TIG WELDING SYSTEMS
SOME LIKE IT HOT.
The centrepiece of a TIG welding device is the optimum
ignition and control. That makes welding devices real
perfectionists: they can handle all metals from 0.3 mm
on with direct or alternating current, depending on the
material. Your advantage: They are so good at handling
the concentrated splash-free electric arc, that bother-
e.g. TIG 170 AC/DC
Digital welding current indicator
with automatic nominal and
actual value changeover.
"HF ignition"
for contact-free ignition
of the TIG electric arc.
2/4-cycle control for
comfortable working.
Electrode function
with switch and automa-
tic hot start, arc
force control and anti-
stick regulation for
perfect, even welding
results without
sticking.
Torch and earth cable
can be removed.
Smart intelligence
State-of-the-art processor
control for simple operation
and ideal welding results.
334 |
some reworking is now a thing of the past. Metabo wel-
ding systems are produced as highly dependable tools:
Only after successfully passing all air condition, dust
chamber and vibration tests and then being checked
again thoroughly, do they leave our factory.
Infinitely adjustable second current
for protecting the material from
overheating.
Automatic finishing
Infinitely adjustable
welding current reduction
for a clean welded end.
Sturdy metal housing
with protection class
IP 23C for safe use
in rough construction
during TIG AC welding can be adjusted
for ideal fusion penetration.
Frequency control
during TIG AC welding can be
adjusted for a stable electric arc.
Approved for welding even in narrow spaces with
increased electrical risk. Automatic test function
with switch for testing the "S-wave" .
device
Continuously
adjustable gas
post flow time
for perfect gas
management.
site conditions.
Balance control
"S mark"
