70-1722
INSTRUCTIONS
FOR AMPLIFIED SOUND
SYS
TEMS
For vehicles with factory amplifiers:
In order to turn on the factory amplifier you
must locate the 20-way harness that was
plugged into the factory radio. In pin 16 in
vehicles without navigation or pin 20 in
vehicles with navigation (see diagram on
reverse side) there is a Light Blue wire that
you must attach to the Amp Turn On wire of
the aftermarket radio for the amplifier to
turn on.
Use Metra's standard wiring instructions for
the remainder of the installation.
(See harness diagram on back of page)
REV. 06/08/06
INST70-1722
