Table of Contents

Advertisement

Quick Links

Operator's Manual
C-Class Wagon

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C-CLASS WAGON C 240 and is the answer not in the manual?

Questions and answers

Related Manuals for Mercedes-Benz C-CLASS WAGON C 240

Summary of Contents for Mercedes-Benz C-CLASS WAGON C 240

  • Page 1 Operator’s Manual C-Class Wagon...
  • Page 2 Ê4Ct5g^Ë 2035842171 Order No. 6515 0143 13 Part No. 203 584 21 71 USA Edition B 2005...
  • Page 3 C 240 C 240 4MATIC...
  • Page 4 Your Mercedes-Benz represents the ef- forts of many skilled engineers and crafts- men. To help assure your driving pleasure, and also the safety of you and your passen-...

  • Page 5: Table Of Contents

    Operator’s Manual ... 10 Service and warranty information .. 10 Important notice for California retail buyers and lessees of Mercedes-Benz automobiles ... 11 Maintenance ... 12 Roadside Assistance ... 12 Change of address or ownership... 12 Operating your vehicle outside the USA or Canada...
  • Page 6 Contents Safety and Security ... 59 Occupant safety... 60 Air bags ... 61 Seat belts ... 66 Children in the vehicle... 70 Blocking of rear door window operation... 82 Panic alarm* ... 83 Activating ... 83 Deactivating ... 83 Driving safety systems... 85 ABS ...
  • Page 7 Automatic transmission... 162 One-touch gearshifting... 164 Gear ranges ... 165 Gear selector lever position ... 166 Automatic shift program ... 168 Driving tips... 169 Emergency operation (Limp Home Mode) ... 170 Good visibility ... 171 Headlamp cleaning system* ... 171 Rear view mirrors...
  • Page 8 Contents Driving systems ... 247 Cruise control... 247 Loading ... 250 Roof rack*... 250 Parcel net in cargo compartment... 250 Storage compartment under cargo compartment floor... 251 Retractable luggage cover and partition net ... 252 Split rear bench seat ... 254 Loading instructions...
  • Page 9 Maximum tire load ... 323 Maximum tire inflation pressure .. 324 Uniform Tire Quality Grading Standards (U.S. vehicles) ... 325 Tire ply material ... 327 Tire and loading terminology... 327 Rotating tires ... 331 Winter driving ... 332 Winter tires ... 332 Block heater (Canada only) ...
  • Page 10 Contents Technical data... 417 Parts service ... 418 Warranty coverage... 419 Loss of Service and Warranty Information Booklet... 419 Identification labels... 420 Layout of poly-V-belt drive ... 421 C 240 (all models) ... 421 Engine... 422 Rims and Tires ... 423 Same size tires ...

  • Page 11: Introduction

    Product information Please observe the following in your own best interest: We recommend using genuine Mercedes-Benz parts as well as conversion parts and accessories explicitly approved by us for your vehicle model. We have tested these parts to determine their reliability, safety and special suitability for Mercedes-Benz vehicles.

  • Page 12: Operator's Manual

    Therefore, you may find explanations for optional equipment not installed in your vehicle. If you have any questions about the operation of any equipment, your authorized Mercedes-Benz Center will be glad to demonstrate the proper proce- dures. We continuously strive to improve our...

  • Page 13: Mercedes-Benz Automobiles

    30 calender days. Written notification should be sent to us, not a dealer, at Mercedes-Benz USA, LLC, Customer Assistance Center, One Mercedes Drive, Montvale, NJ 07645-0350.

  • Page 14: Maintenance

    Calls to the toll-free Roadside Assistance number 1-800-FOR-MERCedes (in the USA) 1-800-387-0100 (in Canada) will be answered by Mercedes-Benz Customer Assistance Representatives 24 hours a day, 365 days a year. For additional information refer to the...

  • Page 15: Operating Your Vehicle Outside The Usa Or Canada

    Certain Mercedes-Benz models are avail- able for delivery in Europe under our Euro- pean Delivery Program. For details, consult an authorized Mercedes-Benz Center or...

  • Page 16: Where To Find It

    Here you will find all the information you need for your first drive. You should read this section first if this is your first Mercedes-Benz vehicle or if you are rent- ing or borrowing this vehicle. Safety and Security Here you will find descriptions of the safety features of your vehicle.

  • Page 17: Symbols

    Symbols The following symbols are found in this Operator’s Manual: Optional equipment is identified with an asterisk. Since standard equipment varies between models, the descriptions and illustrations in this manual may differ slightly from the actual equipment of your vehi- cle.

  • Page 18: Operating Safety

    Electronic malfunctions could seriously impair the operating safety of your vehicle. See an authorized Mercedes-Benz Center for repairs or modifications to electronic components. Other improper work or modifications on the vehicle could also have a negative impact on the operating safety of the vehicle.

  • Page 19: Problems With Your Vehicle

    If you should experience a problem with your vehicle, particularly one that you believe may affect its safe operation, we urge you to immediately contact an authorized Mercedes-Benz Center to have the problem diagnosed and corrected if required. If the matter is...

  • Page 20: Reporting Safety Defects

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Mercedes-Benz USA, LLC. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 21: Vehicle Data Recording

    Vehicle data recording Information regarding electronic recording devices (Including notice pursuant to California Code § 9951) Please note that your vehicle is equipped with devices that can record vehicle systems data and, if equipped with the Tele Aid system, may transmit some data in certain accidents. This information helps, for example, to diagnose vehicle systems after a collision and to continuously improve vehicle safety.

  • Page 23: At A Glance

    At a glance Cockpit Instrument cluster Multifunction steering wheel Center console Overhead control panel Door control panel...

  • Page 24: Cockpit

    At a glance Cockpit...
  • Page 25 Item Page 1 Cruise control lever 2 Multifunction steering wheel 3 Horn 4 Instrument cluster 5 Overhead control panel 6 Glove box lid release 7 Glove box lock 8 Center console Item Page 9 Starter switch a Hood lock release b Steering wheel adjustment handle (manual) c Steering wheel adjustment...

  • Page 26: Instrument Cluster

    At a glance Instrument cluster...

  • Page 27: Brake Warning

    Item Page 1 Speedometer with: v Electronic Stability Program (ESP) warning lamp ; Brake warning lamp, USA only 3 Brake warning lamp, Canada only B Low beam head- lamp indicator lamp 2 L Left turn signal indicator lamp 3 Multifunction display with: Trip odometer Main odometer...

  • Page 28: Multifunction Steering Wheel

    At a glance Multifunction steering wheel Item Page 1 Multifunction display Operating control system 2 Selecting the submenu or setting the volume: Press button æ up/to increase ç down/to decrease 3 Telephone*: Press button s to take a call t to end a call Item Page 4 Menu systems:...

  • Page 29: Important Notice For California Center Console

    Center console Upper part Item Page 1 Seat heating*, driver’s side 2 ESP control switch 3 Hazard warning flasher switch – switching on/off 4 Central locking switch Central unlocking switch 5 Tow-away alarm switch* Anti-theft alarm system indicator lamp* 6 Seat heating*, passenger side At a glance Center console...

  • Page 30: Lower Part

    At a glance Center console Lower Part Item Page 1 Ashtray Cigarette lighter 2 Gear selector lever for automatic transmission 3 Cup holders 4 Armrest 5 Program mode selector switch for automatic transmission...

  • Page 31: Overhead Control Panel

    Overhead control panel 1 Rear interior lighting 2 Power tilt/sliding sunroof* 3 Right reading lamp on/off 4 Interior lighting control 5 Hands-free microphone for Item Page 6 Interior rear view mirror on/off 7 Garage door opener* 8 Left reading lamp on/off 9 Tele Aid* (emergency call 158, Tele Aid* (emergency call...

  • Page 32: Door Control Panel

    At a glance Door control panel Item Page 1 Door handle 2 Memory function* (for storing seat, exterior mirror and steering wheel settings) 3 Switches for seat adjustment* 4 Switches for opening/closing front door windows 5 Switch for rear door window override 6 Switches for opening/closing rear door...

  • Page 33: Getting Started

    Getting started Unlocking Adjusting Driving Parking and locking...

  • Page 34: Unlocking

    Getting started Unlocking The “Getting started” section provides an overview of the vehicle’s most basic func- tions. First-time Mercedes-Benz owners should pay special attention to the infor- mation given here. If you are already familiar with the basic functions described here, the “Controls in detail”...

  • Page 35: Starter Switch Positions

    Starter switch positions Warning! When leaving the vehicle, always remove the SmartKey from the starter switch, take it with you, and lock the vehicle. Do not leave children unattended in the vehicle, or with access to an unlocked vehicle. Unsuper- vised use of vehicle equipment may cause an accident and/or serious personal injury.
  • Page 36 Getting started Unlocking When you switch on the ignition, the indicator and warning lamps (except low beam headlamp indicator lamp, high beam headlamp indicator lamp, and turn signal indicator lamps unless activated) in the instrument cluster come on. This indicates that the respective systems are operational.

  • Page 37: Adjusting

    Adjusting Warning! All seat, head restraint, steering wheel, and rear view mirror adjustments, as well as fas- tening of seat belts, must be done before the vehicle is put into motion. Seats The seats can be adjusted either manually or electrically, depending on the vehicle’s equipment.
  • Page 38 Getting started Adjusting Manual seat adjustment 1 Seat fore and aft adjustment 2 Seat cushion tilt 3 Seat backrest tilt 4 Seat height Seat fore and aft adjustment Lift handle 1. Slide seat to the desired position. Allow handle 1 to reengage. Check for proper engagement before driving.
  • Page 39 Head restraint height 1 Release button Raising: Manually adjust the height of the head restraint by pulling it upward. Lowering: To lower head the restraint, push release button 1 and push down on the head restraint. Warning! For your protection, drive only with properly positioned head restraints.
  • Page 40 Getting started Adjusting Power seat* adjustment The seat adjustment switches are located in each front door. 1 Head restraint height 2 Seat height 3 Seat cushion tilt 4 Seat fore and aft adjustment 5 Seat backrest tilt Switch on ignition ( page 33). Open the respective door.

  • Page 41: Steering Wheel

    Warning! For your protection, drive only with properly positioned head restraints. Adjust head restraint so that the center of the head restraint supports the back of the head at eye level. This will reduce the poten- tial for injury to the head and neck in the event of an accident or similar situation.

  • Page 42: Steering Wheel Adjustment

    Getting started Adjusting Steering wheel adjustment, manual 1 Handle To unlock the steering column, pull handle 1 out to its stop limit. Move steering wheel to the desired position. To lock the steering column, push handle 1 all the way in until it engages.

  • Page 43: Mirrors

    Adjusting steering column in or out Move stalk forward or back in the direction of arrow 1 until a comfort- able steering wheel position is reached with your arms slightly bent at the elbow. Adjusting steering column up or down Move stalk up or down in the direction of arrow 2.
  • Page 44 Getting started Adjusting The buttons are located above the exterior lamp switch. 1 Adjustment button 2 Passenger-side exterior rear view mirror button 3 Driver’s side exterior rear view mirror button Switch on ignition ( page 33). Press button 3 for the driver’s side exterior rear view mirror or button 2 for the passenger-side exterior rear view mirror.

  • Page 45: Driving

    Driving Warning Do not lay any objects in the driver’s foot- well. Be careful that floor mats or carpets in the driver’s footwell have sufficient clear- ance for the pedals. During sudden driving or braking maneuvers the objects could get caught between the pedals.
  • Page 46 Getting started Driving Warning! Never let more people ride in the vehicle than there are seat belts available. Be sure everyone riding in the vehicle is correctly restrained with a separate seat belt. Never use a seat belt for more than one person at a time.
  • Page 47 Belt outlet height adjustment Adjust seat belt so that shoulder portion is located as close as possible to the middle of your shoulder (it should not touch the neck or pass under the arm). Belt outlet, front seats 4 Release button Belt outlet, rear seats 5 Release button Raising...

  • Page 48: Starting The Engine

    In a crash, they may not be able to provide adequate protection. Damaged seat belts or belts that were highly stressed in an accident must be replaced. Contact an authorized Mercedes-Benz Center. Starting the engine Warning! Inhalation of exhaust gas is hazardous to your health.

  • Page 49: 29 D Parking Brake Pedal

    Get a jump start ( page 406). If the engine does not start after several starting attempts, there could be a mal- function in the engine electronics or in the fuel supply system. Notify an authorized Mercedes-Benz Center. Getting started Driving Parking brake...
  • Page 50 Getting started Driving Release parking brake by pulling on handle 1. The warning lamp ; (USA only) or 3 (Canada only) in the instrument cluster goes out. Driving Depress the brake pedal. Move gear selector lever to position D or R. Wait for the gear selection process to complete before setting the vehicle in motion.

  • Page 51: Switching On Headlamps

    Warning! It is dangerous to shift the gear selector lever out of P or N if the engine speed is higher than idle speed. If your foot is not firmly on the brake pedal, the vehicle could accelerate quickly forward or in reverse. You could lose control of the vehicle and hit someone or something.

  • Page 52: Turn Signals

    Getting started Driving Push combination switch in direction of arrow 1. The high beam headlamp indicator lamp A in the instrument cluster comes on ( page 24). Turn signals The combination switch is located on the left of the steering column. Combination switch 1 Turn signals, right 2 Turn signals, left...
  • Page 53 Switching on windshield wipers Turn the combination switch to the desired position depending on the intensity of the rain. 0 Windshield wipers off Intermittent wiping II Normal wiper speed III Fast wiper speed Vehicles without rain sensor: When the vehicle is standing still, the wiper speed returns to next lower setting.
  • Page 54 Remove blockage. Turn the windshield wipers on again. If windshield wipers fail to function at all in switch position I, set the combination switch to the next highest wiper speed have the windshield wipers checked at the nearest authorized Mercedes-Benz Center...

  • Page 55: Rear Window Wiper

    Rear window wiper The combination switch is located on the left of the steering column. Combination switch 1 Rear window wiper switch 2 Wiping rear window with washer fluid 3 Intermittent wiping 4 Rear window wiper off 5 Wiping rear window with washer fluid Switch on ignition ( page 33).

  • Page 56: Problems While Driving

    Unburned gasoline may have entered the catalytic converter and damaged it. Give very little gas. Have the problem repaired by an au- thorized Mercedes-Benz Center as soon as possible. The coolant temperature is above 248°F (120°C) The coolant is too hot and is no longer cooling the engine.

  • Page 57: Parking And Locking

    Parking and locking You have now completed your first drive. You have properly stopped and parked your vehicle. End your drive as follows. Warning! With the engine not running, there is no power assistance for the brake and steering system. In this case, it is important to keep in mind that a considerably higher degree of effort is necessary to brake and steer the vehicle.

  • Page 58: Switching Off Headlamps

    Getting started Parking and locking Warning! When leaving the vehicle, always remove the SmartKey from the starter switch, take it with you, and lock the vehicle. Do not leave children unattended in the vehicle, or with access to an unlocked vehicle. Children could release the parking brake and/or move the gear selector lever from position P, either of which could result in an...

  • Page 59: Turning Off Engine

    Turning off engine Place the gear selector lever in position P. Always set the parking brake in addition to shifting to position P. On slopes, turn the front wheels towards the road curb. Turn the SmartKey in the starter switch to position 0 and remove the SmartKey from the starter switch.

  • Page 61: Safety And Security

    Safety and Security Occupant safety Panic alarm* Driving safety systems Anti-theft systems...

  • Page 62: Occupant Safety

    Safety and Security Occupant safety In this section you will learn the most important facts about the restraint system components of the vehicle. Seat belts ( page 66) Child restraints ( page 79) Lower anchors and tethers for children (LATCH) ( page 80) Supplemental Restraint System (SRS) with Air bags ( page 61) Air bag control unit (with crash...

  • Page 63: Air Bags

    Mercedes-Benz Center. If it is necessary to modify an air bag system to accommodate a person with disabilities, contact your local authorized Mercedes-Benz Center or call our Customer Assistance Center at 1-800-FOR-MERCedes (1-800-367-6372) for details. Safety and Security...
  • Page 64 If you have any prob- lems, please see an authorized Mercedes-Benz Center. Failure to follow these instructions can Do not lean your head or chest close to result in severe injuries to you or other the steering wheel or dashboard.
  • Page 65 Mercedes-Benz Center at an additional cost. Please contact your local authorized Mercedes-Benz Center or call our Customer Assistance Center at 1-800-FOR-MERCedes (1-800-367-6372) for details. Safety and Security Occupant safety...
  • Page 66 Only use belts installed or supplied by an authorized Mercedes-Benz Center. Air bags and emergency tensioning devices (ETDs) are designed to function on a one-time-only basis. An air bag or ETD that is deployed must be replaced.
  • Page 67 These instructions are available from your authorized Mercedes-Benz Center. Given the considerable deployment speed, required inflation volume, and the textile structure of the air bags,...

  • Page 68: Seat Belts

    Safety and Security Occupant safety The air bags will not deploy in impacts which do not exceed the system’s deployment thresholds. You will then be protected by the fastened seat belts. The passenger front air bag will only be deployed if: the system, based on OCS weight sensor readings, senses that the front passenger seat is occupied...
  • Page 69 Warning! For information on infants and children traveling with you in the vehicle and Always fasten your seat belt before driving restraint systems for infants and off. Always make sure all of your passengers children, see “Children in the vehicle” are properly restrained, even those sitting in ( page 70).
  • Page 70 Only use seat belts which have been approved by Mercedes-Benz. Do not make any modifications to the seat belts. This can lead to unintended activation of the ETDs or to failure.
  • Page 71 Never wear belts over rigid or breakable objects in or on your clothing, such as eyeglasses, pens, keys, etc., as these might cause injuries. Position the lap belt as low as possible on your hips and not across the abdo- men.

  • Page 72: Children In The Vehicle

    When disposing of the emergency tension- ing device, our safety instructions must be followed. These are available at your authorized Mercedes-Benz Center. Children in the vehicle If an infant or child is traveling with you in the vehicle:...
  • Page 73 Warning! Information on child seats with mount- ing fittings for tether anchorages Never release the seat belt buckle while the ( page 79). vehicle is in motion, since the special seat For information on LATCH-type child belt retractor will be deactivated. seat mounts ( page 80).
  • Page 74 Safety and Security Occupant safety Children can be killed or seriously injured by an inflating air bag. Note the following important information when circumstances require you to place a child in the front passenger seat: Your vehicle is equipped with air bag technology designed to turn off the front passenger front air bag in your vehicle when the OCS senses the weight of a...
  • Page 75 Warning! Infants and small children should never share a seat belt with another occupant. During an accident, they could be crushed between the occupant and seat belt. A child’s risk of serious or fatal injuries is significantly increased if the child restraints are not properly secured in the vehicle and/or the child is not properly secured in the child restraint.
  • Page 76 Mercedes-Benz Center. Only seat accessories approved by Mercedes-Benz may be used. Both driver and the front passenger should always use the 56 indicator lamp as an indication of whether or not the front passenger is properly positioned.
  • Page 77 When the OCS senses that the front passen- ger seat occupant is classified as being heavier than the weight of a typical 12-month-old child seated in a standard child restraint or as being a small individual (such as a young teenager or a small adult), the 56 indicator lamp will illuminate for approximately six seconds when the engine is started and then, depending on...
  • Page 78 Safety and Security Occupant safety Children can be killed or seriously injured by an inflating air bag. Note the following important information when circumstances require you to place a child in the front passenger seat: Your vehicle is equipped with air bag technology designed to turn off the front passenger front air bag in your vehicle when the system senses the weight of a...
  • Page 79 Deployment of the driver front air bag does not mean that the front passenger front air bag also should have deployed. The Occupant Classification System ( page 73) may have determined: that the seat was empty or occupied by the weight up to or less than that of a typical 12-month-old child seated in a standard child restraint - both instances where the...
  • Page 80 Warning! If the 56 indicator lamp should not illuminate, the system is not functioning. You must see an authorized Mercedes-Benz Center before seating any child on the front passenger seat. More information can be found in the “Practical hints”...
  • Page 81 Installation of infant and child restraint systems Prior to installing a tether strap, note the following steps: Roll up retractable luggage cover and partition net. If you place a child seat in the left or center rear seat position, remove twin roller blind ( page 253) and return seat to its original position.
  • Page 82 Safety and Security Occupant safety Securely fasten hook 2, which is part of the tether strap, to anchorage ring 1. 1 Anchorage ring 2 Hook Once the top tether anchorage hook is attached, the child restraint itself can be secured. Tighten the top tether strap according to the child restraint manufacturer’s instructions.
  • Page 83 To fold anchors back Press down button 2 on each anchor and return anchor 1 to its catch. Non-LATCH-type child seats may also be used and can be installed using the vehicle’s seat belt system. Install child seat according to the manufacturer’s instructions.

  • Page 84: Blocking Of Rear Door Window Operation

    Safety and Security Occupant safety Blocking of rear door window operation You can block the rear door window operation (for instance when you have children riding in the rear passenger compartment). The override switch is located on the door control panel of the driver’s door. 1 Deactivating override switch 2 Activating override switch 3 Override switch...

  • Page 85: Panic Alarm

    Panic alarm* An audible alarm and flashing exterior lamps will operate for approximately minutes. 1 Â button Canada only: Only vehicles equipped with an anti-theft alarm system* have SmartKeys with integrated panic button 1. Activating Press and hold button 1 for at least one second.
  • Page 86 Safety and Security Panic alarm* Canada only: This device complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause interfer- ence, and (2) this device must accept any inter- ference received, including interfer- ence that may cause undesired operation of the device.

  • Page 87: Driving Safety Systems

    Driving safety systems In this section you will find information on the following driving safety systems: ABS (Antilock Brake System) BAS (Brake Assist System) ESP (Electronic Stability Program) 4MATIC (Four Wheel Electronic Traction System) In winter operation, the maximum effectiveness of the ABS, ESP, and 4MATIC (if so equipped) is only achieved with winter tires (M+S tires), or snow chains as required.

  • Page 88: Bas

    Safety and Security Driving safety systems Braking At the instant one of the wheels is about to lock up, a slight pulsation can be felt in the brake pedal, indicating that the ABS is in the regulating mode. Keep firm and steady pressure on the brake pedal while experiencing the pulsation.

  • Page 89: Esp

    Warning! The BAS cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase braking efficiency beyond that afforded by the condition of the vehicle brakes and tires or the traction afforded. The BAS cannot prevent accidents, includ- ing those resulting from excessive speed in turns, following another vehicle too closely, or hydroplaning.
  • Page 90 Safety and Security Driving safety systems Warning! The ESP cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded. The ESP cannot prevent accidents, including those resulting from excessive speed in turns or hydroplaning.
  • Page 91 Avoid spinning of a drive wheel for an extended period with the ESP switched off. This may cause serious damage to the drivetrain which is not covered by the Mercedes-Benz Limited Warranty. Switching on the ESP Press switch 1 again. The ESP warning lamp v in the speedometer goes out.

  • Page 92: Four Wheel Electronic Traction System (4Matic) With The Esp

    Do not tow with one axle raised. Otherwise the transfer case can be damaged, which is not covered by the Mercedes-Benz Limited Warranty. Performance testing must only be con- ducted on a two-axle dynamometer. Otherwise the transfer case can be damaged, which is not covered by the Mercedes-Benz Limited Warranty.

  • Page 93: Anti-Theft Systems

    In case the engine cannot be started (yet the vehicle’s battery is charged), the system is not operational. Contact an authorized Mercedes-Benz Center or call 1-800-FOR-MERCedes (in the USA), or 1-800-387-0100 (in Canada). Anti-theft alarm system* Once the alarm system has been armed, a...
  • Page 94 Safety and Security Anti-theft systems Arming the alarm system The indicator lamp is in the switch for the tow-away alarm* in the center console. 1 Indicator lamp Lock the vehicle with the SmartKey. The turn signal lamps flash three times to indicate that the alarm system is activated.

  • Page 95: Tow-Away Alarm

    Tow-away alarm* Once the tow-away alarm is armed, a visual and audible alarm will be triggered when someone attempts to raise the vehicle. The tow-away protection alarm is triggered, for example, if the vehicle is lifted on one side. If the alarm stays on for more than 30 seconds, a call to the Response Center is initiated automatically by the Tele Aid system* ( page 266) provid-...
  • Page 96 Safety and Security Anti-theft systems Press switch 1. Indicator lamp 2 in switch comes on briefly. Exit and lock your vehicle with the SmartKey. The tow-away alarm remains disarmed until you lock your vehicle again. Canceling the alarm To cancel the alarm: Press the Œ...

  • Page 97: Controls In Detail

    Controls in detail Locking and unlocking Seats Memory function* Lighting Instrument cluster Control system Automatic transmission Good visibility Climate control Automatic climate control* Audio system Power windows Power tilt/sliding sunroof* Driving systems Loading Useful features...

  • Page 98: Locking And Unlocking

    Controls in detail Locking and unlocking In the “Controls in detail” section you will find detailed information on how to oper- ate the equipment installed on your vehi- cle. If you are already familiar with the basic functions of your vehicle, this section will be of particular interest to you.
  • Page 99 Warning! When leaving the vehicle, always remove the SmartKey from the starter switch, take it with you, and lock the vehicle. Do not leave children unattended in the vehicle, or with access to an unlocked vehicle. It is possible for children to open a locked door from the inside, which could result in an accident and/or serious injury.
  • Page 100 Controls in detail Locking and unlocking Factory setting Global unlocking Press button Œ. All turn signal lamps flash once. The locking knobs in the doors move up. The anti-theft alarm system* is disarmed. The vehicle will lock again automatically and reactivate the anti-theft alarm system* within approximately 40 seconds of unlocking if: neither door nor tailgate is opened...
  • Page 101 ( page 383). Have the vehicle battery and the battery connections checked ( page 403). If the SmartKey is malfunctioning, contact an authorized Mercedes-Benz Center. Controls in detail Locking and unlocking Press button ‹ or Œ. Battery check lamp 4 comes on briefly to indicate that the SmartKey batteries are in order.

  • Page 102: Opening The Doors From The Inside

    If necessary, have the mechanical lock replaced. Your authorized Mercedes-Benz Center will be glad to supply you with a replace- ment. Opening the doors from the inside You can open a locked door from the inside.

  • Page 103: Opening The Tailgate

    Front doors Pull on door handle 2 on the respective front door to open door. If door was locked, locking knob 1 will move up. Rear doors Pull up locking knob 1 on the respective rear door to unlock door. Pull on door handle 2 on the respective rear door to open door.

  • Page 104: Automatic Central Locking

    Controls in detail Locking and unlocking Warning! To prevent possible personal injury, always keep hands and fingers away from the tail- gate opening when closing the tailgate. Be especially careful when small children are around. When leaving the vehicle, always remove the SmartKey from the starter switch, take it with you, and lock the vehicle.

  • Page 105: Locking And Unlocking From The Inside

    Locking and unlocking from the inside You can lock or unlock the doors and the tailgate from inside using the central lock- ing or unlocking switch. This can be useful, for example, if you want to lock the vehicle before starting to drive. You cannot lock or unlock the fuel filler flap with the central locking or unlocking switch.
  • Page 106 Controls in detail Locking and unlocking You can open a locked door from the inside. Open door only when conditions are safe to do so. If the vehicle was previously centrally locked using the SmartKey, it will not unlock using the central unlocking switch 2.

  • Page 107: Seats

    Seats For information on seat adjustment, see “Adjusting” ( page 35). Easy-entry/exit feature* This feature allows for easier entry into and exit from the vehicle. The easy-entry/exit feature can be activated or deactivated in the Convenience submenu of the control system ( page 154).
  • Page 108 Controls in detail Seats If the current position for the steering wheel is in the uppermost tilt position, the steering wheel will no longer be able to move upward when the easy-entry/exit feature is activated. If the current seat position falls into a factory-set position range and the system recognizes the current seat position to be rearward enough for...

  • Page 109: Removing And Installing Front Seat Head Restraints

    Removing and installing front seat head restraints For information on head restraint adjustment, see “Seats” ( page 35). Adjust the head restraint in such a way that it is as close to the head as possible. Warning! For your protection, drive only with properly positioned head restraints.

  • Page 110: Rear Seat Head Restraints

    Controls in detail Seats Front seat head restraints, power seat* 1 Head restraint switch Switch on ignition ( page 33). Removing front seat head restraints Press switch 1 upwards and hold until head restraint is fully extended. Pull out head restraint. Installing front seat head restraints Press switch 1 upwards and hold for about five seconds.
  • Page 111 Adjust the head restraint in such a way that it is as close to the head as possible. Warning! For your protection, drive only with properly positioned head restraints. Adjust head restraint so that the center of the head restraint supports the back of the head at eye level.
  • Page 112 Controls in detail Seats Head restraint tilt (rear outer seats) Two different head restraint angle positions are available. Press the release button ( page 109) and tilt the head restraint to the desired position. Removing and installing rear seat head restraints (rear outer seats) Adjust the head restraint in such a way that it is as close to the head as...

  • Page 113: Multicontour Seats

    Multicontour seats* This multicontour seat has a movable seat cushion and inflatable air cushions built into the backrest to provide additional lumbar and side support. The seat cushion movement, backrest cushion height and curvature can be continuously varied with switches on the side of the seat after switching on ignition.

  • Page 114: Seat Heating

    Controls in detail Seats Seat heating* The switches for the front seats are located in the center console. 1 Seat heating switch 2 Indicator lamps The red indicator lamps 2 in the switch show the heating level selected. Level Three indicator lamps on. After approximately five minutes, seat heating is automatically switched to level 2.

  • Page 115: Memory Function

    Memory function* You can store up to three different settings per SmartKey. Prior to operating the vehicle, the driver should check and adjust the seat The following settings are stored when height, seat position fore and aft, and using the buttons on the driver’s door: seat backrest angle if necessary, to ensure adequate control, reach and comfort.

  • Page 116: Storing Positions Into Memory

    Controls in detail Memory function* The memory button and memory position switch are located on the door. 1 Memory button 2 Memory position switch Switch on ignition ( page 33). Open the respective door and insert the SmartKey in the starter switch. Storing positions into memory Adjust the seat, steering wheel and exterior rear view mirrors to the...

  • Page 117: Storing Exterior Rear View Mirror Parking Position

    Storing exterior rear view mirror parking position For easier parking, you can adjust the passenger-side exterior rear view mirror so that you can see the right rear wheel as soon as you engage reverse gear R. For information on activating the parking position, see “Activating exterior rear view mirror parking position*”...

  • Page 118: Lighting

    Relevant information can be obtained at your authorized Mercedes-Benz Center. Exterior lamp switch The exterior lamp switch is located on the dashboard to the left of the steering wheel.
  • Page 119 With the SmartKey removed from the starter switch and the driver’s door open, a warning sounds if the parking lamps or low beam headlamps are switched on. The message Switch off lights. appears in the multifunction display Manual headlamp mode The low beam headlamps and the parking lamps can be switched on and off with the exterior lamp switch.
  • Page 120 Controls in detail Lighting Daytime running lamp mode Turn the exterior lamp switch to position M or U. When the engine is running, the low beam headlamps are switched on. In low ambient light conditions, the following lamps will switch on additionally: Tail and parking lamps License plate lamps Side marker lamps...
  • Page 121 Locator lighting and night security illumination The locator lighting and the night security illumination are described in the “Control system” section, see “Setting locator light- ing” ( page 151) and “Setting night secu- rity illumination” ( page 151). Fog lamps Warning! In low ambient lighting or foggy conditions, only switch from position U to B with...

  • Page 122: Combination Switch

    Controls in detail Lighting Rear fog lamp (driver’s side only) Switch on the front fog lamps ( page 119). Pull out the exterior lamp switch to second stop. The rear fog lamp switches on. The yellow indicator lamp † in the exterior lamp switch comes on ( page 116).

  • Page 123: Cornering Fog Lamps* (All Models With Bi-Xenon* Headlamps)

    Cornering fog lamps* (All models with Bi-Xenon* headlamps) The cornering fog lamps improve illumina- tion of the road into which you are turning. Cornering fog lamps will operate with the engine running and with the exterior lamp switch in position B ( page 116) the exterior lamp switch in position U ( page 116) the daytime running lamp mode...

  • Page 124: Hazard Warning Flasher

    Controls in detail Lighting Driving rearward Switching on cornering fog lamps Place the gear selector lever in position R. The inverse front fog lamp comes on automatically depending on the steering direction and steering angle. Switching off cornering fog lamps Place the gear selector lever out of position R.

  • Page 125: Interior Lighting

    Interior lighting The controls are located in the overhead control panel. 1 Rear interior lights 2 Right front reading lamp 3 Rocker switch for automatic control system 4 Left front reading lamp Activating automatic control Press rocker switch 3 to center position.

  • Page 126: Door Entry Lamps

    Controls in detail Lighting The setting selected for the interior lighting is used for the cargo compart- ment lighting as well. If you leave the tailgate open for an extended period of time, the cargo compartment lighting will switch off automatically after approximately ten minutes Switching rear interior lights on and off...

  • Page 127: Instrument Cluster

    Instrument cluster For a full view illustration of the instrument cluster, see “At a glance” ( page 24). 1 Reset button The instrument cluster is activated when open a door switch on ignition press reset button 1 switch on the exterior lamps You can change the instrument cluster settings in the Instrument cluster submenu of the control system ( page 143).

  • Page 128: Coolant Temperature Gauge

    248°F (120°C). The engine should not be operated with the coolant temperature above 248°F (120°C). Doing so may cause serious en- gine damage which is not covered by the Mercedes-Benz Limited Warranty.

  • Page 129: Trip Odometer

    Avoid driving at excessive engine speeds, as it may result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty. To help protect the engine, the fuel supply is interrupted if the engine is operated within the red marking.
  • Page 130 Controls in detail Instrument cluster The outside temperature is indicated in the multifunction display ( page 129). For information on how to select the unit of the indicated temperature, i.e. degrees Celsius (°C) or degrees Fahrenheit (°F), see “Selecting temperature display mode” ( page 143).

  • Page 131: Control System

    Control system The control system is activated as soon as the SmartKey in the starter switch is turned to position 1. The control system enables you to call up information about your vehicle change vehicle settings For example, you can use the control system to find out when your vehicle is next due for service, to set the language for messages in the instrument cluster...

  • Page 132: Multifunction Steering Wheel

    Controls in detail Control system Multifunction steering wheel The displays in the multifunction display and the settings in the control system are controlled by the buttons on the multifunc- tion steering wheel. 1 Multifunction display Operating the control system 2 Selecting the submenu or setting the volume: Press button æ...
  • Page 133 It is helpful to think of the menus, and the functions within each menu, as being arranged in a circular pattern. If you press button è or ÿ repeatedly, you will pass through each menu one after the other. If you press button k or j repeatedly, you will pass through each function display, one after the other, in the current menu.

  • Page 134: Menus

    Controls in detail Control system Menus This is what you will see when you scroll through the menus. The table on the next page provides an overview of the individual menus.
  • Page 135 Menus, submenus and functions Menu 1 Menu 2 Standard display AUDIO ( page 134) ( page 135) Digital speedometer Select radio or outside tempera- station ture Call up maintenance Select satellite service display radio station* (USA only) Check engine oil Operate the level CD player*...

  • Page 136: Standard Display Menu

    Controls in detail Control system The headings used in the menus table are designed to facilitate navigation within the system and are not neces- sarily identical to those shown in the control system displays. The first function displayed in each menu will automatically show you which part of the system you are in.

  • Page 137: Press Button J Or K Repeatedly

    Display digital speedometer or outside temperature Press button j or k repeatedly until the digital speedometer appears in the multifunction display. The current vehicle speed is shown in the multifunction display. 1 Digital speedometer AUDIO menu You can have the outside temperature The functions in the displayed instead of the digital the audio equipment which you currently...
  • Page 138 Controls in detail Control system Select radio station Turn on the radio ( page 202). Vehicles with COMAND*: Refer to separate operating instructions. Press button è or ÿ repeatedly until the currently tuned station appears in the multifunction display. 1 Waveband setting 2 Station frequency Press button k or j repeatedly Select satellite radio station*...
  • Page 139 Press button k or j repeatedly Operate the CD player* until the desired channel is found. For more information on satellite radio operation, see “Introduction to satellite radio* (USA only)” ( page 212). Vehicles with COMAND*: Refer to separate operating instructions.

  • Page 140: Nav* Menu

    Mercedes-Benz Center to address the malfunction and warning messages ( page 352). Press button è or ÿ repeatedly...
  • Page 141 No vehicle status messages If no conditions are recorded in memory, the message in the multifunction display No message Vehicle status messages have been recorded If conditions have occured causing status messages to be recorded, the number of messages appears in the multifunction display: 1 Number of messages Press button k or j.

  • Page 142: Settings Menu

    Controls in detail Control system Settings menu In the Settings menu there are two functions: The function Reset to factory , with which you can reset all settings the settings to the original factory settings. A collection of submenus with which you can make individual settings for your vehicle.
  • Page 143 Submenus in the Settings menu Press button k or j. The collection of the submenus appears in the multifunction display. Press button ç. The selection marker moves to the next submenu. The submenus are arranged by hierarchy. Scroll down with button ç, scroll up with button æ.
  • Page 144 Controls in detail Control system The table below shows what settings can be changed within the various menus. Instrument cluster Time/Date Selecting temperature Time synchronization with head display mode unit* Selecting speedometer Setting the time (hours) display mode Selecting language Setting the time (minutes) Selecting display (speed Selecting time display mode...
  • Page 145 Instrument cluster submenu Access the Instr.Cl. submenu via the Settings menu. Use the Instr.Cl. submenu to change the instrument cluster display settings. The following functions are available: Function Page Selecting temperature display mode Selecting speedometer display mode Selecting language Selecting display (speed display or outside temperature) for status indicator Selecting temperature display mode...
  • Page 146 Controls in detail Control system Selecting language Move the selection marker with button æ or ç to the Instr.Cl. submenu. Press button j or k repeatedly until the message appears in Language the multifunction display. The selection marker is on the current setting.
  • Page 147 Time/Date submenu Access the Time/Date submenu via the Settings menu. Use the Time/Date submenu to change the instrument cluster display settings. The following functions are available: Function Page Time synchronization with head unit* Setting the time (hours) Setting the time (minutes) Selecting time display mode Selecting automatic time change (Daylight Saving Time (DST)
  • Page 148 Controls in detail Control system The selection marker is on the hour setting. Press button æ or ç to set the hour. Setting the time (minutes) This function can only be seen with audio system. Vehicles with COMAND*: For information on setting the time, refer to the separate COMAND operating instructions.
  • Page 149 Selecting time display mode Move the selection marker with button æ or ç to the Time/Date submenu. Press button j or k repeatedly until the message Clock display appears in the multifunction display. The selection marker is on the current setting.
  • Page 150 Controls in detail Control system The selection marker is on the month setting. Press button æ or ç to set the month. Setting the date (day) This function can only be seen with audio system. Vehicles with COMAND*: For information on setting the date, refer to the separate COMAND operating instructions.
  • Page 151 Setting the date (year) This function can only be seen with audio system. Vehicles with COMAND*: For information on setting the date, refer to the separate COMAND operating instructions. Move the selection marker with button æ or ç to the Time/Date submenu.
  • Page 152 Controls in detail Control system Setting daytime running lamp mode (USA only) This function is not available in countries where the daytime running lamp mode is mandatory and therefore in a constant mode. Move the selection marker with button æ or ç to the Lighting submenu.
  • Page 153 Setting locator lighting With the locator lighting feature activated and the exterior lamp switch in position U, the following lamps will switch on when the vehicle is unlocked with the SmartKey during darkness: Parking lamps Tail lamps License plate lamps Side marker lamps Front fog lamps The locator lighting switches off when the...
  • Page 154 Controls in detail Control system You can reactivate this function within ten minutes by opening a door. Move the selection marker with button æ or ç to the Lighting submenu. Press button j or k repeatedly until the message Hdlamp delay off appears in the multifunction display.
  • Page 155 Setting interior lighting delayed shut-off Use this function to set whether and how long you would like the interior lighting to remain lit during darkness after you have removed the SmartKey from the starter switch. Move the selection marker with button æ...
  • Page 156 Controls in detail Control system The selection marker is on the current setting. Press button æ or ç to switch the automatic central locking Convenience submenu Access the Convenience submenu via the Settings menu. Use the Convenience submenu to change the settings for a number of convenience features.
  • Page 157 Do not leave children unattended in the ve- hicle, or with access to an unlocked vehicle. Children could open the driver’s door and unintentionally activate the easy-entry/exit feature, which could result in an accident and/or serious personal injury. Move the selection marker with button æ...

  • Page 158: Trip Computer Menu

    Controls in detail Control system Press button æ or ç to set key-dependency Setting parking position* for exterior rear view mirror Use the function Mirror set. parking aid to select whether the passenger-side exterior rear view mirror should be turned downward during parking maneuvers when reverse gear R is engaged.
  • Page 159 Fuel consumption statistics after start Press button ÿ or è repeatedly until the first function of the Trip computer menu appears in the multifunction display. Press button j or k repeatedly until the message appears After start in the multifunction display. 1 Distance driven since start 2 Time elapsed since start 3 Average speed since start...

  • Page 160: Tel Menu

    Controls in detail Control system Resetting fuel consumption statistics Press button ÿ or è repeatedly until the first function of the Trip computer menu appears in the multifunction display. Press button j or k repeatedly until the reading that you want to reset appears in the multifunction display.
  • Page 161 Never operate radio transmitters equipped with a built-in or attached antenna (i.e. with- out being connected to an external antenna) from inside the vehicle while the engine is running. Doing so could lead to a malfunc- tion of the vehicle’s electronic system, pos- sibly resulting in an accident and/or personal injury.
  • Page 162 Controls in detail Control system Ending a call Press button t. You have ended the call. The standby message appears in the multifunction display. Dialing a number from the phone book If your telephone is ready to receive calls, you may select and dial a number from the phone book at any time.
  • Page 163 If you press and hold j or k for longer than one second, the system scrolls rapidly through the list of names until you release the button again. Cancel the quick search mode by pressing button t. Press button s. The system dials the selected phone number.

  • Page 164: Automatic Transmission

    Controls in detail Automatic transmission For more information on driving with an automatic transmission, see “Automatic transmission” ( page 46). Your vehicle’s transmission adapts its gear shifting process to your individual driving style by continually adjusting the shift points up or down. These shift point adjust- ments are performed based on current operating and driving conditions.
  • Page 165 Avoid spinning of a drive wheel for an extended period when driving off on slippery road surfaces. This may cause serious damage to the drivetrain which is not covered by the Mercedes-Benz Limited Warranty. When the gear selector lever is in position D, you can influence transmission...

  • Page 166: One-Touch Gearshifting

    Controls in detail Automatic transmission One-touch gearshifting Even with an automatic transmission you can change the gears manually when the gear selector lever is in position D. Downshifting Briefly press the gear selector lever to the left in the D- direction. The transmission will shift from the current gear to the next lower gear as permitted by the shift program.

  • Page 167: Gear Ranges

    Gear ranges With the gear selector lever in position D, you can limit the transmission’s gear range by pressing the gear selector lever to the left (D-), and reverse the gear range limit by pressing the gear selector lever to the right (D+).

  • Page 168: Gear Selector Lever Position

    Controls in detail Automatic transmission Gear selector lever position Effect ì Park position Gear selector lever position when the vehicle is parked. Place gear selector lever in position P only when vehicle is stopped. The park position is not intended to serve as a brake when the vehicle is parked.
  • Page 169 P that is not covered by the is dangerous. Also, position P alone is not Mercedes-Benz Limited Warranty. intended to or capable of preventing your vehicle from moving, possibly hitting people or objects.

  • Page 170: Automatic Shift Program

    Controls in detail Automatic transmission Automatic shift program The program mode selector switch is located on the lower part of the center console. 1 Program mode selector switch C Comfort For comfort driving S Sport For standard driving The current gear selector lever position and the selected program mode ( ) are indicated in the multifunction display...

  • Page 171: Driving Tips

    Driving tips Accelerator position Your driving style influences the transmission’s shifting behavior: Less throttle Earlier upshifting More throttle Later upshifting Kickdown Use kickdown when you want maximum acceleration. Press the accelerator past the point of resistance. The transmission shifts into a lower gear.

  • Page 172: (Limp Home Mode)

    Move gear selector lever to P. Turn off the engine. Wait at least ten seconds before restarting. Restart the engine. Move gear selector lever to position D (for second gear) or R. Have the transmission checked at an authorized Mercedes-Benz Center as soon as possible.

  • Page 173: Good Visibility

    Good visibility For information on the windshield wipers, see “Windshield wipers” ( page 50). Headlamp cleaning system* The switch is located on the left side of the dashboard. 1 Headlamp washer switch Switch on ignition ( page 33). Press switch 1. The headlamps are cleaned with a high-pressure water jet.

  • Page 174: Good Visibility

    Controls in detail Good visibility Auto-dimming rear view mirrors* The reflection brightness of the exterior rear view mirror on the driver’s side and the interior rear view mirror will respond automatically to glare when the ignition is switched on incoming light from headlamps falls on the sensor in the interior rear view mirror.
  • Page 175 Activating exterior rear view mirror parking position* Follow these steps to activate the mirror parking position so that the passenger-side exterior rear view mirror will be turned downward to the stored position. The buttons are located above the exterior lamp switch. 1 Driver’s side exterior rear view mirror button 2 Passenger-side exterior rear view...

  • Page 176: Sun Visors

    Controls in detail Good visibility Sun visors The sun visors protect you from sun glare while driving. Warning! Do not use the vanity mirror while driving. Keep the mirrors in the sun visors closed while vehicle is in motion. Reflected glare can endanger you and others.

  • Page 177: Rear Window Defroster

    Rear window defroster The rear window defroster uses a large amount of power. To keep the battery drain to a minimum, switch off the defroster as soon as the rear window is clear. The defroster is automatically deactivated after approximately 6 to 17 minutes of operation depending on the outside temperature.
  • Page 178 Controls in detail Climate control...

  • Page 179: Climate Control

    Item 1 Left side defroster vent, fixed 2 Left side air vent, adjustable 3 Thumbwheel for air volume control for left side air vent 4 Thumbwheel for air volume control for left center air vent 5 Left center air vent, adjustable 6 Right center air vent, adjustable 7 Thumbwheel for air volume control for right center air vent...
  • Page 180 Controls in detail Climate control The climate control is operational when- ever the engine is running. You can oper- ate the climate control system in either the automatic or manual mode. The system cools or heats the interior depending on the selected interior temperature and the current outside temperature.

  • Page 181: Deactivating The Climate Control System

    Deactivating the climate control system Deactivating Set air volume control 1 ( page 177) to position 0. When the air conditioning is switched off, the outside air supply and circula- tion are also switched off. Only choose this setting for a short time. Otherwise the windows could fog up.

  • Page 182: Adjusting Air Distribution And Volume

    Controls in detail Climate control Adjusting air distribution and volume Use air distribution control 4 ( page 177) to adjust the air distribution. The following symbols are found on the controls: Symbol Function Directs air to the windshield and the side defroster vents Directs air into the entire vehicle interior Directs air to the footwells...

  • Page 183: Defrosting

    Defrosting These settings should only be selected for a short time. Activating Press button P or 0 ( page 177). The indicator lamp on the button comes on. The air conditioning switches automatically to the following functions: maximum blowing and heating power air flows onto the windshield and the front side windows...

  • Page 184: Air Recirculation Mode

    Controls in detail Climate control Air recirculation mode Switch to air recirculation mode to prevent unpleasant odors from entering the vehicle from the outside. This setting cuts off the intake of outside air and recirculates the air in the passenger compartment. Warning! When the outside temperature is below 41°F (5°C), only switch to air...

  • Page 185: Air Conditioning

    The air recirculation mode is activated automatically at high outside tempera- tures. The indicator lamp on the , button is not lit when the air recirculation mode is automatically switched on. After approx. 30 minutes, outside air is added to the air inside the vehicle. If you have turned off the air condi- tioning ( page 183) or the outside temperature is below 41°F (5°C), the...
  • Page 186 CFCs which are harmful to the ozone layer. If the air conditioning cannot be turned on again, this indicates that the air conditioning is losing refrigerant. The compressor has turned itself off. Have the air conditioning checked at the nearest authorized Mercedes-Benz Center.

  • Page 187: Rear Passenger Compartment Adjustable Air Vents

    Rear passenger compartment adjustable air vents The air conditioning for the rear passenger compartment is controlled via the climate control panel ( page 177). The temperature at the center air vents for the rear passenger compartment 1 and 3 is the same as at the dashboard center air vents.
  • Page 188 Controls in detail Automatic climate control*...

  • Page 189: Automatic Climate Control

    Item 1 Left side defroster vent, fixed 2 Left side air vent, adjustable 3 Thumbwheel for air volume control for left side air vent 4 Thumbwheel for air volume control for left center air vent 5 Left center air vent, adjustable 6 Right center air vent, adjustable 7 Thumbwheel for air volume control for right center air vent...
  • Page 190 Controls in detail Automatic climate control* Feature availability is based on prelimi- nary information at time of printing. The automatic climate control may not be available as optional equipment on all models. The automatic climate control is operation- al whenever the engine is running. You can operate the climate control system in ei- ther the automatic or manual mode.

  • Page 191: Deactivating The Automatic

    Deactivating the automatic climate control system Deactivating It is possible to deactivate the automatic climate control system. Press button ´ ( page 187). The indicator lamp on the button ´ comes on. The automatic climate control system is deactivated. When the air conditioning is switched off, the outside air supply and circula- tion are also switched off.

  • Page 192: Adjusting Air Distribution

    Controls in detail Automatic climate control* Display 1 Temperature, left 2 Blower speed 3 Temperature, right Increasing Push temperature control 3 and/or 6 ( page 187). The automatic climate control system will correspondingly adjust the interior air temperature. Decreasing Push temperature control b and/or d ( page 187).

  • Page 193: Adjusting Air Volume

    Windshield fogged on the outside Switch the windshield wipers on ( page 51). Switch to manual mode. Turn air distribution control 1 or 8 to a or Y ( page 187). Adjusting air volume Use button U for automatic mode or air volume controls ˜...

  • Page 194: Defrosting

    Controls in detail Automatic climate control* Defrosting These settings should only be selected for a short time. Activating Press button P or 0 ( page 187). The indicator lamp on the button comes on. The air conditioning switches automatically to the following functions: maximum blowing and heating power air flows onto the windshield and...

  • Page 195: Air Recirculation Mode

    Air recirculation mode Switch to air recirculation mode to prevent unpleasant odors from entering the vehicle from the outside. This setting cuts off the intake of outside air and recirculates the air in the passenger compartment. Warning! When the outside temperature is below 41°F (5°C), only switch to air recirculation mode for short periods to prevent window fogging.

  • Page 196: Charcoal Filter

    Controls in detail Automatic climate control* Deactivating Press button , ( page 187). The indicator lamp on the button goes out. If you keep button , pressed the side windows and tilt/sliding sunroof* will return to their previous position. The air recirculation mode is deactivated automatically: after five minutes if the outside temperature is below...
  • Page 197 Activating Press button e ( page 187). The indicator lamp on the button comes on. If you keep button e pressed the side windows and tilt/sliding sunroof* will close. The activated charcoal filter should be switched off when windows fog up on the inside, or if the passenger compart- ment needs to be quickly heated or cooled down.

  • Page 198: Air Conditioning

    Controls in detail Automatic climate control* Air conditioning The air conditioning is operational while the engine is running and cools the interior air to the temperature set by the operator. Condensation may drip out from under- neath the vehicle. This is normal and not an indication of a malfunction.

  • Page 199: Residual Heat And Ventilation

    The compressor has turned itself off. Have the air conditioning checked at the nearest authorized Mercedes-Benz Center. Residual heat and ventilation (available on automatic climate control panel design A only)

  • Page 200: Rear Passenger Compartment Adjustable Air Vents

    Controls in detail Automatic climate control* Rear passenger compartment adjustable air vents The air conditioning for the rear passenger compartment is controlled via the auto- matic climate control panel ( page 187). The temperature at the center air vents for the rear passenger compartment 1 and 3 is the same as at the dashboard center air vents.

  • Page 201: Audio System

    Audio system Audio and telephone, operation These instructions are intended to help you become familiar with your Mercedes-Benz audio system. They con- tain useful tips and a detailed description of the user functions. Warning! In order to avoid distraction which could...

  • Page 202: Operating And Display Elements

    Controls in detail Audio system Operating and display elements...
  • Page 203 Item Page 1 CD changer mode selector AUX mode selector 2 Single CD mode selector 3 Radio mode selector 4 Mute function (radio) Pause (CD) 5 Volume distribution 6 Sound settings 7 Display 8 Alphanumeric keypad Item Page 9 Speed dialing memory (telephone) in descending order a Accepting a call...

  • Page 204: Button And Soft Key Operation

    Controls in detail Audio system Button and soft key operation In these instructions, the alphanumeric keypad (right side of radio panel) and the function buttons (left side of radio panel) are referred to as “buttons”. The four keys below the display panel are referred to as “soft keys”.
  • Page 205 Turn rotary control of N button. The volume will increase or decrease depending on the direction turned. If your vehicle equipment includes a Mercedes-Benz specified mobile telephone*, you can adjust its volume separately from the volume of the audio system while the telephone is being used.
  • Page 206 Controls in detail Audio system Adjusting treble Press O button repeatedly until TREBLE appears in the display. Press soft key to increase or – decrease tone level accordingly. Press soft key briefly to reset treble tones to their center level. The radio switches back to the standard radio menu eight seconds after the last soft key is pressed.
  • Page 207 Returning sound functions to factory settings Press O button to call up settings menu in the display. Press soft key briefly; the respec- tive sound function is reset to its center level. Press and hold soft key until RESET appears in the display. The sound settings for bass and treble are returned to their center level and the volume is set to a predefined level.
  • Page 208 Telephone* muting If your vehicle equipment includes a Mercedes-Benz specified mobile telephone*, you can adjust its volume separately from the volume of the audio system while the telephone is being used.

  • Page 209: Radio Operation

    Feature description is based on preliminary information at time of printing. Contact an authorized Mercedes-Benz Center for availability. You can adjust the volume ( page 203), the sound settings ( page 203) and the volume distribution ( page 205) for the AUX input.

  • Page 210: Press * Button

    Controls in detail Audio system Calling up wavebands for radios with SAT Press , or soft key repeatedly until desired waveband has been selected. The FM, AM, and WB wavebands are called up one after another. The waveband currently selected appears in the upper left-hand corner of the display.
  • Page 211 You can only enter frequencies within the respective waveband. If a button is not pressed within four seconds, the radio will return to the last station tuned. Manual tuning Select desired waveband. Press S or T button for approx. three seconds. Press button repeatedly until desired frequency has been reached.
  • Page 212 Controls in detail Audio system Ending scan search soft key or S or T. Press The station last played will be selected and disappears from the display. Station memory You can store ten AM and ten FM stations in the memory. Storing stations Tune in desired station.
  • Page 213 Calling up stations Press desired station button 1 to R. Leaving the Autostore memory level Press soft key briefly. Interrupting radio mode The radio mode is interrupted by an incoming call on the telephone* ( page 229). Mute on Press U button. The radio mode is interrupted and MUTED appears in the display.

  • Page 214: Introduction To Satellite Radio* (Usa Only)

    Contact an authorized Mercedes-Benz Center for details and availability for your vehicle. Note that categories and channels shown in illustrations are dependent on programming content delivered by the service provider.
  • Page 215 Satellite radio service may be unavail- able or interrupted from time to time for a variety of reasons, such as envi- ronmental or topographic conditions and other things beyond the service provider’s or our control. Service might also not be available in certain places (e.g., in tunnels, parking garages, or within or next to buildings) or near other technologies.
  • Page 216 Controls in detail Audio system The system will tune to a default station if no station had been selected previously. The first channel 001 is called up and the PTY system changes to All categories. If no station can be received, ACQUIRING appears in the display.
  • Page 217 Press * button. Input line appears in the main radio menu. Use number keys to enter desired channel within eight seconds, e.g. 1 6. The system tunes to channel 16. The station you have selected begins to play. You can only enter available channel numbers.
  • Page 218 Controls in detail Audio system Tuning via scan search Scan search is characterized as follows: Scan search plays a channel for approx. eight seconds and then skips to the next channel within the current category. Scan search can be terminated manually.

  • Page 219: Cd Mode

    Calling up the ESN information menu Press soft key. Press soft key. The twelve-digit electronic serial number (ESN) of the SAT tuner* installed in your vehicle is displayed. Press soft key to exit the menu. CD mode Safety precautions Warning! The single CD player and the CD changer* are Class 1 laser products.
  • Page 220 In certain situations, the CDs can then no longer be ejected and cause damage to the drive. Such damage is not covered by the Mercedes-Benz Limited Warranty. Your CD drive or CD changer has been designed to play CDs which correspond to the EN 60908 standard.
  • Page 221 Inserting a second CD in the slot with another CD still loaded will cause dam- age to the CD drive not covered by the Mercedes-Benz Limited Warranty. If a CD has been inserted incorrectly or cannot be read, will appear WRONG CD0 in the display.
  • Page 222 Controls in detail Audio system 1 CD 2 CD changer 3 CD tray 4 CD magazine Remove magazine 4 and pull CD tray 3 fully out. Place CD 1 in recess of tray, label side Push tray into magazine in direction of arrow.
  • Page 223 Playing tracks You have the following options: Audio system with CD changer*: selecting CDs Direct track entry Track skip forward/reverse Fast forward/reverse Scan Random tracks Repeat track Selecting CDs in the audio unit with CD changer* You can select from among the inserted CDs with buttons R to 6.
  • Page 224 Controls in detail Audio system The number of the track being played appears next to in the display. TRACK You can only enter available track numbers. Skipping tracks forward/backward Skipping tracks forward Press S button briefly. The next track will be played. Skipping tracks backward Press T button briefly.
  • Page 225 Switching on random Press soft key. appears in the display. A randomly selected track is played. Switching off random Press soft key again. Repeat The track being played is repeated until the repeat function is switched off. When you start the RPT function, the RDM function is automatically switched off.

  • Page 226: Gsm Network Phones

    If your audio system is set up for telephone operation, the t symbol will appear in the display. When you insert your Mercedes-Benz specified mobile telephone* into the telephone cradle, you will be prompted to enter your PIN for 30 seconds ( page 225).
  • Page 227 PIN entry Enter PIN number using buttons 1 to R. If necessary, correct number entered with the soft key. Press soft key briefly to delete the last digit entered; press soft key and hold to delete the complete number. Press soft key after entering correct PIN.
  • Page 228 Controls in detail Audio system If necessary, correct number entered with the soft key. Press soft key briefly to delete the last digit entered; press soft key and hold to delete the complete number. After correct telephone number has been entered, press s button. If the telephone number has been saved together with a name in the telephone book, the name will appear...
  • Page 229 Press button ‚ or ƒ repeatedly until desired entry has been reached. The stored entries are selected in alphabetical order with the sub-entries. Several sub-entries can be stored for each main entry (name). These entries are marked by a corresponding abbreviation that appears in the upper left-hand corner of the display.
  • Page 230 Controls in detail Audio system Speed dial If you have stored telephone numbers as speed dial numbers in your telephone, you can also enter these with buttons 1 to R on the radio head unit. Press desired button 1 to R briefly.
  • Page 231 Accepting an incoming call If the telephone is active in the background (reception symbol is visible in the display), the audio source is muted when an incom- ing call is received. A ringing tone can be heard and the caller’s telephone number, or the name under which the telephone number has been saved in the phone book, appears in the display.

  • Page 232: Tdma Or Cdma Network Phones

    Terminating a combined call operation, the t symbol will appear in Press t button. the display. When you insert your Mercedes-Benz The connection to both callers is specified mobile telephone* into the terminated. telephone cradle, you will be prompted to enter your PIN for 30 seconds ( page 231).
  • Page 233 Switching on the telephone Switching on the telephone Press h button. If you have programmed an unlock code for the telephone, you must now enter the code. Enter code using buttons 1 to R. If necessary, correct number entered with the soft key.
  • Page 234 Controls in detail Audio system If necessary, correct number entered with the soft key. Press soft key briefly to delete the last digit entered; press soft key and hold to delete the complete number. After correct telephone number has been entered, press s button. If the telephone number has been saved together with a name in the phone book, the name will appear in...
  • Page 235 Press button ‚ or ƒ repeatedly until desired entry has been reached. The stored entries are selected in alphabetical order with the sub-entries. Several sub-entries can be stored for each main entry (name). These entries are marked by a corresponding abbreviation that appears in the upper left-hand corner of the display.
  • Page 236 Controls in detail Audio system Speed dial If you have stored telephone numbers as speed dial numbers in your telephone, you can also enter these with buttons 1 to R on the radio unit. Press desired button 1 to R briefly.
  • Page 237 Accepting an incoming call If the telephone is active in the background (reception symbol is visible in the display), the audio source is muted when an incom- ing call is received. A ringing tone can be heard and the caller’s telephone number, or the name under which the telephone number has been saved in the telephone book, appears in the display.
  • Page 238 Controls in detail Audio system Switching between calls Press s button. This switches between the calls. The non-active call is kept on hold. Terminating a call Press t button. The current call is terminated. The connection to the caller previously kept on hold is also interrupted;...

  • Page 239: Emergency Calls "911

    Emergency calls “911” The following describes how to dial a “911” emergency call using the audio system head unit when a Mercedes-Benz specified mobile phone* is inserted in the phone cradle*. Unless otherwise specified, the descriptions refer to the audio system head unit.
  • Page 240 Controls in detail Audio system Placing a “911” emergency call using audio head unit with the phone unlocked Press h button to switch to telephone operation. Enter 911 using the number keypad on the audio head unit. Press s button for dialing to begin. DIALING appears in the audio display while the telephone establishes the...

  • Page 241: Power Windows

    Power windows Opening and closing the windows The side windows are opened and closed electrically. The switches for all the side windows are on the driver’s door. The switches for the respective windows are on the front passenger door and the rear doors.
  • Page 242 Controls in detail Power windows You can also open or close the windows using the SmartKey (summer opening/convenience closing feature) ( page 241). You can close and reopen the windows using the air recirculation button , in the climate control panel ( page 177) or automatic climate control panel* ( page 187).
  • Page 243 Warning! If the upward movement of the window is blocked during the closing Driver’s door only: procedure, the window will stop and If within five seconds you again pull the open slightly. switch past the resistance point and Remove the obstruction, pull the release, the automatic reversal will not switch again past the resistance point function.

  • Page 244: Synchronizing Power Windows

    Controls in detail Power windows Aim transmitter eye at the driver’s door handle. Opening (Summer opening feature) Press and hold button Œ after unlocking the vehicle. The windows and tilt/sliding sunroof* begin to open after approximately one second. Release the Œ button to stop procedure.

  • Page 245: Power Tilt/Sliding Sunroof

    Power tilt/sliding sunroof* Opening and closing the power tilt/sliding sunroof The tilt/sliding sunroof can be opened and closed electrically. The switch for the tilt/sliding sunroof is on the overhead control panel. Sunroof switch 1 Push up to raise sunroof at rear 2 Pull down to lower sunroof at rear 3 Push forward to slide sunroof closed 4 Push back to slide sunroof open...
  • Page 246 Controls in detail Power tilt/sliding sunroof* When leaving the vehicle, always remove the SmartKey from the starter switch, take it with you, and lock the vehicle. Do not leave children unattended in the vehicle, or with access to an unlocked vehicle. Unsuper- vised use of vehicle equipment can cause an accident and/or serious personal injury.
  • Page 247 Stopping the power tilt/sliding sunroof during Express-operation Move the sunroof switch in any direction. If the movement of the tilt/sliding sunroof is blocked during the closing procedure, the tilt/sliding sunroof will stop and reopen slightly. Opening and closing the tilt/sliding sunroof with the SmartKey The power windows ( page 241) will also be opened or closed when you operate the...

  • Page 248: Synchronizing The Power Tilt/Sliding Sunroof

    Controls in detail Power tilt/sliding sunroof* Closing (Convenience feature) Press and hold button ‹ after locking the vehicle. The windows and the tilt/sliding sunroof begin to close after approximately one second. Release the ‹ button to stop procedure. Make sure all side windows and the tilt/sliding sunroof are properly closed before leaving the vehicle.

  • Page 249: Driving Systems

    Driving systems The driving system of your vehicle is described on the following pages: Cruise control, with which the vehicle can maintain a preset speed For information on the BAS, ABS, and ESP driving systems, see “Driving safety sys- tems” ( page 85). Cruise control Cruise control automatically maintains the speed you set for your vehicle.
  • Page 250 Controls in detail Driving systems 1 Sets current or higher speed 2 Sets current or lower speed 3 Cancels cruise control 4 Resumes at last set speed Setting current speed Accelerate or decelerate to the desired speed. Briefly lift 1 or depress 2 the cruise control lever.
  • Page 251 Setting a higher speed Lift cruise control lever to position 1 and hold it up until the desired speed is reached. Release cruise control lever. The new speed is set. Depressing the accelerator pedal does not deactivate cruise control. After brief acceleration (e.g.

  • Page 252: Loading

    Controls in detail Loading Roof rack* Warning! Only use roof racks approved by Mercedes-Benz for your vehicle model to avoid damage to the vehicle. Follow manu- facturer’s installation instructions. Attach the roof rack only to the roof rails. Secure the roof rack according to manufacturer’s instructions for...

  • Page 253: Storage Compartment Under Cargo Compartment Floor

    1 Rail 2 Mounting lug Removal of parcel net Slide rails 1 upward and remove. Installation of parcel net Place mounting lugs 2 in opening. Slide rails 1 down as far as they can Storage compartment under cargo compartment floor To open cargo compartment floor Press handle 1 on the recess.

  • Page 254: Retractable Luggage Cover And Partition Net

    Controls in detail Loading Retractable luggage cover and partition net The twin-reel roller blind comprises a lug- gage cover and a partition net. It is mount- ed on the backrest of the rear seat and can also be used with backrest folded down. Partition net Warning! To help avoid personal injury during a colli-...
  • Page 255 Luggage cover Closing Pull luggage cover back by handle 1 until it locks into position. Opening Press handle 1 down and release. The luggage cover retracts automati- cally. With the luggage cover rolled up, fold the lip down. Twin-reel roller blind 1 Twin-reel roller blind 2 Guide rail Retract the partition net and luggage...

  • Page 256: Split Rear Bench Seat

    Controls in detail Loading Split rear bench seat To expand the cargo compartment, you can fold down the left and right rear seat backrests. The two sections can be folded down separately. Warning! When expanding the luggage compartment, always fold the seat cushions fully forward and always use the partition net when trans- porting cargo.
  • Page 257 Returning the backrest to original position Pull release lever 4. Fold backrest 5 forward. With the twin-reel roller blind installed: When folding the backrest forward, fold the right section first and then the left section. If only the left section is to be folded, first remove the twin-reel roller blind ( page 253).

  • Page 258: Loading Instructions

    Controls in detail Loading Warning! If a red indicator is visible with the backrest up, then the backrest is not properly locked into position. Always lock backrest in its upright position when rear seat bench is occupied, or the extended cargo compartment is not in use. Check for secure locking by pushing and pulling on the backrest.

  • Page 259: Cargo Tie-Down Rings

    Warning! Always fasten items being carried as secure- ly as possible. In an accident, during hard braking or sud- den maneuvers, loose items will be thrown around inside the vehicle and can cause in- jury to vehicle occupants unless the items are securely fastened in the vehicle.

  • Page 260: Useful Features

    Controls in detail Useful features Storage compartments Warning! To help avoid personal injury during a colli- sion or sudden maneuver, exercise care when stowing objects in the vehicle. Put lug- gage or cargo in the cargo compartment if possible. Do not pile luggage or cargo higher than the seat backs.
  • Page 261 Armrest storage compartments 1 Handle 2 Button, passenger side 3 Button, driver’s side Opening storage compartment Pull handle 1 and lift armrest. Closing storage compartment Press armrest down until it engages into place. Opening telephone compartment Press button 3 on driver’s side or button 2 on passenger side and lift armrest.
  • Page 262 Controls in detail Useful features Armrest in the rear passenger compartment Pull the top of the armrest out and fold it down. Cup holders in front of seat armrest Warning! In order to help prevent spilling liquids on vehicle occupants, only use containers that fit into the cup holder.
  • Page 263 No objects should be in the swiveling cup holder when the swiveling cup holder is slided upward. Otherwise the swiveling cup holder or the objects could be damaged. Turning the swiveling cup holder outward Turn the cup holder in the direction of arrow 2 until it engages.

  • Page 264: Ashtrays

    Controls in detail Useful features 1 Cup holder Opening cup holder Briefly press the front of cup holder 1. The cup holder slides out slightly. Pull out the cup holder until it stops. Closing cup holder Slide cup holder 1 in until it engages. Parcel net in front passenger footwell A small convenience parcel net is located in the front passenger footwell.
  • Page 265 Removing ashtray insert Warning! Remove front ashtray only with vehicle standing still. Set the parking brake to secure vehicle from movement. Move gear selector lever to position N. With gear selec- tor lever in position N, turn off the engine. Secure vehicle from movement by setting the parking brake.

  • Page 266: Cigarette Lighter

    Controls in detail Useful features Cigarette lighter 1 Cover plate 2 Cigarette lighter Switch on ignition ( page 33). Briefly press the bottom of cover plate 1. The cover plate opens automatically. Push in cigarette lighter 2. The cigarette lighter will pop out automatically when hot.

  • Page 267: Telephone

    The external antenna must be approved by Mercedes-Benz. Please contact an autho- rized Mercedes-Benz Center for informa- tion on the installation of an approved external antenna. Refer to the radio trans- mitter operation instructions regarding use of an external antenna.

  • Page 268: Tele Aid

    Controls in detail Useful features You can take and place telephone calls using the s and t buttons on the steering wheel. To carry out other tele- phone functions, use the control system ( page 158). See separate operating manual for instruc- tions on how to use the telephone.
  • Page 269 If a malfunction is indicated as outlined above, the system may not operate as expected. Have the system checked at the nearest Mercedes-Benz Center as soon as possible.
  • Page 270 Controls in detail Useful features Emergency calls An emergency call is initiated automatically following an accident in which the emergency tensioning devices (ETDs) or air bags deploy. An emergency call can also be initiated manually by opening the cover next to the interior rear view mirror labeled SOS, then briefly pressing the button located under the cover.
  • Page 271 Located below the center armrest cover is the Roadside Assistance button •. Press and hold button (for longer than two seconds). A call to a Mercedes-Benz Roadside Assistance dispatcher will be initiated. The button will flash while the call is in progress. The message...

  • Page 272: Information Button

    Controls in detail Useful features The Mercedes-Benz Roadside Assistance dispatcher will either dispatch a qualified Mercedes-Benz technician or arrange to tow your vehicle to the nearest authorized Mercedes-Benz Center. For services such as labor and/or towing, charges may apply. Refer to the Roadside Assistance manual for more information.
  • Page 273 Tele Aid system has detected a malfunction or the service is not currently active, and may not initiate a call. Visit your Mercedes-Benz Center and have the system checked or contact the Response Center at 1-800-756-9018 (in the USA) or 1-888-923-8367 (in Canada) as soon as possible.
  • Page 274 If the indicator lamp continues to flash or the system does not reset, contact the Response Center at 1-800-756-9018 (in the USA) or 1-888-923-8367 (in Canada), or Mercedes-Benz Customer Assistance at 1-800-FOR-MERCedes (1-800-367-6372) in the USA or Customer Service at 1-800-387-0100 in Canada.
  • Page 275 In case you have locked your vehicle unin- tentionally (e.g. SmartKey inside vehicle), and the reserve SmartKey is not handy: Contact the Mercedes-Benz Response Center at 1-800-756-9018 (in the USA) or 1-888-923-8367 (in Canada). You will be asked to provide your pass- word which you provided when you completed the subscriber agreement.

  • Page 276: Garage Door Opener

    Controls in detail Useful features Garage door opener* The built-in remote control is capable of operating up to three separately controlled devices, for example garage door openers, gate openers, or other devices compatible ® with HomeLink or some other systems. You can program the signal transmitter buttons.
  • Page 277 Certain types of garage door openers are incompatible with the integrated opener. If you should experience difficulties with programming the transmitter, contact an authorized Mercedes-Benz Center, or call Mercedes-Benz Customer Assistance Center (in the USA only) at 1-800-FOR-MERCedes, or Customer Service (in Canada) at 1-800-387-0100.
  • Page 278 Controls in detail Useful features Programming or reprogramming the integrated remote control Step 1: Switch on ignition ( page 33). Step 2: If you have previously programmed an integrated signal transmitter button and wish to retain its programming, proceed to step 3. Otherwise, press and hold the two outer signal transmit- ter buttons 2 and 4 and release them only when the indicator lamp 1...
  • Page 279 If the indicator lamp 1 flashes rapidly for about two seconds and then turns to a constant light, continue with programming steps 8 through 12 as your garage door opener may be equipped with the “rolling code” feature. Step 7: To program the remaining two buttons, repeat the steps above starting with step 3.
  • Page 280 Controls in detail Useful features Step 12: Confirm the garage door operation by pressing the programmed integrated signal transmitter button (2, 3 or 4). Step 13: To program the remaining two buttons, repeat the steps above starting with step 3. Gate operator/Canadian programming Canadian radio-frequency laws require transmitter signals to “time-out”...
  • Page 281 Operation of integrated remote control Switch on ignition ( page 33). Select and press the appropriate integrated signal transmitter button (2, 3 or 4) to activate the remote controlled device. The integrated remote control trans- mitter continues to send the signal as long as the button is pressed –...

  • Page 283: Operation

    Operation The first 1000 miles (1500 km) Driving instructions At the gas station Engine compartment Tires and wheels Winter driving Maintenance Vehicle care...

  • Page 284: The First 1000 Miles (1500 Km)

    Operation The first 1000 miles (1500 km) In the “Operation” section you will find detailed information on operating, main- taining and caring for your vehicle. The more cautiously you treat your vehicle during the break-in period, the more satis- fied you will be with its performance later Drive your vehicle during the first 1000 miles (1500 km) at varying but moderate vehicle and engine speeds.

  • Page 285: Driving Instructions

    Have all maintenance work performed at the intervals specified in the Maintenance Booklet and as required by the maintenance service display. Contact an authorized Mercedes-Benz Center. Fuel consumption is also increased by driving in cold weather, in stop-and-go traffic, on short trips and in hilly area.

  • Page 286: Brakes

    Contact an authorized Mercedes-Benz Center. Only install brake pads and brake fluid rec- ommended by Mercedes-Benz. Warning! If other than recommended brake pads are installed, or other than recommended brake fluid is used, the braking properties of the vehicle can be degraded to an extent that safe braking is substantially impaired.

  • Page 287: Driving Off

    ESP switched off. Doing so may cause serious damage to the drivetrain which is not covered by the Mercedes-Benz Limited Warranty. Simultaneously depressing the accelerator pedal and applying the brake reduces engine performance and causes premature brake and drivetrain wear.

  • Page 288: Tires

    Inspect the tires and the vehicle underbody for possible damage. If the vehicle or tires appear unsafe, have it towed to the nearest Mercedes-Benz Center or tire dealer for repairs. Treadwear indicators (TWI) are required by law. These indicators are located in six...

  • Page 289: Tire Traction

    If ice has formed on the road, tire traction will be substantially reduced. Under such weather conditions, drive, steer and brake with extreme caution. Mercedes-Benz recommends M+S rated radial-ply tires with a minimum tread depth of approximately in (4 mm) on all four wheels for the winter season to ensure normal balanced handling characteristics.

  • Page 290: Winter Driving Instructions

    Operation Driving instructions Your vehicle is factory equipped with “H”-rated tires, which have a speed rating of 130 mph (210 km/h). An electronic speed limiter prevents your vehicle from exceeding the tire speed rating. For information on speed rating for winter tires, see “Winter tires”...

  • Page 291: Standing Water

    Any such damage is not covered by the Mercedes-Benz Limited Warranty. Operation Driving instructions Passenger compartment Warning! Always fasten items being carried as securely as possible.

  • Page 292: Driving Abroad

    Operation Driving instructions Driving abroad Abroad, there is an extensive Mercedes-Benz service network at your disposal. If you plan to drive into areas which are not listed in the index of your Mercedes-Benz Center directory, you should request pertinent information from an authorized Mercedes-Benz Center.

  • Page 293: Catalytic Converter

    Catalytic converter Your Mercedes-Benz is equipped with monolithic-type catalytic converters, an important element in conjunction with the oxygen sensors to achieve substantial control of the pollutants in the exhaust emissions. Keep your vehicle in proper operating condition by following our recommended maintenance instructions as outlined in your Maintenance Booklet.

  • Page 294: Coolant Temperature

    The engine should not be operated with the coolant temperature above 248°F (120°C). Doing so may cause serious engine damage which is not covered by the Mercedes-Benz Limited Warranty. Warning! Driving when your engine is badly overheated can cause some fluids, which may have leaked into the engine compartment, to catch fire.

  • Page 295: At The Gas Station

    At the gas station Refueling Warning! Gasoline is highly flammable and poisonous. It burns violently and can cause serious injury. Whenever you are around gasoline, avoid inhaling fumes and skin contact, extinguish all smoking materials. Never allow sparks, flame or smoking materials near gasoline! Warning! Flexible Fuel Vehicles only (identified by a...
  • Page 296 Operation At the gas station Open the fuel filler flap by pushing at the point indicated by arrow 1. The fuel filler flap springs open. Turn fuel cap counterclockwise and hold on to it until possible pressure is released. Take off cap and set it in direction of arrow 2 in the recess on fuel filler flap.

  • Page 297: Check Regularly And Before A Long Trip

    Notify an authorized Mercedes-Benz Center immediately. Do not add brake fluid as this will not solve the problem. For more information, see “Practical hints”...

  • Page 298: Engine Compartment

    Operation Engine compartment Hood Warning! Do not pull the release lever while the vehicle is in motion. Otherwise the hood could be forced open by passing air flow. Opening The hood lock release lever is located to the left of the steering wheel under the dashboard.
  • Page 299 Warning! If you see flames or smoke coming from the engine compartment, or if the coolant tem- perature display indicates that the engine is overheated, do not open the hood. Move away from vehicle and do not open the hood until the engine has cooled.

  • Page 300: Engine Oil

    Do not use any special lubricant addi- tives, as these may damage the drive assemblies. Using special additives not approved by Mercedes-Benz may cause damage not covered by the Mercedes-Benz Limited Warranty. More information on this subject is available at any Mercedes-Benz Center.
  • Page 301 Mercedes-Benz Center. Excess oil must be siphoned or drained off. It could cause damage to the engine and catalytic converter not covered by the Mercedes-Benz Limited Warranty. More information on messages in the display concerning engine oil can be found in the “Practical hints”...

  • Page 302: Transmission Fluid Level

    Maintenance System (U.S. vehicles) or FSS (Canada Vehicles) will result in engine damage not covered by the Mercedes-Benz Limited Warranty. 1 Filler cap Unscrew filler cap 1 from filler neck.

  • Page 303: Coolant Level

    Coolant level The engine coolant is a mixture of water and anticorrosion/antifreeze. To check the coolant level, the vehicle must be parked on level ground and the engine must be cool. The coolant expansion tank is located on the passenger side of the engine compart- ment.

  • Page 304: Battery

    When replacing the battery, always use batteries approved by Mercedes-Benz. If you do not intend to operate your vehicle for an extended period of time, consult an authorized Mercedes-Benz Center about steps you need to observe.

  • Page 305: Windshield Washer System And Headlamp Cleaning System

    Windshield washer system and headlamp cleaning system* The windshield washer reservoir is located in the engine compartment. 1 Washer fluid reservoir cap Fluid for the windshield washer system and the headlamp cleaning system* is supplied from the windshield washer reservoir. It has a capacity of: 3.2 US qt (3.0 l) in vehicles without headlamp cleaning system*...

  • Page 306: Tires And Wheels

    When replacing rims, only use genuine Mercedes-Benz wheel bolts specified for the particular rim type. Failure to do so can result in the bolts loosening and possibly an accident.

  • Page 307: Tire Care And Maintenance

    Tire care and maintenance Warning! Regularly check the tires for damage. Dam- aged tires can cause tire inflation pressure loss. As a result, you could lose control of your vehicle. Worn, old tires can cause accidents. If the tire tread is badly worn, or if the tires have sustained damage, replace them.
  • Page 308 Operation Tires and wheels Tread depth Do not allow your tires to wear down too far. Adhesion properties on wet roads are sharply reduced at tread depths under in (3 mm). Treadwear indicators (TWI) are required by law. These indicators are located in six places on the tread circumference and become visible at a tread depth of approx- imately...

  • Page 309: Direction Of Rotation

    Direction of rotation Unidirectional tires offer added advan- tages, such as better hydroplaning perfor- mance. To benefit, however, you must make sure the tires rotate in the direction specified. An arrow on the sidewall indicates the intended direction of rotation (spinning) of the tire.
  • Page 310 Operation Tires and wheels 1 Driver’s door B-pillar Following is a discussion on how to work with the information contained on the two placards with regards to loading your vehicle. Tire and Loading Information Warning! Do not overload the tires by exceeding the specified load limit or vehicle capacity weight as indicated on the placard on the driver’s door B-pillar.
  • Page 311 Placard (Example B) 1 Load limit information on the Vehicle Tire Information placard The placard showing the load limit informa- tion is located on the driver’s door B-pillar. If your vehicle is equipped with the Vehicle Tire Information placard (Example B), locate the heading “Vehicle Capacity Weight”...
  • Page 312 Operation Tires and wheels Steps for determining correct load limit The following steps have been developed as required of all manufacturers under Title 49, Code of U.S. Federal Regulations, Part 575 pursuant to the “National Traffic and Motor Vehicle Safety Act of 1966”. Step 1 (Vehicles equipped with placard Example A) Locate the statement “The combined...
  • Page 313 Example Combined Number of Seating weight limit occupants configura- of occu- (driver and tion pants and passengers) cargo from placard 1500 lbs front: 2 rear: 3 1500 lbs front: 1 rear: 2 1500 lbs front:1 The higher the weight of all occupants, the less cargo and luggage load capacity is available.
  • Page 314 The tongue load typically is ten percent of the trailer weight and every- thing loaded in it. Your Mercedes-Benz has been designed primarily to carry passengers and their cargo. Mercedes-Benz does not recom- mend trailer towing with your vehicle.

  • Page 315: Recommended Tire Inflation Pressure

    Recommended tire inflation pressure Warning! Follow recommended tire inflation pressures. Do not underinflate tires. Underinflated tires wear excessively and/or unevenly, adversely affect handling and fuel economy, and are more likely to fail from being over- heated. Do not overinflate tires. Overinflated tires can adversely affect handling and ride comfort, wear unevenly, increase stopping distance, and result in sudden deflation...
  • Page 316 Operation Tires and wheels Placard (Example A) 1 Tire and Loading Information placard with recommended cold tire inflation pressures Placard (Example A) lists the recommend- ed cold tire inflation pressures for maxi- mum loaded vehicle weight. The tire inflation pressures listed apply to the tires installed as original equipment.

  • Page 317: Checking Tire Inflation Pressure

    Be sure to readjust the tire inflation pressure for normal driving speeds. You should wait until the tires are cold before adjusting the tire inflation pressure. Some vehicles may have supplemental tire inflation pressure information for vehicle loads less than the maximum loaded vehicle condition.
  • Page 318 Operation Tires and wheels If you have overfilled the tire, release tire inflation pressure by pushing the metal stem of the valve with e.g. a tip of a pen. Then recheck the tire inflation pressure with the tire gauge. Install the valve cap. Repeat this procedure for each tire.

  • Page 319: Tire Labeling

    Overinflated tire inflation pressure Overinflated tires can: adversely affect handling characteristics cause uneven tire wear be more prone to damage from road hazards adversely affect ride comfort increase stopping distance Warning! Follow recommended tire inflation pressures. Do not overinflate tires. Overinflated tires can adversely affect handling and ride comfort, wear unevenly, increase stopping distance, and result in sudden deflation...
  • Page 320 Operation Tires and wheels Tire size designation, load and speed rating 1 Tire width 2 Aspect ratio in % 3 Radial tire code 4 Rim diameter 5 Tire load rating 6 Tire speed rating For illustration purposes only. Actual data on tires is specific to each vehicle and may vary from data shown in above illustration.
  • Page 321 Rim diameter The rim diameter 4 ( page 318) is the diameter of the bead seat, not the diameter of the rim edge. Rim diameter is indicated in inches (in). Tire load rating The tire load rating 5 ( page 318) is a numerical code associated with the maximum load a tire can support.
  • Page 322 Operation Tires and wheels Tire speed rating The tire speed rating 6 ( page 318) indicates the approved maximum speed for the tire. Warning! Even when permitted by law, never operate a vehicle at speeds greater than the maximum speed rating of the tires. Exceeding the maximum speed for which tires are rated can lead to sudden tire failure, causing loss of vehicle control and...

  • Page 323: Load Identification

    If a service description 5 and 6 All-season and winter tires ( page 318) is given, the speed capa- Index bility is limited by the speed symbol in Q M+S the service description. Example: 245/40 ZR18 97Y. T M+S In this example, “97Y” is the service H M+S description.

  • Page 324: Dot, Tire Identification Number (Tin)

    Operation Tires and wheels In addition to tire load rating, special load information may be molded into the tire sidewall following the letter designating the tire speed rating 1 ( page 321). No specification given: absence of any text (like in above example) indicates a standard load (SL) tire.

  • Page 325: Maximum Tire Load

    DOT (Department of Transportation) A tire branding symbol 1 ( page 322) which denotes the tire meets require- ments of the U.S. Department of Transpor- tation. Manufacturer’s identification mark The manufacturer’s identification mark 2 ( page 322) denotes the tire manufacturer.

  • Page 326: Maximum Tire Inflation Pressure

    Operation Tires and wheels Warning! Do not overload the tires by exceeding the specified load limit or vehicle capacity weight as indicated on the placard located on the driver’s door B-pillar. Overloading the tires can overheat them, possibly causing a blowout.

  • Page 327: Standards (U.s. Vehicles)

    Uniform Tire Quality Grading Standards (U.S. vehicles) Tire manufacturers are required to grade tires based on three performance factors: treadwear, traction, and temperature resistance. 1 Treadwear 2 Traction 3 Temperature resistance For illustration purposes only. Actual data on tires is specific to each vehicle and may vary from data shown in above illustration.
  • Page 328 Operation Tires and wheels Traction The traction grades, from highest to low- est, are AA, A, B, and C. Those grades rep- resent the tire’s ability to stop on wet pavement as measured under controlled conditions on specified government test surfaces of asphalt and concrete.

  • Page 329: Tire Ply Material

    Tire ply material 1 Plies in sidewall 2 Plies under tread For illustration purposes only. Actual data on tires is specific to each vehicle and may vary from data shown in above illustration. This marking tells you about the type of cord and number of plies in the sidewall and under the tread.
  • Page 330 Operation Tires and wheels Curb weight The weight of a motor vehicle with stan- dard equipment including the maximum capacity of fuel, oil, and coolant, and, if so equipped, air conditioning and additional optional equipment, but without passen- gers and cargo. DOT (Department of Transportation) A tire branding symbol which denotes the tire meets requirements of the...
  • Page 331 Normal occupant weight The number of occupants the vehicle is designed to seat, multiplied by 68 kilograms (150 lbs). Occupant distribution The distribution of occupants in a vehicle at their designated seating positions. Production options weight The combined weight of those installed regular production options weighing over 5 lbs (2.3 kilograms) in excess of those standard items which they replace, not...
  • Page 332 Operation Tires and wheels Tire speed rating Part of tire designation; indicates the speed range for which a tire is approved. Traction Force exerted by the vehicle on the road via the tires. The amount of grip provided. Tread The portion of a tire that comes into contact with the road.

  • Page 333: Rotating Tires

    Wheels could become loose if not tightened with a torque of 80 lb-ft (110 Nm). Only use genuine Mercedes-Benz wheel bolts specified for your vehicle’s rims. For information on wheel change, see the “Practical hints” section ( page 377) and...

  • Page 334: Winter Driving

    Operation Winter driving Before the onset of winter, have your vehicle winterized at an authorized Mercedes-Benz Center. This service includes: Check of anticorrosion and antifreeze concentration. Addition of cleaning concentrate to the water of the windshield and headlamp cleaning system. Add MB Concentrate “S”...

  • Page 335: Block Heater (Canada Only)

    Snow chains should only be used on the rear wheels. Follow the manufac- turer’s mounting instructions. Only use snow chains that are approved by Mercedes-Benz. Your authorized Mercedes-Benz Center will be glad to advise you on this subject. Use of snow chains may be prohibited depending on location.

  • Page 336: Maintenance

    Operation Maintenance We strongly recommend that you have your vehicle serviced by an authorized Mercedes-Benz Center, in accordance with the Maintenance Booklet at the times called for by the maintenance service indicator display. Failure to have the vehicle maintained in...

  • Page 337: Clearing The Maintenance Service Indicator

    Service A exceeded by XX Days Service A exceeded by XX Miles In addition, a signal sounds when the message appears. Any authorized Mercedes-Benz Center will reset the maintenance service indicator following a completed maintenance service. Operation Maintenance...

  • Page 338: Resetting The Maintenance Service Indicator

    Resetting the maintenance service indicator In the event that the maintenance service on your vehicle is not carried out by an authorized Mercedes-Benz Center, you can have the maintenance service indicator reset. The automotive maintenance facility carrying out the maintenance service will...

  • Page 339: Vehicle Care

    Post-production treatment is neither necessary nor recommended by Mercedes-Benz because of the possibility of incompatibility between materials used in the production process and others applied later.
  • Page 340 We have selected car-care products and compiled recommendations which are specially matched to our vehicles and which always reflect the latest technology. You can obtain Mercedes-Benz approved car-care products at an authorized Mercedes-Benz Center. Scratches, corrosive deposits, corrosion or damage due to negligent or incorrect care cannot always be removed or repaired with the car-care products recommended here.
  • Page 341 Vehicle washing Do not use hot water or wash your vehicle in direct sunlight. Only use a mild car wash detergent, such as Mercedes-Benz approved Car Shampoo. Thoroughly spray the vehicle with a dif- fused jet of water. Direct only a very weak spray towards the ventilation intake.
  • Page 342 If released, the force of the impact from the tensioning spring could crack the windshield. Light alloy wheels Mercedes-Benz approved Wheel Care should be used for regular cleaning of the light alloy wheels. If possible, clean wheels once a week with...
  • Page 343 Steering wheel and gear selector lever Wipe with a damp cloth and dry thoroughly or clean with Mercedes-Benz approved Leather Care. Cup holders Use a gentle dishwashing detergent or mild detergent for delicate fabrics as a washing solution. Wipe with a cloth moist- ened in lukewarm solution.
  • Page 344 Clean with soft bristle brush, or use a dry-shampoo cleaner in case of excessive dirt. MB Tex upholstery Pour Mercedes-Benz approved Interior Care onto soft lint-free cloth and apply with light pressure. Plastic and rubber parts Do not use oil or wax on these parts.

  • Page 345: Practical Hints

    Practical hints What to do if … Where will I find ...? Unlocking/locking in an emergency Opening/closing in an emergency Replacing SmartKey batteries Replacing bulbs Replacing wiper blades Flat tire Battery Jump starting Towing the vehicle Fuses...

  • Page 346: Uniform Tire Quality Grading What To Do If

    Read and observe messages in the display ( page 352). Have the system checked at an autho- rized Mercedes-Benz Center as soon as possible. Failure to follow these instructions increases the risk of an accident. Switch off electrical consumers that are currently not needed, e.g.
  • Page 347 Practical hints What to do if … Release the parking brake ( page 47). Risk of accident! Carefully stop the vehicle and notify an authorized Mercedes-Benz Center. Do not add brake fluid! This will not solve the problem.
  • Page 348 Suggested solution There is a malfunction in: Have the vehicle checked as soon as possible by an authorized The fuel management Mercedes-Benz Center. system An on-board diagnostic connector is The ignition system used by the service station to link the...
  • Page 349 If it is closed properly: Have the fuel system checked by an authorized Mercedes-Benz Center. Your fuel tank is empty. After refuelling start, turn off and restart the engine three or four times in succession.
  • Page 350 Suggested solution Switch the ESP back on ( page 87). If the ESP cannot be switched back on, have the system checked at an autho- rized Mercedes-Benz Center as soon as possible. When driving off, apply as little throttle as possible.
  • Page 351 (ETDs) could deploy unexpectedly or fail to deploy in an accident. For your safety, we strongly recommend that you visit an authorized Mercedes-Benz Center immediately to have the system checked; otherwise the SRS may not be deployed when needed in an accident, Practical hints What to do if …...

  • Page 352: Lamp In Center Console

    Possible cause Suggested solution The system is malfunctioning Have the system checked as soon as possible by an authorized Mercedes-Benz Center. Also note any messages in the multifunction display and follow corrective steps ( page 354).
  • Page 353 If the front passenger front air bag off indicator lamp remains out, have the system checked as soon as possible by an authorized Mercedes-Benz Center. Do not transport a child on the front passenger seat until the system has been repaired.

  • Page 354: Vehicle Status Messages In The Multifunction Display

    Mercedes-Benz Center. Failure to repair condition noted may cause damage not covered by the Mercedes-Benz Limited Warranty, or result in property damage or personal injury. Warning!
  • Page 355 Switching on the ignition causes all instrument cluster lamps (except low beam headlamp indicator lamp, high beam headlamp indicator lamp, and turn signal indicator lamps unless activated) as well as the multifunction display to come on. Make sure the lamps and multifunction display are in working order before starting your journey.
  • Page 356 Practical hints What to do if … Text messages Display message Front-pass. airbag activated See Operator’s Manual Possible cause Possible solution Air bag is activated while driving even Stop the vehicle in a safe location as soon as though a child, small individual, or possible and check the following: object below the system’s weight Make sure that there is nothing between seat...
  • Page 357 56 indicator lamp remains out even after performing the above corrective steps, have the system checked as soon as possible by an authorized Mercedes-Benz Center. remains out even after performing the above corrective steps, do not have any children12 years old and under and other small individuals use the front passenger seat until the system has been repaired.
  • Page 358 Practical hints What to do if … Display message Front-pass. airbag deactivated See Operator’s Manual Possible cause Possible solution Air bag is deactivated while driving Stop the vehicle in a safe location as soon as even though an adult or someone possible and check the following: larger than a small individual is Do not lean on armrests or lift yourself up...
  • Page 359 56 indicator lamp remains on even after performing the above corrective steps, have the system checked as soon as possible by an authorized Mercedes-Benz Center. Do not have any passenger use the front passenger seat until the system has been repaired.
  • Page 360 Continue driving with added caution. Wheels may lock during hard braking, reducing steering capability. Have the system checked at an authorized Mercedes-Benz Center as soon as possible. Continue driving with added caution. Wheels may lock during hard braking, reducing steering capability.
  • Page 361 If necessary, have the generator and battery checked. Continue driving with added caution. Have the system checked at an authorized Mercedes-Benz Center as soon as possible. Continue driving with added caution. Have the system checked at an authorized Mercedes-Benz Center as...
  • Page 362 When the voltage is above this value again, the ESP is operational again. Continue driving with added caution. Visit an authorized Mercedes-Benz Center as soon as possible. Continue driving with added caution. If necessary, have the generator and battery checked.
  • Page 363 The system is malfunctioning. For your safety, we strongly recommend that you visit an authorized Mercedes-Benz Center immediately to have the system checked; otherwise the SRS may not be deployed when needed in an accident, Practical hints What to do if …...
  • Page 364 Do not continue to drive. Otherwise the engine will overheat due to an inoperative water pump which may result in damage to the engine. Notify an authorized Mercedes-Benz Center. Drive immediately to the nearest authorized Mercedes-Benz Center. Start the engine ( page 46).
  • Page 365 ( page 47). Have the brake pads replaced as soon as possible. Risk of accident! Stop the vehicle and notify an authorized Mercedes-Benz Center. Do not add brake fluid! This will not solve the problem. Brake pad thickness must be visually...
  • Page 366 Do not ignore the low engine coolant level warning. Extended driving with the message and symbol displayed may cause serious engine damage not covered by the Mercedes-Benz Limited Warranty. Do not drive without sufficient amount of coolant in the cooling system. The engine will overheat causing major engine damage.
  • Page 367 Only start the engine again after the message disappears. You could otherwise damage the engine. The engine should not be operated with the coolant temperature above 248°F (120°C). Doing so may cause serious engine damage which is not covered by the Mercedes-Benz Limited Warranty.
  • Page 368 Do not continue to drive the vehicle with this message displayed. Doing so could result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty. Observe the coolant temperature gauge in the instrument cluster ( page 24).
  • Page 369 Cruise control display You are attempting to drive with one or more doors open. Practical hints What to do if … Visit an authorized Mercedes-Benz Center. Continue driving with added caution. Visit an authorized Mercedes-Benz Center as soon as possible.
  • Page 370 Practical hints What to do if … Display symbol Display message USA only: At next gas station add 1.0 qt engine oil Canada only: At next gas station add 1.0 l engine oil Engine oil level Stop, engine off! Engine oil level Reduce oil level Change engine oil Visit workshop.
  • Page 371 Have the measuring system checked by an authorized Mercedes-Benz Center. The engine oil level warnings should not be ignored. Extended driving with the symbol displayed could result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty.
  • Page 372 No additional code available for SmartKey. Check the fuel cap ( page 293). Close the fuel cap. Have the fuel system checked by an authorized Mercedes-Benz Center. Close the hood ( page 296). Remove the SmartKey from the starter switch. Change the SmartKey.
  • Page 373 The right front side marker lamp is malfunctioning. Practical hints What to do if … Visit an authorized Mercedes-Benz Center as soon as possible. Replace the bulb as soon as possible. Replace the bulb as soon as possible. Visit an authorized Mercedes-Benz Center as soon as possible.
  • Page 374 In the control system, set lamp operation to manual ( page 150). Switch on the headlamps using the exterior lamp switch ( page 116). Visit an authorized Mercedes-Benz Center as soon as possible. Replace the bulb as soon as possible. Visit an authorized Mercedes-Benz...
  • Page 375 A substitute bulb is being used. Practical hints What to do if … Replace the bulb as soon as possible. Visit an authorized Mercedes-Benz Center as soon as possible. Replace the bulb as soon as possible. Replace the bulb as soon as possible.
  • Page 376 A substitute bulb is being used. Replace the bulb as soon as possible. Replace the bulb as soon as possible. Visit an authorized Mercedes-Benz Center as soon as possible. Visit an authorized Mercedes-Benz Center as soon as possible. Replace the bulb as soon as possible.
  • Page 377 Do not add steering oil without checking the steering system. Do not drive the vehicle. Have the system checked at an authorized Mercedes-Benz Center as soon as possible. Possible cause Possible solution The seat belt system is malfunctioning.
  • Page 378 The fluid level has dropped to about of total reservoir capacity. Close the tilt/sliding sunroof ( page 243). Close the tilt/sliding sunroof ( page 243). Have the Tele Aid system* checked by an authorized Mercedes-Benz Center. Close the tailgate. Add washer fluid ( page 303).

  • Page 379: Where Will I Find

    Where will I find ...? First aid kit The first aid kit is located in the storage compartment behind the left trim panel. Press button 1. Fold down panel 2. Vehicle tool kit The vehicle tool kit is located in the storage compartment behind the left trim panel.
  • Page 380 Practical hints Where will I find ...? 3 Vehicle tool kit The following is included: Towing eye bolt Wheel wrench Alignment bolt Vehicle jack Spare wheel bolts Fuse extractor Spare fuses Collapsible wheel chock A pair of gloves Vehicle jack Warning! The jack is designed exclusively for jacking up the vehicle at the jack take-up brackets...
  • Page 381 Operational position Turn crank handle clockwise until it engages (operational position). Before storing the vehicle jack in its compartment: It should be fully collapsed. The handle must be folded in (storage position). Setting up the collapsible wheel chock The collapsible wheel chock serves to additionally secure the vehicle, e.g.

  • Page 382: Minispare Wheel

    Practical hints Where will I find ...? Minispare wheel The Minispare wheel is located in the storage compartment underneath the cargo compartment floor. Removing the Minispare wheel Lift up cargo compartment floor cover. 1 Storage box Remove storage box 1. 2 Retaining screw 3 Minispare wheel Loosen retaining screw 2 by turning it...
  • Page 383 In the case of a flat tire, you may temporarily use the Minispare wheel when observing the following restrictions: Do not exceed a vehicle speed of 50 mph (80 km/h). Drive to the nearest tire repair facility to have the flat tire repaired or replaced as appropriate.

  • Page 384: Unlocking/Locking In An Emergency

    Practical hints Unlocking/locking in an emergency Unlocking the vehicle If you are unable to unlock the vehicle with the SmartKey, open the driver’s door using the mechanical key and the tailgate using the emergency release. Removing the mechanical key 1 Mechanical key locking tab 2 Mechanical key Move locking tab 1 in direction of arrow.

  • Page 385: Locking The Vehicle

    Remove cover 2 from the trim on the Locking the vehicle tailgate. If you are unable to lock the vehicle with Push release lever 1 all the way to the the SmartKey, do the following: right. Lift the tailgate. Always make sure there is sufficient overhead clearance.

  • Page 386: Fuel Filler Flap

    Practical hints Unlocking/locking in an emergency Fuel filler flap In case the central locking system does not release the fuel filler flap, you can open it manually. Warning! If you operate the emergency release button, be careful of the sharp edges so that you do not injure yourself.

  • Page 387: Opening/Closing In An Emergency

    Opening/closing in an emergency Power tilt/sliding sunroof* You can open or close the tilt/sliding sunroof manually should an electrical malfunction occur. The tilt/sliding sunroof drive is located behind the lens 1 of the interior overhead light. Remove SmartKey from the starter switch.

  • Page 388: Replacing Smartkey Batteries

    Many states require sellers of batteries to accept old batteries for recycling. When inserting the batteries, make sure they are clean and free of lint. When replacing batteries, always replace both batteries. The required replacement batteries are available at any Mercedes-Benz Center.

  • Page 389: Smartkey

    SmartKey Replacement batteries: Lithium, type CR 2025 or equivalent. Remove the mechanical key ( page 382). 1 Mechanical key 2 Battery compartment Insert mechanical key 1 in side opening and push grey slide. Battery compartment 2 is unlatched. Pull battery compartment 2 out of the housing in direction of arrow.

  • Page 390: Replacing Bulbs

    Correct headlamp adjustment is extremely important. Have headlamps checked and readjusted at regular intervals and when a bulb has been replaced. See an authorized Mercedes-Benz Center for headlamp adjustment. Bulbs If the headlamps or front fog lamps are fogged up on the inside as a result of...
  • Page 391 Low and high beam D2S-35 W Vehicles with Bi-Xenon* headlamps: Low beam and high beam use the same D2S-35W lamp. Do not replace the Xenon bulbs yourself. See an authorized Mercedes-Benz Center. Lamp Type 4 Halogen headlamp: High beam/high beam...

  • Page 392: Replacing Bulbs

    Your hands should be dry and free of oil and grease. If the newly installed bulb does not come on, visit an authorized Mercedes-Benz Center. Have the LEDs and bulbs for the following lamps replaced by an authorized Mercedes-Benz Center:...

  • Page 393: Replacing Bulbs For Front Lamps

    Replacing bulbs for front lamps Before you start to replace a bulb for a front lamp, do the following first: Turn the exterior lamp switch to position M ( page 116). Open the hood ( page 296) (except for side marker lamps). Halogen headlamp 1 Housing cover for low beam headlamp 2 Housing cover for high beam head-...
  • Page 394 Practical hints Replacing bulbs High beam bulb Press the clamp on housing cover 2 and remove it. Pull the electrical connector off. Turn bulb socket 5 counterclockwise and take out the bulb. Insert the new bulb so that its socket locates in the recess of the lamp housing.
  • Page 395 Bi-Xenon* headlamp Warning! Do not remove the cover 1 for the Bi-Xenon headlamp. Because of high voltage in Bi-Xenon lamps, it is dangerous to replace the bulb or repair the lamp and its compo- nents. We recommend that you have such work done by a qualified technician.
  • Page 396 Practical hints Replacing bulbs Front turn signal lamp bulb Turn bulb socket 3 with the bulb counterclockwise and remove it. Press gently onto the bulb and turn it counterclockwise out of bulb socket 3. Press new bulb gently into bulb socket 3 and turn clockwise until it engages.

  • Page 397: Replacing Bulbs For Rear Lamps

    Replacing bulbs for rear lamps Before you start to replace a bulb for a rear lamp, do the following first: Turn the exterior lamp switch to position M ( page 116). Open the tailgate ( page 101). Tail lamp unit 1 Latch 2 Trim panel Press latch 1 on the corresponding...
  • Page 398 Practical hints Replacing bulbs Bulb carrier 4 Brake lamp bulb 5 Turn signal lamp bulb 6 Backup lamp bulb 7 Rear fog lamp (driver’s side only), tail, parking, standing and side marker lamp bulb Press gently onto the respective bulb License plate lamp and turn counterclockwise out of its bulb socket.

  • Page 399: Replacing Wiper Blades

    Make certain that the wiper blades are properly installed. Improperly installed wiper blades may cause windshield damage. For your convenience, we recommend that you have this work carried out by an authorized Mercedes-Benz Center.

  • Page 400: Flat Tire

    50 mph (80 km/h). Drive to the nearest Mercedes-Benz Center as soon as possible to have the Minispare wheel replaced with a regular road wheel. Never operate the vehicle with more than one Minispare wheel mounted.
  • Page 401 Lifting the vehicle Prevent the vehicle from rolling away by blocking wheels with wheel chocks or other sizable objects. One wheel chock is included with the vehicle tool kit ( page 378). When changing wheel on a level surface: Place the wheel chock in front of and another sizable object behind the wheel that is diagonally opposite to the wheel being changed.
  • Page 402 Practical hints Flat tire The jack take-up brackets are located directly behind the front wheel housings and in front of the rear wheel housings. 1 Take-up bracket 2 Jack Place jack 2 on firm ground. Position jack 2 under take-up bracket 1 so that it is always vertical (plumb-line) as seen from the side, even if the vehicle is parked on an...
  • Page 403 Never apply oil or grease to wheel bolts. Damaged wheel hub threads should be repaired immediately. Do not continue to drive under these circumstances! Contact an authorized Mercedes-Benz Center or call Roadside Assistance. Incorrect wheel bolts or improperly tight- ened wheel bolts can cause the wheel to come off.
  • Page 404 Unscrew the alignment bolt, install last wheel bolt and tighten slightly. Warning! Only use genuine equipment Mercedes-Benz wheel bolts. Other wheel bolts may come loose. Do not tighten the wheel bolts when the vehicle is raised. Otherwise the vehicle could fall off the jack.

  • Page 405: Battery

    Have the battery checked regularly by an authorized Mercedes-Benz Center. Refer to Maintenance Booklet for main- tenance intervals or contact an autho- rized Mercedes-Benz Center for further information. Warning! Do not place metal objects on the battery as this could result in a short circuit.

  • Page 406: Disconnecting The Battery

    Practical hints Battery Warning! With a disconnected battery you will no longer be able to turn the SmartKey in the starter switch the gear selector lever will remain locked in position P 1 Negative terminal 2 Positive terminal cover Disconnecting the battery Turn off the engine ( page 57).

  • Page 407: Reconnecting The Battery

    Reconnecting the battery Turn off all electrical consumers. Remove SmartKey from starter switch. Connect the battery positive lead and fasten its cover 2. Connect the battery negative lead. NEVER invert the terminal connections. Reinstall the filter box ( page 403). The battery, its filler caps and the vent tube must always be securely installed when the vehicle is in operation.

  • Page 408: Jump Starting

    (12 V). Jump starting with a more powerful battery could damage the vehicle’s electrical system, which will not be covered by the Mercedes-Benz Limited Warranty. Only use jumper cables with sufficient cross-section and insulated terminal clamps. Always make sure the jumper cables...
  • Page 409 Remove the jumper cables first from negative terminals 3 and 4 and then from positive terminals 2 and 1. You can now turn on the lights. Have the battery checked at the near- est authorized Mercedes-Benz Center. Do not tow-start the vehicle.

  • Page 410: Towing The Vehicle

    Practical hints Towing the vehicle Mercedes-Benz recommends that the vehicle be transported with all wheels off the ground using flatbed or appropriate wheel lift/dolly equipment. This method is preferable to other types of towing. Use flatbed or wheel lift/dolly equip- ment with the SmartKey in the starter switch turned to position 0.

  • Page 411: Towing The Vehicle

    Warning! To be certain to avoid a possibility of damage to the drivetrain, however, we If circumstances require towing the vehicle recommend the drive shaft be discon- with all wheels on the ground, always tow nected at the rear axle drive flange with a tow bar if: (vehicles with 4MATIC: disconnected at the front and rear axle drive flanges) for...
  • Page 412 Practical hints Towing the vehicle Warning! With the engine not running, there is no power assistance for the brake and steering systems. In this case, it is important to keep in mind that a considerably higher degree of effort is necessary to brake and steer the ve- hicle.

  • Page 413: Installing Towing Eye Bolt

    Installing towing eye bolt 1 Cover on right side of front bumper. 2 Cover on right side of rear bumper. Practical hints Towing the vehicle Removing cover Press mark on cover 1 or 2 in direction of arrows. Lift cover off to reveal threaded hole for towing eye bolt.

  • Page 414: Fuses

    ( page 413): Fuse chart Spare fuses Fuse extractor Warning! Only use fuses approved for Mercedes-Benz with the specified amperage for the system in question. Otherwise, a short circuit could result and cause a fire. Only install fuses that have been tested...

  • Page 415: Aids For Changing Fuses

    Aids for changing fuses Fuse chart The fuse chart is found in the main fuse box in the passenger compartment ( page 413). The amperages of the fuses are also given there. Spare fuses Spare fuses are found in the vehicle tool kit in the cargo compartment ( page 415).

  • Page 416: Fuse Box In Engine Compartment

    Practical hints Fuses Fuse box in engine compartment The fuse box is located in the engine compartment on the driver’s side. 1 Cover 2 Screws 3 Retainer Removing cover Twist screws 2 90° counterclockwise. Lift the rear of cover 1. Slide out retainer 3 and remove cover 1 by pulling towards front.

  • Page 417: Fuse Box In Cargo Compartment

    Fuse box in cargo compartment The fuse box is located in the cargo compartment behind the left hand trim panel. 1 Button for unlocking trim panel 2 Trim panel Opening trim panel Press button 1. Fold down trim panel 2. 3 Fuse extractor 4 Fuse box 5 Spare fuses...

  • Page 419: Technical Data

    Technical data Parts service Warranty coverage Identification labels Layout of poly-V-belt drive Engine Rims and Tires Electrical system Main Dimensions Weights Fuels, coolants, lubricants, etc.

  • Page 420: Parts Service

    Mercedes-Benz vehicles. Therefore, genuine Mercedes-Benz parts should be installed. The use of non-genuine Mercedes-Benz parts and accessories not authorized by Mercedes-Benz could damage the vehicle, which is not covered by the Mercedes-Benz Limited Warranty, or could compromise the vehicle’s...

  • Page 421: Warranty Coverage

    Emission System Warranty Emission Performance Warranty California, Maine, Massachusetts, and Vermont Emission Control Systems Warranty Replacement parts and accessories are covered by the Mercedes-Benz Parts and Accessories warranties, copies of which are available at any Mercedes-Benz Center. Technical data Warranty coverage...

  • Page 422: Identification Labels

    Technical data Identification labels 1 Certification label (includes Paintwork code) 2 Vehicle Identification Number (VIN) 3 Emission control information label, includes both federal and California certification exhaust emission standards 4 Engine number (engraved on engine) 5 VIN, visible (lower edge of windshield) 6 Vacuum line routing diagram label When ordering parts, please specify vehicle identification and engine...

  • Page 423: Layout Of Poly-V-Belt Drive

    Technical data Layout of poly-V-belt drive Layout of poly-V-belt drive C 240 (all models) 1 Automatic belt tensioner 2 Power steering pump 3 Air conditioning compressor 4 Crankshaft 5 Coolant pump 6 Generator (alternator) 7 Idler pulley...

  • Page 424: Engine

    Maximum engine speed Firing order Poly-V-belt The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies and special equipment. Premium fuel required. Performance may vary with fuel octane rating.

  • Page 425: Rims And Tires

    Rims and Tires Only use tires and rims which have been specifically developed for your vehicle and tested and approved by Mercedes-Benz. Other tires and rims can have detrimental effects, such as poor handling characteristics increased noise increased fuel consumption...

  • Page 426: Same Size Tires

    Technical data Rims and Tires Same size tires Model C 240 (all models) Rims (light alloy) 7 J x16 H2 Wheel offset 1.22 in (31 mm) All-season tires (radial-ply tires) 205/55 R16 91H M+S Summer tires (radial-ply tires) Winter tires (radial-ply tires) 205/55 R16 91H M+S...

  • Page 427: Minispare Wheel

    Minispare wheel Model C 240 (all models) Rim (steel) 3.5 B x16 H2 Wheel offset 0.67 in (17 mm) Tire T 125/90 R16 98M Must not be used with snow chains. Technical data Rims and Tires...

  • Page 428: Electrical System

    Technical data Electrical system Model C 240 (all models) Generator (alternator) 14 V/120 A Starter motor 12 V/1.7 kW Battery 12 V/100 Ah Spark plugs Bosch F 8 DPP 332 NGK PFR 5 R-11 Electrode gap 0.039 in (1.0 mm) Tightening torque 15 –...

  • Page 429: Main Dimensions

    Main Dimensions Model C 240 (all models) Overall vehicle length 179.0 in (4546 mm) Overall vehicle width 68.0 in (1728 mm) Overall vehicle height 57.8 in (1467 mm) Wheelbase 106.9 in (2715 mm) Track, front 59.3 in (1505 mm) Track, rear 58.1 in (1476 mm) Technical data Main Dimensions...

  • Page 430: Weights

    Technical data Weights Roof load max. 220 lb (100 kg)

  • Page 431: Fuels, Coolants, Lubricants, Etc

    0.5 US qt (0.5 l) MB Brake Fluid (DOT 4+) approx. 6.8 US qt (6.4 l) MB 325.0 Anticorrosion/Antifreeze Agent Technical data Fuels, coolants, lubricants, etc. Please refer to the Factory Approved Service Products pamphlet, or inquire at your Mercedes-Benz Center.
  • Page 432 Technical data Fuels, coolants, lubricants, etc. Model Fuel tank including a reserve of Air conditioning system Windshield washer Windshield washer and headlamp cleaning system* Use MB Windshield Washer Concentrate “S” and water for temperatures above freezing point or MB Windshield Washer Concentrate “S” and commercially available premixed windshield washer solvent/antifreeze for temperatures below freezing point.

  • Page 433: Engine Oils

    System (U.S. vehicles) or FSS (Canada vehicles). For a listing of approved engine oils and oil filters, refer to the Factory Approved Service Products pamphlet, or contact an authorized Mercedes-Benz Center. Using engine oils and oil filters of specification other than those expressly required for the Maintenance System (U.S.

  • Page 434: Premium Unleaded Gasoline

    Technical data Fuels, coolants, lubricants, etc. Premium unleaded gasoline To maintain the engine’s durability and performance, premium unleaded gaso- line must be used. If premium unleaded is not available and low octane fuel is used, follow these precautions: Have the fuel tank only partially filled with unleaded regular and fill up with premium unleaded as soon as possible.

  • Page 435: Gasoline Additives

    In areas where carbon deposits may be encountered due to lack of availability of gasolines which contain these additives, Mercedes-Benz recommends the use of additives approved by us for use on Mercedes-Benz vehicles. Refer to Factory Approved Service Products pamphlet for a listing of approved product(s).
  • Page 436 E85 compared to gasoline operation. Use of E85 may reduce your driving range. Maintenance Please inform your Mercedes-Benz Center if you use or have used E85 fuel when your vehicle is delivered for maintenance or repairs.

  • Page 437: Coolants

    The replacement interval published in the Maintenance Booklet is only applicable if MB 325.0 anticorrosion/antifreeze solution or other Mercedes-Benz approved products of equal specification (see Factory Approved Service Products pamphlet) are used to renew the coolant concentration or bring it back up to the proper level.
  • Page 438 Before the start of the winter season (or once a year in hot southern regions), you should have the anticorrosion/antifreeze concentration checked. The coolant is also regularly checked each time you bring your vehicle to an authorized Mercedes-Benz Center for service.

  • Page 439: Windshield Washer And Headlamp Cleaning System

    Windshield washer and headlamp cleaning system* Both the windshield washer and headlamp cleaning system* are supplied from the windshield washer fluid reservoir. The washer fluid reservoir has a capacity of approx.: 3.2 US qt (3.0 l) in vehicles without headlamp cleaning system* 6.4 US qt (6.0 l) in vehicles with headlamp cleaning system* Refill the reservoir with MB Windshield...

  • Page 441: Technical Terms

    Bi-Xenon headlamps produce low beam and high beam. (Customer Assistance Center) Mercedes-Benz customer service center, which can help you with any questions about your vehicle and provide assistance in the event of a breakdown.
  • Page 442 Technical terms Control system The control system is used to call up vehicle information and to change component settings. Information and messages appear in the multifunction display. The driver uses the buttons on the multifunction steering wheel to navigate through the system and to adjust settings.
  • Page 443 GAWR (Gross Axle Weight Rating) ( page 328) Gear range Number of gears which are available to the automatic transmission for shifting. The automatic gear shifting process can be adapted to specific operating conditions using the gear selector lever. (Global Positioning System) Satellite-based system for relaying geographic location information to and from vehicles equipped with special...
  • Page 444 Engine speeds within the red marking of the tachometer dial. Avoid this engine speed range, as it may result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty. Poly-V-belt drive Drives engine-components (alternator, AC compressor, etc.) from the engine.
  • Page 445 (Pounds per square inch) ( page 329) Recommended tire inflation pressure ( page 329) Restraint systems Seat belts, child restraints, lower anchors and tethers for children (LATCH). As independent systems, their protective functions complement one another. ( page 329) (Research Octane Number) The Research Octane Number for gaso- line as determined by a standardized method.
  • Page 446 Technical terms Telematics* A combination of the terms “tele- communications” and “informatics”. Tightening torque Force times lever arm (e.g. a lug wrench) with which threaded fasteners such as wheel bolts are tightened. (Tire Identification Number) ( page 329) Tire load rating ( page 329) Tire ply composition and material used ( page 329)

  • Page 447: Index

    ABS 85, 439 ABS control 85 Indicator lamp 25 Malfunction indicator lamp 344 Messages in display 358 Accelerator position, automatic transmission 169 Accessory weight 327 Accident In case of 54 Activating Air conditioning (cooling) 184, 196 Air recirculation mode 182, 193 Anti-theft alarm system* 92 Automatic climate control* 187 Central locking (control system) 153...
  • Page 448 Index Multicontour seat* 111 Placing upright rear seat head restraints 109 Power seat* 38 Rear seat head restraints 108 Seat belt height 45 Seat cushion depth 111 Seat cushion tilt, manual seat 36 Seat cushion tilt, power seat* 38 Seat fore and aft adjustment, manual seat 36 Seat fore and aft adjustment, power seat* 38...
  • Page 449 Anti-theft systems 91 Anti-theft alarm system* 91 Immobilizer 91 Tow-away alarm* 93 Aquaplaning see Hydroplaning Armrest Changing inclination of 259 Storage spaces 259 Armrest in rear passenger compartment 260 Ashtrays 262 Aspect ratio 327 ATF 300 AUDIO menu 135 Selecting radio station 136 Selecting satellite radio* station 136 Audio system 199 Audio and telephone, operation 199...
  • Page 450 Index Backrest Folding forward 254 Folding rearward 255 Backrest contour Adjusting 111 Backrest side bolsters Adjusting 111 Backrest tilt Manual seat 36 Power seat* 38 Backup lamps Messages in display 371 Replacing bulbs 389 Bar 327 BAS 86, 439 Messages in display 359 Batteries, SmartKey Changing 387 Check lamp 99...
  • Page 451 Low beam headlamps 389 Parking lamps, front 389, 392, 394 Parking lamps, rear 389, 396 Rear lamps 389 Side marker lamps, front 389, 394 Side marker lamps, rear 389, 396 Standing lamps, front 389, 392, 394 Standing lamps, rear 389, 396 Tail lamp unit 395 Tail lamps 389, 396 Turn signal lamps,...
  • Page 452 Index Changing Batteries (SmartKey) 387 CDs 217 Changing key setting 155 Charcoal filter 194 Activating 195 Deactivating 195 Charging Vehicle battery 404 Checking Brake fluid 295 Coolant level 295, 301 Engine oil level 295, 298 Tire inflation pressure 295 Vehicle lighting 295 Washer reservoir level 295 Child safety 70 Air bags 62...
  • Page 453 Combination switch 120 High beam flasher 49 Rear window wiper 53 Turn signals 50 Windshield wipers 50 Control and operation of radio transmitter 290 Control system 129, 440 AUDIO menu 135 Convenience submenu 154 Display digital speedometer 135 Display outside temperature 135 Functions 130, 133 Instrument cluster submenu 143, 145...
  • Page 454 Index Date (day) Setting 148 Date (month) Setting 147 Date (year) Setting 149 Daytime running lamp mode 118 Setting 150 Deactivating Air conditioning (cooling) 184, 196 Air recirculation mode 183, 194 Alarm 92 Anti-theft alarm system* 92 Automatic climate control* 187 Central locking (control system) 153 Charcoal filter 195 Climate control 177...
  • Page 455 Distance to empty (range) Calling up 158 Door control panel 30 Door entry lamps 124 Door handle 100 Door unlock With Tele Aid* 273 Doors Message in display 367 Opening from inside vehicle 100 Opening from the outside 98 DOT 328 Downhill driving Cruise control 248 Downshifting 164...
  • Page 456 Index Emergency operations Closing power tilt/sliding sunroof* 385 Locking the vehicle 383 Opening power tilt/sliding sunroof* 385 Remote door unlock 273 Unlocking the vehicle 382 Emergency Tensioning Device see ETD Emission control 291 Emission control information label 420 Ending A call (telephone*) 160 Engine Compartment 296 Starting with...
  • Page 457 Fahrenheit Setting temperature units 143 Fastening the seat belts 43 Fine adjustment Cruise control 249 First aid kit 377 Flat tire 398 Lowering the vehicle 402 Minispare wheel 380 Mounting the Minispare wheel 398 Preparing the vehicle 398 Flexible fuel vehicles 433 At the gas station 293 Switching fuels 434 Flexible Service System see FSS...
  • Page 458 Index Fuel additives 433 Fuel cap Message in display 347, 370 Fuel consumption statistics After start 157 Since last reset 157 Fuel filler flap 293 Locking 293 Opening in an emergency 384 Unlocking 293 Fuel gauge 25 Fuel requirements 432 For ethanol fuel 433 Fuel reserve Warning lamp 25...
  • Page 459 Global Locking 98 Unlocking 98 Global Positioning System see GPS Glove box 258 Closing 258 Locking 258 Opening 258 Unlocking 258 Good visibility 171 GPS 441 Gross Axle Weight Rating see GAWR Gross Vehicle Weight Rating see GVWR Gross Vehicle Weight see GVW GVW 328 GVWR 328 Halogen-type...
  • Page 460 Index Height adjustment Head restraints, manual seat 37 Head restraints, power seat* 38 Rear seat head restraints 108 Seat belts 45 Steering wheel, electrical* adjustment 40 Steering wheel, manual adjustment 40 High beam flasher 49, 120 High beam headlamps Indicator lamp 25 Messages in display 372 Replacing bulbs 389, 392 Switching on 49, 120...
  • Page 461 Interior lighting 123 Activating automatic control 123 Deactivating automatic control 123 Delayed shut-off 153 Manual operation 123 Interior rear view mirror Adjusting 41 Antiglare 171 Interior storage spaces 258 Armrest 259 Cup holder in rear seat armrest 261 Cup holders in front of seat armrest 260 Glove box 258 Parcel net in front...
  • Page 462 Index Labels, identification 420 Lamp bulbs, exterior 388 Lamp sensor Message in display 372 Lamps, exterior Front 389 Light sensor 372 Messages in display 371–374 Rear 389 Lamps, indicator and warning ABS 25, 344 Battery (SmartKey) 98 Brakes 25, 345 Engine diagnostics 346, 349 Engine malfunction 25, 346–347 ESP 25, 348...
  • Page 463 Loading 250 Cargo tie-down rings 257 Instructions 256 Roof rack* 250 Split rear bench seat 254 Loading terminology 327 Loading the vehicle 307 Locator lighting 119 Setting 151 Lock button 441 Locking 55, 96 Automatic while driving 102 Centrally from inside 103 Fuel filler flap 293 Global, SmartKey 98 Glove box 258...
  • Page 464 Index Manual operations Fuel filler flap 384 Interior lighting control 123 Locking the vehicle 383 Tilt/sliding sunroof* 385 Unlocking the driver’s door 382 Unlocking the tailgate 382 Unlocking transmission gear selector lever 384 Manual seat Adjusting 36 Adjusting backrest tilt 36 Adjusting head restraint height 37 Adjusting head restraint tilt 37 Adjusting seat cushion tilt 36...
  • Page 465 Motor Octane Number see MON Mph or km/h in speedometer 143 Multicontour seats* 111 Multifunction display 129, 442 Displaying gear range 165 Selecting language 144 Setting date (day) 148 Setting date (month) 147 Setting date (year) 149 Multifunction display messages ABS 358 BAS 359 Brake fluid 363...
  • Page 466 Index Occupant Classification System see OCS Occupant distribution 329 Occupant safety 60 Air bags 61 Children and air bags 62 Children in the vehicle 70 Fastening the seat belt 43 Front passenger front air bag off indicator lamp 77 Infant and child restraint systems 70 LATCH-type child seat anchors 80 OCS 73 Seat belts 43, 64...
  • Page 467 Paintwork 338 Panic alarm* 83 Panic button on SmartKey 83 Parcel net In cargo compartment 250 In front passenger footwell 262 Parking 55, 285 Parking brake 47, 55 Engaging 55 Message in display 363 Releasing 47 Parking lamps Messages in display 373 Parking lamps, front Replacing bulbs 389 Parking lamps, rear...
  • Page 468 Index Practical hints Collapsible wheel chock 379 First aid kit 377 Fuses 412 Lamp in center console 350 Lamps in instrument cluster 344 Minispare wheel 380 Symbol messages 362 Text messages 354 Towing the vehicle 408 Vehicle jack 377, 378 Vehicle status messages in the display 352 Vehicle tool kit 377...
  • Page 469 Rear lamps see Tail lamps Rear outer seats Adjusting head restraint height 108 Rear passenger compartment Adjustable air vents 185, 198 Rear seat ashtray 263 Rear seat head restraints 108 Adjusting 108 Adjusting tilt 110 Folding back 109 Installing 110 Outer seats 110 Placing upright 109 Removing 110...
  • Page 470 Index Reporting Safety defects 18 Research Octane Number see RON Reset button in the instrument cluster 125, 140, 141 Resetting All functions (control system) 140 All functions of a submenu 141 Fuel consumption 158 Maintenance service indicator 336 Trip odometer 127 Residual heat utilization 197 Residual ventilation 197 Restraint system...
  • Page 471 Selecting Automatic time change (summer/winter) 147 Display for status indicator 144 Station (satellite radio) 214 Selecting radio mode 207 Selector lever see gear selector lever Self-test OCS 78 Tele Aid* 267 Service Parts 418 Service and Warranty Booklet Loss of 419 Service and warranty information 10 Service life (tires) 305 Service see Maintenance...
  • Page 472 Index Settings Convenience functions 154 Factory, SmartKey 98 Individual, SmartKey 155 Lighting (control system) 149 Menus and submenus 131 Resetting all (control system) 140 Resetting in the submenu 141 Selective, SmartKey 98 Settings menu Functions in 140 Individual vehicle settings 140 Submenus 141 Shift lock 443 Shift program mode 129...
  • Page 473 Sliding out Swiveling cup holder, in front of seat armrest 260 SmartKey 96 Changing batteries 387 Locking and unlocking 96 Opening and closing the tilt/sliding sunroof* with 245 Opening and closing windows with 241 Unlocking with 32 Snow chains 333 Soft keys Audio system 202 Sound system* 204...
  • Page 474 Index Submenus Convenience 154 For settings 131 In control system 133 Instrument cluster 143, 145 Lighting 149 Resetting functions in control system 141 Selecting 141 Settings menu 141 Time/Date 145 Vehicle 153 Substitute lamps Bulbs 388 Sun visors 174 Supplemental Restraint System see SRS Switching Fuel (Flexible fuel vehicle) 434 Switching off...
  • Page 475 Tachometer 25, 127 Overspeed range 127 Tail lamps Cleaning 339 Messages in display 373 Replacing bulbs 389, 395 Tailgate Closing 101 Message in display 376 Opening 101 Tar stains 338 Technical data Air conditioning refrigerant 431 Brake fluid 431 Coolant 429 Coolants 435 Electrical system 426 Engine 422...
  • Page 476 Index Temperature Display mode 143 Setting interior temperature 179 Setting units in display 143 Tires 314 Tie-down rings (cargo compartment) 257 Tightening torque (wheel bolts) 402, 444 Tilt Head restraint, manual seat 37 Head restraint, power seat* 39 Tilt/sliding sunroof* Closing 243, 385 Closing with SmartKey 245 Messages in display 376...
  • Page 477 Transmission gear selector lever Unlocking manually 384 Transmission see Automatic transmission Traveling abroad 290 Tread 330 Tread depth 306 Tread depth (tires) 332 Treadwear indicators 330 Trim panel Closing 415 Opening 415 Trip computer 156 Trip odometer Resetting 127 Trunk see Cargo compartment Turn signal lamps, front Messages in display 374 Replacing bulbs 389...
  • Page 478 Index Upgrade scenario Tele Aid* 272 Uphill driving Cruise control 248 Upholstery Cleaning 341 Upshifting 164 Useful features 258 Ashtrays 262 Cigarette lighter 264 Electrical outlet 264 Interior storage spaces 258 Tele Aid* 266 Telephone* 265 Vacuum line routing diagram label 420 Vehicle Individual settings 140, 142 Locking 103...
  • Page 479 Vehicle Identification Number see VIN Vehicle jack 378 Vehicle lighting Checking 295 Vehicle loading terminology 327 Vehicle maximum load on the tire 330 Vehicle status message memory 138 Calling up 138 Clearing 139 Vehicle status messages Displaying 139 Vehicle tool kit 377 Alignment bolt 378 Collapsible wheel chock 378 Fuse extractor 378...
  • Page 480 Index Winter driving 332 Block heater (Canada only) 333 Snow chains 333 Tires 332 Winter driving instructions 288 Winter tires 332 Wiper blades Cleaning 340 Installing 397 Removing 397 Replacing 397 Wiping Rear window with washer fluid 53 Windshield with washer fluid 52 Wood trims Cleaning 342 Xenon headlamps...
  • Page 481 If you have questions about carrying out any type of service, turn to the advice of an authorized Mercedes-Benz Center.

This manual is also suitable for:

C-class wagon c 240 4maticC-class wagonC 240C 240 4matic

Table of Contents
