COMPONENTS A) Radio Housing TOOLS REQUIRED: 86-9001 Head Unit Removal Keys • Flat Blade Screwdriver 1-800-221-0932 www.metraonline.com © COPYRIGHT 2004-2009 METRA ELECTRONICS CORPORATION...
- Page 2 99-9103 Dash Disassembly • • Audi A4 - 2001-2007 ----------------------------------------- 1 Kit Assembly • - DIN Head Unit Provision -------------------------------------- 2 Final Assembly -------------------------------------------------- 3 • NOWLEDGE IS Enhance your installation and fabrication skills by enrolling in the most recognized and respected mobile electronics school in our industry.
- Page 3 99-9103 AUDI A4 2001-2007 Disconnect the negative battery terminal to prevent an accidental short circuit. Insert Metra’s 86-9001 into the slots in the factory head unit and pull the unit out. Figure A Disconnect the wiring.
- Page 4 99-9103 DIN Head Unit Provision Slide the DIN cage into the Radio Housing and secure by bending the metal locking tabs down. Slide the after-market head unit into the cage until secure.
-
Page 5: Final Assembly
Figure A Re-connect the negative battery terminal and test the unit for proper operation. Snap radio housing assembly into factory radio opening. 99-9103 Strip wire ends back 1/2" Twist ends together Solder Tape... - Page 6 99-9103...
- Page 7 99-9103...
- Page 8 1-800-221-0932 www.metraonline.com © COPYRIGHT 2004-2009 METRA ELECTRONICS CORPORATION REV. 04-16-09...
