INSTALLATION INSTRUCTIONS FOR PART 95-9308B
METRA. THE WORLD'S BEST KITS.™
1-800-221-0932
© COPYRIGHT 2004-2009 METRA ELECTRONICS CORPORATION
metraonline.com
INSTALLATION INSTRUCTIONS FOR PART 95-9308B
APPLICATIONS
BMW X5
2000 - 2006
(non-navigation models)
95-9308B
KIT FEATURES
• DDIN Head Unit Provision
• ISO Stacked Head Unit Provision
• Painted Scratch Resistant Matte Black
KIT COMPONENTS
• DDIN Radio Trim Plate • DDIN Brackets • (4) Plastic Snaps • (8) Flush ISO Screws
TOOLS REQUIRED
• Phillips Screwdriver • Torx Screwdriver • Panel Removal Tool
• Small Flat Blade Screwdriver • Cutting Tool or File
METRA. THE WORLD'S BEST KITS.™
1-800-221-0932
© COPYRIGHT 2004-2009 METRA ELECTRONICS CORPORATION
metraonline.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the 95-9308B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Metra Electronics 95-9308B

  • Page 1 INSTALLATION INSTRUCTIONS FOR PART 95-9308B METRA. THE WORLD’S BEST KITS.™ 1-800-221-0932 metraonline.com © COPYRIGHT 2004-2009 METRA ELECTRONICS CORPORATION INSTALLATION INSTRUCTIONS FOR PART 95-9308B APPLICATIONS BMW X5 2000 - 2006 (non-navigation models) 95-9308B KIT FEATURES • DDIN Head Unit Provision • ISO Stacked Head Unit Provision •...
  • Page 2: Dash Disassembly

    95-9308B TABLE OF CONTENTS DASH DISASSEMBLY • BMW X5 2000 - 2006 ....1,2 KIT ASSEMBLY • BMW X5 2000 - 2006 ....3 *NOTE: Refer Also to the instructions included with the aftermarket radio.
  • Page 3 95-9308B NOTES 95-9308B DASH DISASSEMBLY BMW X5 2000-2006 Disconnect the negative battery terminal to prevent an accidental short circuit. Remove the volume knob. (Fig. A) Using a T-10 torx-head screwdriver, turn the release lever under the shaft 90º. (Fig. A)
  • Page 4 95-9308B DASH DISASSEMBLY BMW X5 2000-2006 ...Coninued from Pg. 1 With the factory radio door open, press in on the tabs at either side and remove the door. (Fig. C) Cut and remove shown sec- tion from the sub dash.
