INSTALLATION INSTRUCTIONS FOR PART 99-8710
APPLICATIONS
Mercedes C-Class 2001-2004
Mercedes CLK 2004
99-8710
KIT FEATURES
• DIN Radio Provision with Pocket
KIT COMPONENTS
A) Radio Housing
A
TOOLS REQUIRED:
Small Flat Blade Screwdriver/ Panel Removal Tool
• Phillips Screwdriver • Torx Screwdriver
1-800-221-0932
www.metraonline.com
© COPYRIGHT 2004-2008 METRA ELECTRONICS CORPORATION
Advertisement
Table of Contents
Related Manuals for Metra Electronics 99-8710
Summary of Contents for Metra Electronics 99-8710
- Page 1 INSTALLATION INSTRUCTIONS FOR PART 99-8710 APPLICATIONS Mercedes C-Class 2001-2004 Mercedes CLK 2004 99-8710 KIT FEATURES • DIN Radio Provision with Pocket KIT COMPONENTS A) Radio Housing TOOLS REQUIRED: Small Flat Blade Screwdriver/ Panel Removal Tool • Phillips Screwdriver • Torx Screwdriver 1-800-221-0932 www.metraonline.com...
-
Page 2: Dash Disassembly
Final Assembly ......... . 4 *Note: Refer also to the instructions included with the aftermarket radio. 99-8710 NOWLEDGE IS Enhance your installation and fabrication skills by enrolling in the most recognized and respected mobile electronics school in our industry. - Page 3 Unclip the (2) metal clips at the bot- tom edge of the climate control/radio trim panel and remove trim panel. Remove (4) Phillips screws securing factory radio then unplug and remove the radio. Continue to kit assembly. 99-8710 DASH DISASSEMBL Y “C” “B” “A”...
- Page 4 Remove (2) screws from bottom of cli- mate control/radio trim panel. Unclip climate control/radio trim panel. Unplug and remove trim panel. Remove the (4) screws securing the radio then unplug and remove the radio. Continue to final assembly. 99-8710 DASH DISASSEMBL Y MERCEDES CLK 2004...
- Page 5 (Figure A) Slide the DDIN radio unit into the trim plate bracket assembly and secure the unit to the kit using the screws sup- plied with the head unit. (Figure B) Continue to final assembly. 99-8710 KIT ASSEMBL Y...
- Page 6 *NOTE: When a Black wire is not present, ground radio to vehicle chassis. All colors may not be present on all leads due to manufacturer’s specifications. 99-8710 FINAL ASSEMBL Y (A) Strip wire ends back 1/2" B) Twist ends together...
- Page 7 99-8710 NOTES...
- Page 8 99-8710 INSTRUCTIONS www.metraonline.com 1-800-221-0932 REV. 08/07/08 © COPYRIGHT 2004-2008 METRA ELECTRONICS CORPORATION INST99-8710...
