EQUIPMENT FEATURES
For sawing wood, plastics, gypsum boards, metals...
Lock-on button for remaining switched
on continuously
Aluminum die cast saw blade guide with
plastic trays
Axially adjustable guide for limiting cutting length
Vario Constamatic (VC) full-wave electronics
Thumbwheel for preselection of number of strokes
4-level pendulum blade movement
Auto-stop carbon brushes
Multi-purpose machine by the comprehensive
range of saw blades
Comparative
device characteristics
Torque
Strokes at no load
Rated input power
Output power
Saw blade stroke
Weight (without mains cable)
Standard equipment
Type
Order no.
Ps E 0525
500 Watt
Electronic Orbital
All-Purpose Saw
Ps E 0525
7 Nm
500 - 2.500 /min
500 W
310 W
25 mm
2,8 kg
Flexible HCS saw
blade, hexagon
spanner
Ps E 0525
6.00525
ALL-PURPOSE SAW / SABRE SAW
EQUIPMENT FEATURES
To saw wood, plastics, metal pipes and profiles
Ergonomically designed for bent handle for optimum power
transmission
Sheathed die cast aluminium gear housing
Large, easy to use trigger button
Saw blade rotatable by 180°
Metabo "Quick" saw blade change
Axially adjustable guide for limiting cutting length
Multi-purpose machine that will accept a comprehensive range
of saw blades
Li-Ion battery packs for up to 40% more power with up to 40%
less weight. No memory effect!
With "AIR COOLED" quick charger AC 30 Plus for charging NiCd,
NiMH and Li-Ion battery packs; charge time approx. 30 minutes
(at 1.4 Ah)
... 40% more output
with 40% less weight
Comparative device characteristics
Type of battery pack
Battery pack voltage
Capacity of battery pack
Strokes at no load
Saw blade stroke
Weight (including battery pack)
Standard equipment
1)
at nominal,
maximal voltage 20 Volts
Type
Order no.
ASE 18
18 Volt
Cordless Sabre Saw
ASE 18
Li-Ion
18 V
1)
2,2 Ah
0 - 2.600 /min
27 mm
3,8 kg
3 saw blades, hexagon spanner,
2 Li-Ion battery packs (18 V/2.2 Ah),
"AIR COOLED" quick charger
AC 30 Plus, carry case
ASE 18
6.02169.50
