CONSTRUCTION NAVALE BORDEAUX
FR-CNB _ _ _ _ _ _ _ _ _
/.
BENETEAU REF:
CONTENTS:
1.
INTRODUCTION .....................................................................................................................................2
2.
CHARACTERISTICS ..............................................................................................................................4
2.1.
'
2.2.
2.3.
..................................................................................................................................................5
2.4.
3.
SAFETY ...................................................................................................................................................11
3.1.
..................................................................................................................................................11
3.2.
V
........................................................................................................................................13
3.3.
,
3.4.
3.5.
(
4.
EQUIPMENT ..........................................................................................................................................15
4.1.
.............................................................................................................................................15
4.2.
4.3.
4.4.
4.5.
4.6.
,
5.
ANCHORING, MOORING AND TOWING........................................................................................28
6.
HAULING OUT AND TRANSPORTATION ......................................................................................29
7.
SNSM........................................................................................................................................................30
8.
CHARTER FOR THE SEA AND INLAND WATERWAYS .............................................................31
LAGOON 440 - ANG - 12/06/06
OWNER'S MANUAL
LAGOON 440
..............................................................................................................4
.......................................................................................................................................4
............................................................................................................................7
..........................................................................................................13
)................................................................................................................14
............................................................................................................................17
........................................................................................................................18
.....................................................................................................................................23
.............................................................................................14
.........................................................................................24
.............................................................................................26
1 / 31

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 440 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lagoon 440

Summary of Contents for Lagoon 440

  • Page 1: Table Of Contents

    ..................24 RESHWATER AND BLACK WATER TANKS 4.6....................26 UMPS SEACOCKS AND SKIN FITTINGS ANCHORING, MOORING AND TOWING..................28 HAULING OUT AND TRANSPORTATION ..................29 SNSM................................30 CHARTER FOR THE SEA AND INLAND WATERWAYS .............31 LAGOON 440 – ANG – 12/06/06 1 / 31...

  • Page 2: Introduction

    Madame, Monsieur, Dear Madam, dear Sir, You have just taken delivery of your new LAGOON, and we would first of all like to thank you for your confidence in choosing one of our products. A LAGOON is built to last: each boat is the subject of attentive care down to the slightest details, from her design until she leaves the factory and is launched, so that she will provide you with the many years of joy that you expect from her.
  • Page 3 (regulations for the prevention of collisions at sea). Make sure you always have sufficient distance to stop or manœuvre if necessary in order to avoid a collision Explanation of the typography used: DANGER WARNING CAUTION LAGOON 440 – ANG – 12/06/06 3 / 31...

  • Page 4: Characteristics

    2.2. Dimensions LENGTH OF HULL 13.61 m* BEAM 7.68 m* LENGTH OVERALL 13.61 m BEAM OVERALL 7.68 m DRAUGHT: 1.30 m MAX AIR DRAUGHT 21.73 m * according to ISO 8666 standard LAGOON 440 – ANG – 12/06/06 4 / 31...

  • Page 5: Load

    Freshwater foot pump Microwave with grill Dishwasher Freezer instead of 2 fridge Watermaker Ice maker Cockpit fridge Washing machine Saloon fans Cabins fans Heating (Incompatible with air conditioning) Air conditioning 44000 BTU LAGOON 440 – ANG – 12/06/06 5 / 31...
  • Page 6 The maximum load recommended, as indicated on the boat builder’s plate required by the European directive 2003/44CE, does not include the weight of the contents of the rigid tanks when full (fuel, freshwater, grey and black water). LAGOON 440 – ANG – 12/06/06 6 / 31...

  • Page 7: Sails And Rigging

    For synthetic cables (Kevlar, Twaron, etc.) used for running backstays, halyards, sheets, docklines, etc.: Change as soon as signs of fray or wear appear. Regularly check the other elements of the rigging; sheets, docklines, etc. ; and replace if worn. LAGOON 440 – ANG – 12/06/06 7 / 31...
  • Page 8 2nd Reef 3rd Reef Mainsail halyard Mainsail outhaul Mainsheet Mainsail car control Genoa furler Mainsail car control Free Spinnaker halyard Genoa halyard Mainsail topping lift Genoa sheet Mainsheet (spare) Genoa sheet LAGOON 440 – ANG – 12/06/06 8 / 31...
  • Page 9 Furling mast DESCRIPTION Foot Furler Free Main halyard Mainsheet Mainsheet car control Genoa furler Mainsheet car control Free Spinnaker halyard Genoa halyard Mainsail topping lift Genoa sheet Mainsheet (spare) Genoa sheet LAGOON 440 – ANG – 12/06/06 9 / 31...
  • Page 10 Force Knts Mainsail 100% Genoa 100% Mainsail (1 reef) Genoa 100% Mainsail (1 reef) Genoa 70% Mainsail (2 reef) Genoa 70% Mainsail (2 reef) Genoa 30% Mainsail (3 reef) Genoa 30% LAGOON 440 – ANG – 12/06/06 10 / 31...

  • Page 11: Safety

    On boats fitted with an inboard engine, there is a discharge aperture for the engine compartment whose location is identified on the following diagram by the symbol: 3.1.3. Escape routes The recommended escape routes are indicated on the opposite diagram by the arrow: LAGOON 440 – ANG – 12/06/06 11 / 31...
  • Page 12 Replace portable fire extinguishers if they have passed their use-by-date or have been discharged, with appliances having equal or superior extinguishing capacity. Fill or replace fixed fire extinguishing systems if they have been discharged or have passed their use- by-date. LAGOON 440 – ANG – 12/06/06 12 / 31...

  • Page 13: Visibility

    On a boat where a bilge pump is not required, it is the responsibility of the user / owner to have at least a bucket / bailer on board fitted with a means of preventing its accidental loss. LAGOON 440 – ANG – 12/06/06 13 / 31...

  • Page 14: Prevention Of Falling Overboard

    For synthetic fibre guardrails, change them as soon as any signs of wear appear due to fraying or UV. 3.5. Life raft (not supplied) Carefully read its instruction manual. Description Life lines fixing points Life raft stowage Swimming ladder : zones excluded from the working deck LAGOON 440 – ANG – 12/06/06 14 / 31...

  • Page 15: Equipment

    Anticipate the deterioration of fuel lines and hoses. Flexible fuel hoses should be replaced by hoses bearing the same markings Meaning of symbols 1 : Attention 2 : Ventilate for 4 minutes 3 : Start LAGOON 440 – ANG – 12/06/06 15 / 31...
  • Page 16 Fuel filter Fuel closing latch Fuel tank 395 litres (optional) The indicated capacities cannot be totally used depending on trim, load or the position of filling and possible places of draining. LAGOON 440 – ANG – 12/06/06 16 / 31...

  • Page 17: Steering System

    The emergency tiller is designed for running at reduced speed only in the event of a steering failure. DESIGNATION Emergency tiller Rudder stock access cover Rudder stock Steering cable Steering arm Rudder stock tube bush Bronze bush Compensation bush Link Emergency tiller fitting Rudder stock head recess LAGOON 440 – ANG – 12/06/06 17 / 31...

  • Page 18: Electrical System

    Connect the boxes or metal envelopes of the electrical appliances installed to the boat’s protection lead (green with yellow stripes lead) Use electrical appliances with double insulation or with earthing. Please note, phase wires are brown, neutrals are blue and earth wires are green and yellow LAGOON 440 – ANG – 12/06/06 18 / 31...
  • Page 19 LAGOON 440 – ANG – 12/06/06 19 / 31...
  • Page 20 220/110 V Socket Load repartitor Cockpit speaker Fwd port cabin air-conditioning control Autopilot computer Shore power socket circuit breaker Shore power air-conditioning socket circuit breaker Battery charger Load repartitor Operation of battery switches LAGOON 440 – ANG – 12/06/06 20 / 31...
  • Page 21 LAGOON 440 – ANG – 12/06/06 21 / 31...
  • Page 22 12V DC socket Pressurised water unit Std bilge pump Refrigerator Comfort Navigation central unit Port bilge pump Spare 2 220V AC sockets 220V AC battery charger 220V AC water heater 220V AC spare LAGOON 440 – ANG – 12/06/06 22 / 31...

  • Page 23: Gas System

    Make sure that empty tank valves are closed and disconnected. Keep protective devices in place; caps and bungs. Never use ammonia based solutions for cleaning or leak detection. 4.4.2. Plan of the gas system DESCRIPTION Hob/Oven Stopcock under sink Gas locker Regulator Gas locker drain LAGOON 440 – ANG – 12/06/06 23 / 31...

  • Page 24: Freshwater And Black Water Tanks

    Do not discharge the contents of the holding tanks close to the shore; use the pumping systems of ports or marinas for emptying the holding tanks before leaving port. Make sure that the holding tank discharge cock is closed in order to avoid any inadvertent discharging. LAGOON 440 – ANG – 12/06/06 24 / 31...
  • Page 25 LAGOON 440 – ANG – 12/06/06 25 / 31...

  • Page 26: Pumps, Seacocks And Skin Fittings

    Port electric bilge pump outlet Fwd locker drain Forward std watertight compartment Chain locker drain bulkhead drain Forward std toilet inlet Aft std toilet inlet Fwd std toilet outlet Aft std toilet outlet LAGOON 440 – ANG – 12/06/06 26 / 31...
  • Page 27 LAGOON 440 – ANG – 12/06/06 27 / 31...

  • Page 28: Anchoring, Mooring And Towing

    The owner should ensure that dock lines, tow ropes, attachment points and chains correspond to conditions of use of the boat. Description Bow fitting Chain locker Windlass Mooring and towing cleats Mooring cleats LAGOON 440 – ANG – 12/06/06 28 / 31...

  • Page 29: Hauling Out And Transportation

    DIAGRAM AND MEASUREMENTS OF POSITIONING CENTRELINES FOR CRADLES AND LIFTING SLINGS Make sure that the boat is stable on its trailer, both longitudinally and laterally. Do not forget to tighten the straps or belts. LAGOON 440 – ANG – 12/06/06 29 / 31...

  • Page 30: Snsm

    130 FF min (20 €) - 45 € (300 FF) (donateur) - 2500 FF (380 €) (bienfaiteur) Un reçu de déductibilité fiscale me sera adressé avec la carte et l'autocollant de membre NOM:…………………………………………………..PRENOM:……………………………… ADRESSE………………………………………………………………………………………… LAGOON 440 – ANG – 12/06/06 30 / 31...

  • Page 31: Charter For The Sea And Inland Waterways

    • Je m'assure que toute opération d'entretien (bateau, matériel, équipement) est effectuée dans le respect de l'environnement. Je manipule avec précaution tous les liquides susceptible de polluer lors de leur transvasement. LAGOON 440 – ANG – 12/06/06 31 / 31...
