Meridian RS232 Datasheet

The RS232 interface for the 568 can be operated from any terminal which operates at 9600 baud
with 1 start bit, 1 stop bit and no parity. Commands take the form of 2 ASCII characters, in some
cases followed by a signed argument ('nn' below). All characters are echoed by the processor. A
carriage return character will execute the command, and backspace is also implemented. When a
command is executed, the 568 will return 12 characters.
The following table lists the commands available and shows examples of the messages returned.
These always correspond to the display on the front panel.
Source Commands.
CD Select CD source.
RD Select Radio.
LP Select LP.
TV Select TV.
T1 Select Tape 1.
T2 Select Tape 2.
CR Select CDR.
CB Select Cable.
DV Select DVD.
V1 Select VCR 1.
V2 Select CDR.
LD Select Laser Disc.
Volume Commands.
VP Volume +.
VM Volume -.
VNnn Goto volume (1-99). Trifield
MU Mute.
General Commands.
SB Standby.
MR Menu Right
ML Menu Left
MP Menu Plus (Up)
MM Menu Minus (Down) Balance
1
PNnn Go to preset
Meridian 568 RS232 Interface
CD 65
Radio 65
LP 65
TV 65
Tape1 65
Tape2 65
CDR 65
Cable 65
DVD 65
VCR1 65
VCR2 65
Ldisc 65
Trifield 66
Trifield 64
87
Mute
Standby
Centre +OdB
Balance <O>
Balance <1
1>
Trifield 65
Meridian Audio Limited, Stonehill, Stukeley Meadows, Huntingdon, Cambs PE29 6EX
Tel +44 1480 52144 Fax +44 1480 459934
http://www.meridian-audio.com/
RS232 Information
JMB v 1.5 – 09-01-2001
