Page 1 Before driving Introduction Instrumentation Controls and features Seating and safety restraints Starting and driving Starting Driving Roadside emergencies Servicing Maintenance and care Capacities and specifications Customer assistance Reporting safety defects Index All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company.
Page 2: Introduction
Introduction The following warning may be required by California law: CALIFORNIA Proposition 65 Warning WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
Page 3 BREAKING-IN YOUR VEHICLE There are no particular breaking-in rules for your vehicle. During the first 1 600 km (1 000 miles) of driving, vary speeds frequently. This is necessary to give the moving parts a chance to break in. INFORMATION ABOUT THIS GUIDE The information found in this guide was in effect at the time of printing.
Page 4 Introduction These are some of the symbols you may see on your vehicle. Safety Alert Fasten Safety Belt Air Bag-Side Child Seat Installation Warning Brake System Brake Fluid - Non-Petroleum Based Master Lighting Switch Fog Lamps-Front Fuel Pump Reset Windshield Defrost/Demist Power Windows Front/Rear...
Page 5 Child Safety Door Lock/Unlock Panic Alarm Engine Coolant Do Not Open When Hot Avoid Smoking, Flames, or Sparks Explosive Gas Power Steering Fluid Emission System Passenger Compartment Air Filter Check fuel cap Vehicle Symbol Glossary Interior Luggage Compartment Release Symbol Engine Oil Engine Coolant Temperature...
Page 6: Instrumentation
Instrumentation Headlamp control (pg. 21) Instrument panel dimmer switch (pg. 22) CHECK ENGINE FUEL RESET Tilt steering wheel lever (pg. 82) Parking brake release (pg. 150) Instrument cluster (pg. 8) Speed control DOOR AJAR CHECK GAGE RPMx1000 Turn signal and wiper/washer control (pg.
Page 7 Gearshift (includes overdrive button) (pg. 156) VOL - PUSH ON BASS TREB SEEK SCAN TUNE 4wd control* (pg. 159) Electronic sound system Rear wiper/washer (pg. 36) R. WIPE PUSH FADE TAPE SIDE 1 - 2 Climate control system (pg. 22) Instrumentation control (pg.
Page 8 Instrumentation WARNING LIGHTS AND CHIMES CHECK GAGE CHECK ENGINE CHECK FUEL CAP BRAKE Check engine Your vehicle is equipped with a computer that monitors the engine’s emission control system. This system is commonly known as the On Board Diagnostics System (OBD II). This OBD II system protects the environment by ensuring that your vehicle continues to meet government emission standards.
Page 9 These temporary malfunctions can be corrected by filling the fuel tank with high quality fuel of the recommended octane and/or properly installing and securely tightening the gas cap. After three driving cycles without these or any other temporary malfunctions present, the Check Engine light should turn off.
Page 10 Instrumentation Air bag readiness Momentarily illuminates when the ignition is turned ON. If the light fails to illuminate, continues to flash or remains on, have the system serviced immediately. Safety belt Momentarily illuminates when the ignition is turned to the ON position to remind you to fasten your safety belts.
Page 11 Instrumentation Turn signal Illuminates when the left or right turn signal or the hazard lights are turned on. If one or both of the indicators stay on continuously or flash faster, check for a burned-out turn signal bulb. Refer to Bulbs in the Maintenance and care chapter. High beams Illuminates when the high beam headlamps are turned on.
Page 12 Instrumentation Four wheel drive low (if equipped) Momentarily illuminates when the ignition is turned to the ON/START position. Illuminates when four-wheel drive low is engaged. If the light continues to flash have the system serviced. Four wheel drive high (if equipped) Momentarily illuminates when the ignition is turned to the START position.
Page 13 Instrumentation Speed control This light comes on when either the SPEED SET/ACCEL or RESUME controls CONT are pressed. It turns off when the speed control OFF control is pressed, the brake or clutch (if equipped) is applied or the ignition is turned to the OFF position.
Page 14: Engine Coolant Temperature Gauge
Instrumentation GAUGES CHECK GAGE CHECK ENGINE CHECK FUEL BRAKE Speedometer Indicates the current vehicle speed. Engine coolant temperature gauge Indicates the temperature of the engine coolant. At normal operating temperature, the needle remains within the normal area (the area between the “H” and “C”). If it enters the red section, the engine is overheating.
Page 15 Never remove the coolant reservoir cap while the engine is running or hot. This gauge indicates the temperature of the engine coolant, not the coolant level. If the coolant is not at its proper level the gauge indication will not be accurate. Odometer Registers the total kilometers (miles) of the vehicle.
Page 16 Instrumentation Battery voltage gauge This shows the battery voltage when the ignition is in the ON position. If the pointer moves and stays outside the normal operating range (as indicated by arrows), have the vehicle’s electrical system checked as soon as possible. Engine oil pressure gauge This shows the engine oil pressure in the system.
Page 17 The FUEL DOOR icon and arrow indicates which side of the vehicle the fuel filler door is located. MESSAGE CENTER (IF EQUIPPED) With the ignition in the ON position, the message center displays important vehicle information through a constant monitor of vehicle systems. You may select display features on the message center for a display of status preceded by a brief indicator...
Page 18 Instrumentation Fuel status Press once to display the approximate amount of fuel remaining in the fuel tank. Press again to display the approximate amount of fuel used since the system was last reset. Fuel economy Press to display your vehicle’s average fuel economy in liters/100 km or (miles/gallons).
Page 19 System check Press the system check control to display the status of the following systems: engine oil life left engine oil level voltage level engine coolant temperature washer fluid level fuel level The engine oil life left has two phases. The first display will indicate the oil change status (OK, SOON, REQUIRED).
Page 20 Instrumentation Oil change reset Press the OIL CHANGE RESET control to reset the oil life feature to 100% (or your personalized oil reset percentage) (at optimal driving conditions, 100% oil life is equivalent to a maximum of 12 000 kilometers [7 500 miles]).
Page 21: Controls And Features
HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps. Rotate to the second position to also turn on the headlamps. Foglamp control (if equipped) Turn on the low-beam headlamps or parking lamps and press the foglamp control to activate the foglamps.
Page 22 Controls and features Flash to pass Pull toward you to activate and release to deactivate. PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel during headlamp and parklamp operation. Rotate up to brighten. Rotate down to dim. Rotate to full up position (past detent) to turn on interior lamps.
Page 23 Mode selector control Controls the direction of the airflow to the inside of the vehicle. The air conditioning compressor will operate in all modes except . However, the air conditioning will only function if the outside temperature is about 6°C (43°F) or higher. Since the air conditioner removes considerable moisture from the air during operation, it is normal if clear water drips on the ground under the air conditioner drain while the system is working and even after you...
Page 24 Controls and features (Floor and defrost)-Distributes outside air through the windshield defroster ducts and the floor ducts. Heating and air conditioning capabilities are provided in this mode. For added customer comfort, when the temperature control knob is anywhere in between the full hot and full cold positions, the air distributed through the floor ducts will be slightly warmer than the air sent to the windshield defrost ducts.
Page 25 windows open. This will force most of the hot, stale air out of the vehicle. Once the vehicle has been “aired out”, operate the climate control system as desired. Do not put objects under the front seat that will interfere with the airflow to the back seats (if equipped).
Page 26: Automatic Operation
Controls and features Electronic Automatic Temperature Control (EATC) system (if equipped) The EATC system will maintain a selected temperature and automatically control airflow. You can override automatic operation with any of the override controls, the fan speed control or the steering wheel controls.
Page 27 Controls and features When in AUTOMATIC and weather conditions require heat, air will be sent to the floor. However, if the engine is not warm enough to provide heat, the fan will be at a low speed and the air will be directed to the windshield.
Page 28 Controls and features Temperature conversion Press MAX A/C and DEF the same time (for one second) to switch between Fahrenheit and Celsius. If your vehicle has an English/Metric (E/M) control, this control will also change the temperature display. Fan speed ( When AUTOMATIC is pressed, fan speed is adjusted automatically for existing conditions.
Page 29 The air conditioning compressor will operate in all modes except FLOOR and VENT. It will also operate only when required when AUTOMATIC has been selected. However, the air conditioning will only function if the outside temperature is about 6°C (43°F) or higher. Since the air conditioner removes considerable moisture from the air during operation, it is normal if clear water drips on the ground under the air conditioner drain while the system is working and even after you...
Page 30 Controls and features OFF-Outside air is shut out and the fan will not operate. For short periods of time only, use this mode to reduce undesirable odors from entering the vehicle. Rear fan off Press REAR FAN OFF to turn off the rear console fan.
Page 31 Remove any snow, ice or leaves from the air intake area at the base of the windshield. If your vehicle has been parked with the windows closed during hot weather, the air conditioner will do a much faster job of cooling if you drive for two or three minutes with the windows open.
Page 32 Controls and features Turn the fan speed control to the - VOLUME + MODE desired position. SEEK MEMORY Select for air to flow through these vents: – VOLUME BAND SEEK MEMORY Select for air to flow through these vents: – VOLUME BAND SEEK...
Page 33 REAR WINDOW DEFROSTER The rear defroster control is located on the instrument panel. Press the rear defroster control to clear the rear window of thin ice and fog. A small LED will illuminate when the rear defroster is activated. The ignition must be in the ON position to operate the rear window defroster.
Page 34 Controls and features To help avoid personal injury, always use caution when in reverse and when using the reverse sensing system. This system is not designed to prevent contact with small or moving objects. The system is designed to provide a warning to assist the driver in detecting large stationary objects to avoid damaging the vehicle.
Page 35 Controls and features The reverse sensing system is automatically enabled when the gear selector is placed in R (Reverse) and the ignition is ON. A reverse sensing control allows the driver to disable the reverse sensing system only when the ignition is ON, and the gear selector is in R (Reverse).
Page 36 Controls and features USING YOUR AUDIO SYSTEM AM/FM stereo cassette VOL - PUSH ON BASS SEEK TUNE Volume/power control Press the control to turn the audio system on or off. Turn the control to raise or lower volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal”...
Page 37 AM/FM select The AM/FM select control works in radio and tape modes. AM/FM select in radio mode This control allows you to select AM or FM frequency bands. Press the AM control to select from AM selections, and press the FM control to select from FM1 or FM2 memory preset stations.
Page 38 Controls and features Scan function The scan function works in radio mode. SCAN Scan function in radio mode Press the SCAN control to hear a brief sampling of all listenable stations on the frequency band. Press the SCAN control again to stop the scan mode.
Page 39 Treble adjust The treble adjust control allows you to increase or decrease the audio system’s treble output. Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers.
Page 40 Controls and features Automatic Music Search The Automatic Music Search feature allows you to quickly locate the beginning of the tape selection being played or to skip to the next selection. To activate the feature, momentarily depress the TAPE AMS button. Then, press either REW (for the beginning of the current selection) or FF (to advance to the next selection).
Page 41 Dolby noise reduction Dolby noise reduction operates only in tape mode. Dolby noise reduction reduces the amount of hiss and static during tape playback. Press the control to activate (and deactivate) Dolby noise reduction. Dolby noise reduction is manufactured under license from Dolby Laboratories Licensing Corporation.
Page 42 Controls and features To set the minute, press and hold the CLK control and press the TUNE control: to decrease minutes and to increase minutes. The CLK control will allow you to switch between media display mode (radio station, stereo information, etc.) and clock display mode (time). When in clock mode, the media information will display for 10 seconds, when the radio is turned on, and then revert to clock information.
Page 43 Premium AM/FM Stereo/Cassette/Single CD VOL PUSH ON SEEK TUNE SCAN Volume/power control Press the control to turn the audio system on or off. Audio power can also be turned on by pressing the AM/FM select control or the tape/CD select control.
Page 44 Controls and features If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. AM/FM select The AM/FM select control works in radio, tape and CD modes.
Page 45 Tune adjust for CD changer (if equipped) Press to select the previous disc in the CD changer. (Play will begin on the first track of the disc unless the CD changer is in shuffle mode. Refer to Shuffle feature for more information. Hold the control to continue reversing through the remaining discs.
Page 46 Controls and features Seek function for CD or CD changer (if equipped) Press to seek to the previous track of the current disc. If a selection has been playing for three seconds or more and you press , the CD changer will replay that selection from the beginning.
Page 47 Controls and features Setting memory preset stations 1. Select the frequency band with the AM/FM select control. 2. Select a station. Refer to Tune adjust or Seek function for more information on selecting a station. SIDE 1-2 COMP SHUFFLE 3. Press and hold a memory preset control until the sound returns, indicating the station is held in memory on the control you selected.
Page 48 Controls and features To deactivate autoset and return to your audio system’s manually set memory stations, press the AUTO control again. Bass adjust The bass adjust control allows you to increase or decrease the audio system’s bass output. Press the BASS control then press: to decrease the bass output to increase the bass output.
Page 49 Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. Press the BAL control then press: to shift sound to the left and to shift sound to the right. Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers.
Page 50 Controls and features With the dual media audio system, press the CD control to toggle between single CD and CD changer play (if equipped). Do not insert any promotional (odd shaped or sized) discs, or discs with removable labels into the CD player as jamming may occur.
Page 51 Dolby noise reduction Dolby noise reduction operates in tape mode. Dolby noise reduction reduces the amount of hiss and static during tape playback. Press the control to activate (and deactivate) the Dolby noise reduction. Dolby noise reduction is manufactured under license from Dolby Laboratories Licensing Corporation.
Page 52 Controls and features Setting the clock To set the hour, press and hold the CLK control and press SEEK: to decrease hours and to increase hours. To set the minute, press and hold the CLK control and press TUNE: to decrease minutes and to increase minutes.
Page 53 Controls and features The CLK button will allow you to switch between media display mode AUTO (radio station, stereo information, etc.) and clock display mode (time). When in clock mode, the media information will display for 10 seconds, when the radio is turned on, and then revert to clock information.
Page 54 Controls and features To turn on the rear seat controls, press the memory preset controls 3 and 5 at the same time. The will appear in the display. Pressing 3 and 5 at the same time again will turn the rear seat controls off.
Page 55 Turning the speakers on and off Press to turn all speakers on or off. Using headphones Plug a 3.5 mm headphone (not included) into the speaker on/off control to operate the headphones. The rear speakers will cut out once the speaker on/off control is pressed. The front speaker will remain playing for the front passengers.
Page 56 Controls and features Memory preset control Push the MEMORY control successively to allow rear seat passengers to scroll through the 6 memory presets in AM, FM1 or FM2. Push the MEMORY control in CD changer mode (if equipped) to advance to the next disc. Seek function In radio mode, press the next listenable station down...
Page 57 MACH Audio System with AM/FM Stereo/Cassette/Single CD VOL - PUSH ON SEEK TUNE SCAN Volume/power control Press the control to turn the audio system on or off. Turn control to raise or lower volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal”...
Page 58 Controls and features AM/FM select The AM/FM select control works in radio, tape and CD modes. AM/FM select in radio mode This control allows you to select AM or FM frequency bands. Press the control to switch between AM, FM1 or FM2 memory preset stations. AM/FM select in tape mode Press this control to stop tape play and begin radio play.
Page 59 Tune adjust for CD changer (if equipped) Press to select the previous disc in the CD changer. (Play will begin on the first track of the disc unless the CD changer is in shuffle mode. Refer to Shuffle feature for more information. Hold the control to continue reversing through the disc.
Page 60 Controls and features Seek function for CD changer (if equipped) Press to seek to the previous track of the current disc. If a selection has been playing for three seconds or more and you press , the CD changer will replay that selection from the beginning.
Page 61 Setting memory preset stations 1. Select the frequency band with the AM/FM select control. 2. Select a station. Refer to Tune adjust or Seek function for more information on selecting a station. 3. Press and hold a memory preset control until the sound returns, indicating the station is held in memory on the control you selected.
Page 62 Controls and features Bass adjust The bass adjust control allows you to increase or decrease the audio system’s bass output. Press the BASS control then press: to decrease bass output and to increase bass output. Treble adjust The treble adjust control allows you to increase or decrease the audio system’s treble output.
Page 63 Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers. Press the FADE control then press: to shift sound to the front to shift sound to the rear. Tape/CD/CD changer (if equipped) select To begin tape play (with a tape loaded into the audio system) while in the radio or CD mode, press the TAPE control.
Page 64 Controls and features Rewind The rewind control works in tape and CD modes. In tape mode, radio play will continue until rewind is stopped (with the TAPE control) or the beginning of the tape is reached. In CD mode, pressing the REW control for less than three seconds results in slow rewind.
Page 65 Dolby noise reduction Dolby noise reduction operates only in tape mode. Dolby noise reduction reduces the amount of hiss and static during tape playback. Press the control to activate (and deactivate) Dolby noise reduction. The Dolby noise reduction system is manufactured under license from Dolby Laboratories Licensing Corporation.
Page 66 Controls and features Setting the clock Press the clock/RDS control until SELECT HOUR is displayed and press: to decrease hours and to increase hours. To set the minute, press the clock/RDS control until SELECT MIN is displayed and press: to decrease minutes and to increase minutes.
Page 67 Radio Data System (RDS) feature This feature allows your audio system to receive text information from RDS-equipped FM radio stations. Press and hold the control for three seconds to turn the feature on or off. Press the control to scroll through the following selections: RDS traffic announcement Press the RDS control until...
Page 68 Controls and features RDS select program type Press the RDS control until FIND program type is displayed. Use the SEL control to select the program type. With the feature on, use the SEEK or AUTOSET or SCAN control to find the desired program type from the following selections: Classic...
Page 69 Use the SEL control to select TYPE, NAME, TEXT or NONE. When your radio is turned to a RDS station, RDS station TYPE, station NAME, or TEXT message will be displayed along with the frequency. Press SEL in order to scroll through the text messages.
Page 70 Controls and features If there is a discrepancy between the rear seat and the front audio controls, (such as both trying to listen to the same playing media), the front audio system will receive the desired selection. To activate the Personal Audio System, press the speaker/headphone control.
Page 71 Turning the speakers on and off Press to turn all speakers on or off. Using headphones Plug a 3.5 mm headphone (not included) into the speaker on/off control to operate the headphones. The rear speakers will cut out once the speaker on/off control is pressed. The front speaker will remain playing for the front passengers.
Page 72 Controls and features Memory preset control Push the MEMORY control successively to allow rear seat passengers to scroll through the 6 memory presets in AM, FM1 or FM2. Push the MEMORY control in CD changer mode (if equipped) to advance to the next disc. Seek function In radio mode, press the next listenable station down...
Page 73 CD changer (if equipped) The CD changer is located in one of the following locations: in the trunk in the center console under the driver’s seat 1. Slide the door to access the CD changer magazine. 2. Press to eject the magazine. 3.
Page 74 Controls and features If you pull too hard on the disc holder, the disc holder may come completely out of the magazine. If this happens, reinsert the disc holder back into the magazine while pressing on the lever (A). 5. Line up the CD with the groove of the disc holder.
Page 75 The CD magazine may be inserted or ejected with the radio power off. ONLY use the magazine supplied with the CD changer, other types will damage the unit. Keep the CD changer door closed. Coins and foreign objects will damage the CD player and void your audio system warranty.
Page 76 Controls and features Do not insert more than one disc into each slot of the CD changer magazine. Do not insert any promotional (odd shaped or sized) discs, or discs with removable labels into the CD player as jamming may occur.
Page 77 Terrain. Hills, mountains and tall buildings between your vehicle’s antenna and the radio station signal can cause FM reception problems. Static can be caused on AM stations by power lines, electric fences, traffic lights and thunderstorms. Moving away from an interfering structure (out of its “shadow”) returns your reception to normal.
Page 78 Controls and features 3. OFF, shuts off the engine and all accessories without locking the steering wheel. 4. ON, all electrical circuits operational. Warning lights illuminated. Key position when driving. 5. START, cranks the engine. Release the key as soon as the engine starts. SPEED CONTROL To turn speed control on Press ON.
Page 79 Once speed control is switched off, the previously programmed set speed will be erased. To set a speed Press SET/SET ACC/SET ACCEL. For speed control to operate, the speed control must be ON and the vehicle speed must be greater than 48 km/h (30 mph).
Page 80 Controls and features Accelerate with your accelerator pedal. When the desired vehicle speed is reached, press and release SET/SET ACC/SET ACCEL. You can accelerate with the accelerator pedal at any time during speed control usage. Releasing the accelerator pedal will return your vehicle to the previously programmed set speed.
Page 81 Pressing OFF will erase the previously programmed set speed. To return to a previously set speed Press RES/RSM/RESUME. For RES/RSM/RESUME to operate, the vehicle speed must be faster than 48 km/h (30 mph). Indicator light This light comes on when either the SET ACCEL or RES controls are pressed.
Page 82 Controls and features TILT STEERING WHEEL Pull the tilt steering control toward you to move the steering wheel up or down. Hold the control while adjusting the wheel to the desired position, then release the control to lock the steering wheel in position. Never adjust the steering wheel when the vehicle is moving.
Page 83 Controls and features Push (tap) the end of the stalk briefly for a single swipe (no wash). Push and hold for three swipes with wash. Push and hold for a longer wash (up to ten seconds). Speed dependent wipers When the windshield wiper control is set on the intermittent settings, speed-sensitive front wipers automatically adjust as the vehicle’s speed changes.
Page 84 Controls and features STEERING WHEEL CONTROLS (IF EQUIPPED) These controls allow you to operate some radio and climate control features. Radio control features Press BAND/MODE to select AM, FM1, FM2, TAPE or CD (if equipped). In Radio mode: Press MEM/NEXT to select a preset station from memory.
Page 85 OVERHEAD CONSOLE (IF EQUIPPED) The appearance of your vehicle’s overhead console will vary according to your option package. Storage compartment (if equipped) Press the OPEN control to open the storage compartment. The door will open slightly and can be moved to full open.
Page 86 Controls and features Place the provided height adaptors onto the back of the GARAGE control as needed. Press the GARAGE control to activate the transmitter. Moon roof (if equipped) You can move the moon roof back to open the glass panel or tilt up to ventilate the vehicle.
Page 87 Do not let children play with the moon roof. They may seriously hurt themselves. Electronic compass/temperature display (if equipped) Outside air temperature The outside temperature display is contained in the overhead console. The temperature display can be turned off and on by pressing the MODE control on the overhead console.
Page 88 Controls and features Compass zone adjustment 1. Determine which magnetic zone you are in by referring to the zone map. 2. Turn ignition to the ON position. 3. Press and hold the MODE control until VAR appears in the display, then release.
Page 89 Compass calibration adjustment Perform this adjustment in an open area free from steel structures and high voltage lines: Press and hold the MODE control until CAL appears in the display (approximately eight seconds) and release. Drive the vehicle slowly (less than 5 km/h [3 mph]) in circles until CAL indicator turns off in about 2–3 complete circles.
Page 90 Controls and features Programming 1. Prepare for programming the HomeLink Universal Transceiver by erasing the three factory default codes by holding down the two outside buttons until the red light begins to flash after 20 seconds. Release both buttons. 2. Hold the end of your hand-held transmitter 5–14 cm (2–5 inches) away from the HomeLink Universal Transceiver surface (located on your visor) while keeping the red light in view.
Page 91 To program your hand-held transmitters: continue to hold the button on the HomeLink Universal Transceiver. press and re-press the hand-held transmitter button every two seconds until the red light changes from a slow to a fast flash. Operating the HomeLink Universal Transceiver Once programmed, the HomeLink Universal Transceiver can be used in place of hand-held transmitters.
Page 92 Controls and features 3. Press and release the programmed HomeLink button. Press and release the HomeLink button a second time to complete the training process. (Some garage door openers may require this procedure to be done a third time to complete the training). The 2nd or 3rd press from step 3 will activate the door.
Page 93 Operating TravelNote TravelNote records and stores messages for up to three minutes in total length with simple controls. When you get an idea or remember something important while you’re driving, you don’t have to try to scribble it down or pull off the side of the road. All you have to do is push a button and begin speaking.
Page 94 Controls and features To delete a message: 1. Press and release the DEL button while listening to a message or shortly after. The indicator light will flash green twice. 2. To delete all recorded messages, simultaneously press and release the PLAY and REC buttons at the same time.
Page 95 4. The autolamp automatically turns the lamps on and off. The indicator light will illuminate when the headlamps turn on. AUTOMATIC DIMMING REAR VIEW MIRROR The autolamp/automatic dimming mirror is equipped with an automatic dimming feature. This feature will change from the normal state to the non-glare “active”...
Page 96 Controls and features One touch down Press AUTO completely down and release quickly. The driver’s window will open fully. Depress again to stop window operation. One touch down can be deactivated during operation by pushing down on the top part of the driver power window control.
Page 97 Controls and features CHILDPROOF DOOR LOCKS When these locks are set, the rear doors cannot be opened from the inside. The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
Page 98 Controls and features Heated outside mirrors (if equipped) Both mirrors are heated automatically to remove ice, mist and fog when the rear window defrost is activated. Do not remove ice from the mirrors with a scraper or attempt to readjust the mirror glass if it is frozen in place.
Page 99 Use only soft cups in the cupholder. Hard objects can injure you in a collision. Auxiliary power point The power point is an additional power source for electrical accessories. Rear console features The rear console incorporates the following features: air vents audio system controls rear seat climate controls cupholders...
Page 100 Controls and features CENTER ARMREST/REAR CUPHOLDER (IF EQUIPPED) Do not attempt to raise the console armrest when the rear cupholder is in use. If you find resistance when raising the armrest, make sure the cupholder is fully closed or else damage may occur to the armrest.
Page 101 The liftgate door and window should be closed before driving your vehicle. If not, possible damage may occur to the liftgate door lift cylinders and attaching hardware. Make sure that the liftgate door and/or window are closed to prevent exhaust fumes from being drawn into the vehicle. This will also prevent passengers and cargo from falling out.
Page 102 Controls and features 1. Remove the shade from the vehicle and extend it with the smooth grain facing you. 2. Wrap the vinyl around the roller tube twice. Tuck the edges of the vinyl inside the end cap with each wrap.
Page 103 Controls and features Unlocking the doors Press this control to unlock the driver’s door. The interior lamps will illuminate. Press the control a second time within five seconds to unlock all doors. Locking the doors Press this control to lock all doors. To confirm all doors are closed and locked, press the control a second time within five seconds.
Page 104 Controls and features Memory seat feature (if equipped) The remote entry system can also control the memory seat feature. Press the control once to unlock the driver’s door and move the memory seat feature to the corresponding memory position, just as if you had pressed the memory control in the vehicle.
Page 105 Replacing the battery The transmitter is powered by one coin type three-volt lithium battery CR2032 or equivalent. Typical operating range will allow you to be up to 10 meters (33 feet) away from your vehicle. A decrease in operating range can be caused by: weather conditions nearby radio towers structures around the vehicle...
Page 106 Controls and features Programming remote transmitters It is necessary to have all (maximum of four — original and/or new) of your remote transmitters available prior to beginning this procedure. To program the transmitters yourself: Place the key in the ignition and turn from 2 (LOCK) to 3 (OFF) and cycle between 3 (OFF) and 4(ON) eight times in rapid...
Page 107 The battery saver will shut off the interior lamps 45 minutes after the ignition has been turned to the OFF position. Keyless entry system (if equipped) With the keyless entry keypad, you can: lock or unlock the vehicle doors without using the key activate/deactivate the autolock feature See also Remote entry system in this chapter for more information.
Page 108 Controls and features If you wish to erase your personal code, use the following instructions: Erasing personal code 1. Enter the factory-set code. 2. Press 1/2 within five seconds of step 1. 3. Press the 7/8 and 9/0 controls at the same time within five seconds of step 2.
Page 109 The autolock feature repeats when: any door, except the drivers door, is opened then closed while the engine is running and you put the vehicle in motion Deactivating autolock Before following the activation or deactivation procedures, make sure that the ignition is OFF and all vehicle doors and liftgate window are closed. 1.
Page 110 Controls and features SECURILOCK PASSIVE ANTI-THEFT SYSTEM SecuriLock passive anti-theft system is an engine immobilization system. This system prevents the engine from being started unless a coded key is used. The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection.
Page 111 The SecuriLock passive anti-theft system is not compatible with non-Ford (aftermarket) remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Large metallic objects, electronic devices on the key chain that can be used to purchase gasoline or similar items, or a second key on the same key ring as the PATS ignition key may cause...
Page 112 Controls and features Programming spare keys A maximum of eight keys can be coded to your vehicle. Only SecuriLock keys can be used. To program a coded key yourself, you will need two previously programmed coded keys (keys that already operate your vehicle’s engine) and the new unprogrammed key(s) readily accessible for timely implementation of each step in the procedure.
Page 113: Seating And Safety Restraints
SEATING Adjustable head restraints (if equipped) Your vehicle’s seats may be equipped with head restraints which are vertically adjustable. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
Page 114 Seating and safety restraints Always drive and ride with your seatback upright and the lap belt snug and low across the hips. Reclining the seatback can reduce the effectiveness of the seat’s safety belt in the event of a collision. Lift handle to move seat forward or backward.
Page 115 Reclining the seatback can reduce the effectiveness of the seat’s safety belt in the event of a collision. The control is located on the outboard side of the seat cushion. Press front to raise or lower the front portion of the seat cushion. Press rear to raise or lower the rear portion of the seat cushion.
Page 116 Seating and safety restraints Using the manual lumbar support (if equipped) Turn the lumbar support control toward the front of vehicle to move the lumbar support forward for more direct support. Turn the lumbar support control toward the rear of vehicle to move the lumbar support back for less direct support.
Page 117 To return the seat to the upright position: Press downward on the upper corner of the seatback and hold. Pull the release handle upward to unlatch the seat. Rotate the seatback upward until the seatback latches in the upright position. The seatback will click when it is locked into position.
Page 118 Seating and safety restraints All occupants of the vehicle, including the driver, should always properly wear their safety belts, even when an air bag SRS is provided. It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed.
Page 119 After any vehicle collision, the safety belt system at all outboard seating positions (except driver, which has no “automatic locking retractor” feature) must be checked by a qualified technician to verify that the “automatic locking retractor” feature for child seats is still functioning properly.
Page 120 Seating and safety restraints The front and rear outboard safety restraints in the vehicle are combination lap and shoulder belts. The front passenger and rear seat outboard safety belts have two types of locking modes described below: Vehicle sensitive mode The vehicle sensitive mode is the normal retractor mode, allowing free shoulder belt length adjustment to your movements and locking in response to vehicle movement.
Page 121 Grasp the shoulder portion and pull downward until the entire belt is extracted. Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode. How to disengage the automatic locking mode Disconnect the combination lap/shoulder belt and allow it to retract completely to disengage the automatic locking mode and activate the...
Page 122 Seating and safety restraints Front safety belt height adjustment Your vehicle has safety belt height adjustments for the driver and front passenger. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To lower the shoulder belt height, push the button and slide the height adjuster down.
Page 123 Safety belt warning light and indicator chime The seat belt warning light illuminates in the instrument cluster and a chime sounds to remind the occupants to fasten their safety belts. Conditions of operation If... The driver’s safety belt is not buckled before the ignition switch is turned to the ON position...
Page 124 Seating and safety restraints The following are reasons most often given for not wearing safety belts: (All statistics based on U.S. data) Reasons given... Crashes are rare events I’m not going far Belts are uncomfortable I was in a hurry Seat belts don’t work Traffic is light Belts wrinkle my clothes...
Page 125 Reasons given... I have an air bag I’d rather be thrown clear Do not sit on top of a buckled safety belt to avoid the Belt Minder chime. Sitting on the safety belt will increase the risk of injury in an accident. To disable (one-time) or deactivate the Belt Minder feature please follow the directions stated below.
Page 126 Seating and safety restraints 1. Turn the ignition switch to the RUN (or ON) position. (DO NOT START THE ENGINE) 2. Wait until the safety belt warning light turns off. (Approximately 1–2 minutes) Steps 3–5 must be completed within 60 seconds or the procedure will have to be repeated.
Page 127 recommends that all safety belt assemblies used in vehicles involved in a collision be replaced. However, if the collision was minor and a qualified technician finds that the belts do not show damage and continue to operate properly, they do not need to be replaced. Safety belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.
Page 128 Seating and safety restraints Important supplemental restraint system (SRS) precautions The supplemental restraint system is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Air bags DO NOT inflate slowly or gently and the risk of injury from a deploying air bag is greatest close to the trim covering the air bag...
Page 129 Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln Mercury dealer. Children and air bags For additional important safety information, read all information on safety restraints in this guide.
Page 130 Seating and safety restraints How does the air bag supplemental restraint system work? The air bag SRS is designed to activate when the vehicle sustains longitudinal deceleration sufficient to cause the sensors to close an electrical circuit that initiates air bag inflation.
Page 131 Several air bag system components get hot after inflation. Do not touch them after inflation. If the air bag has deployed, the air bag will not function again and must be replaced immediately. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision.
Page 132 Do not attempt to service, repair, or modify the air bag Supplemental Restraint System, its fuses or the seat cover on a seat containing an air bag. See your Ford or Lincoln Mercury dealer. All occupants of the vehicle including the driver should always...
Page 133 How does the side air bag system work? The side air bag system consists of the following: An inflatable nylon bag (air bag) with a gas generator concealed behind the outboard bolster of the driver and front passenger seatbacks. A special seat cover designed to allow airbag deployment.
Page 134 Seating and safety restraints Several air bag system components get hot after inflation. Do not touch them after inflation. If the side air bag has deployed, the air bag will not function again. The side air bag system (including the seat) must be inspected and serviced by a qualified technician in accordance with...
Page 135 Disposal of air bags and air bag equipped vehicles (including pretensioners) For disposal of air bags or air bag equipped vehicles, see your local dealership or qualified technician. Air bags MUST BE disposed of by qualified personnel. SAFETY RESTRAINTS FOR CHILDREN See the following sections for directions on how to properly use safety restraints for children.
Page 136 Seating and safety restraints If the shoulder belt portion of a combination lap and shoulder belt can be positioned so it does not cross or rest in front of the child’s face or neck, the child should wear the lap and shoulder belt. Moving the child closer to the center of the vehicle may help provide a good shoulder belt fit.
Page 137 When installing a child safety seat: Review and follow the information presented in the Air Bag Supplemental Restraint System section in this chapter. Use the correct safety belt buckle for that seating position (the buckle closest to the direction the tongue is coming from).
Page 138 Seating and safety restraints Installing child safety seats in combination lap and shoulder belt seating positions Air bags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active air bag. If you must use a forward-facing child seat in the front seat, move the seat all the way back.
Page 139 Seating and safety restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
Page 140 Seating and safety restraints 7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with your knee on the child seat. 8. Allow the safety belt to retract to remove any slack in the belt.
Page 141 The rear seats of your vehicle are equipped with built-in tether strap anchors located behind the seats as described below. The tether anchors in your vehicle are located in the rear cargo area. The tether strap anchors in your vehicle are in the following positions (shown from top view): Attach the tether strap only to the appropriate tether...
Page 142 Seating and safety restraints 4. Clip the tether strap to the anchor. If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. 5. Refer to the Installing child safety seats in combination lap and shoulder belt seating positions section of this chapter for further instructions to secure the child safety seat.
Page 143 PREPARING TO START YOUR VEHICLE Engine starting is controlled by the powertrain control system. This system meets all Canadian Interference-Causing Equipment standard requirements regulating the impulse electrical field strength of radio noise. When starting a fuel-injected engine, avoid pressing the accelerator before or during starting.
Page 144 Starting Important safety precautions A computer system controls the engine’s idle revolutions per minute (RPM). When the engine starts, the idle RPM runs faster to warm the engine. If the engine idle speed does not slow down automatically, have the vehicle checked. Before starting the vehicle: 1.
Page 145 steering wheel is turned when getting in or out of the vehicle CHECK GAGE CHECK ENGINE <FUEL DOOR CHECK FUEL CAP BRAKE Make sure the corresponding lights illuminate briefly. If a light fails to illuminate, have the vehicle serviced. If the driver’s safety belt is fastened, the STARTING THE ENGINE 1.
Page 146 Starting Using the engine block heater (if equipped) An engine block heater warms the engine coolant, which improves starting, warms up the engine faster and allows the heater-defroster system to respond quickly. Use of an engine block heater is strongly recommended if you live in a region where temperatures reach -23°C (-10°F) or below.
Page 147 Starting Important ventilating information If the engine is idling while the vehicle is stopped in an open area for long periods of time, open the windows at least 2.5 cm (one inch). Adjust the heating or air conditioning (if equipped) to bring in fresh air. Improve vehicle ventilation by keeping all air inlet vents clear of snow, leaves and other debris.
Page 148: Driving
Driving BRAKES Your service brakes are self-adjusting. Refer to the scheduled maintenance guide for scheduled maintenance. Occasional brake noise is normal and often does not indicate a performance concern with the vehicle’s brake system. In normal operation, automotive brake systems may emit occasional or intermittent squeal or groan noises when the brakes are applied.
Page 149 ABS warning lamp warning lamp in the instrument cluster momentarily illuminates when the ignition is turned to the ON position. If the light does not illuminate momentarily at start up, remains on or continues to flash, the ABS needs to be serviced. With the ABS light on, the anti-lock brake system is disabled and normal braking is still effective unless the...
Page 150 Driving Parking brake Apply the parking brake whenever the vehicle is parked. To set the parking brake, press the parking brake pedal down until the pedal stops. The BRAKE warning lamp in the instrument cluster illuminates and remains illuminated (when the ignition is turned ON) until the parking brake is released.
Page 151 STEERING Your vehicle is equipped with power steering. Power steering uses energy from the engine to help steer the vehicle. To prevent damage to the power steering pump: Never hold the steering wheel to the extreme right or the extreme left for more than a few seconds when the engine is running.
Page 152 Driving The air suspension shut-off switch is located in the cargo area behind the left rear quarter trim panel. On vehicles equipped with Air Suspension, turn OFF the Air Suspension switch prior to jacking, hoisting or towing your vehicle. Normal vehicle operation does not require any action by the driver.
Page 153 Your vehicle has the capability to haul more cargo and people than most passenger cars. Depending upon the type and placement of the load, hauling people and cargo may raise the center of gravity of the vehicle. Use extra caution while becoming familiar with your vehicle. Know the capabilities and limitations of both you as a driver and your vehicle.
Page 154 Driving Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn off the ignition whenever you leave your vehicle. If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly. See your dealer or a qualified service technician.
Page 155 N (Neutral) With the gearshift in N (Neutral), the vehicle can be started and is free to roll. Hold the brake pedal down while in this gear. (Overdrive) The normal driving position for the best fuel economy. Transmission operates in gears one through four. (Overdrive) can be deactivated by pressing the transmission control switch on the gearshift lever.
Page 156 Driving 2 (Second) Use 2 (Second) to start-up on slippery roads or to provide additional engine braking on downgrades. Transmission operates only in Second gear. 1 (First) Use 1 (Low) to provide maximum engine braking on steep downgrades. Upshifts can be made by shifting to 2 (Second) or to (Overdrive).
Page 157 Understanding gearshift positions Hold the brake pedal down while you move the gearshift lever from P (Park) to another position. If you do not hold the brake pedal down, your vehicle may move unexpectedly and injure someone. P (Park) To put your vehicle in gear, start the engine, depress the brake pedal, then move gearshift lever out of P (Park).
Page 158 Driving (Overdrive) can be deactivated by pressing the transmission control switch on the end of the gearshift lever. The transmission control indicator light (TCIL) will illuminate on the instrument cluster. Drive – Not shown on the display. Activate by pressing the transmission control switch on the end of the gearshift lever with the gearshift in (Overdrive) position.
Page 159 Forced Downshifts To gain acceleration in passing another vehicle, push the accelerator to the floor. The transmission will downshift to the appropriate gear: fourth, third, second or first gear. FOUR-WHEEL DRIVE (4WD) OPERATION (IF EQUIPPED) For important information regarding safe operation of this type of vehicle, see Preparing to drive your vehicle in this chapter.
Page 160 Driving Positions of the Control-Trac system The Control-Trac system functions in three modes: The 4WD AUTO mode provides four-wheel drive with full power delivered to the rear axle, and to the front axle as required for increased traction. This is appropriate for normal on-road operating conditions, such as dry road surfaces, wet pavement,...
Page 161 If your vehicle is equipped with 4WDor AWD, a spare tire of a different size than the road tires should never be used. Such a tire could result in damage to driveline components and make the vehicle difficult to control. Utility and four-wheel drive vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under...
Page 162 Driving Shifting from 4WD LOW to 4WD AUTO or 4WD HIGH 1. Bring the vehicle to a stop. 2. Depress the brake. 3. Place the gearshift in N (Neutral). 4. Move the 4WD control to the 4WD AUTO or 4WD HIGH position. Driving off-road with 4WD Your vehicle is specially equipped for driving on sand, snow, mud and rough terrain and has operating characteristics that are somewhat...
Page 163 Driving Sand When driving over sand, try to keep all four wheels on the most solid area of the trail. Do not reduce the tire pressures but shift to a lower gear and drive steadily through the terrain. Apply the accelerator slowly and avoid spinning the wheels.
Page 164 Driving When speed control is on and you are driving uphill, your vehicle speed may drop considerably, especially if you are carrying a heavy load. If vehicle speed drops more than 16 km/h (10 mph), the speed control will cancel automatically. Resume speed with accelerator pedal. If speed control cancels after climbing the hill, reset speed by pressing and holding the SET ACCEL button (to resume speeds over 50 km/h (30 mph).
Page 165 Driving off-road with AWD Your vehicle is specially equipped for driving on sand, snow, mud and rough terrain and has operating characteristics that are somewhat different from conventional vehicles, both on and off the road. Maintain steering wheel control at all times, especially in rough terrain. Since sudden changes in terrain can result in abrupt steering wheel motion, make sure you grip the steering wheel from the outside.
Page 166 Driving When driving through water, determine the depth; avoid water higher than the bottom of the hubs (if possible) and proceed slowly. If the ignition system gets wet, the vehicle may stall. Once through water, always try the brakes. Wet brakes do not stop the vehicle as effectively as dry brakes.
Page 167 Automatic transmissions may shift frequently while driving up steep grades. Eliminate frequent shifting by shifting out of D (Drive). Driving on snow and ice An AWD vehicle has advantages over 2WD vehicles in snow and ice but can skid like any other vehicle. Avoid sudden applications of power and quick changes of direction on snow and ice.
Page 168 Driving GVWR (Gross Vehicle Weight Rating): Maximum total weight of the base vehicle, passengers, optional equipment and cargo. The GVWR is specific to each vehicle and is listed on the Safety Certification Label on the driver’s door pillar. GAWR (Gross Axle Weight Rating): Carrying capacity for each axle system.
Page 169 to the front of your vehicle, (potentially including weight added to the cab), the weight added should not exceed the front axle reserve capacity (FARC). Additional frontal weight may be added to the front axle reserve capacity provided you limit your payload in other ways (i.e. restrict the number of passengers or amount of cargo carried).
Page 170 Driving DRIVING THROUGH WATER Do not drive quickly through standing water, especially if the depth is unknown. Traction or brake capability may be limited and if the ignition system gets wet, your engine may stall. Water may also enter your engine’s air intake and severely damage your engine.
Page 171 Do not exceed the maximum loads listed on the Safety Compliance Certification label. For load specification terms found on the label, refer to Vehicle loading in this chapter. Remember to figure in the tongue load of your loaded vehicle when figuring the total weight. GCWR (Gross Combined Weight Rating)/Trailer Weights Rear Engine...
Page 172 Driving Towing trailers beyond the maximum recommended gross trailer weight exceeds the limit of the vehicle and could result in engine damage, transmission damage, structural damage, loss of control, and personal injury. Preparing to tow Use the proper equipment for towing a trailer, and make sure it is properly attached to your vehicle.
Page 173 Trailer lamps Trailer lamps are required on most towed vehicles. Make sure your trailer lamps conform to local and Federal regulations. See your dealer or trailer rental agency for proper instructions and equipment for hooking up trailer lamps. Never connect any trailer lighting to the vehicle’s taillamp circuits, because it may damage the electrical system resulting in fire.
Page 174 Driving Trailer towing tips Practice turning, stopping and backing up before starting on a trip to get the feel of the vehicle trailer combination. When turning, make wider turns so the trailer wheels will clear curbs and other obstacles. Allow more distance for stopping with a trailer attached. The trailer tongue weight should be no more than 10–15% of the loaded trailer weight.
Page 175 Driving LUGGAGE RACK Maximum load is 75 kg (165 lbs), evenly distributed. If it is not possible to distribute the load, position it as far rearward as possible. Adjustable tie down loops (not equipped) must be used to secure the load. To adjust cross-bar position: 1.
Page 176: Roadside Emergencies
In the United States, this card is found in the Owner Guide portfolio in the glove compartment in Ford vehicles and is mailed to you if you own a Mercury or Lincoln. In Canada, it is found in the Roadside Assistance book in the glove compartment.
Page 177 In the United States, you may purchase additional roadside assistance coverage beyond this period through the Ford Auto Club by contacting your Ford or Lincoln Mercury dealer. Similarly in Canada, you may purchase additional coverage beyond the basic coverage period by consulting the Ford Roadside Assistance Club brochure or by calling 1–877–294–CLUB (1–877–894–2582).
Page 178 Roadside emergencies FUEL RESETTING THE FUEL PUMP SHUT-OFF SWITCH RESET The fuel pump shut-off switch is a device intended to stop the electric fuel pump when your vehicle has been involved in a substantial jolt. After a collision, if the engine cranks but does not start, the fuel pump shut-off switch may have been activated.
Page 179 FUSES AND RELAYS Fuses If electrical components in the vehicle are not working, a fuse may have blown. Blown fuses are identified by a broken wire within the fuse. Check the appropriate fuses before replacing any electrical components. Always replace a fuse with one that has the specified amperage rating.
Page 180 Roadside emergencies Passenger compartment fuse panel The fuse panel is located on the left hand side of the instrument panel facing the driver’s side door. Pull the panel cover outward to access the fuses. To remove a fuse use the fuse puller tool provided on the fuse panel cover.
Page 181 The fuses are coded as follows: Fuse/Relay Fuse Amp Location Rating Roadside emergencies Passenger Compartment Fuse Panel Description 7.5A Power Mirror Switch, Power Antenna, Memory Seat 7.5A Blower Motor Relay, Air Bag Diagnostic Monitor 7.5A Left Stop/Turn Trailer Tow Connector Left Headlamp Data Link Connector (DLC) 7.5A...
Page 182 Roadside emergencies Fuse/Relay Fuse Amp Location Rating Passenger Compartment Fuse Panel Description 7.5A Instrument Cluster 7.5A Washer Pump Relay, Rear Washer Pump Relay Brake Pedal Position Switch, Brake Pressure Switch 4 Wheel Anti-Lock Brake System (4WABS) Module, 4WABS Main Relay 7.5A Instrument Cluster Windshield Wiper Motor, Wiper Hi-Lo...
Page 183 Fuse/Relay Fuse Amp Location Rating Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses.
Page 184 Roadside emergencies MEGAFUSE The high-current fuses are coded as follows: Fuse/Relay Fuse Amp Location Rating 60A** 40A** 50A** 30A** 50A** 20A** 20A** 40A** 30A** Power Distribution Box I/P Fuse Panel fuses 1, 9, and 13 Blower Motor Relay 4 Wheel Anti-Lock Brake System (4WABS) Module Power Moon Roof, Accessory Relay Delay...
Page 185 Fuse/Relay Fuse Amp Location Rating 15A* 10A* 30A* 15A* 20A* 15A* 15A* 30A* 15A* 30A* * Mini Fuses ** Maxi Fuses Roadside emergencies Power Distribution Box Fog Lamps and Daytime Running Lamps — Not Used Powertrain Control Module 4 Wheel Anti-Lock System (4WABS) Module Rear Wiper Motor Fuel Pump Relay and RAP Module...
Page 186 Roadside emergencies CHANGING THE TIRES If you get a flat tire while driving, do not apply the brake heavily. Instead, gradually decrease your speed. Hold the steering wheel firmly and slowly move to a safe place on the side of the road. Spare tire information Your vehicle is equipped with a spare tire that must be used for emergencies only.
Page 187 Stowing the spare tire 1. Lay the tire on the ground with the valve stem facing up. 2. Slide the wheel under the vehicle and install the retainer through the wheel center. 3. Turn the jack handle clockwise until the tire is raised to its original position underneath the vehicle.
Page 188 Roadside emergencies 3. Block the diagonally opposite wheel. 4. Use the tip of the lug wrench to remove any wheel trim. 5. Loosen each wheel lug nut, but do not remove them until the wheel is raised off the ground. On vehicles equipped with Air Suspension, turn OFF the Air Suspension switch prior to...
Page 189 Front Rear To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack. The jack is only meant for changing the tire. Never use the front or rear differential as a jacking point.
Page 190 Roadside emergencies 10. Lower the wheel by turning the jack handle counterclockwise. 11. Remove the jack and fully tighten the lug nuts in the order shown. 12. Stow the flat tire, jack and lug wrench. Make sure the jack is fastened so it does not rattle when you drive.
Page 191 Roadside emergencies Preparing your vehicle When the battery is disconnected or a new battery is installed, the transmission must relearn its adaptive strategy. As a result of this, the transmission may shift firmly. This operation is considered normal and will not effect function or durability of the transmission. Over time, the adaptive learning process will fully update transmission operation to its optimum shift feel.
Page 192 Roadside emergencies 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 193 Engines except 4.0L SOHC 4.0L SOHC 5. Ensure that the cables are clear of fan blades, belts, moving parts of both engines, or any fuel delivery system parts. Roadside emergencies...
Page 194 Roadside emergencies Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables.
Page 195 Roadside emergencies 4.0L SOHC 2. Remove the jumper cable on the negative (-) connection of the booster vehicle’s battery.
Page 196 Roadside emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 197 Roadside emergencies WRECKER TOWING If you need to have your vehicle towed, contact a professional towing service or, if you are a member, your roadside assistance center. It is recommended that your vehicle be towed with a wheel lift or flatbed equipment.
Page 198: Maintenance And Care
Maintenance and care SERVICE RECOMMENDATIONS To help you service your vehicle: We highlight do-it-yourself items in the engine compartment for easy location. We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
Page 199 Do not start your engine with the air cleaner removed and do not remove it while the engine is running. OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the steering column on the instrument panel.
Page 200 Maintenance and care IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 4.0L SOHC V6 engine 1. Windshield washer fluid reservoir 2. Automatic transmission fluid dipstick 3. Engine oil filler cap 4. Engine oil dipstick 5. Brake fluid reservoir 6. Power distribution box 7.
Page 201 Maintenance and care 5.0L V8 engine 1. Engine coolant reservoir 2. Windshield washer fluid reservoir 3. Engine oil filler cap 4. Automatic transmission fluid dipstick 5. Brake fluid reservoir 6. Power distribution box 7. Battery 8. Power steering fluid reservoir 9.
Page 202 Maintenance and care 3. Set the parking brake and ensure the gearshift is securely latched in P (Park). 4. Open the hood. Protect yourself from engine heat. 5. Locate and carefully remove the engine oil level indicator (dipstick). 4.0L V6 engine 5.0L V8 engine...
Page 203 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. If the oil level is between the MIN and MAX marks, or between teh MIN and FULL marks the oil level is acceptable. DO NOT ADD OIL. If the oil level is below the MIN mark, add enough oil to raise the level within the MIN-MAX range...
Page 204 Maintenance and care Engine Oil Recommendations 5.0L Engine Look for this certification trademark. SAE 5W-20 engine oil is recommended. Only use oils “Certified For Gasoline Engines” by the American Petroleum Institute (API). Use Motorcraft (Part: XO–5W20–QSP in U.S.) or an equivalent oil meeting Ford Specification WSS-M2C153–H. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.
Page 205 Maintenance and care SAE 5W-30 engine oil is recommended. Only use oils “Certified For Gasoline Engines” by the American Petroleum Institute (API). Use Motorcraft (Part: XO–5W30–QSP in U.S.) or an equivalent oil meeting Ford Specification WSS-M2C153–G. Do not use supplemental engine oil additives, oil treatments or engine treatments.
Page 206 Maintenance and care 2. Visually inspect the fluid level. 3. If necessary, add brake fluid from a clean un-opened container until the level reaches MAX. Do not fill above this line. 4. Use only a DOT 3 brake fluid certified to meet Ford specifications. Refer to Lubricant specifications in the Capacities and specifications chapter.
Page 207 Only use a washer fluid that meets Ford specifications. Refer to Lubricant specifications in the Capacities and specifications chapter. State or local regulations on volatile organic compounds may restrict the use of methanol, a common windshield washer antifreeze additive. Washer fluids containing non-methanol antifreeze agents should be used only if they provide cold weather protection without damaging the vehicle’s paint finish, wiper blades or washer system.
Page 208 Maintenance and care When the engine is cold, check the level of the engine coolant in the reservoir. The engine coolant should be at the “cold fill level” or within the “cold fill range” as listed on the engine coolant reservoir (depending upon application).
Page 209 Adding engine coolant Use only Ford Premium Engine Coolant E2FZ-19549-AA (in Canada, Motorcraft CXC-10) or a premium engine coolant that meets Ford specification ESE-M97B44-A. Use only Ford G05 Engine Coolant WSS—M97B51–A1 (in Canada, Motorcraft CXC-10) or a premium engine coolant that meets Ford specification ESE-M97B44-A.
Page 210 Maintenance and care Plain water may be added in an emergency, but you must replace it with a 50/50 mixture of engine coolant and distilled water as soon as possible. Check the coolant level in the reservoir before you drive your vehicle the next few times (with the engine cool).
Page 211 Coolant refill capacity To find out how much fluid your vehicle’s cooling system can hold, refer to Refill capacities in the Capacities and specifications chapter. Fill your engine coolant reservoir as outlined in Adding engine coolant in this chapter. Severe climates If you drive in extremely cold climates (less than –36°...
Page 212 Maintenance and care CHECKING AND ADDING POWER STEERING FLUID Check the power steering fluid. Refer to the scheduled maintenance guide for the service interval schedules. If adding fluid is necessary, use only MERCON ATF. 4.0L SOHC V6 engine 5.0L V8 engine 1.
Page 213 Maintenance and care 6. If the fluid is low, add fluid in small amounts, continuously checking the level until it reaches the correct operating range. Be sure to put the cap back on the reservoir. TRANSMISSION FLUID Checking automatic transmission fluid (if equipped) Refer to your scheduled maintenance guide for scheduled intervals for fluid checks and changes.
Page 214 Maintenance and care Low fluid level Do not drive the vehicle if the fluid level is at the bottom of the dipstick and the ambient temperature is above 10°C (50°F). COLD DO NOT ADD Correct fluid level The transmission fluid should be checked at normal operating temperature 66°C-77°C (150°F-170°F) on a level surface.
Page 215 High fluid level Fluid levels above the safe range may result in transmission failure. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage. High fluid levels can be caused by an overheating condition. Adjusting automatic transmission fluid levels Before adding any fluid, make sure the correct type is used.
Page 216 Maintenance and care CHECKING AND ADDING TRANSFER CASE FLUID (IF EQUIPPED) 1. Clean the filler plug. 2. Remove the filler plug and inspect the fluid level. 3. Add only enough fluid through the filler opening so that the fluid level is at the bottom of the opening.
Page 217 Maintenance and care BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. However, for severe usage or in high temperature climates, check the battery electrolyte level. Refer to the scheduled maintenance guide for the service interval schedules.
Page 218 Maintenance and care Batteries normally produce explosive gases which can cause personal injury. Therefore, do not allow flames, sparks or lighted substances to come near the battery. When working near the battery, always shield your face and protect your eyes. Always provide proper ventilation.
Page 219 The vehicle may need to be driven 16 km (10 miles) or more to relearn the idle and fuel trim strategy. If you do not allow the engine to relearn its idle trim, the idle quality of your vehicle may be adversely affected until the idle trim is eventually relearned.
Page 220 Maintenance and care Changing the wiper blades To replace the wiper blades: 1. Pull the wiper arm away from the windshield and lock into the service position. 2. Turn the blade at an angle from the wiper arm. Push the lock pin manually to release the blade and pull the wiper blade down toward the windshield to remove it from the...
Page 221 Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
Page 222 Maintenance and care SERVICING YOUR TIRES Checking the tire pressure Use an accurate tire pressure gauge. Check the tire pressure when tires are cold, after the vehicle has been parked for at least one hour or has been driven less than 5 km (3 miles). Adjust tire pressure to recommended specifications found on the Certification Label or the Tire Label.
Page 223 Replacing the tires Replace the tires when the wear band is visible through the tire treads. When replacing full size tires, never mix radial bias-belted, or bias-type tires. Use only the tire sizes that are listed on the Certification Label. Make sure that all tires are the same size, speed rating, and load-carrying capacity.
Page 224 Maintenance and care SNOW TIRES AND CHAINS Snow tires must be the same size and grade as the tires you currently have on your vehicle. The tires on your vehicle have all weather treads to provide traction in rain and snow. However, in some climates, you may need to use snow tires and chains.
Page 225 If you do not use the proper fuel filler cap, excessive pressure or vacuum in the fuel tank may damage the fuel system or cause the fuel cap to disengage in a collision, which may result in possible personal injury. Automotive fuels can cause serious injury or death if misused or mishandled.
Page 226 Maintenance and care Be particularly careful if you are taking “Antabuse” or other forms of disulfiram for the treatment of alcoholism. Breathing gasoline vapors, or skin contact could cause an adverse reaction. In sensitive individuals, serious personal injury or sickness may result. If fuel is splashed on the skin, promptly wash skin thoroughly with soap and water.
Page 227 Maintenance and care Octane recommendations Your vehicle is designed to use “Regular” unleaded gasoline with pump (R+M)/2 octane rating of 87. We do not recommend the use of (R+M)/2 METHOD gasolines labeled as “Regular” that are sold with octane ratings of 86 or lower in high altitude areas. Do not be concerned if your engine sometimes knocks lightly.
Page 228 Maintenance and care Running out of fuel Avoid running out of fuel because this situation may have an adverse affect on powertrain components. If you have run out of fuel: You may need to cycle the ignition from OFF to ON several times after refueling, to allow the fuel system to pump the fuel from the tank to the engine.
Page 229 If you do not use the proper fuel filler cap, excessive pressure or vacuum in the fuel tank may damage the fuel system or cause the fuel cap to disengage in a collision, which may result in possible personal injury. Fuel Filter For fuel filter replacement, see your dealer or a qualified service technician.
Page 230 Maintenance and care For consistent results when filling the fuel tank: Turn the engine/ignition switch to the off position prior to refueling, an error in the reading will result if the engine is left running. Use the same filling rate setting (low — medium — high) each time the tank is filled.
Page 231 Driving style — good driving and fuel economy habits Give consideration to the lists that follow and you may be able to change a number of variables and improve your fuel economy. Habits Smooth, moderate operation can yield up to 10% savings in fuel. Steady speeds without stopping will usually give the best fuel economy.
Page 232 Maintenance and care Conditions Heavily loading a vehicle or towing a trailer may reduce fuel economy at any speed. Carrying unnecessary weight may reduce fuel economy (approximately 0.4 km/L [1 mpg] is lost for every 180 kg [400 lb] of weight carried). Adding certain accessories to your vehicle (for example bug deflectors, rollbars/light bars, running boards, ski/luggage racks) may reduce fuel economy.
Page 233 Do not turn off the ignition while your vehicle is moving, especially at high speeds. Have the items listed in your scheduled maintenance guide performed according to the specified schedule. The scheduled maintenance items listed in the scheduled maintenance guide are essential to the life and performance of your vehicle and to its emissions system.
Page 234 Maintenance and care Readiness for Inspection/Maintenance (I/M) testing In some localities, it may be a legal requirement to pass an I/M test of the on-board diagnostics system. If your “Check Engine/Service Engine Soon” light is on, refer to the description in the Warning Lights and Chimes section of the Instrumentation chapter.
Page 235 Replacing headlamp bulbs To remove the headlamp bulb: 1. Make sure headlamp switch is in OFF position, then lift hood and open the hinged headlamp cover. 2. Disconnect the electrical connector from the bulb by pulling rearward. 3. Remove the bulb retaining ring by rotating it counterclockwise (when viewed from the rear) to free it from the bulb socket, and slide the...
Page 236 Maintenance and care If the bulb is accidentally touched, it should be cleaned with rubbing alcohol before being used. 1. With the flat side of the new bulb’s plastic base facing upward, insert the glass end of the bulb into the lamp assembly. You may need to turn the bulb left or right to align the grooves in the plastic base with the tabs in the lamp assembly.
Page 237 Maintenance and care 4. Rotate bulb socket counterclockwise about ⁄ turn and remove from lamp assembly. 5. Carefully pull bulb straight out of socket and push in the new bulb. 6. Install bulb socket in lamp assembly by turning clockwise. 7.
Page 238 Maintenance and care Replacing license plate lamp bulbs 1. Remove two screws and the license plate lamp assembly from the liftgate. 2. Remove bulb socket from lamp assembly by turning counterclockwise. 3. Pull the bulb out from socket and push in the new bulb. 4.
Page 239 4. Pull the bulb straight out of the socket and push in the new bulb. To complete installation, follow the removal procedure in reverse order. USING THE RIGHT BULBS Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.” for North America and an “E”...
Page 240 Maintenance and care AIMING THE HEADLAMPS The headlamps on your vehicle are properly aimed at the assembly plant. If your vehicle has been in an accident the alignment of your headlamps should be checked by a qualified service technician. CLEANING AND CARING FOR YOUR VEHICLE Refer to the Customer Assistance chapter for a list of Ford-approved cleaners, polishes and waxes.
Page 241 Waxing your vehicle Waxing your vehicle on a regular basis will reduce minor scratches and paint damage. Wax when water stops beading on the surface. This could be every three or four months, depending on operating conditions. Use only carnauba or synthetic-based waxes. Use a cleaning fluid with a clean cloth to remove any bugs before waxing your vehicle.
Page 242 Maintenance and care Cover the highlighted areas to prevent water damage when cleaning the engine. 5.0L 4.0L SOHC Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. Cleaning the wheels Wash with the same detergent as the body of your vehicle.
Page 243 Maintenance and care The brushes used in some automatic car washes may damage the finish on your wheels. Before going to a car wash, find out if the brushes are abrasive. Underbody Flush the complete underside of vehicle frequently. Keep body drain holes unplugged.
Page 244 Maintenance and care Do not use chemical solvents or strong detergents when cleaning the seat mounted side air bag. Such products could contaminate the side air bag system and affect performance of the side air bag in a collision. Cleaning the instrument panel Clean with a damp cloth, then dry with a dry cloth.
Page 245 Maintenance and care Cleaning leather seats (if equipped) To clean, simply use a soft cloth dampened with water and a mild soap. Wipe the leather again with a damp cloth to remove soap residue. Dry with a soft cloth. For tougher soiling concerns, Ford recommends using the Deluxe Leather Care Kit F8AZ-19G253–AA, which is available from your Ford Dealer.
Page 246: Capacities And Specifications
Capacities and specifications MOTORCRAFT PART NUMBERS Component Air filter element Fuel filter Battery Oil filter PCV valve Spark plugs* * Refer to Vehicle Emissions Control Information (VECI) decal for spark plug gap information. ** If a spark plug is removed for inspection, it must be reinstalled in the same cylinder.
Page 247 REFILL CAPACITIES Fluid Ford Part Name Brake fluid High Performance DOT 3 Motor Vehicle Brake Fluid Engine oil Motorcraft SAE (including filter 5W-30 Super change) Premium Motor Motorcraft SAE 5W-20 Super Premium Motor Fuel tank Power steering Motorcraft fluid MERCON Transmission Motorcraft fluid...
Page 248 Capacities and specifications Fluid Ford Part Name Front axle Motorcraft SAE lubricant 80W-90 Premium Rear Axle Lubricant Rear axle Motorcraft SAE lubricant 80W-90 Premium Rear Axle Lubricant Motorcraft SAE 75W-140 High Performance Synthetic Rear Axle Lubricant Windshield Ultra-Clear washer fluid Windshield Washer Concentrate Ensure the correct automatic transmission fluid is used.
Page 249 lubricants are not to be checked or changed unless a leak is suspected or service is required. The axle lubricant should be changed any time the axle has been submerged in water. Add 118 ml (4 oz.) of Additive Friction Modifier C8AZ-19B546-A or equivalent meeting Ford specification EST-M2C118–A for complete refill of Traction-Lok axles.
Page 250 Capacities and specifications Ford part name Item or equivalent Automatic Motorcraft MERCON V ATF XT-5-QM transmission Power steering Motorcraft fluid MERCON ATF Ford conventional and Traction-Lok rear axles Motorcraft SAE 80W-90 Premium Front axle (4X4) Rear Axle Lubricant Transfer case Motorcraft (4X4) MERCON ATF...
Page 251 4.0L vehicles with limited slip differentials and all 5.0L applications use rear axles that are filled with Motorcraft SAE 75W-140 High Performance Synthetic Rear Axle Lubricant, part number F1TZ-19780-B, Ford specification WSL-M2C192-A. 4.0L vehicles with limited slip differentials and all 5.0L applications must add 118 ml (4 oz) of Additive Friction Modifier C8AZ-19B546-A or equivalent meeting Ford specification EST-M2C118-A to the rear axle whenever the axle has been serviced.
Page 252 Capacities and specifications VEHICLE DIMENSIONS Vehicle dimensions (1) Overall length (2) Overall width (3) Maximum height* (4) Wheelbase (5) Track - Front (5) Track - Rear * P255 tire with roof rack mm (in) 4 845 (190.7) 1 832 (72.1) 1 817 (71.5) 2 889 (113.7) 1 547 (60.9)
Page 253 Capacities and specifications...
Page 254: Certification Label
Capacities and specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Certification Label be affixed to a vehicle and prescribe where the Certification Label may be located. The Certification Label is located on the front door latch pillar on the driver’s side.
Page 255: Customer Assistance
You may purchase Ford ESP from any participating Ford and Lincoln Mercury and Ford of Canada dealer. There are several plans available in various time, distance and deductible combinations which can be tailored to fit your own driving needs. Ford ESP also offers reimbursement benefits for towing and rental coverage.
Page 256 Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 257 Ford Motor Company of Canada, Limited P.O. Box 2000 Oakville, Ontario L6J 5E4 1-800-565-3673 (FORD) In order to help you service your Ford or Lincoln Mercury vehicle, please have the following information available when contacting a Customer Relationship Center: Your telephone number (home and business)
Page 258 Unresolved warranty repair concerns or vehicle performance as designed concerns on Ford and Lincoln Mercury cars and Ford and Lincoln Mercury light trucks which are within the terms of any applicable written new vehicle warranty are eligible for review, except those involving:...
Page 259 Ford or Lincoln Mercury dealership representative Consumer candidates for Board membership are recruited and trained by an independent consulting firm. The dealership Board member is chosen from Ford and Lincoln Mercury dealership management, recognized for their business leadership qualities. What the Board needs...
Page 260 Customer assistance a brief summary of the action taken by the dealer(s) and Ford Motor Company the names (if known) of all the people you contacted at the dealership(s) a description of the action you expect to resolve your concern You will receive a letter of explanation if your application does not qualify for Board review.
Page 261 Customer assistance You may also contact the North American Customer Relationship Center at 1-800-392-3673 (Ford), TDD for the hearing impaired: 1-800-232-5952 or by writing to the Center at the following address: Ford Motor Company Customer Relationship Center 16800 Executive Plaza Drive P.O.
Page 262 Customer assistance The use of leaded fuel in your vehicle without proper conversion may damage the effectiveness of your emission control system and may cause engine knocking or serious engine damage. Ford Motor Company/Ford of Canada is not responsible for any damage caused by use of improper fuel.
Page 263 FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of Ford accessories are available for your vehicle through your local authorized Ford, Lincoln Mercury or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 264 Customer assistance Comfort and convenience Cargo net Cargo organizer Cargo shade Cargo tray Engine block heaters Home link visor Tire step Travel equipment Auto headlamps with daytime running lamps (DRL) Cellular phone holder Daytime running lights Factory luggage rack adaptors (bike and ski) Heavy-duty battery Interior mirror, electrochromic with compass (with and without temperature display)
Page 265 Protection and appearance equipment Air bag anti-theft locks Cargo liners, interior Carpet floor mats Cleaners, waxes and polishes Door edge guards Front end covers (full and sport) Hood deflectors Instrument panel trim (simulated wood) Locking gas cap Lubricants and oils Molded splash guards Molded vinyl floor mats Rear spoiler...
Page 266 Customer assistance Mobile communications systems may harm the operation of your vehicle, particularly if they are not properly designed for automotive use or are not properly installed. When operated, such systems may cause the engine to stumble or stall or cause the transmission to be damaged or operate improperly.
Page 267: Reporting Safety Defects
Reporting safety defects REPORTING SAFETY DEFECTS (U.S. ONLY) If you believe that your vehicle has a defect that could cause a crash, or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Ford Motor Company.
Page 268: Index
Index Air bag supplemental restraint system ...127–128, 132 and child safety seats ...129 description ...128, 132 disposal ...135 driver air bag ...130, 133 indicator light ...10, 131, 134 operation ...130, 133 passenger air bag ...130, 133 side air bag ...132 Air cleaner filter ...246 Air conditioning ...22 automatic temperature...
Page 269 Certification Label ...254 Child safety restraints ...135 child safety belts ...135 Child safety seats ...136 attaching with tether straps ..140 in front seat ...138 in rear seat ...138 Cleaning your vehicle ...240 engine compartment ...241 exterior ...241, 243 exterior lamps ...243 instrument cluster lens ...244 instrument panel ...244 interior ...243–244...
Page 270 Index Driveline universal joint and slip yoke ...216 Driving under special conditions ...163, 166 mud ...162–163, 165 sand ...163, 165 snow and ice ...162, 164–165, 167 through water ...163, 165, 170 Emergencies, roadside jump-starting ...190 Emission control system ...232 Engine ...251–252 check engine/service engine soon light ...8 cleaning ...241...
Page 271 engine coolant temperature gauge ...14 engine oil pressure gauge ...16 fuel gauge ...16 odometer ...15 speedometer ...14 tachometer ...15 trip odometer ...15 GAWR (Gross Axle Weight Rating) ...167 calculating ...169 definition ...167 driving with a heavy load ...167 location ...167 GVWR (Gross Vehicle Weight Rating) ...167 calculating ...167, 169...
Page 272 Index Lamps bulb replacement specifications chart ...239 cargo lamps ...22 daytime running light ...21 fog lamps ...21 headlamps ...21 headlamps, flash to pass ...22 instrument panel, dimming ...22 replacing bulbs ...234–238 Lane change indicator (see Turn signal) ...77 Liftgate ...100 Lights, warning and indicator ...8 air bag ...10 anti-lock brakes (ABS) ...10, 149...
Page 273 fluid, checking and adding ...212 fluid, refill capacity ...247 fluid, specifications ...249, 251 Preparing to drive your vehicle ...152 Radio ...36 Relays ...179 Remote entry system ...102–103 illuminated entry ...106 locking/unlocking doors ...103 panic alarm ...103 replacement/additional transmitters ...105 replacing the batteries ...105 Reverse sensing system ...33 Roof rack ...175 Safety belts (see Safety...
Page 274 Index Traction-lok rear axle ...167 Transfer case fluid checking ...216 Transmission ...153 fluid, checking and adding (automatic) ...213 fluid, refill capacities ...247 lubricant specifications ..249, 251 Trip odometer ...15 Turn signal ...11, 77 Vehicle dimensions ...252 Vehicle Identification Number (VIN) ...254 Vehicle loading ...167 Ventilating your vehicle ...147 Warning chimes ...13...
Page 279: Filling Station Information
Item Required fuel Fuel tank capacity 4.0L Engine oil capacity (includes filter change) 5.0L Engine oil capacity (includes filter change) Tire size and pressure Hood release Coolant capacity-(4.0L SOHC V6 engine) Coolant capacity-(5.0L V8 engine) Power steering fluid capacity Automatic transmission fluid capacity (4R70W with 5.0L V8 engine AWD) Automatic transmission fluid...
Page 280 Filling station information handle. MERCON and MERCON V are not interchangeable. DO NOT mix MERCON and MERCON V. Refer to your scheduled maintenance guide to determine the correct service interval. Indicates only approximate dry-fill capacity. Some applications may vary based on cooler size and if equipped with in-tank cooler.The amount of transmission fluid and fluid level should be set by the indication on the dipstick’s normal operating range.

Mercury Mountaineer 2001 Owner's Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mercury Mountaineer 2001

Summary of Contents for Mercury Mountaineer 2001

Table of Contents
