INSTALLATION INSTRUCTIONS FOR PART 95-8903B

(NON-NAVIGATION RADIOS ONLY)

95-8903B

KIT FEATURES

• DDIN radio provision

• Stacked ISO radio provision

• Painted scratch resistant matte black

KIT COMPONENTS

A) DDIN Trim plate B) DDIN Brackets

• Small Flat Blade Screwdriver • Phillips Screwdriver

METRA. THE WORLD'S BEST KITS.™

1-800-221-0932

APPLICATIONS

SUBARU

LEGACY & OUTBACK

2010

WIRING AND ANTENNA CONNECTIONS (Sold Separately)

• 70-8901 Subaru Harness 1990-Up

• 70-7552 Nissan Harness 2007-Up

• 40-SB10 Subaru Antenna Adapter 2005-Up

TOOLS REQUIRED:

• Panel Removal Tool • Socket Wrench

Wiring Harness:

Antenna Adapter:

www.metraonline.com

Page 1 INSTALLATION INSTRUCTIONS FOR PART 95-8903B LEGACY & OUTBACK (NON-NAVIGATION RADIOS ONLY) 95-8903B KIT FEATURES • DDIN radio provision • Stacked ISO radio provision • Painted scratch resistant matte black KIT COMPONENTS A) DDIN Trim plate B) DDIN Brackets • Small Flat Blade Screwdriver • Phillips Screwdriver •...
Page 2 - Double DIN / Stacked ISO DIN Head Unit Provision....2 *Note: Refer also to the instructions included with the aftermarket radio. 95-8903B Metra recommends MECP certified technicians.
Page 3 2010 SUBARU LEGACY / OUTBACK isconnect the negative battery ter- minal to prevent an accidental short circuit. Unclip and remove the radio trim panel including the a/c vents. (Figure A) Remove (4) Phillips screws securing the factory radio. 95-8903B DASH DISASSEMBLY...
Page 4 Double DIN head unit or stacked ISO head units to the assem- bly using the screws supplied with the radio. (Figure B) Reassemble dash in reverse order of disassembly. 95-8903B KIT ASSEMBLY PROVISIONS (Figure A)
Page 5 95-8903B NOTES...
Page 6 95-8903B NOTES...
Page 7 95-8903B NOTES...
