COMMON FEATURES
Ideal for mobile use
Suitable for extracting dust and solid particles and
non-inflammable fluids
Optimum noise damping
Optimum utilisation of container volume through compact cons-
truction
High power motor with separate cooling circuit
Sturdy and washable pleated filter
Automatic shutoff that is disconnected while absorbing
the suction flow as soon as the maximum filling height
of the container is reached
AS 1200
Special advantages
Integrated socket with automatic
start mechanism
Suction hose with swivel joint
Comparative device characteristics
Air output (at fan)
Vacuum pressure
Filter surface
Rated input power
Container volume
Suction hose
- Diameter
- Length
Weight
Standard equipment
Type
Order no.
MULTI-PURPOSE VACUUM CLEANERS
Paper filter bag as accessory
Shock resistant plastic container
Stable
Movable on attached wheels and castors
Option to wind up the cable
Practical accessory case and storage area
1200 Watt Multi-Purpose Vacuum Cleaner
AS 1200
60 l/s
171 hPa (mbar) / 17.1 kpa
2.950 cm²
1.200 W
20 l
35 mm
1,75 m
5 kg
Suction hose (Ø 35 mm, 1.75 m long),
2 suction pipes, grouting nozzle,
multi-purpose nozzle with universal insert
AS 1200
6.01200
ASA 1202
1200 Watt Multi-Purpose Vacuum Cleaner
ASA 1202
60 l/s
171 hPa (mbar) / 17.1 kpa
2.950 cm²
1.200 W
32 l
35 mm
2,5 m
7 kg
Suction hose (Ø 35 mm, 2.5 m long),
2 suction pipes, pipe holder, grouting nozzle,
suction nozzle (120 mm wide), multi-purpose
nozzle with universal insert
ASA 1202
6.01202
