Meridian DSP420 General Information

Meridian DSP420 RS232 Interface.

General Information

The RS232 interface for the DSP420 can be operated from any terminal that operates at 9600 baud
with 1 start bit, 1 stop bit and no parity. Commands take the form of 2 ASCII characters, in some
cases followed by a signed argument ('nn' below). All characters are echoed by the speaker. A
carriage return character will execute the command and backspace is also implemented. When a
command is executed, the speaker will return 8 characters.
Basic Functions
The following tables list the basic commands available and show examples of the messages
returned. In each case the message retuned via RS232 corresponds with the display on the front
panel of the processor.
RS232 Command
CD
RD
LP
TV
T1
T2
CR
CB
DV
V1
V2
LD
RS232 Command
VP
VM
VNnn
MU
SB
POnn
BNnn
TNnn
LNnn
%inn
PHnn
