Metra Electronics 99-3413 Installation Instructions

ALL VEHICLES
5
Fig. A
2-SHAFT HEAD UNITS: Slide the aftermarket head unit into the kit and secure with shaft
nuts. (see Fig. A)
DIN HEAD UNITS: Cut and remove the shaft supports. Slide the DIN cage into the Radio
Housing and secure by bending the metal locking tabs down. Slide the aftermarket head unit
into the cage until secure. (see Fig. B)
(If an equalizer will be included, slide the unit into the back of the Radio Housing
If an equalizer will NOT be included, snap theEqualizer Dummy Plate
6
A
B
C
D
A) Strip wire ends back ½"
B) Twist ends together
C) Solder
D) Tape
Locate the factory wiring harness in the
dash. Metra recommends using the
proper mating adaptor and making
connections as shown. (Isolate and
individually tape off the ends of any
unused wires to prevent electrical short
circuit).
3
Fig. B
and secure.
into the opening).
7
"A"
"B"
"A"
"B"
COROLLA: Re-connect the battery terminal and
test the unit for proper operation. Mount the head
unit/kit assembly to the sub-dash with (4) Phillips
screws previously removed in step #1.
PRIZM: Re-connect the battery terminal and test
the unit for proper operation. Mount the head
unit/kit assembly to the sub-dash with (2) Phillips
screws previously removed in step #1 ("A") and
(2) Phillips Screws supplied ("B").
rev. 06-13-07
KIT FEATURES
Shaft and
DIN unit 99-3413
provisions
INSTALLATION
Cupholder
provisions
INSTRUCTIONS
Equalizer
provisions
APPLICATIONS
KIT COMPONENTS
CAR
Radio Housing
CHEVROLET
Prizm 1998-2003.........................................................1
TOYOTA
Corolla 1998-2002.....................................................2
Prizm
Spacers
Equalizer
Dummy Plate
(2) Phillips
Screws
TOOLS REQUIRED
Phillips screwdriver
Cutting tool
1-800-221-0932
© COPYRIGHT 2001-07 METRA ELECTRONICS CORPORATION
Wrench
PAGE
www.metraonline.com
