Page 1: User Manual
DVR - HSD8000 / HSD6000 Series User Manual ─ DVR - HSD6000 / HSD8000 Series ─ User Manual This do cument cont ains p reliminary inform ation and subje ct to chang e witho ut notice. - Page 2 WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. NOTE: This equipm ent has b een te sted and fou nd to com ply with the limit s fo r a class digit al device, pu rsuant to p art 15 of the FCC Rul es.
-
Page 3: Table Of Contents
Table of Contents CHAPTER 1 P ACKING DET AIL AND INST ALLATION _____________________ 5 1-1 PACKING ___________________________________________________ 5 1-2 Hard Disk Installation ________________________________________ 6 1-3 DVD-RW Installation(Only Support DVD/RW) ____________________ 7 CHAPTER 2 P ANEL L OCATION ________________________________________ 9 2-1 FRONT PANEL CONTROLS ___________________________________ 9 2-2 16CH REAR PANEL CONNECTORS___________________________ 10 2-3 8CH REAR PANEL CONNECTORS ____________________________ 11 2-4 4CH REAR PANEL CONNECTORS ____________________________ 12... - Page 4 5-2.1.1 CRITERIA SETUP FOR EVENT SEARCH _____________ 42 5-2.2 TIME SEARCH_________________________________________ 43 CHAPTER 6 Remote Sof tware Inst allation an d Setup ____________________ 44 6-1 AP Software Installation and instruction ______________________ 44 6-2 How to do remote monitoring through IE _____________________ 46 6-3 AP Software Operation ______________________________________ 47 CHAPTER 7 SPECIFICAIT ONS_______________________________________ 48 CHAPTER 8 MOBILE APPLICATION INST ALLATION AND USAGE __________ 50...
-
Page 5: Chapter 1 Packing Detail And Installation
CHAPTER 1 PACKING DETAIL AND INSTALLATION 1-1 PACKING 1. DVR 2. Quick Start 3. IR Remote Control 4.Batteries x2 5. CD 6. Hard Disk Mount x2 7.Scre ws x20 8. Power Adaptor 9. Power Cord 10. SATA Cord 2pcs 11.DB25 Connecter Mouse Cat-5 Network Patch Cable Note: Standard shipping products include neither HDD nor DVD R/W... -
Page 6: Hard Disk Installation
1-2 Hard Disk Installation Step 1) Fix the HDD to rack mount with the screws as indicated. Step 2) Place the HDD on the HDD plate and screw it as indicated. Step 3) Connect the power and the SATA cables as indicated. Note: After installation, please initialize Hard Disk before starting to record. -
Page 7: Dvd-Rw Installation(Only Support Dvd/Rw)
1-3 DVD-RW Installation(Only Support DVD/RW) Step 1) Remove the front cover from DVR. Step 2) Put the DVD-RW into the DVR as indicated by the arrow. - Page 8 Step 3) Screw the bottom of the DVR as indicated to fix the DVD-RW. Step 4) Connect the power and the SATA cables.
-
Page 9: Chapter 2 Panel Location
CHAPTER 2 PANEL LOCATION 2-1 FRONT PANEL CONTROLS ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ Control Keys Description Optional DVD-RW backup device. DVD Writer ○ In SETUP mode, press to mo ve cursor down. In PLAYBACK mode, press ○... -
Page 10: 16Ch Rear Panel Connectors
2-2 16CH REAR PANEL CONNECTORS ①②③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ① MAIN monitor BNC port for the main monitor. BNC port to display full screen image of all installed cameras in ② SPOT monitor sequence. -
Page 11: 8Ch Rear Panel Connectors
2-3 8CH REAR PANEL CONNECTORS ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ BNC port to display full screen image of all installed cameras in ① SPOT monitor sequence. ② VIDEO IN BNC input ports for cameras, 8 in total. RCA inp ut port for audio signal. -
Page 12: 4Ch Rear Panel Connectors
2-4 4CH REAR PANEL CONNECTORS ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ BNC port to display full screen ima ge of all installed cameras ① SPOT monitor in sequence. ② VIDEO IN BNC input ports for cameras, 4 in total. RCA input port for audio signal. -
Page 13: Chapter 3 Live, Playback And Ptz Operations
CHAPTER 3 LIVE, PLAYBACK AND PTZ OPERATIONS The IR remote control and mouse operate differently under each mode; this chapter describes the functions of them under three different modes: LIVE, PLAYBACK and PTZ. 3-1 LIVE Mode You can monitor all the channels, listen to audio signal and have some related operations under LIVE mode. - Page 14 Table 3-1.2 Graphical icons that will display after right-clicking your mouse under LIVE mode. Icon Description Resting the cursor on this icon will bring up the following four menu icons. Main menu. Search menu. Backup menu. PTZ mode. Turn on/off recording. Playback.
- Page 15 Table 3-1.3 Description of on screen graphical icons in LIVE mode Icon Description Recording is on Schedule Recording is on Live Audio is on Live Audio is off Motion detected on the channel Sensor triggered on the channel Video loss detected on the channel USB device detected DVD burner is detected Connected to the LAN cable.
-
Page 16: Playback Mode
3-2 PLAYBACK Mode Switch to PLAYBACK mode by pressi ng “PLAY” under the LIVE mode, the graphi cal icon will show up on the upper center of the screen and the operation panel ( see below picture) will show up at right lower corner of the screen. Y ou can drag the p anel by mouse to place it on any location of your screen. - Page 17 Table 3-2.2 The mouse operation under the PLAYBACK mode. Icon Description 」 Fast rewind 「 」Fast forward 「 Play/pause ／ 「▲ / SLOW」 ，slow playback 「▼ / ■」stop playback Playback channel by channel with snap shot display Full screen display Quad display 9-channel display 16-channel display...
-
Page 18: Ptz Mode
3-3 PTZ Mode Switch to the PTZ mode by pressi ng “PTZ” button under the LIVE mode. The PTZ icon will appear on upper left side of screen and the control panel will appear on the down right side of screen. Table 3-3.1 Remote Control functions under the PTZ mode Description Button... - Page 19 Table 3-3.2 Mouse operation under the PTZ mode Icon Description Leave PTZ Mode ，back to the LIVE mode Pre-set num ber N. (0~25 5) Go to pre -set number N. Set current PTZ location at pre-set n umber N. 「TOUR」 ，press to ac tivate pre-set tour ＊...
-
Page 20: Chapter 4 Main Menu Setup
CHAPTER 4 MAIN MENU SETUP To enter the main menu and set up DVR, log-in account and user password are required. The default password of the admi nistrator is “ 123456”. Please ch eck the “A ccount Setup” f or related setup of other log-in users. -
Page 21: Record Setup
Table 4-0.2 The operation of remote control under the setting menu Item Description Switch to dif ferent optio ns under o ne i tem Switch to dif ferent item s MENU Save setup and ba ck to LIVE mode Back to Upp er level of menu with out saving ENTER Enter the menu, or di splay virtual ke yboard PS. -
Page 22: 4-1.1 Quality & Frame Rate Setup
4-1.1 Quality & Frame Rate Setup Note：4CH DVR will display 4 channels and 8CH DVR will display 8 channels. Item Description Normal setup/ Select recording mode event setup Select recording resolution: NTSC:352x240, 704x240, 704x480 Resolution PAL:352X288,704X288,704X576 You can setup quality and FPS separately for record type. Record Type Check/uncheck the box enable/disable selected channel recording Select quality: Lowest/ Low/ Normal/ High/ Highest... -
Page 23: 4-2.1 Motion Setup
4-2.1 MOTION SETUP Item Description When motion detect ，the number of seco nds co ntinuous ala rm Alarm Duration(Seconds) Check the b ox to Enable/Disable p opup screen f unction for a ll channels. When motio n i s dete cted i n LIVE mod e, the dete cted Motion Popup channel image will pop up in full screen display. -
Page 24: 4-2.2 Sensor Setup
Item Description Switch between “select” and “deselect” for cursor-dragging function Mask Mouse Selection Select entire screen as detection area. All Area Detection Deselect entire detection area. Mask All Area Continue setup Continue Save setup and leave Exit & Save Cancel setup and leave Exit &... -
Page 25: Schedule Setup
4-3 SCHEDULE SETUP Except from st arting re cording man ually, you can a lso setup the reco rding time by wee ks and sche dule inclu ding n ormal, motio n detect, an d sen sor det ect re cording type. Item Description Each page provides 10 schedules for setup. -
Page 26: 4-3.2 Holiday Setup
4-3.2 Holiday Setup Since holida ys are dif ferent by dif ferent c ountry and region, you can setu p the holiday of your locatio n accordingly . 4-4 CAMERA SETUP Item Description You can setup independently for each channel. 1~16 Check the box to Enable/Disable mask function for LIVE mode Mask... -
Page 27: Account Setup
4-5 ACCOUNT SETUP The Acco unt Setup menu i s u sed to p rovide role -based pe rmission indep endently setting fo r each user (maximum of 4 users) to access DVR over network. The default admin account and password i s “admin”... -
Page 28: 4-5.2 User Picture Setup
4-5.2 User Picture Setup User can sel ect pictu re wishe d to be cha nged to from ha rd d rive. 4-6 NETWORKING SETUP Item Description Setup mode for network connection: (DHCP、LAN、ADSL). Connect type Enter to set up HTTP HTTP Setup Enter to set up DDNS DDNS Setup... -
Page 29: 4-6.1 Networking Setup
4-6.1 NETWORKING SETUP There are three ways to connect to the network as followed. 4-6.1.1 DHCP When DHCP is selected, IP address will be assigned by DHCP server automatically. 4-6.1.2 LAN Select LAN for network connection, the following information is required. Item Description Enter IP address provided by ISP... -
Page 30: 4-6.1.3 Adsl
4-6.1.3 ADSL Select ADSL for network connection, the following information is required. Item Description Enter user name provided by ISP User Name Enter password provided by ISP Password 4-6.2 HTTP Setup Item Description Check to ena ble HTTP server. Users ca n remotely a ccess into th e Enable HTTP DVR over the network if the HTTP function is activated. -
Page 31: 4-6.3 Ddns Setup
4-6.3 DDNS Setup Item Description Enable/disable DDNS function. Enable DDNS Enter the registered SMTP Server: DDNS Server 、DYNDNS.ORG、NO-IP.ORG、3322.ORG ez-dns、I-DVR.NET＊ Enter the completed registered SMTP Server. (Including username SMTP Server + Server) If the user n ame is h.26 4 and you ch oose i-dvr a s your server, you should enter: h.264.i-dvr.net Enter user name. -
Page 32: Ptz & Rs485 Setup
Item Description Check the box to enable/disable E-mal Notification function. Enable E-mail Notification Enter to set up SMTP Server nam e. SMTP Server (Varie s accordin g to the user) Enter to set up User Name. User Name Enter to set up Password. Password Enter to set up e-mail address of receivers. -
Page 33: System Setup
Item Description Click the box to Enable/Disable PTZ function for each channel. Enable PTZ Set up the p rotocol of PT Z cam. Th e supported protocol a re Protocol PELCO-P, PELCO-D, KND, LI-LIN, SAMSUNG, LG, AVTECH. Click or press to set up PTZ ID. -
Page 34: 4-8.1 Display Setup
4-8.1 DISPLAY SETUP Item Description Set up duration time in secon ds for the interval between ch annels Auto-Seq Interval under Auto-Seq mode. Turn On / Off OSD display Show OSD Turn On / Off DVR illustration and record status display Show DVR Status Turn On / Off date and time display Show Date/Time... -
Page 35: 4-8.2.1 Change Date & Time
Item Description 12HOURS/ 24HOURS Hour Format MM-DD-YY/DD-MM-YY/YY-MM-DD Date Format Choose the position of Time and Date display Date/Time Position Setup time and date of DVR Change Date & Time Set up GMT and Daylight Saving Time. Time Zone Setup Setup automatic synchronization with internet server Internet Time Setup 4-8.2.1 CHANGE DATE &... -
Page 36: 4-8.2.3 Internet Time Setup
4-8.2.3 INTERNET TIME SETUP Synchronize your DVR time with internet time server. Item Description Check to enable DVR automatic sy nchronization function. Effective by this option sele cted, DVR will automaticall Automatic synchronize the time upo n rebooting or by every 24 hours after Synchronization booting. -
Page 37: 4-8.4 Spot Setup
Item Description Enable/Disable keystrokes. Key Tone Enable/Disable buzzer op eration w hen the alarm is triggered for Buzzer sensor, motion and vloss (Video Loss). Enable/Disable the signal to be sent to the RELA Y OUT blocks Relay when the alarm is triggered for sensor, motion and vloss. 4-8.4 SPOT SETUP The DV R ha s two mod es of video output;... -
Page 38: Utility Setup
4-9 UTILITY SETUP Item Description Select to ent er hard disk initialization menu. Please stop HDD Initialization recording before entering this menu. Enter the menu, system will show all the data (model ,volume ) of HDD that installed in DVR. Che ck the HDD you’ d like to initialize then pre ss “S tart”. -
Page 39: Diagnostic
4-10 DIAGNOSTIC Item Description The current firmware version of DVR Version The connected IP add ress of DV R. If disconne cted from net work, the screen will di splay” NET WORK DISCONNECT”. MAC Address of DVR HDD num ber HDD Status HDD C apacity Volume... -
Page 40: Chapter 5 Backup & Search
CHAPTER 5 BACKUP & SEARCH 5-1 BACKUP SETUP User can backup any segment of recorded data in a specified time frame. To do so, either a CD R/W o r storage devi ce, like U SB, mu st be conn ected to the DVR. Re corded dat a can al so backup into NB/PC through our rem ote access sof tware: 「DVRemoteDesktop.exe」... -
Page 41: Search Setup
5-2 SEARCH SETUP Item Description Event search menu Event Search Enter time search menu Time Search 5-2.1 EVENT SEARCH The DVR automatically records events with type, time and channel information included. If there is re cording data for an event, a yellow sig will be shown on the lef t side of time information. -
Page 42: 5-2.1.1 Criteria Setup For Event Search
Item Description Setup conditions of event search Criteria Switch between pages of events Page Date/time when event occurred. Date/Time Event type, defined a s followin g Motion Detected MOTION Sensor Detected SENSOR Video Loss Video Loss user log-in over the network Remote Login Event Type user log-out over the network... -
Page 43: 5-2.2 Time Search
5-2.2 TIME SEARCH TIME SEARCH can search for the specific time of recording data to playback. Press “Enter” or left click on the desired date to playback. Note that dates with recording data are marked with a red square “ “System will start playi ng back according to the da te you selected. -
Page 44: Chapter 6 Remote Software Installation And Setup
CHAPTER 6 Remote Software Installation and Setup 6-1 AP Software Installation and instruction AP software:「DVR Remote Desktop」can allow you to remotely access and control the DVR from PC. p.s. Operation system currently supports Windows XP SP2 and above and Window s Vista, Windows 7 Step One：Enter the IP address of DVR in IE browser Step Two: Windows as below will show up. - Page 45 Step Four: Run or Save our AP software. Step Five: If you choose to run the software, Start window will be shown up. Please enter information of login DVR: IP, Port, Username and Password, or choose “Play Recorded File” to open backup files in your PC. Step Six: You’ve logged into the DVR Note：4CH DVR will display 4 channels and 8CH DVR will display 8 channels.
-
Page 46: How To Do Remote Monitoring Through Ie
6-2 How to do remote monitoring through IE Step One：Enter the IP address of DVR in IE browse r. The address appeared in this image is only for demonstration. Actual address is depending on the setup of on-site DVR. Step Two: Windows as below will show up. Please enter the user name and password. Default user name and password is admin/123456. -
Page 47: Ap Software Operation
Step Four: DVR ima ges appea r. Note：4CH DVR will display 4 channels and 8CH DVR will display 8 channels. 6-3 AP Software Operation Open the fi le “DV RemoteDesktop.exe”; enter th e i nformation of DVR “IP ad dress”, “Po rt” “Username”... -
Page 48: Chapter 7 Specificaitons
CHAPTER 7 SPECIFICAITONS 1. VIDEO Input Level 1.0 Vp-p±10% Composite, 75 Balanced NTSC 480 fps(16CH), 240fps(8CH), 120fps(4CH) Display Speed 400 fps(16CH), 200fps(8CH) , 100fps(4CH) NTSC 720(H) X 480(V) Display Resolution 720(H) X 576(V) Monitor Output 2Vp-p Composite, 75 Balanced 2. RECORDING Compression Method H.264 Recording Speed... - Page 49 7. ENVIRONMENTAL 5℃ ~ + 40℃ Operatio n Temperature Humid ity Less than 90% 8. PHYSICAL Dimension 430(W) x 293(D) x 55(H) mm Weight 2.5kg (3.5kg including 1 HDD and DVD-RW) 9. BACKUP USB Stick Video Data, Audio ±RW BACKUP Video Data, Audio Network Video Data, Audio...
-
Page 50: Chapter 8 Mobile Application Installation And Usage
CHAPTER 8 MOBILE APPLICATION INSTALLATION AND USAGE You can remotely monitor all channels of DVR through your mobile device. The required mobile application is from DVR m anufacturer and it supports mobile OS for both Windows mobile 5.0 above and Symbian. Please confirm network function of DVR has been activated before mobile connection: Main menu ... -
Page 51: 8-1.2 Mobile Application Operation
8-1.2 Mobile Application Operation After the installation, enter the Prog ram Files me nu in your mobile device to run a file called “DVRH264”. Select “Menu” at the right lo wer corner of your mobile screen, 4 commands, Login Add Modify and Delete, will show up. -
Page 52: 8-1.2.3 Modify The Login Information Of Dvr
8-1.2.3 Modify the Login Information of DVR You can use the “Modify” command to cha nge the login inform ation of DVR. The dialog ue is identical to that of the “Add” command. 8-1.2.4 Delete the Login Information of DVR “Delete”... -
Page 53: 8-1.3.1 Scroll The Image
8-1.3.1 Scroll the Image You can use the keypad on your mobile device to scroll the image if it’s oversized. Key Ac tion 2 Scroll 4 Scroll Left 6 Scroll Right 8 Scroll Down 8-1.3.2 Image Quality Setup Select “Quality” under the “Menu” There will be 5 levels for your to choose: Low、... -
Page 54: 8-1.3.4 Size Of Image
8-1.3.4 Size of Image The screen size of dif ferent mobile de vice ca n be dif ferent. You can sele ct “ Size” un der t he “Menu” to choose from “Original” or “Fit Screen” to resize the display image. Item Description Original... -
Page 55: Mobile Application Installation And Operation For Windows Mobile System
8-2 Mobile Application Installation and Operation for Windows Mobile System There are two kind s of application s for Wind ow M obile OS: JPEG comp ression an d H.2 64 compression. The one for H.264 compression can transfer both audio and video signal to your mobile device. -
Page 56: 8-2.2 Mobile Application Operation
8-2.2 Mobile Application Operation After the inst allation, ente r the Program Files menu in your mo bile device to run files n amed “Jrviewer” and “H264Pocket”. This application allo ws yo u to re motely logon an d monitor DVR. Pre ss “OK” to brin g up the operation menu, see below chart to further information. -
Page 57: 8-2.3 Operation Under The Live Monitoring
8-2.3 Operation under the LIVE monitoring. After successful logon the DVR, press “V iew” to bring up ope ration menu. Y ou can choose t he channel, re size t he i mage, choose t he quality, and t urn o n/off th e status bar, alarm, full scre en di splay….etc Item Function... -
Page 58: Chapter 9 Cms Installation And Usage Guide
CHAPTER 9 CMS INSTALLATION AND USAGE GUIDE 9-1 CMS Installation System Requirement: Intel Pentium 4 processor or equivalent. ＊ Microsoft Windows Vista、Windows XP、Windows 2003 Server. ＊ Besides OS and other required APs, there will be 512MB remaining memory needed or above. ＊... - Page 59 5.”Confirm Installation” wind ow shows. S elect ‘ Next’ then the inst allation st arts. 6. Select ‘ Close’ to finish inst allation when the “ Installation Complete” windo w sh ows.
-
Page 60: Instruction For Log-In Failure To Cms After Upgrade
Instruction for Log-in Failure to CMS After Upgrade Log in to CMS with the default accou nt and p assword af ter CMS upgrad e. If an error message occurs as shown in the image, please follow the instruction to solve the error. Step 1: Please enter file manager to enter folder, “Windows”... -
Page 61: Cms Login And Environment
9-2 CMS LOGIN AND ENVIRONMENT To enter CM S, the administrator ’s u ser name and password a re req uired. The default s a re ‘admin’ and ‘123456’. After successful login, the following image shows on your screen: ③ ①... -
Page 62: Dvrs, Groups & Events
9-3 DVRs, Groups & Events Icon Description View list of logged in DVR／ G roup. View Logs: list all the event information of DVR ／ 9-3.1 View DVR Group List Single lef t click on ‘ DVR’ or ‘ Group’ will expand/collapse the entire DV Rs an d groups list. -
Page 63: 9-3.2 View Event Logs
9-3.2 View Event Logs Under th is p age, a ll the events of a DVR can be exp anded/collapsed in the order of mote in/Remote ou t, Video Loss , Motion, Sensor, Others ( Power Rese t, Ke y Lock, Key Unlock, HD Full). -
Page 64: Main Display
9-5 Main Display The main display area is whe re the live image of DVR is sho wn. You can dra g to change the location of screen for each channel and turn on/off audio signal with mouse-click. 9-5.1 Audio Control In live mode, you can turn on/of f the audio signal of Ch1 ~Ch4: 」Audio signal is O n... -
Page 65: 9-5.2 Emap Display
9-5.2 eMAP Display In Live mode, pressin g will bring th e e-MAP dra g-down m enu. If the cha nnel ha s been set up to use e-M AP, the menu will sh ow all the e-MA P titles that have bee n entitled to this ch annel;... -
Page 66: 9-5.3 Ptz Control
9-5.3 PTZ Control In the main displ ay, right click on the chan nel will bring up PT Z control p anel as b elow. Icon De scription 8 dire ction key Rotate the P TZ ZOOM+：Zoom i n ZOOM : Zoom out Setup the PTZ spot a s pre -set N. -
Page 67: Operation Bar
9-6 Operation Bar 10 Ope rations to be liste d as bel ow: Table 9-6.1 descri ption o f 10 operatio ns: Icon De scription User Admini stration. Plea se s ee “9 -6.1 User ad ministration” DVR Admini stration. Plea se see “9-6.2 DVR Admi nistration” Group Admin istration. -
Page 68: 9-6.1 User Administration
9-6.1 User administration Before the CMS can b e used on a PC, user accounts should be added with p roper authority. Each user should also be assigned a password and optionally a description. If a user does not have certain authority assigned, he/she will not be a ble to ope rate the co rresponding function on the Operation Bar. -
Page 69: 9-6.3 Group Administration
9-6.3 Group Administration A ‘Grou p’ me ans a set of video ch annels from on e or many DV Rs, which m eans, use r can organize channels from different DVRs to be set in a group. This function allows you to monitor and manager channels from multiple DVRs easily and flexible. -
Page 70: 9-6.4 Emap Administration
9-6.4 eMap Administration If geographi cal location s are releva nt, or if it is desired to use a picture as the backgroun d, eMap can be used for the purpose. With eMap, the background picture can b e picked by th e user and channels from multiple DVRs can be placed and dragged around on the picture. -
Page 71: 9-6.5 Remote Play
9-6.5 Remote Play Video image s re corded o n a DVR ca n be displ ayed on a rem ote CMS. With Remote Pl ay function, select a DV R and a displ ay mode on t op of the screen. Af ter the re corded segments are listed below, double click on one to show its image on the right. -
Page 72: 9-6.6 Hdd Playback
9-6.6 HDD Playback You can directly play the recording data in the HDD that’s uninstalled from DVR by CMS. See the picture below, the left part of screen is recording data in list that’s separated by hour and the right p art is main displ ay. You can ch ange the display modes and play files fast forwa rd or rewind. -
Page 73: 9-6.8 Event Playback
9-6.8 Event Playback Event recordings on the DVR can be played back in CMS. Steps to follow: 1. Select a DVR and a display mode. 2. Select a date. 3. Double click an event and play back the images on the right. Use buttons at the bottom to control the playback. -
Page 74: 9-6.10 Recording Data
9-6.10 Recording Data It can play all the re cording files you’ve recorded in l ine in “Re cording Data”. You can play or delete them here. Steps to follow: 1. Choose the recording time at upper left corner, it will be played on the main display. 2. -
Page 75: Appendix I I-Dvr.net Regist Ration
APPENDIX I I-DVR.NET REGISTRATION DDNS Registration on I-DVR.NET In the p ackage of each DVR, you will find a st icker sho ws a ccount information inclu ding username and password that allows users to login I-DVR.NET for registration. To register DDNS on I-DVR.NET, please follow the steps as shown. Step 1. - Page 76 Step 4. Enter DVR →Main Menu → Ne twork Setup → DDNS. Activate DDNS functions and input related information. DDNS work properly when this option selected. This part of the information required and the same within the i-dvr.net Step 5.Back to the i-dvr.net, on this page by pressing "F5: Refresh", IP will be automatically updated into the DVR of the real IP location.
-
Page 77: Appendix Ii Remote Monitoring Ie Activex Control Installation Instruction
APPENDIX II Remote Monitoring IE ActiveX Control Installation Instruction When usin g IE for remote monitoring f or the first time, IE ActiveX Control i s needed to b e downloaded. 1. When remote monitoring o n IE for the firs t time, an alert mess age occurs “Install ActiveX control”... - Page 78 4. After installation, IE remote monitoring image appears. 5. If message, “Your security Settings do not allow web sites to use ActiveX controls installed on your computer.” pops on when logging in, please follow the next instruction. 6. First select “Tools” on the tool bar and then select “Internet Options”...
- Page 79 7. Selec t Security →Trusted Sites → Sites 8. Enter DVR a ddress (Thi s addre ss is onl y for demonstration. Please use th e addre ss depends on the setup of on-site DVR.) into the blanks sho wn in picture, and then pre ss “add.”...
- Page 80 9. Newly added website will appear at the trusted web sites list. Press close. 10. Go back to IE window, press refresh button or F5.
