Operator's Manual

S-Class

Ê6%t;ÂWË

2205842797

Order No. 6515 2190 13 Part No. 220 584 27 97 USA Edition B 2006

Table of Contents

Summary of Contents for Mercedes-Benz 2006 S 350

Page 1 Sommer\ Corporate\ Media\ AG Bild in der Größe 215x70 mm einfügen Operator’s Manual S-Class Ê6%t;ÂWË 2205842797 Order No. 6515 2190 13 Part No. 220 584 27 97 USA Edition B 2006...
Page 2 S 350 S 430 S 430 4MATIC S 500 S 500 4MATIC S 55 AMG S 600 S 65 AMG...
Page 3 Your Mercedes-Benz represents the ef- forts of many skilled engineers and crafts- men. To help assure your driving pleasure, and also the safety of you and your passen-...
Page 4: Table Of Contents
Operator’s Manual ... 10 Service and warranty information .. 10 Important notice for California retail buyers and lessees of Mercedes-Benz automobiles ... 11 Maintenance ... 12 Roadside Assistance ... 12 Change of address or ownership... 12 Operating your vehicle outside the USA or Canada...
Page 5 Contents Safety and Security ... 59 Occupant safety... 60 Air bags ... 61 Seat belts ... 67 Preventive occupant safety ® (PRE-SAFE )... 70 Children in the vehicle... 71 Override switch for rear passenger compartment ... 77 Panic alarm ... 78 Activating ...
Page 6 CD changer* operating mode ... 151 TEL menu* ... 153 NAVI menu... 155 Distronic* menu... 156 Trip computer menu... 157 Vehicle status message memory menu ... 159 Settings menu... 160 Automatic transmission... 173 Gear selector lever position ... 175 Driving tips... 177 Gear ranges ...
Page 7 Contents Loading ... 239 Roof rack*... 239 Loading instructions... 240 Cargo tie-down hooks ... 240 Useful features ... 241 Vanity mirrors... 241 Storage compartments... 242 Cup holders... 248 Ashtrays ... 249 Cigarette lighters... 250 Heated steering wheel* (except S 55 AMG and S 65 AMG)...
Page 8 DOT, Tire Identification Number (TIN) ... 318 Maximum tire load ... 319 Maximum tire inflation pressure .. 320 Uniform Tire Quality Grading Standards (U.S. vehicles) ... 320 Tire ply material ... 322 Tire and loading terminology... 323 Rotating tires ... 326 Winter driving ...
Page 9 Contents Technical data... 419 Parts service ... 420 Warranty coverage... 421 Loss of Service and Warranty Information Booklet... 421 Identification labels... 422 Layout of poly-V-belt drive ... 423 S 350/S 430/S 430 4MATIC/ S 500/ S 500 4MATIC ... 423 S 55 AMG...
Page 10: Introduction
Product information Please observe the following in your own best interest: We recommend using genuine Mercedes-Benz parts as well as conversion parts and accessories explicitly approved by us for your vehicle model. We have tested these parts to determine their reliability, safety and special suitabili- ty for Mercedes-Benz vehicles.
Page 11: Operator's Manual
Therefore, you may find explanations for optional equipment not installed in your vehicle. If you have any questions about the operation of any equipment, your au- thorized Mercedes-Benz Center will be glad to demonstrate the proper proce- dures. We continuously strive to improve our...
Page 12: Mercedes-Benz Automobiles
30 calendar days. Written notification should be sent to us, not a dealer, at Mercedes-Benz USA, LLC, Customer Assistance Center, One Mercedes Drive, Montvale, NJ 07645-0350.
Page 13: Maintenance
Always have the Maintenance Booklet with you when you take the vehicle to your au- thorized Mercedes-Benz Center for ser- vice. The service advisor will record each service in the booklet for you. Roadside Assistance...
Page 14: Operating Your Vehicle Outside The Usa Or Canada
Certain Mercedes-Benz models are avail- able for delivery in Europe under our Euro- pean Delivery Program. For details, consult your authorized Mercedes-Benz Center or...
Page 15: Where To Find It
Here you will find all the information you need for your first drive. You should read this section first if this is your first Mercedes-Benz vehicle or if you are rent- ing or borrowing this vehicle. Safety and Security Here you will find descriptions of the safety and security features of your vehicle.
Page 16: Symbols
Symbols ® Registered trademarks ® ® and PRE-SAFE are registered trade- marks of DaimlerChrysler. The following symbols are found in this Operator’s Manual: Optional equipment is identified with an asterisk. Since standard equipment varies between models, the descriptions and illustrations in this manual may differ slightly from the actual equipment of your vehi- cle.
Page 17: Operating Safety
Electronic malfunctions could seri- ously impair the operating safety of your vehicle. See an authorized Mercedes-Benz Center for repairs or modifications to electronic components. Other improper work or modifications on the vehicle could also have a negative impact on the operating safety of the vehicle.
Page 18: Problems With Your Vehicle
If you should experience a problem with your vehicle, particularly one that you believe may affect its safe operation, we urge you to immediately contact an authorized Mercedes-Benz Center to have the problem diagnosed and corrected if required. If the matter is...
Page 19: Reporting Safety Defects
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Mercedes-Benz USA, LLC. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 20: Vehicle Data Recording
Vehicle data recording Information regarding electronic recording devices (Including notice pursuant to California Code § 9951) Please note that your vehicle is equipped with devices that can record vehicle systems data and, if equipped with the Tele Aid system, may transmit some data in certain accidents. This information helps, for example, to diagnose vehicle systems after a collision and to continuously improve vehicle safety.
Page 22: At A Glance
At a glance Cockpit Instrument cluster Multifunction steering wheel Center console Overhead control panel Door control panel...
Page 23: Cockpit
At a glance Cockpit...
Page 24 Item Page 1 Combination switch Turn signals Windshield wipers High beam 2 Cruise control lever Cruise control Distronic* 3 Instrument cluster 4 Multifunction steering wheel 5 Steering wheel gearshift control (S 55 AMG and S 65 AMG only) Item Page 6 Lever for voice control sys- tem*, see separate operat- ing instructions...
Page 25: Instrument Cluster
At a glance Instrument cluster...
Page 26 Item Page 1 Coolant temperature gauge 2 Fuel gauge with fuel tank reserve warning lamp 3 L Left turn signal indicator lamp K Right turn signal indicator lamp 4 Speedometer with: v Electronic Stability ® Program (ESP warning lamp l Distance warning lamp Vehicles without Distronic*: Distance warning lamp with-...
Page 27: Multifunction Steering Wheel
At a glance Multifunction steering wheel Item Page 1 Multifunction display Operating control system 2 Selecting the submenu or setting the volume: Press button æ up/to increase ç down/to decrease 3 Telephone*: Press button s to take a call to dial a call t to end a call to reject an incoming call...
Page 28: Important Notice For California Center Console
Center console Upper part Item Page 1 Switch for rear window sun- shade 2 Parktronic* deactivation button 3 Airmatic or Active Body Control (ABC)* button 4 Level control button 5 Central locking switch Anti-theft alarm system indi- cator lamp 6 Hazard warning flasher on/off switch At a glance Center console...
Page 29: Lower Part
At a glance Center console Lower part Item Page 1 KEYLESS-GO* start/stop button 2 Gear selector lever for automatic transmission 3 Front passenger front air bag off indicator lamp 4 Thumbwheel for setting dis- tance in Distronic* 5 Distance warning function* on/off button 6 Lower storage compart- ments...
Page 30: Overhead Control Panel
Overhead control panel Item Page 1 Left reading lamp on/off 2 Rear interior lighting on/off 3 Right reading lamp on/off 4 Interior lighting control 5 Tilt/sliding sunroof 6 Hands-free microphone for Tele Aid (emergency call system), telephone*, and voice control system* (see separate operating instruc- tions) 7 Garage door opener...
Page 31: Door Control Panel
At a glance Door control panel Item Page 1 Door handle 2 Memory function (for stor- ing seat, exterior mirror, and steering wheel settings) 3 Seat heating* Seat ventilation* 4 Seat adjustment Item Page 5 Exterior mirror adjustment Mirror folding function 6 Switches for opening/clos- ing front door windows 7 Override switch for rear pas-...
Page 32: Getting Started
Getting started Unlocking Adjusting Driving Parking and locking...
Page 33: Unlocking
Getting started Unlocking The “Getting started” section provides an overview of the vehicle’s most basic func- tions. First-time Mercedes-Benz owners should pay special attention to the infor- mation given here. If you are already familiar with the basic functions described here, the “Controls in detail”...
Page 34: Unlocking With Keyless-Go
Unlocking with KEYLESS-GO* With the KEYLESS-GO function, you can lock and unlock the vehicle without using the remote control buttons on the SmartKey and start the engine without in- serting the SmartKey in the starter switch. To unlock the vehicle, the SmartKey with KEYLESS-GO must be outside the vehicle, no further than approximately 3 feet (1 meter) away from the door.
Page 35: Starter Switch Positions
Getting started Unlocking Starter switch positions Warning! When leaving the vehicle, always remove the SmartKey or SmartKey with KEYLESS-GO* from the starter switch, take it with you, and lock the vehicle. Do not leave children unat- tended in the vehicle, or with access to an unlocked vehicle.
Page 36 If the SmartKey cannot be turned in the starter switch, the battery may not be sufficiently charged. Check the battery and charge it if necessary ( page 408). Get a jump start ( page 411). To prevent accelerated battery dis- charge or a completely discharged bat- tery, always remove the SmartKey from the starter switch when the engine is...
Page 37 Getting started Unlocking Position 0 Before you press the KEYLESS-GO start/stop button, the vehicle’s on-board electronics have status 0 (as with SmartKey removed). Position 1 Press KEYLESS-GO start/stop button once. This supplies power for some electrical consumers, such as seat adjustment. If you now press the KEYLESS-GO start/stop button once again, the ignition (position 2)
Page 38: Adjusting
Adjusting Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart system installed in the ve- hicle to deactivate the passenger front air bag when it is properly installed.
Page 39 Getting started Adjusting A child’s risk of serious or fatal injuries is significantly increased if the child restraints are not properly secured in the vehicle and the child is not properly secured in the child restraint. Seat adjustment The seat adjustment switches are located on the front doors.
Page 40 The feature below is deactivated at the factory for U.S. vehicles. If you wish to have it activated, contact an authorized Mercedes-Benz Center. The front passenger seat head restraint automatically lowers after a few sec- onds when the front passenger seat is not occupied.
Page 41: Steering Wheel
Getting started Adjusting Steering wheel Warning! Do not adjust the steering wheel while driv- ing. Adjusting the steering wheel while driv- ing could cause the driver to lose control of the vehicle. When leaving the vehicle, always remove the SmartKey or SmartKey with KEYLESS-GO* from the starter switch, take it with you, and lock the vehicle.
Page 42: Mirrors
Mirrors Adjust the interior and exterior rear view mirrors before driving so that you have a good view of the road and traffic condi- tions. Warning! In case of an accident, liquid electrolyte may escape the mirror housing if the mirror glass breaks.
Page 43 Getting started Adjusting The buttons are located on the driver’s door. 1 Driver’s side exterior rear view mirror button 2 Passenger-side exterior rear view mir- ror button 3 Adjustment button Switch on the ignition ( page 34). Press button 1 for the left mirror or button 2 for the right mirror.
Page 44: Driving
( page 60). Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart system installed in the ve- hicle to deactivate the passenger front air bag when it is properly installed.
Page 45 Getting started Driving According to accident statistics, children are safer when properly restrained in the rear seating positions than in the front seat- ing positions. Infants and small children must ride in back seats and be seated in an appropriate infant or child restraint system, which is properly secured with the vehicle’s seat belt and top tether strap, or secured via lower anchors and top tether strap, fully in...
Page 46 Do not bleach or dye seat belts as this may severely weaken them. In a crash, they may not be able to provide adequate protection. Damaged seat belts or belts that were highly stressed in an accident must be replaced. Contact an authorized Mercedes-Benz Cen- ter.
Page 47: Starting The Engine
Getting started Driving Starting the engine Warning! Inhalation of exhaust gas is hazardous to your health. All exhaust gas contains carbon monoxide, and inhaling it can cause uncon- sciousness and lead to death. Do not run the engine in confined areas (such as a garage) which are not properly ventilated.
Page 48 Starting with KEYLESS-GO* Warning! As long as the SmartKey with KEYLESS-GO is in your vehicle, the vehicle can be started. Therefore, never leave children unattended in the vehicle, as they could otherwise acci- dentally start the engine. When leaving the vehicle, always take the SmartKey with KEYLESS-GO with you and lock the vehicle.
Page 49: Parking Brake
If the engine does not start after several starting attempts, there could be a mal- function in the engine electronics or in the fuel supply system. Notify an authorized Mercedes-Benz Center. Parking brake 1 Parking brake pedal 2 Release handle...
Page 50: Driving
Driving Depress the brake pedal. Move gear selector lever to position D or R. Warning! It is dangerous to shift the gear selector le- ver out of P or N if the engine speed is high- er than idle speed. If your foot is not firmly on the brake pedal, the vehicle could accel- erate quickly forward or in reverse.
Page 51: Switching On Headlamps
Getting started Driving Simultaneously depressing the acceler- ator pedal and applying the brake re- duces engine performance and causes premature brake and drivetrain wear. You can open a locked door from the inside. Open doors only when condi- tions are safe to do so. You can deactivate the automatic lock- ing using the control system ( page 168).
Page 52: Turn Signals
Push combination switch in the direc- tion of arrow 1. The high beam headlamps are switched The high beam headlamp indicator A in the tachometer comes on. For more information, see “Lighting” ( page 131). Turn signals The combination switch is located on the left of the steering column.
Page 53: Windshield Wipers
Getting started Driving Windshield wipers The combination switch is located on the left of the steering column. Combination switch 1 Single wipe Wiping with windshield washer fluid 2 Switching on windshield wipers Switch on the ignition ( page 34). Do not operate the wipers when the windshield is dry.
Page 54 Remove blockage. Turn the windshield wipers on again. If windshield wipers fail to function at all in switch position I, set the combination switch to the next highest wiper speed have the windshield wipers checked at the nearest authorized Mercedes-Benz Center...
Page 55: Problems While Driving
Unburned gasoline may have entered the catalytic converter and damaged it. Give very little gas. Have the problem repaired by an au- thorized Mercedes-Benz Center as soon as possible. The coolant temperature is above 248°F (120°C) The coolant is too hot and is no longer cooling the engine.
Page 56: Parking And Locking
Parking and locking You have now completed your first drive. You have properly stopped and parked your vehicle. End your drive as follows. Warning! With the engine not running, there is no power assistance for the brake and the steering systems. In this case, it is impor- tant to keep in mind that a considerably higher degree of effort is necessary to brake and steer the vehicle.
Page 57: Parking Brake
Getting started Parking and locking Parking brake 1 Parking brake pedal 2 Release handle Step firmly on parking brake pedal 1. When the engine is running, the indicator lamp ; (USA only) or 3 (Canada only) in the instrument cluster illuminates. Warning! When leaving the vehicle, always remove the SmartKey or SmartKey with KEYLESS-GO*...
Page 58: Switching Off Headlamps
Switching off headlamps Turn the exterior lamp switch to M. For more information, see “Lighting” ( page 131). Turning off the engine Place the gear selector lever in position P. Always set the parking brake in addi- tion to shifting to position P. On slopes, turn the front wheels to- wards the curb.
Page 59: Locking
Getting started Parking and locking Locking Warning! To prevent possible personal injury, always keep hands and fingers away from the door openings when closing the doors. Be espe- cially careful when small children are around. Before closing doors, make sure there is no possibility of someone getting caught in a door during closing.
Page 60: Safety And Security
Safety and Security Occupant safety Panic alarm Driving safety systems Anti-theft systems...
Page 61: Occupant Safety
For safety reasons, we strongly recom- mend that you visit an authorized Mercedes-Benz Center immediately to have the system checked.
Page 62: Air Bags
SRS self-check has detected a malfunction. For your safety, we strongly recommend that you visit an authorized Mercedes-Benz Center immediately to have the system checked; otherwise the SRS may not be activated when needed in an acci-...
Page 63 Corp. Warning! Accident research shows that the safest place for children in an automobile is in the rear seat. Should you choose to place a child 12 years old or under in the front passenger seat of your vehicle, you must properly use...
Page 64 Mercedes-Benz Center at an additional cost. Please contact your local authorized Mercedes-Benz Center or call our Customer Assistance Center at 1-800-FOR-MERCedes (1-800-367-6372) for details.
Page 65 These instructions are available from your authorized Mercedes-Benz Center. Given the considerable deployment speed and the textile structure of the air bags, there is the possibility of abra- sions or other injuries resulting from air bag deployment.
Page 66 When you sell your vehicle we strongly urge you to give notice to the subsequent owner that it is equipped with an SRS by alerting them to the applicable section in the Operator’s Manual. Front air bags 1 Driver’s front air bag 2 Passenger front air bag Driver’s and passenger front air bags are deployed:...
Page 67 Safety and Security Occupant safety Side impact air bags 1 Side impact air bags The side impact air bags are deployed: in impacts exceeding a preset deploy- ment threshold on the impacted side of the vehicle independently of the front air bags The side impact air bags are not deployed in impacts which do not exceed the sys- tem’s deployment threshold.
Page 68: Seat Belts
Seat belts When the engine is started, the seat belt telltale < illuminates to remind you and your passengers to fasten your seat belts. If the driver’s seat belt is not fastened be- fore the engine is started, the seat belt telltale <...
Page 69 Only use seat belts which have been ap- proved by Mercedes-Benz. Do not make any modifications to the seat belts. This can lead to failure of the seat belts.
Page 70 (ETD) that was activated must be replaced. When disposing of the pyrotechnic emer- gency tensioning device, our safety instruc- tions must be followed. These are available at your authorized Mercedes-Benz Center. ® PRE-SAFE has electrically operated revers- ible pre-tensioners that do not require replacement after activation.
Page 71: Preventive Occupant Safety (Pre-Safe ® )
Safety and Security Occupant safety Automatic comfort-fit feature seat belt An automatic comfort-fit feature for front seats and for the rear outer seats (only for vehicles with electrically adjustable rear bench seat* or with individual seats* in the rear) reduces the retracting force of the seat belts when they are in normal use.
Page 72: Children In The Vehicle
Infant and child restraint seats and infor- mation on choosing an appropriate re- straint system can be obtained from any authorized Mercedes-Benz Center. Infant and child restraint systems Use only a BabySmart compatible child restraint for the front passenger seat in this vehicle.
Page 73 Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart system installed in the ve- hicle to deactivate the passenger front air bag when it is properly installed.
Page 74 1 Indicator lamp Special BabySmart compatible child seats, designed for use with the Mercedes-Benz system and available at any authorized Mercedes-Benz Center are required for use with the BabySmart air bag deactivation system. With the spe- cial child seat properly installed, the pas- senger front air bag will not deploy.
Page 75 Safety and Security Occupant safety Warning! When using a BabySmart compatible child seat on the front passenger seat, the passenger front air bag will not deploy only if the indicator lamp remains il- luminated. Make sure to check the indica- tor lamp every time you use the special sys- tem child seat.
Page 76 2 Hook 3 Anchorage ring Securely fasten hook 2, which is part of the tether strap, to anchorage ring 3. For safety reasons, make sure hook 2 has attached to ring 3 beyond the safety catch, as illustrated. Once the top tether anchorage hook is at- tached, the child restraint itself can be se- cured.
Page 77 Safety and Security Occupant safety Move rear power seats*/bench* to the rearmost position ( page 117). Fold upholstery blend 3 upward. Turn installation device 4 to a vertical position so that upholstery blend 3 does not fold down. Install child seat according to the man- ufacturer’s instructions.
Page 78: Override Switch For Rear Passenger Compartment
Override switch for rear passenger compartment You can disable select functions in the rear passenger compartment for added safety (for instance when you have children riding in the rear passenger compartment). You can disable the following functions in the rear passenger compartment: rear door window operation ( page 208) adjustment of front passenger seat...
Page 79: Panic Alarm
Safety and Security Panic alarm An audible alarm and flashing exterior lamps will operate for approximately minutes. 1 Â button USA only: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any inter-...
Page 80: Driving Safety Systems
Driving safety systems In this section you will find information on the following driving safety systems: ABS (Antilock Brake System) BAS (Brake Assist System) ® (Electronic Stability Program) 4MATIC (Four Wheel Electronic Trac- tion System) In winter operation, the maximum ef- ®...
Page 81: Bas
Safety and Security Driving safety systems Braking At the instant one of the wheels is about to lock up, a slight pulsation can be felt in the brake pedal, indicating that the ABS is in the regulating mode. Keep firm and steady pressure on the brake pedal while experiencing the pul- sation.
Page 82: Esp
Warning! The BAS cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase braking efficiency beyond that af- forded by the condition of the vehicle brakes and tires or the traction afforded. The BAS cannot prevent accidents, including those resulting from excessive speed in turns, fol- lowing another vehicle too closely, or hydro-...
Page 83 Safety and Security Driving safety systems Warning! ® The ESP cannot prevent the natural laws of physics from acting on the vehicle, nor can ® it increase the traction afforded. The ESP cannot prevent accidents, including those resulting from excessive speed in turns, or hydroplaning.
Page 84 Avoid spinning of a drive wheel for an extended period with the ESP ® switched off. This may cause serious damage to the drivetrain which is not covered by the Mercedes-Benz Limited Warranty. ® Switching on the ESP ® switch 1.
Page 85: Four Wheel Electronic Traction System (4Matic) With The Esp
Do not tow with one axle raised. Otherwise the transfer case can be damaged, which is not covered by the Mercedes-Benz Limited Warranty. Performance testing must only be con- ducted on a two-axle dynamometer. Otherwise the transfer case can be damaged, which is not covered by the Mercedes-Benz Limited Warranty.
Page 86: Anti-Theft Systems
The immobilizer is deactivated. In case the engine cannot be started (yet the vehicle’s battery is charged), the system is not operational. Contact an authorized Mercedes-Benz Center or call 1-800-FOR-MERCedes (in the USA), or 1-800-387-0100 (in Canada).
Page 87: Anti-Theft Alarm System
Safety and Security Anti-theft systems Anti-theft alarm system Once the alarm system has been armed, a visual and audible alarm is triggered when someone opens: a door the trunk the hood The alarm will stay on even if the activating element (a door, for example) is immedi- ately closed.
Page 88 Disarming the alarm system Unlock your vehicle with the SmartKey or KEYLESS-GO*. The turn signal lamps flash once to in- dicate that the alarm system is dis- armed. The alarm system will rearm automati- cally again after approximately 40 sec- onds if no door was opened.
Page 89: Tow-Away Alarm
Safety and Security Anti-theft systems Tow-away alarm Once the tow-away alarm is armed, a visual and audible alarm will be triggered when someone attempts to raise the vehicle. The tow-away protection alarm is trig- gered, for example, if the vehicle is lift- ed on one side.
Page 90 Press button 2. The indicator lamp 1 in the button comes on briefly. Exit the vehicle and lock it with the SmartKey or (vehicles with KEYLESS-GO*) with the lock button on each outside door handle or trunk lid. When you unlock your vehicle, the tow-away protection disarms automati- cally.
Page 92: Controls In Detail
Controls in detail Locking and unlocking Seats Memory function Lighting Instrument cluster Control system Automatic transmission Good visibility Automatic climate control Power windows Power tilt/sliding sunroof Driving systems Loading Useful features...
Page 93: Locking And Unlocking
Controls in detail Locking and unlocking In the “Controls in detail” section you will find detailed information on how to oper- ate the equipment installed in your vehicle. If you are already familiar with the basic functions of your vehicle, this section will be of particular interest to you.
Page 94 Warning! When leaving the vehicle, always remove the SmartKey from the starter switch, take it with you, and lock the vehicle. Do not leave children unattended in the vehicle, or with access to an unlocked vehicle. It is possible for children to open a locked door from the inside, which could result in an accident and/or serious personal injury.
Page 95 Controls in detail Locking and unlocking Factory setting Global unlocking Press button Œ. All turn signal lamps flash once. The locking knobs in the doors move up. The anti-theft alarm system is dis- armed. The vehicle will lock again automatically and reactivate the anti-theft alarm system within approximately 40 seconds of un- locking if:...
Page 96 ( page 388). Have the vehicle battery and the battery connections checked ( page 408). If the SmartKey is malfunctioning, con- tact an authorized Mercedes-Benz Cen- ter. Checking the batteries Press button ‹ or Œ. Battery check lamp 5 comes on briefly to indicate that the SmartKey batteries are in order.
Page 97: Smartkey With Keyless-Go
Report the loss of the SmartKey or the mechanical key immediately to your car insurance company. If necessary, have the mechanical lock replaced. Your authorized Mercedes-Benz Center will be glad to supply you with a replace- ment. SmartKey with KEYLESS-GO* Vehicles equipped with KEYLESS-GO come...
Page 98 Warning! When leaving the vehicle, always take the SmartKey with KEYLESS-GO* with you and lock the vehicle. Do not leave children unat- tended in the vehicle, or with access to an unlocked vehicle. Unsupervised use of vehi- cle equipment may cause an accident and/or serious personal injury.
Page 99 Controls in detail Locking and unlocking Important notes on using KEYLESS-GO You can also use the SmartKey with KEYLESS-GO like a normal SmartKey ( page 92). You can combine KEYLESS-GO func- tions with normal SmartKey functions (e.g. unlocking with KEYLESS-GO and locking with the ‹...
Page 100 If the SmartKey with KEYLESS-GO is re- moved from the vehicle while the igni- tion is switched on (e.g. if passenger exits the vehicle with the SmartKey with KEYLESS-GO), the message: NOT RECOGNIZED will appear in the multifunction display while driving off. Find the SmartKey or change its present location immediately (e.g.
Page 101 Controls in detail Locking and unlocking Selective setting If you frequently travel alone, you may wish to reprogram the SmartKey with KEYLESS-GO so when you, grasp the driv- er’s outside door handle only the driver’s door and the fuel filler flap unlocks. Press and hold buttons Œ...
Page 102 SmartKey battery with KEYLESS-GO is discharged. Replace the battery ( page 392). You can obtain the required battery at any authorized Mercedes-Benz Center. If the battery is checked within signal range of the vehicle, pressing the button ‹ or Œ will lock or unlock the vehicle accordingly.
Page 103: Opening The Doors From The Inside
Have the mechanical lock replaced if necessary. Your authorized Mercedes-Benz Center will be glad to supply you with a replace- ment. Opening the doors from the inside You can open a locked door from the in- side.
Page 104: Opening The Trunk
If the vehicle has previously been locked with the SmartKey or KEYLESS-GO*, opening a door from the inside will trigger the anti-theft alarm system. To cancel the alarm, do one of the fol- lowing: Insert the SmartKey in the starter switch.
Page 105 Controls in detail Locking and unlocking The trunk lid swings open upwards au- tomatically. Always make sure that there is sufficient overhead clearance. Vehicles with trunk lid opening/closing system*: To stop the opening proce- dure, press button Š on the SmartKey or SmartKey with KEYLESS-GO*.
Page 106: Closing The Trunk
Limiting opening height of trunk lid* Vehicles with trunk lid opening/closing system*: The trunk lid opening height can be limited when transporting goods on a roof rack (e.g. presence of an accessory MB sport luggage container*). When activated, the trunk lid opens to approximately the height of the roof edge.
Page 107 Controls in detail Locking and unlocking Closing the trunk from the outside manually 1 Handle Lower trunk lid by pulling firmly on handle 1. 2 Extending handle Push the trunk lid down gently at the extending handle 2 until it engages into the lock.
Page 108 Do not place the SmartKey in the open trunk. You may lock yourself out. Vehicles with KEYLESS-GO*: To pre- vent a possible inadvertent lockout, the trunk lid will open automatically if a SmartKey with KEYLESS-GO is recog- nized inside the vehicle or in the trunk. If the vehicle was previously centrally locked, the trunk will lock automatical- ly after closing it.
Page 109 Controls in detail Locking and unlocking Warning! Only drive with the trunk closed as, among other dangers such as blocked visibility, ex- haust fumes may enter the vehicle interior. Do not place the SmartKey in the open trunk. You may lock yourself out. If the vehicle was previously centrally locked, the trunk will lock automatical- ly after closing it.
Page 110 Warning! Monitor the closing procedure carefully to make sure no one is in danger of being in- jured. To prevent possible personal injury, always keep hands and fingers away from the trunk opening when closing the trunk. Be especially careful when small children are around.
Page 111 Controls in detail Locking and unlocking Press switch 1 briefly. The vehicle is locked and the trunk lid closes automatically. With the hood and all doors closed, All turn signal lamps flash three times to confirm locking. The locking knobs in the doors move down.
Page 112: Trunk Lid Emergency Release
Trunk lid emergency release With the emergency release button, the trunk can be opened from inside the trunk. The emergency release button is located on the inside of the trunk lid. 1 Emergency release button Briefly press emergency release button 1. The trunk unlocks and the trunk lid opens.
Page 113: Power Closing Assist For Doors And Trunk Lid
Controls in detail Locking and unlocking Power closing assist for doors and trunk lid It is not necessary to slam the door or trunk lid closed. A pneumatic power-as- sisted mechanism draws doors and trunk lid closed quietly and automatically once door and trunk lid has been latched.
Page 114: Locking And Unlocking From The Inside
Locking and unlocking from the inside You can lock or unlock the doors and the trunk from inside using the central locking or unlocking switch. This can be useful, for example, if you want to lock the vehicle be- fore starting to drive. The fuel filler flap will not be locked or un- locked with the central locking or unlock- ing switch, respectively.
Page 115: Seats
Controls in detail Seats For more information on seat adjustment, see “Adjusting” ( page 37). Easy-entry/exit feature This feature allows for easier entry into and exit from the vehicle. The easy-entry/exit feature can be activat- ed or deactivated in the CONVENIENCE sub- menu of the control system ( page 170).
Page 116 If the current position for the steering wheel is in the uppermost tilt position, the steering wheel will no longer be able to move upward when the easy-entry/exit feature is activated. If the current seat position falls into a factory-set position range and the sys- tem recognizes the current seat posi- tion to be rearward enough for easy entry and exit, the driver’s seat will not...
Page 117: Removing And Installing Front Seat Head Restraints
Controls in detail Seats Removing and installing front seat head restraints For information on head restraint adjust- ment, see “Seats” ( page 37). Warning! For your protection, drive only with properly positioned head restraints. Adjust head restraint so that the center of the head restraint supports the back of the head at eye level.
Page 118: Rear Seats
Rear seats Power seat bench* The switches for adjusting the seat bench are located at the respective rear doors. 1 Seat bench fore and aft adjustment 2 Head restraint, folding down or placing upright Seat bench fore and aft adjustment Press switch forward or backward in the direction of arrow 1.
Page 119 Controls in detail Seats Seat fore and aft adjustment Press switch forward or backward in the direction of arrow 1. Seat height Press switch up or down in the direc- tion of arrow 2. Head restraint, folding down or placing upright Press switch in the up direction of arrow 3 to place the head restraint...
Page 120 The switch is located on the right rear pas- senger door. 1 Front passenger seat adjustment 2 Right rear passenger seat adjustment 3 Seat height 4 Head restraint height 5 Backrest tilt 6 Seat fore and aft adjustment Switch on the ignition ( page 34). Open the right rear passenger door.
Page 121: Rear Seat Head Restraints
Controls in detail Seats Warning! For your protection, drive only with properly positioned head restraints. Adjust head restraint so that the center of the head restraint supports the back of the head at eye level. This will reduce the poten- tial for injury to the head and neck in the event of an accident or similar situation.
Page 122 Placing head restraints upright Pull the rear head restraint upright until it locks into position. Make sure the head restraints engage when placing them upright manually. Otherwise their protective function cannot be ensured. Placing power head restraints* upright (rear outer seats) Switch on the ignition ( page 34).
Page 123: Lumbar Support
Controls in detail Seats Head restraint tilt You can adjust the angle manually by pull- ing or pushing the head restraints by hand. Adjust the head restraint in such a way that it is as close to the head as possi- ble.
Page 124 The switches for the driver and front pas- senger seat are located on the inner side of the seat. 1 Shoulder region support 2 Side bolster adjustment 3 Massage function (PULSE) 4 Lumbar region support Switch on the ignition ( page 34). Shoulder region support Press æ...
Page 125: Drive-Dynamic Seat
Controls in detail Seats Drive-dynamic seat* The drive-dynamic seat automatically ad- justs the lateral support provided by the seat backrest to your driving style. The switches for the driver’s and front pas- senger seat are located on the inner side of the seat.
Page 126: Seat Heating
Seat heating* Vehicles without seat ventilation* The switches are located on the door. 1 Normal heating 2 Rapid heating The red indicator lamps above the switch- es show the heating level selected: Level No indicator lamp on. One left indicator lamp on. Two right indicator lamps on.
Page 127 Controls in detail Seats Vehicles with seat ventilation* The switch is located on the door. 1 Seat heating switch The red indicator lamps above the switch show the heating level selected: Level No indicator lamp on. One indicator lamp on. Two indicator lamps on.
Page 128: Seat Ventilation
Seat ventilation* The switch is located on the door. Seat ventilation can be activated manually with the ignition switched on. The driver’s seat ventilation can be activated automatically by the summer opening feature ( page 210). The blue indicator lamps on the switch show the ventilation level selected: Level Three indicator lamps on...
Page 129: Memory Function
Controls in detail Memory function Prior to operating the vehicle, the driv- er should check and adjust the seat height, seat position fore and aft, and seat backrest angle if necessary, to en- sure adequate control, reach, and com- fort. The head restraint should also be adjusted for proper height.
Page 130: Storing Positions Into Memory
The memory button and stored position switch are located on the door. 1 Memory position buttons 2 Memory button Switch on the ignition ( page 34). Open the respective door. Storing positions into memory Adjust the seats, steering wheel and exterior rear view mirrors to the de- sired position ( page 37).
Page 131: Storing Exterior Rear View Mirror Parking Position
Controls in detail Memory function Storing exterior rear view mirror park- ing position For easier parking, you can adjust the pas- senger-side exterior rear view mirror so that you can see the right rear wheel as soon as you engage reverse gear R. For information on activating the parking position, see “Setting parking position for exterior rear view mirror”...
Page 132: Lighting
Relevant information can be obtained at your authorized Mercedes-Benz Cen- ter. Exterior lamp switch The exterior lamp switch is located on the dashboard to the left of the steering wheel.
Page 133 Controls in detail Lighting With the SmartKey removed from the starter switch or the engine turned off with KEYLESS-GO* and the driver’s door open, a warning sounds if the parking lamps or low beam headlamps are switched on. The message: TURN OFF LIGHTS appears in the multifunction display.
Page 134 Turn the exterior lamp switch to U. With the SmartKey in starter switch po- sition 1 or the KEYLESS-GO* start/stop button pressed once, only the parking lamps will switch on and off automatically. When the engine is running, the low beam headlamps, the tail and parking lamps, the license plate lamps, and the side marker lamps will switch on and...
Page 135 Controls in detail Lighting Switching on fog lamps Warning! In low ambient lighting or foggy conditions, only switch from position U to B with the vehicle at a standstill in a safe location. Switching from U to B will briefly switch off the headlamps.
Page 136: Combination Switch
Combination switch The combination switch is located on the left side of the steering column. 1 High beam 2 High beam flasher Switching on high beams Turn exterior lamp switch to position B or to U ( page 131). Push the combination switch in the direction 1.
Page 137: Hazard Warning Flasher
Controls in detail Lighting Hazard warning flasher The hazard warning flasher can be switched on at all times, even with the SmartKey removed from the starter switch or with the SmartKey with KEYLESS-GO* removed from the vehicle. The hazard warning flasher switches on au- tomatically when an airbag deploys.
Page 138: Interior Lighting
Interior lighting The controls are located in the overhead control panel. 1 Left reading lamp on/off 2 Rear interior lamps on/off 3 Right reading lamp on/off 4 Rocker switch for automatic control on/off Leaving an interior light switch in the ON position for extended periods of time with the engine turned off could result in a discharged battery.
Page 139 Controls in detail Lighting Rear interior lighting Press switch 2 on the ò symbol. The rear compartment lighting switch- es on. Press switch 2 on the ò symbol again. The rear compartment lighting switch- es off. The setting selected for the interior lighting is used for the trunk lighting as well.
Page 140: Courtesy Lighting
Courtesy lighting For better orientation in the dark, courtesy lamps will illuminate the interior of your ve- hicle as follows: With parking lamps switched on: the door handles the driver and passenger footwells With the SmartKey in the starter switch position 1: the door handles the center console...
Page 141: Instrument Cluster
Controls in detail Instrument cluster A full view illustration of the instrument cluster can be found in the “At a glance” section of this manual ( page 24). 1 Reset button J The instrument cluster is activated when you: open a door switch on the ignition ( page 34) press the reset button J1 switch on the exterior lamps...
Page 142: Coolant Temperature Gauge
248°F (120°C), i.e. in the red zone of the coolant temperature gauge. Doing so may cause serious engine damage which is not cov- ered by the Mercedes-Benz Limited War- ranty. Controls in detail Instrument cluster Trip odometer Make sure you are viewing the trip odometer display.
Page 143: Tachometer
Avoid driving at excessive engine speeds, as it may result in serious en- gine damage that is not covered by the Mercedes-Benz Limited Warranty. To help protect the engine, the fuel supply is interrupted if the engine is operated within the red marking.
Page 144: Control System
Control system The control system is activated as soon as the SmartKey in the starter switch is turned to position 1 or as soon as the KEYLESS-GO* start/stop button ( page 35) is in position 1. The control system enables you to: call up information about your vehicle change vehicle settings For example, you can use the control sys-...
Page 145: Multifunction Steering Wheel
Controls in detail Control system Multifunction steering wheel The displays in the multifunction display and the settings in the control system are controlled using the buttons on the multi- function steering wheel. 1 Multifunction display in the speed- ometer Operating the control system 2 Selecting the submenu or setting the volume æ...
Page 146 Pressing any of the buttons on the multi- function steering wheel will alter what is shown in the multifunction display. The information available in the multifunc- tion display is arranged in menus, each containing a number of functions or sub- menus.
Page 147: Menus
Controls in detail Control system Menus This is what you will see when you scroll through the menus. The table on the next page provides an overview of the individual menus.
Page 148 Menus, submenus and functions Menu 1 Menu 2 Menu 3 Standard dis- AUDIO Telephone* play ( page 148) ( page 148) ( page 153) ( page 155) Call up mainte- Select radio Load phone nance service station book display Check tire in- Select satel- Search for flation pres-...
Page 149: Standard Display Menu
Controls in detail Control system The headings used in the menus table are designed to facilitate navigation within the system and are not neces- sarily identical to those shown in the control system displays. The first function displayed in each menu will automatically show you which part of the system you are in.
Page 150 Additional optional satellite radio equipment and a subscription to satel- lite radio service provider are required for satellite radio operation. Contact an authorized Mercedes-Benz Center for details and availability for your vehicle. For more information, refer to separate COMAND operating instructions.
Page 151 Controls in detail Control system Select CD track Turn on COMAND and select CD. Refer to separate COMAND operating in- structions. Press button è or ÿ repeatedly until the settings for the CD currently being played appear in the multifunc- tion display.
Page 152: Cd Changer* Operating Mode
CD changer* operating mode General notes Should excessively high temperatures oc- cur while in CD mode, CD TEMP HIGH will appear on the multifunction display and muting will take place. The unit will then switch back to the last operating mode used until the temperature has decreased to a safe operating level.
Page 153 Controls in detail Control system Warning! The CD changer is a Class 1 laser product. There is a danger of invisible laser radiation if the cover is opened or damaged. Do not remove the cover. The CD changer does not contain any parts which can be ser- viced by the user.
Page 154: Tel Menu
TEL menu* Warning! A driver’s attention to the road must always be his/her primary focus when driving. For your safety and the safety of others, we rec- ommend that you pull over to a safe location and stop before placing or taking a tele- phone call.
Page 155 Controls in detail Control system The following functions are available: Function Page Answering a call Ending a call Dialing a number from the phone book Redialing Answering a call When your telephone is ready to receive calls, you can answer a call at any time. In the display you will then see the message: Press button s.
Page 156: Navi Menu
Press button s. The system dials the selected phone number. If the connection is successful, the name of the party you called and the duration of the call will appear in the display. If no connection is made, the con- trol system stores the dialed num- ber in the redial memory.
Page 157: Distronic* Menu
Controls in detail Control system Distronic* menu Use the DISTRONIC menu to display the current settings for your Distronic system. What information is shown in the display depends on whether the Distronic system is active or inactive. Please refer to the “Driving systems” sec- tion of this manual ( page 218) for in- structions on how to activate Distronic.
Page 158: Trip Computer Menu
Trip computer menu Use the trip computer menu to call up sta- tistical data on your vehicle. The following information is available: Function Page Fuel consumption statistics after start Fuel consumption statistics since last reset Resetting fuel consumption sta- tistics Calling up range (distance to empty) Fuel consumption statistics after start...
Page 159 Controls in detail Control system Fuel consumption since last reset Press button ÿ or è repeatedly until you see the first function of the trip computer menu. Press button j or k repeatedly until you see this message in the dis- play: AFTER RESET 1 Distance driven since last reset...
Page 160: Vehicle Status Message Memory Menu
Mercedes-Benz Center to address the malfunction and warning messages ( page 349). Press button è or ÿ repeatedly...
Page 161: Settings Menu
Controls in detail Control system Settings menu In the SETTINGS menu there are two func- tions: The function TO RESET PRESS R BUTTON FOR 3 SEC. , with which you can reset all settings to the original factory set- tings. A collection of submenus with which you can make individual settings for your vehicle.
Page 162: Submenus In The Settings Menu
Submenus in the Settings menu Press button j. In the multifunction display you will see the collection of the submenus. Press button ç or æ. The selection marker moves to the next submenu. The submenus are arranged by hierarchy. Scroll down with the ç button, scroll up with the æ...
Page 163 Controls in detail Control system The table below shows what settings can be changed within the various menus. De- tailed instructions on making individual settings can be found on the following pag- INSTRUMENT CLUSTER LIGHTING Select temperature display Set daytime running lamp mode mode (USA only) Select multifunction display...
Page 164: Instrument Cluster Submenu
Instrument cluster submenu Access the INST. CLUS. submenu via the menu. Use the SETTINGS INST. CLUS. submenu to change the instrument cluster display settings. The following functions are available: Function Page Select temperature display mode Select multifunction display mode Select language Select tire inflation pressure unit Selecting temperature display mode Move the selection marker with...
Page 165: Lighting Submenu
Controls in detail Control system Selecting language Move the selection marker with the æ or ç button to the INST. CLUS. submenu. Press button j or k repeatedly until you see this message in the multi- function display: LANGUAGE The selection marker is on the current setting.
Page 166 Setting daytime running lamp mode (USA only) This function is not available in coun- tries where the daytime running lamp mode is mandatory and therefore in a constant mode. Move the selection marker with the æ or ç button to the LIGHT- submenu.
Page 167 Controls in detail Control system Setting locator lighting With the locator lighting feature activated and the exterior lamp switch in position U, the following lamps will switch on during darkness when the vehicle is un- locked with the SmartKey: Parking lamps Tail lamps License plate lamps Front fog lamps...
Page 168 You can reactivate this function within ten minutes by opening a door. If after turning off the engine you do not open a door or do not close an opened door, the lamps will automatically switch off after 60 seconds. To activate night security illumination: Select delayed switch-off period (see below).
Page 169: Vehicle Submenu
Controls in detail Control system Press button j or k repeatedly until you see this message in the multi- function display: INTERIOR LIGHTING DELAYED SWITCH-OFF The selection marker is on the current setting. Press æ or ç to select the de- sired lamp-on time period.
Page 170: Convenience Submenu
Limiting opening height of trunk lid* This function is available in vehicles with the trunk lid opening/closing system*. Use this function to activate or deactivate the limiting opening height of trunk lid. Move the selection marker with the æ or ç button to VEHICLE submenu.
Page 171 Controls in detail Control system Activating easy-entry/exit feature Use this function to activate and deacti- vate the easy-entry/exit feature ( page 114). Warning! You must make sure no one can become trapped or injured by the moving steering wheel and driver’s seat when the easy-en- try/exit feature is activated.
Page 172 To have this feature activated and ap- pear in the multifunction display, contact an authorized Mercedes-Benz Center. Without this screen appearing and set to ON, the rear view mirror parking position feature ( page 187) is not available.
Page 173 Controls in detail Control system Setting fold-in function for exterior rear view mirrors Using this function, you can set the exteri- or rear view mirrors to be automatically folded in when you lock your vehicle ( page 188). Move the selection marker to the submenu with the æ...
Page 174: Automatic Transmission
Automatic transmission For more information on driving with an automatic transmission see “Automatic transmission” ( page 46). Your vehicle’s transmission adapts its gear shifting process to your individual driving style by continually adjusting the shift points up or down. These shift point adjust- ments are performed based on current operating and driving conditions.
Page 175 Avoid spinning of a drive wheel for an extended period when driving off on slippery road surfaces. This may cause serious damage to the drivetrain which is not covered by the Mercedes-Benz Limited Warranty. When the gear selector lever is in position D, you can influence transmission...
Page 176: Gear Selector Lever Position
Gear selector lever position Effect ì Park position Gear selector lever position when the vehicle is parked. Place gear selector lever in position P only when vehicle is stopped. The park position is not intended to serve as a brake when the vehicle is parked.
Page 177 Coasting the vehicle, or driving for any other reason with gear selector lever in N can result in transmission damage that is not covered by the Mercedes-Benz Limited Warranty. Warning! Getting out of your vehicle with the gear selector lever not fully engaged in position P is dangerous.
Page 178: Driving Tips
Driving tips Accelerator position Your driving style influences the transmission’s shifting behavior: Less throttle Earlier upshifting More throttle Later upshifting Kickdown Use kickdown when you want maximum acceleration. Press the accelerator past the point of resistance. The transmission shifts into a lower gear.
Page 179: Gear Ranges
Controls in detail Automatic transmission Gear ranges With the gear selector lever in position D and driving in the automatic shift program C or S ( page 179), you can select a gear range for the automatic transmission to operate within: Gear selector lever ( page 180): You can limit the gear range by pressing the gear selector lever to the left (D-), and...
Page 180: Automatic Shift Program
Automatic shift program The program mode selector switch is located on the lower part of the center console. 1 Program mode selector switch C Comfort For comfort driving S Sport For standard driving The current gear selector lever position and the selected program mode ( ) are indicated in the tachometer display ( page 174).
Page 181: Gear Selector Lever One-Touch Gearshifting
Avoid spinning of a drive wheel for an extended period when driving off on slippery road surfaces. This may cause serious damage to the drivetrain which is not covered by the Mercedes-Benz Limited Warranty. Downshifting Warning! On slippery road surfaces, never downshift in order to obtain braking action.
Page 182: Steering Wheel Gearshift Control One-Touch Gearshifting S 55 Amg And S 65 Amg
Avoid spinning of a drive wheel for an extended period when driving off on slippery road surfaces. This may cause serious damage to the drivetrain which is not covered by the Mercedes-Benz Limited Warranty. Controls in detail Automatic transmission The steering wheel gearshift buttons are located to the left and right of the steering wheel.
Page 183 Controls in detail Automatic transmission You cannot shift with the steering wheel gearshift buttons when the gear selector lever is in position P, N or R. The last selected program mode (C or S) is switched on when the engine is restarted in the automatic program mode.
Page 184: Manual Shift Program S 55 Amg And S 65 Amg
Avoid spinning of a drive wheel for an extended period when driving off on slippery road surfaces. This may cause serious damage to the drivetrain which is not covered by the Mercedes-Benz Limited Warranty. Controls in detail Automatic transmission The program mode selector switch is located on the lower part of the center console.
Page 185 Controls in detail Automatic transmission For information on automatic program modes C or S, see “Automatic shift program” ( page 179), “Gear selector lever one-touch gearshifting” ( page 180), and “Steering wheel gearshift control one-touch gearshift- ing S 55 AMG and S 65 AMG” ( page 181).
Page 186: Emergency Operation (Limp Home Mode)
Move gear selector lever to P. Turn off the engine. Wait at least ten seconds before restarting. Restart the engine. Move gear selector lever to position D (for second gear) or R. Have the transmission checked at an authorized Mercedes-Benz Center as soon as possible.
Page 187: Good Visibility
Controls in detail Good visibility For information on the windshield wipers, see “Windshield wipers” ( page 52). Headlamp cleaning system* (Standard on S 500, S 600, S 55 AMG and S 65 AMG) The switch is located on the left side of the dashboard.
Page 188 Warning! The auto-dimming function does not react if incoming light is not aimed directly at sen- sors in the interior rear view mirror. The interior rear view mirror and the exterior rear view mirror on the driver’s side do not react, for example, if the rear window sun shade* is in raised position.
Page 189: Power Folding Exterior Rear View Mirrors
Controls in detail Good visibility 1 Driver’s side exterior rear view mirror button 2 Passenger-side exterior rear view mir- ror button Press button 2 for the passenger-side exterior rear view mirror. Place the gear selector lever in reverse gear R. The passenger-side exterior rear view mirror will be turned downward to the stored position.
Page 190 Folding exterior rear view mirrors in and out manually The exterior rear view mirrors can vibrate if they are not folded out completely. The buttons are located on the driver’s door. 1 Folds the exterior mirrors out 2 Folds the exterior mirrors in Switch on the ignition ( page 34).
Page 191: Sun Visors
Controls in detail Good visibility Sun visors The sun visors protect you from sun glare while driving. Warning! Do not use the vanity mirror while driving. Keep the mirrors in the sun visors closed while vehicle is in motion. Reflected glare can endanger you and others.
Page 192: Rear Window Sunshade
Rear window sunshade The switch is located on the upper part of the front center console. 1 Rear window sunshade switch Switch on the ignition ( page 34). Press switch 1 briefly to raise the sun- shade. Press switch 1 briefly to lower the sunshade.
Page 193: Automatic Climate Control
Controls in detail Automatic climate control...
Page 194 Item 1 Left center air vent, adjustable 2 Left air vent, fixed 3 Thumbwheel for air volume control for left center air vent 4 Thumbwheel for air temperature control for center air vents 5 Thumbwheel for air volume control for right center air vent 6 Right air vent, fixed 7 Right center air vent, adjustable 8 Side defroster vent, fixed...
Page 195 Controls in detail Automatic climate control The automatic climate control is operation- al whenever the engine is running. You can operate the climate control system in ei- ther the automatic or manual mode. The system cools or heats the interior depend- ing on the selected interior temperature and the current outside temperature.
Page 196: Deactivating The Climate Control System
Deactivating the climate control sys- Deactivating It is possible to completely deactivate the automatic climate control system. Press button M ( page 193). The display shows When the air conditioning is switched off, the outside air supply and circula- tion are also switched off. Only choose this setting for a short time.
Page 197: Adjusting Air Distribution
Controls in detail Automatic climate control Adjusting air distribution Use air distribution controls c and 6 ( page 193) to separately adjust the air distribution on each side of the passenger compartment. The following symbols are found on the controls: Symbol Function Directs air through the cen-...
Page 198: Adjusting Air Volume
Adjusting air volume Use air volume control 9 ( page 193) for both automatic and manual air volume ad- justment. Adjusting automatically Press A on air volume switch 9 ( page 193). The display shows AUTO . The air volume is adjusted automatically.
Page 199: Air Recirculation Mode
Controls in detail Automatic climate control Air recirculation mode Switch to air recirculation mode to prevent unpleasant odors from entering the vehicle from the outside. This setting cuts off the intake of outside air and recirculates the air in the passenger compartment. Warning! When the outside temperature is below 41°F (5°C), only switch to air recirculation...
Page 200 The air recirculation mode is activated automatically: at high outside temperatures if the concentration of carbon mon- oxide and nitrogen oxide in the out- side air increases beyond a predetermined level, for example in a tunnel Please note that the charcoal filter must be activated ( page 200) for the air recirculation mode to be activated automatically.
Page 201: Charcoal Filter
Controls in detail Automatic climate control Charcoal filter An activated charcoal filter markedly re- duces bad odors and removes pollutants from air entering the passenger compart- ment. Activating Press button e ( page 193). The indicator lamp on the button comes on.
Page 202: Rear Window Defroster
The system automatically switches to the air recirculation mode if the carbon monoxide (CO) or nitrogen oxide (NO concentration of the outside air increases beyond a predetermined level, for example in a tunnel. The automatic air recirculation mode does not function if ± is selected or if the outside temperature has fallen below 41°F (5°C).
Page 203: Air Conditioning
The compressor has turned itself off. The air conditioning cannot be turned on again. Have the air conditioning checked at the nearest authorized Mercedes-Benz Center. Residual heat and ventilation With the engine switched off, it is possible to continue to heat or ventilate the interior.
Page 204: Ventilated Storage Compartment
Deactivating Press button T ( page 193). The indicator lamp on button T goes out. The residual heat is automatically turned off: when the ignition is switched on after approximately 30 minutes (15 minutes when residual heat and ventilation in the rear* are also switched on) if the battery voltage drops How long the system will provide heat-...
Page 205: Rear Passenger Compartment Adjustable Air Vents
Controls in detail Automatic climate control Rear passenger compartment adjust- able air vents Rear center console air vents 1 Left center air vent, adjustable 2 Right center air vent, adjustable 3 Thumbwheel for center air vents with adjustable booster blower To open center air vents and to adjust the booster blower: Turn thumbwheel 3.
Page 206: Rear Passenger Compartment Climate Control
Rear passenger compartment climate control* The automatic climate control is operation- al whenever the engine is running. You can operate the climate control system in ei- ther the automatic or manual mode. The system cools or heats the interior depend- ing on the selected interior temperature and the current outside temperature.
Page 207 Controls in detail Automatic climate control Deactivating and reactivating the cli- mate control system Deactivating It is possible to completely deactivate the automatic climate control system. Press button M ( page 205). The display shows When the air conditioning is switched off, the outside air supply and circula- tion are also switched off.
Page 208 Adjusting air volume Adjusting automatically Press A on air volume switch 6 ( page 205). The display shows AUTO The air volume is adjusted automatically. Reducing air volume Press switch 6 down until the desired air volume is reached. The display shows the current level. Increasing air volume Press switch 6 up until the desired air volume is reached.
Page 209: Power Windows
Controls in detail Power windows Opening and closing the power windows The side windows are opened and closed electrically. The switches for all side win- dows are on the driver’s door. The switch- es for the respective windows are on the front passenger door and the rear doors.
Page 210 Operating the windows from the rear is not possible if you activate the override switch ( page 77). With the SmartKey in starter switch po- sition 0 or removed from the starter switch, the power windows can be op- erated: until you open the driver’s or front passenger door for at least five minutes...
Page 211: Synchronizing The Power Windows
Controls in detail Power windows still does not close when there is no ob- struction, press and hold the respec- tive power window switch at the symbol j. The side window will then close without the obstruction sen- sor function. Stopping windows during Express-op- eration Briefly press the respective power win-...
Page 212: Convenience Closing Feature
Convenience closing feature When you lock the vehicle, you can close the side windows and tilt/sliding sunroof simultaneously. Aim transmitter eye of the SmartKey or SmartKey with KEYLESS-GO* at the driver’s outside door handle ( page 210). The SmartKey or SmartKey with KEYLESS-GO* must be in close proximity to the driver’s door handle.
Page 213: Power Tilt/Sliding Sunroof
Controls in detail Power tilt/sliding sunroof Opening and closing the power tilt/sliding sunroof The tilt/sliding sunroof is opened and closed electrically. The switch for the tilt/sliding sunroof is on the overhead con- trol panel. 1 Push up to raise sunroof at rear 2 Pull down to lower sunroof at rear 3 Push forward to slide sunroof closed 4 Push back to slide sunroof open...
Page 214 When leaving the vehicle, always remove the SmartKey or SmartKey with KEYLESS-GO* from the starter switch, take it with you, and lock the vehicle. Do not leave children unat- tended in the vehicle, or with access to an unlocked vehicle. Unsupervised use of vehi- cle equipment can cause an accident and/or serious personal injury.
Page 215: Synchronizing The Power Tilt/Sliding Sunroof
Canada vehicles, but deactivated for U.S. vehicles at the factory. If you wish to have it activated, contact an au- thorized Mercedes-Benz Center. To select a tilt/sliding sunroof opening position, press the sunroof switch to the resistance point and release it when the tilt/sliding sunroof has reached the desired position.
Page 216: Driving Systems
Driving systems The driving systems of your vehicle are de- scribed on the following pages: Cruise control and Distronic*, with which the vehicle can maintain a preset speed. Airmatic adjusts the vehicle suspen- sion characteristics automatically and controls the vehicle level. ABC* with vehicle level control system, with which you can change vehicle sus- pension characteristics.
Page 217 Controls in detail Driving systems 1 Sets current or higher speed 2 Sets current or lower speed 3 Cancels cruise control 4 Resumes at last set speed Setting current speed Accelerate or decelerate to the desired speed. Briefly lift the cruise control lever in the direction of arrow 1 or depress in the direction of arrow 2.
Page 218 Setting a higher speed Lift cruise control lever in the direction of arrow 1 and hold it up until the de- sired speed is reached. Release cruise control lever. The new speed is set. Depressing the accelerator pedal does not deactivate cruise control. After brief acceleration (e.g.
Page 219: Distronic
Controls in detail Driving systems Distronic* When activated, the Distronic adaptive cruise control system increases driving convenience afforded by the cruise control during travel on expressways and other major roads. If the Distronic distance sensor detects a slower moving vehicle directly ahead, your vehicle speed will be reduced so that you follow that vehicle at a preset distance.
Page 220 Canada only: This device complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause interfer- ence, and (2) this device must accept any inter- ference received, including interfer- ence that may cause undesired operation of the device.
Page 221 Controls in detail Driving systems Distronic displays in the speedometer dial Set speed If Distronic is activated, one or two seg- ments come on around the set speed. The vehicle speed displayed on the speedometer can briefly vary from the speed setting on the Distronic system.
Page 222 Warning! An intermittent warning sounds and the Distronic warning lamp l in the instru- ment cluster is illuminated if the Distronic system calculates that the distance to the vehicle ahead and your vehicle’s current speed indicate that Distronic will not be ca- pable of slowing the vehicle sufficiently to maintain the preset following distance, which creates a danger of a collision.
Page 223 Controls in detail Driving systems Distronic deactivated If Distronic is deactivated, the standard display of Distronic appears in the multi- function display. 1 Vehicle ahead, if detected 2 Actual distance to vehicle ahead 3 Preset distance threshold to vehicle ahead 4 Symbol for activated distance warning function 5 Your vehicle...
Page 224 Activating Distronic You can activate Distronic when: you are driving above 25 mph (40 km/h) ® the ESP switched on ( page 81) The maximum speed you can set is 110 mph (180 km/h). If Distronic has not been activated after pressing the cruise control lever, you will see the message: in the multifunction...
Page 225 Controls in detail Driving systems Setting a higher speed Briefly tip the cruise control lever in the direction of arrow 1 ( page 222) to increase vehicle speed in increments of 5 mph (Canada: 10 km/h). The new speed is set. The stored speed is displayed in the multifunction display for approximately five seconds ( page 222), and one or...
Page 226 Deactivating Distronic There are several ways to deactivate the Distronic system: Briefly tip the cruise control lever in the direction of arrow 3 ( page 222). Step on the brake pedal. Distronic will be deactivated. The last speed set will be stored into memory. The following message will appear in the multifunction display for approxi- mately five seconds:...
Page 227 Controls in detail Driving systems The distance warning function on/off but- ton and thumbwheel for setting distance are located on the lower part of the front center console. 1 Distance warning function on/off but- 2 Thumbwheel for setting distance Increasing distance Increasing the distance setting causes Dis- tronic to maintain a greater following dis- tance to the vehicle ahead.
Page 228 Activating Press button 1. The indicator lamp on the button comes on. A loudspeaker symbol ap- pears in the multifunction display ( page 222). Deactivating Press button 1. The indicator lamp on the button goes out. Driving with Distronic This section describes a number of driving situations where special precaution is re- quired on the part of the driver.
Page 229 Controls in detail Driving systems The most likely cause for a malfunctioning system is a dirty sensor (located behind the hood grille), especially at times of snow and ice or heavy rain. In such a case, Dis- tronic will switch off, and the message: DISTRONIC CURRENTLY UNAVAILABLE SEE OPERATORS MANUAL...
Page 230: Airmatic
Lane changing Distronic has not yet detected the vehicle changing lanes. There will be insufficient distance to the lane-changing vehicle. Narrow vehicles Because of their narrow profile, the vehi- cles traveling near the outer edge of the lane have not yet been detected by Dis- tronic.
Page 231 Controls in detail Driving systems 1 Indicator lamps 2 Damping button Start the engine. Press the damping button 2 until the desired suspension style is set. If both indicator lamps are out, you have chosen the automatic mode for soft damping. The message: AIRMATIC CONVENIENCE for Comfort suspension tuning ap-...
Page 232 The following vehicle level settings can be selected when the vehicle is stationary: Level Normal For driving on normal roads. The indicator lamp is off. Raised For driving on rough roads or with snow chains.The indica- tor lamp is on. Select the “Raised”...
Page 233: Active Body Control Abc
Controls in detail Driving systems Active Body Control (ABC)* The ABC system automatically selects the optimum suspension tuning and ride height for your vehicle. Suspension tuning The suspension tuning is set according to: your driving style road surface conditions the vehicle loading your choice of suspension style You can set following suspension style: regular (convenience)
Page 234 Vehicle level control with ABC* Warning! To help avoid personal injury, keep hands and feet away from wheel housing area, and stay away from under the vehicle when low- ering the vehicle chassis. Your vehicle automatically adjusts its ride height to: Vehicle level Use for when stationary...
Page 235 Controls in detail Driving systems The button with the indicator lamps is lo- cated on the upper part of the front center console. 1 Indicator lamps 2 Vehicle level control button Start the engine. Briefly press button 2 to change from one level setting to the next.
Page 236: Parktronic System* (Parking Assist)
Parktronic system* (Parking assist) Warning! Parktronic is a supplemental system. It is not intended to, nor does it replace, the need for extreme care. The responsibility during parking and other critical maneuvers always rests with the driver. Special attention must be paid to objects with smooth surfaces or low silhouettes (e.g.
Page 237 Controls in detail Driving systems Front sensors Center approx. 40 in (100 cm) Corners approx. 24 in (60 cm) Rear sensors Center approx. 48 in (120 cm) Corners approx. 32 in (80 cm) During parking maneuvers, pay special attention to objects located above or below the height of the sensors (e.g.
Page 238 1 Left side of the vehicle 1 Right side of the vehicle Each warning indicator is divided into six yellow and two red distance segments for either side of the vehicle. The Parktronic system is ready when the border around the indicator is illuminated.
Page 239 20 seconds and the indicator lamp in the Parktronic switch comes on. Have the Parktronic system checked by an authorized Mercedes-Benz Cen- ter as soon as possible. If only the red distance segments illumi- nate and no acoustic warning sounds, the...
Page 240: Loading
Loading Roof rack* Warning! Use only roof racks approved by Mercedes-Benz for your vehicle model to avoid damage to the vehicle. Follow manu- facturer’s installation instructions. Controls in detail Loading Preparing roof rack installation Open trim at the trim strips in the roof.
Page 241: Loading Instructions
Controls in detail Loading Loading instructions The total load weight including vehicle oc- cupants and luggage/cargo should not ex- ceed the load limit or vehicle capacity weight as indicated on the corresponding placard located on the driver’s door B-pillar ( page 300). Warning! Always fasten items being carried as secure- ly as possible.
Page 242: Useful Features
Useful features Vanity mirrors Vanity mirror in the sun visor Warning! Do not use the vanity mirror while driving. Keep the mirrors in the sun visors closed while vehicle is in motion. Reflected glare can endanger you and others. 1 Mirror cover 2 Mirror lamp 3 Document holder To use mirror, lift up cover 1.
Page 243: Storage Compartments
Controls in detail Useful features Vanity mirror in the rear The vanity mirrors are located in the roof lining for the rear seat passengers. Opening the vanity mirror Press the cover of the vanity mirror. The vanity mirror folds down and the mirror lamp comes on.
Page 244 Unlocking the glove box Insert mechanical key ( page 388) into the glove box lock. Turn the mechanical key to position 1. Opening the glove box Press glove box lid release 3. The glove box lid opens downward. Closing the glove box Push lid up to close.
Page 245 Controls in detail Useful features Storage compartment in front of arm- rest 1 Storage compartment Opening The compartment contains a cup holder ( page 248). Lightly touch the chrome label on plate 1. The cover opens automatically. Closing Lightly push cover plate 1 up until it engages.
Page 246 Opening storage tray The tray contains a coin holder. Press button 2 and lift the armrest. Do not store any objects under the storage tray. Do not let bank cards, credit cards, or other cards with a magnetic strip come near the storage tray, as a magnet built into the tray could erase or change the information on the card.
Page 247 Controls in detail Useful features Storage compartments in the rear pas- senger compartment Armrest with integrated storage com- partment 1 Rear armrest 2 Lid handle Opening the storage compartment: Pull down the armrest by its strap. Press handle 2 and lift lid. Before storing the armrest in the back- rest, close the storage compartment lid.
Page 248 Storage compartments under the front seats 1 Lid 2 Buttons Opening Press buttons 2 together and fold lid 1 down. Closing Close lid 1 until both buttons 2 of lock engage. Parcel net in front passenger footwell A small convenience parcel net is located in the front passenger footwell.
Page 249: Cup Holders
Liquids spilled on vehicle equipment may cause damage not covered by the Mercedes-Benz Limited Warranty. When not in use, keep the cup holder closed. An open cup holder may cause injury to you or others when contacted during braking, vehicle maneuvers, or in an acci- dent.
Page 250: Ashtrays
Folding in cup holder 1 Cup holder Swing cup holder 1 back and press it into the storage compartment until it engages. Cup holder in rear seat armrest 1 Compartment for cup holder Opening cup holder Push front of sliding compartment 1. The cup holder slides out.
Page 251: Cigarette Lighters
Controls in detail Useful features Removing ashtray insert Warning! Remove front ashtray only with vehicle standing still. Set the parking brake to se- cure vehicle from movement. Move gear se- lector lever to position N. With gear selector lever in position N turn off the engine. Secure vehicle from movement by set- ting the parking brake.
Page 252 1 Center console cigarette lighter Switch on the ignition ( page 34). Push in cigarette lighter 1. The lighter will pop out automatically when hot. The lighter socket can be used to ac- commodate electrical accessories up to a maximum 180 W. Rear door lighter Warning! Never touch the heating element or sides of...
Page 253: Heated Steering Wheel* (Except S 55 Amg And S 65 Amg)
Controls in detail Useful features Heated steering wheel* (except S 55 AMG and S 65 AMG) The steering wheel heating warms up the leather area of the steering wheel. The stalk with the heated steering wheel switch is on the lower left-hand side of the steering wheel.
Page 254: Telephone
The external antenna must be approved by Mercedes-Benz. Please contact an autho- rized Mercedes-Benz Center for informa- tion on the installation of an approved external antenna. Refer to the radio trans- mitter operation instructions regarding use of an external antenna.
Page 255: Tele Aid
Controls in detail Useful features Tele Aid The initial activation of the Tele Aid sys- tem may only be performed by com- pleting the subscriber agreement and placing an acquaintance call using the Information button ¡. Failure to complete either of these steps will re- sult in a system that is not activated.
Page 256 If a malfunction is indicated as outlined above, the system may not operate as ex- pected. Have the system checked at the nearest Mercedes-Benz Center as soon as possible. Controls in detail Useful features Emergency calls...
Page 257 Controls in detail Useful features A voice connection between the Response Center and the occupants of the vehicle will be established automatically soon af- ter the emergency call has been initiated. The Response Center will attempt to deter- mine more precisely the nature of the acci- dent provided they can speak to an occupant of the vehicle.
Page 258 Useful features Roadside Assistance button • Press and hold the button • (for longer than two seconds). A call to a Mercedes-Benz Roadside As- sistance dispatcher will be initiated. The button will flash while the call is in progress. The message:...
Page 259 Describe the nature of the need for as- sistance. The Mercedes-Benz Roadside Assistance dispatcher will either dispatch a qualified Mercedes-Benz technician or arrange to tow your vehicle to the nearest authorized Mercedes-Benz Center. For services such as labor and/or towing, charges may ap- ply.
Page 260 Assistance Center representative and the occupants of the vehicle will be estab- lished. Information regarding the operation of your vehicle, the nearest authorized Mercedes-Benz Center or Mercedes-Benz USA products and services is available to you. For more details concerning the Tele Aid system, please visit www.mbusa.com and...
Page 261 Tele Aid system has detected a fault or the service is not currently ac- tive, and may not initiate a call. Visit an Mercedes-Benz Center and have the system checked or contact the Re- sponse Center at 1-800-756-9018 (in the USA) or 1-888-923-8367 (in Cana- da) as soon as possible.
Page 262 In case you have locked your vehicle unin- tentionally (e.g. SmartKey inside vehicle), and the reserve SmartKey is not handy: Contact the Mercedes-Benz Response Center at 1-800-756-9018 (in the USA) or 1-888-923-8367 (in Canada). You will be asked to provide your pass- word which you provided when you completed the subscriber agreement.
Page 263 Report the incident to the police. The police will issue a numbered incident report. Pass this number on to the Mercedes-Benz Response Center along with your password issued to you when you subscribed to the service. The Response Center will then attempt to covertly contact the vehicle’s...
Page 264: Garage Door Opener
Garage door opener The built-in remote control is capable of operating up to three separately controlled devices, for example garage door openers, gate openers, or other devices compatible ® with HomeLink or some other systems. You can program the signal transmitter buttons.
Page 265 Certain types of garage door openers are incompatible with the integrated opener. If you should experience diffi- culties with programming the transmit- ter, contact an authorized Mercedes-Benz Center, or call Mercedes-Benz Customer Assistance Center (in the USA) at 1-800-FOR-MERCedes, or Customer Service (in Canada) at 1-800-387-0100.
Page 266 Programming or reprogramming the in- tegrated remote control Step 1: Switch on the ignition ( page 34). Step 2: If you have previously programmed an integrated signal transmitter button and wish to retain its programming, proceed to step 3. Otherwise, press and hold the two outer signal transmit- ter buttons 2 and 4 and release them only when the indicator lamp 1...
Page 267 Controls in detail Useful features If the indicator lamp 1 flashes rapidly for about two seconds and then turns to a constant light, continue with pro- gramming steps 8 through 12 as your garage door opener may be equipped with the “rolling code feature”. Step 7: To program the remaining two buttons, repeat the steps above starting with...
Page 268 Step 12: Confirm the garage door operation by pressing the programmed integrated signal transmitter button (2, 3 or 4). Step 13: To program the remaining two buttons, repeat the steps above starting with step 3. Gate operator/Canadian programming Canadian radio-frequency laws require transmitter signals to “time-out”...
Page 269 Controls in detail Useful features Operation of integrated remote control Switch on the ignition ( page 34). Select and press the appropriate inte- grated signal transmitter button (2, 3 or 4) to activate the remote con- trolled device. The integrated remote control trans- mitter continues to send the signal as long as the button is pressed –...
Page 270: Infrared Reflecting Windshield
Infrared reflecting windshield 1 Mounting location for electronic toll collection devices (infrared transpar- ent) 2 Infrared transparent area (pass-through for electronic signals) 3 31.5 in (80 cm) 4 19.0 in (48 cm) 5 1.75 in (4.5 cm) Your vehicle is equipped with infrared re- flecting glass which reduces the amount of radiated heat entering the interior through the windows.
Page 272: Operation
Operation The first 1000 miles (1500 km) Driving instructions At the gas station Engine compartment Tires and wheels Winter driving Maintenance Vehicle care...
Page 273: The First 1000 Miles (1500 Km)
Operation The first 1000 miles (1500 km) In the “Operation” section you will find de- tailed information on operating, maintain- ing and caring for your vehicle. The more cautiously you treat your vehicle during the break-in period, the more satis- fied you will be with its performance later Drive your vehicle during the first 1000 miles (1500 km) at varying but...
Page 274: Driving Instructions
Booklet and as required by the Maintenance System (U.S. vehicles) or FSS (Canada vehicles). Contact an au- thorized Mercedes-Benz Center. Fuel consumption is also increased by driv- ing in cold weather, in stop-and-go traffic, on short trips, and in hilly area.
Page 275: Brakes
Have the brake system inspected immedi- ately. Contact an authorized Mercedes-Benz Center. All checks and service work on the brake system should be carried out by qualified technicians only. Contact an authorized Mercedes-Benz Center. Only install brake pads and brake fluid recommended by Mercedes-Benz.
Page 276 Warning! If other than recommended brake pads are installed, or other than recommended brake fluid is used, the braking properties of the vehicle can be degraded to an extent that safe braking is substantially impaired. This could result in an accident. When driving down long and steep grades, relieve the load on the brakes by shifting into a lower gear to use the...
Page 277: Driving Off
ESP switched off. Doing so may cause serious damage to the drivetrain which is not covered by the Mercedes-Benz Limited Warranty. Simultaneously depressing the acceler- ator pedal and applying the brake re- duces engine performance and causes premature brake and drivetrain wear.
Page 278: Tires
Inspect the tires and the vehicle underbody for possible damage. If the vehicle or tires appear unsafe, have it towed to the nearest Mercedes-Benz Center or tire dealer for re- pairs. Treadwear indicators (TWI) are required by law. These indicators are located in six...
Page 279: Tire Traction
If ice has formed on the road, tire traction will be substantially reduced. Under such weather conditions, drive, steer and brake with extreme caution. Mercedes-Benz recommends winter tires ( page 327) with a minimum tread depth of approximately in (4 mm) on all four wheels for the winter season to ensure normal balanced handling characteristics.
Page 280: Winter Driving Instructions
S 350, S 430, S 430 4MATIC, S 500 and S 500 4MATIC Your vehicle is factory equipped with “H”-rated tires, which have a speed rating of 130 mph (210 km/h). An electronic speed limiter prevents your vehicle from exceeding a speed of 130 mph (210 km/h).
Page 281: Standing Water
Any such dam- age is not covered by the Mercedes-Benz Limited Warranty.
Page 282: Passenger Compartment
The trunk is the preferred place to carry ob- jects. Driving abroad Abroad, there is an extensive Mercedes-Benz service network at your disposal. If you plan to drive into areas which are not listed in the index of your Mercedes-Benz Center directory, you should request pertinent information from an authorized Mercedes-Benz Center.
Page 283: Catalytic Converter
Operation Driving instructions Catalytic converter Your Mercedes-Benz is equipped with monolithic-type catalytic converters, an important element in conjunction with the oxygen sensors to achieve substantial con- trol of the pollutants in the exhaust emis- sions. Keep your vehicle in proper...
Page 284: Coolant Temperature
The engine should not be operated with the coolant temperature over 248°F (120°C). Doing so may cause serious en- gine damage which is not covered by the Mercedes-Benz Limited Warranty. Operation Driving instructions Warning! Driving when your engine is badly over-...
Page 285: At The Gas Station
Operation At the gas station Refueling Warning! Gasoline is highly flammable and poisonous. It burns violently and can cause serious injury. Whenever you are around gasoline, avoid inhaling fumes and skin contact, extin- guish all smoking materials. Never allow sparks, flame or smoking materials near gasoline! The fuel filler flap is located on the right-hand side of the vehicle towards the...
Page 286: Check Regularly And Before A Long Trip
Warning! Overfilling of the fuel tank may create pres- sure in the system which could cause a gas discharge. This could cause the gas to spray back out when removing the fuel pump noz- zle, which could cause personal injury. Replace fuel cap by turning it clockwise until it audibly engages.
Page 287 Notify an authorized Mercedes-Benz Center immediately. Do not add brake fluid as this will not solve the problem. For more information, see “Practical hints”...
Page 288: Engine Compartment
Engine compartment Hood Warning! Do not pull the release lever while the vehi- cle is in motion. Otherwise the hood could be forced open by passing air flow. Opening The hood lock release lever is located in the driver’s footwell to the left of the park- ing brake pedal.
Page 289: Engine Oil
Do not use any special lubricant addi- tives, as these may damage the drive assemblies. Using special additives not approved by Mercedes-Benz may cause damage not covered by the Mercedes-Benz Limited Warranty. More information on this subject is available at any Mercedes-Benz Center.
Page 290 Checking the engine oil level with the control system When checking the oil level the vehicle must be parked on level ground with the engine at operating tempera- ture, the vehicle must have been sta- tionary for at least five minutes with the engine turned off with the engine not at operating tem- perature yet, the vehicle must have...
Page 291 Excess oil must be siphoned or drained off. It could cause damage to the en- gine and catalytic converter not cov- ered by the Mercedes-Benz Limited Warranty. Perform the engine oil level check with the dipstick (S 430, S 500, and S 55 AMG only) if it cannot be complet- ed with the control system.
Page 292 Checking the engine oil level with the oil dipstick (S 350, S 430, S 500 and S 55 AMG only) When checking the oil level the vehicle must be parked on level ground with the engine at operating tempera- ture, the vehicle must have been sta- tionary for at least five minutes with the engine turned off The engine oil level can be checked by...
Page 293 Maintenance System (U.S. vehicles) or FSS (Canada vehi- cles) will result in engine damage not covered by the Mercedes-Benz Limited Warranty. S 350, S 430, S 430 4MATIC, S 500, S 500 4MATIC, S 55 AMG...
Page 294: Transmission Fluid Level
Excess oil must be siphoned or drained off. It could cause damage to the en- gine and catalytic converter not cov- ered by the Mercedes-Benz Limited Warranty. Screw filler cap 1 back on filler neck. For more information on engine, see the “Technical data”...
Page 295: Coolant Level
Operation Engine compartment Coolant level The engine coolant is a mixture of water and anticorrosion/antifreeze. When checking the coolant level, the vehicle must be parked on level ground, and the engine must be cool. Warning! In order to avoid any possibly serious burns: Use extreme caution when opening the hood if there are any signs of steam or coolant leaking from the cooling system,...
Page 296: Battery
When replacing the battery, always use batteries approved by Mercedes-Benz. If you do not intend to operate your vehicle for an extended period of time, consult an authorized Mercedes-Benz Center about steps you need to observe.
Page 297: Windshield Washer System And Headlamp Cleaning System
Operation Engine compartment Windshield washer system and headlamp cleaning system* The windshield washer reservoir is located in the engine compartment. 1 Washer fluid reservoir Fluid for the windshield washer system and the headlamp cleaning system is supplied from the windshield washer reservoir. It has a capacity of approximately: 3.2 US qt.
Page 298: Tires And Wheels
When replacing rims, only use genuine Mercedes-Benz wheel bolts specified for the particular rim type. Failure to do so can result in the bolts loosening and possibly an accident.
Page 299: Tire Care And Maintenance
Operation Tires and wheels Tire care and maintenance Warning! Regularly check the tires for damage. Dam- aged tires can cause tire inflation pressure loss. As a result, you could lose control of your vehicle. Worn, old tires can cause accidents. If the tire tread is badly worn, or if the tires have sustained damage, replace them.
Page 300 Tread depth Do not allow your tires to wear down too far. Adhesion properties on wet roads are sharply reduced at tread depths under in (3 mm). Treadwear indicators (TWI) are required by law. These indicators are located in six places on the tread circumference and become visible at a tread depth of approx- imately...
Page 301: Direction Of Rotation
Operation Tires and wheels Direction of rotation Unidirectional tires offer added advan- tages, such as better hydroplaning perfor- mance. To benefit, however, you must make sure the tires rotate in the direction specified. An arrow on the sidewall indicates the intended direction of rotation (spinning) of the tire.
Page 302 Tire and Loading Information Warning! Do not overload the tires by exceeding the specified load limit or vehicle capacity weight as indicated on the placard on the driver’s door B-pillar. Overloading the tires can overheat them, possibly causing a blowout. Overloading the tires can also result in handling or steering problems, or brake failure.
Page 303 Operation Tires and wheels Placard (Example B) 1 Load limit information on the Vehicle Tire Information placard The placard showing the load limit informa- tion is located on the driver’s door B-pillar. If your vehicle is equipped with the Vehicle Tire Information placard (Example B), locate the heading “Vehicle Capacity Weight”...
Page 304 Steps for determining correct load limit The following steps have been developed as required of all manufacturers under Title 49, Code of U.S. Federal Regulations, Part 575 pursuant to the “National Traffic and Motor Vehicle Safety Act of 1966”. Step 1 (Vehicles equipped with placard Example A) Locate the statement “The combined weight of occupants and cargo should...
Page 305 Operation Tires and wheels Example Combined Number of weight limit occupants of occu- (driver and pants and passengers) cargo from placard 1500 lbs 1500 lbs 1500 lbs The higher the weight of all occupants, the less cargo and luggage load capacity is available.
Page 306 The tongue load typically is ten percent of the trailer weight and every- thing loaded in it. Your Mercedes-Benz has been designed primarily to carry passengers and their cargo. Mercedes-Benz does not recom- mend trailer towing with your vehicle.
Page 307: Recommended Tire Inflation Pressure
Operation Tires and wheels Recommended tire inflation pressure Warning! Follow recommended tire inflation pressures. Do not underinflate tires. Underinflated tires wear excessively and/or unevenly, adversely affect handling and fuel economy, and are more likely to fail from being over- heated. Do not overinflate tires.
Page 308 Placard (Example B) 1 Vehicle Tire Information placard with recommended cold tire inflation pressures Placard (Example B) lists the recommend- ed cold tire inflation pressures for maxi- mum loaded vehicle weight. The tire inflation pressures listed apply to the tires installed as original equipment.
Page 309: Checking Tire Inflation Pressure
Operation Tires and wheels Checking tire inflation pressure Regularly check your tire inflation pressure at least once a month. Check and adjust the tire inflation pressure when the tires are cold. The tires can be considered cold if the vehicle has been parked for at least three hours or driven less than one mile (1.6 km).
Page 310 After you have reactivated the tire infla- tion pressure monitor, the current tire inflation pressures will only be shown after a few minutes’ driving time. During this time, you will see the follow- ing message in the multifunction dis- play: TIRE PRES.
Page 311 Operation Tires and wheels The recommended tire inflation pres- sures for your vehicle can be found on the tire placard located on the driver’s door B-pillar. The tire inflation pres- sures are not listed in the owner’s man- ual. Warning! The tire inflation pressure monitor does not indicate a warning for wrongly selected tire inflation pressures.
Page 312 Reactivating the tire inflation pressure monitor The tire inflation pressure monitor must be reactivated in the following situations: If you have changed the tire inflation pressure. If you have replaced the wheels or tires. If you have installed new wheels or tires.
Page 313 Operation Tires and wheels This display appears until the individual tire inflation pressure values are matched with the tires. The individual values are then displayed ( page 309). If you wish to cancel activation: Press the ç button. If one of the following messages appears in the multifunction display: TIRE PRES.
Page 314: Tire Labeling
Tire labeling Besides tire name (sales designation) and manufacturer name, a number of markings can be found on a tire. Following are some explanations for the markings on your vehicle’s tires: 1 Uniform Quality Grading Standards ( page 320) 2 DOT, Tire Identification Number (TIN) ( page 318) 3 Maximum tire load ( page 319) 4 Maximum tire inflation pressure...
Page 315 Operation Tires and wheels General: Depending on the design standards used, the tire size molded into the sidewall may have no letter or a letter preceding the tire size designation. No letter preceding the size designation (as illustrated above): Passenger car tire based on European design standards.
Page 316 Warning! The tire load rating must always be at least half of the GAWR ( page 323) of your vehi- cle. Otherwise, tire failure may be the result which may cause an accident and/or seri- ous personal injury to you or others. Always replace rims and tires with the same designation, manufacturer and type as shown on the original part.
Page 317 Operation Tires and wheels Summer tires Index Speed rating up to 100 mph (160 km/h) up to 106 mph (170 km/h) up to 112 mph (180 km/h) up to 118 mph (190 km/h) up to 130 mph (210 km/h) up to 149 mph (240 km/h) up to 168 mph (270 km/h) up to 186 mph (300 km/h) above 186 mph (300 km/h)
Page 318: Load Identification
All-season and winter tires Index Speed rating Q M+S up to 100 mph (160 km/h) T M+S up to 118 mph (190 km/h) H M+S up to 130 mph (210 km/h) V M+S up to 149 mph (240 km/h) or M+S.for winter tires Not all M+S rated tires provide special winter performance.
Page 319: Dot, Tire Identification Number (Tin)
Operation Tires and wheels DOT, Tire Identification Number (TIN) U.S. tire regulations require each new tire manufacturer or tire retreader to mold a TIN into or onto a sidewall of each tire produced. The TIN is a unique identifier which facili- tates efforts by tire manufactures to notify purchasers in recall situations or other safety matters concerning tires and gives...
Page 320: Maximum Tire Load
Tire type code The code 4 ( page 318) may, at the option of the manufacturer, be used as a descriptive code for identifying significant characteristics of the tire. Date of manufacture The date of manufacture 5 ( page 318) identifies the week and year of manufac- ture.
Page 321: Maximum Tire Inflation Pressure
Operation Tires and wheels Maximum tire inflation pressure 1 Maximum permissible tire inflation pressure For illustration purposes only. Actual data on tires are specific to each vehi- cle and may vary from data shown in above illustration. This is the maximum permissible tire inflation pressure for the tire.
Page 322 Quality grades can be found, where appli- cable, on the tire sidewall between tread shoulder and maximum section width. For example: Treadwear Traction Temperature All passenger car tires must conform to federal safety requirements in addition to these grades. Treadwear The treadwear grade is a comparative rat- ing based on the wear rate of the tire when tested under controlled conditions on a...
Page 323: Tire Ply Material
Operation Tires and wheels Temperature The temperature grades are A (the high- est), B, and C, representing the tire’s resis- tance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 324: Tire And Loading Terminology
Tire and loading terminology Accessory weight The combined weight (in excess of those standard items which may be replaced) of automatic transmission, power steering, power brakes, power windows, power seats, radio, and heater, to the extent that these items are available as factory-installed equipment (whether installed or not).
Page 325 Operation Tires and wheels GVWR (Gross Vehicle Weight Rating) This is the maximum permissible vehicle weight of the fully loaded vehicle (weight of the vehicle including all options, passen- gers, fuel, and cargo and, if applicable, trailer tongue load). It is indicated on Certification label located on the driver’s door B-pillar.
Page 326 TIN (Tire Identification Number) Unique identifier which facilitates efforts by tire manufacturers to notify purchasers in recall situations or other safety matters concerning tires and gives purchases the means to easily identify such tires. The TIN is comprised of “Manufacturer’s identifica- tion mark”, “Tire size”, “Tire type code”...
Page 327: Rotating Tires
Wheels could become loose if not tightened with a torque of 110 lb-ft (150 Nm). Only use genuine Mercedes-Benz wheel bolts specified for your vehicle’s rims. For information on wheel change, see the “Practical hints” section ( page 403).
Page 328: Winter Driving
Winter driving Before the onset of winter, have your vehicle winterized at an authorized Mercedes-Benz Center. This service includes: Check of anticorrosion and antifreeze concentration. Addition of cleaning concentrate to the water of the windshield and headlamp cleaning system. Add MB Concentrate “S”...
Page 329: Block Heater (Canada Only)
Snow chains should only be used on the rear wheels. Follow the manufac- turer’s mounting instructions. Only use snow chains that are approved by Mercedes-Benz. Your authorized Mercedes-Benz Center will be glad to advise you on this subject. Use of snow chains may be prohibited depending on location.
Page 330: Maintenance
Maintenance We strongly recommend that you have your vehicle serviced by an authorized Mercedes-Benz Center, in accordance with the Maintenance Booklet at the times called for by the maintenance service indi- cator display. Failure to have the vehicle maintained in...
Page 331: Clearing The Maintenance Service Indicator
XXX DAYS 'A' SERVICE EXCEEDED BY X DAY In addition, a signal sounds when the mes- sage appears. Any authorized Mercedes-Benz Center will reset the maintenance service indicator following a completed maintenance ser- vice. Calling up the maintenance service in- dicator Switch on the ignition ( page 34).
Page 332: Resetting The Maintenance Service Indicator
In the event that the maintenance service on your vehicle is not carried out by an au- thorized Mercedes-Benz Center, you can have the maintenance service indicator re- set. The automotive maintenance facility carrying out the maintenance service will...
Page 333: Vehicle Care
Post-production treatment is neither necessary nor recommended by Mercedes-Benz because of the possibility of incompatibility between materials used in the production process and others ap- plied later.
Page 334 We have selected car-care products and compiled recommendations which are specially matched to our vehicles and which always reflect the latest technology. You can obtain Mercedes-Benz approved car-care products at an authorized Mercedes-Benz Center. Scratches, corrosive deposits, corrosion or damage due to negligent or incorrect care cannot always be removed or repaired with the car-care products recommended here.
Page 335 Vehicle washing Do not use hot water or wash your vehicle in direct sunlight. Only use a mild car wash detergent, such as Mercedes-Benz ap- proved Car Shampoo. Thoroughly spray the vehicle with a dif- fused jet of water. Direct only a very weak spray towards the ventilation intake.
Page 336 1 Parktronic system sensors Clean the sensors 1 on the bumpers using a mild car wash detergent, such as Mercedes-Benz approved Car Sham- poo, with plenty of water and a soft, non-scratchy cloth. When using a steam cleaner or power...
Page 337 Operation Vehicle care Warning! For safety reasons, switch off wipers and re- move SmartKey from starter switch (vehi- cles with KEYLESS-GO*: Make sure the vehicle’s on-board electronics have status 0) before cleaning the wiper blades. Otherwise, the wiper motor could suddenly turn on and cause injury.
Page 338 If possible, clean wheels once a week with Mercedes-Benz approved Wheel Care, us- ing a soft bristle brush and a strong spray of water. Follow the instructions on container.
Page 339 Leather upholstery Wipe leather upholstery with a damp cloth and dry thoroughly or clean with Mercedes-Benz approved Leather Care. Exercise particular care when cleaning per- forated leather as its underside should not become wet. Plastic and rubber parts Do not use oil or wax on these parts.
Page 340: Practical Hints
Practical hints What to do if …? Where will I find ...? Unlocking/locking in an emergency Opening/closing in an emergency Replacing SmartKey batteries Replacing bulbs Replacing wiper blades Flat tire Battery Jump starting Towing the vehicle Fuses...
Page 341: What To Do If
Read and observe messages in the mul- tifunction display ( page 353). Have the system checked at an autho- rized Mercedes-Benz Center as soon as possible. Failure to follow these instructions increas- es the risk of an accident.
Page 342 Practical hints What to do if …? Suggested solution Release the parking brake ( page 48). Risk of accident! Carefully stop the vehicle and notify an authorized Mercedes-Benz Center. Do not add brake fluid! This will not solve the problem.
Page 343 Your fuel tank is empty. Suggested solution Have the vehicle checked as soon as possible by an authorized Mercedes-Benz Center. An on-board diagnostic connector is used by the service station to link the vehicle to the shop diagnostics system. It allows the accurate identification of system malfunctions through the read- out of diagnostic trouble codes.
Page 344 Check the fuel cap ( page 284). If it is not closed properly: Close the fuel cap. If it is closed properly: Have the fuel system checked by an au- thorized Mercedes-Benz Center. Refuel at the next gas station ( page 284).
Page 345 Practical hints What to do if …? Problem Only vehicles with Distronic*: The red distance warning lamp comes on while driving. Only vehicles with Distronic*: The red distance warning lamp comes on while driving and you hear a warning sound. ®...
Page 346 Adapt your speed and driving to the pre- vailing road and weather conditions. ® If the ESP cannot be switched back on, have the system checked at an authorized Mercedes-Benz Center as soon as possible. Fasten your seat belt. The warning lamp goes out.
Page 347 Practical hints What to do if …? Problem The yellow warning lamp for the tire inflation pressure monitor comes on. Warning! When the tire inflation pressure monitoring system warning light is lit, one or more of your tires is significantly under-inflated. You should stop and check your tires as soon as possible, and inflate them to the proper pressure as indicated on the vehicle’s tire in-...
Page 348 SRS may not be operational. For your safety, we strongly recommend that you visit an authorized Mercedes-Benz Center immediately to have the system checked; otherwise the SRS may not be activated when needed in an acci-...
Page 349: Lamp In Center Console
The system is malfunctioning. The system is malfunctioning. Suggested solution Have the system checked as soon as possible by an authorized Mercedes-Benz Center. Make sure there is nothing between seat cushion and child seat and check installation of the child seat.
Page 350: Vehicle Status Messages In The Multifunction Display
Mercedes-Benz Center. Failure to repair condition noted may cause damage not covered by the Mercedes-Benz Limited Warranty, or result in property dam- age or personal injury. Warning!
Page 351 Practical hints What to do if …? Switching on the ignition causes all in- strument cluster lamps (except high beam headlamp indicator lamp and turn signal indicator lamps unless acti- vated) as well as the multifunction dis- play to come on. Make sure the lamps and multifunction display are in work- ing order before starting your journey.
Page 352 What to do if …? Possible solution Do not exceed a speed of 50 mph (80 km/h). Visit an authorized Mercedes-Benz Center as soon as possible. Stop your vehicle as soon as it is safe to do Press the vehicle level control button to se- lect level 2 ( page 233).
Page 353 Listen for scraping noises. Do not exceed a speed of 50 mph (80 km/h). Visit an authorized Mercedes-Benz Center as soon as possible. Visit an authorized Mercedes-Benz Center as soon as possible. Do not exceed a speed of 50 mph (80 km/h).
Page 354 BAS are may lock during hard braking, reducing steer- ing capability. Have the system checked at an authorized Mercedes-Benz Center as soon as possible. Failure to follow these instructions increases the risk of an accident. Continue driving with added caution. Wheels may lock during hard braking, reducing steer- ing capability.
Page 355 Possible solution Have the air filter checked by an authorized Mercedes-Benz Center. Try activating Distronic* again later. Clean the Distronic* cover in the radiator grille ( page 335). Restart the vehicle. Visit an authorized Mercedes-Benz Center as soon as possible.
Page 356 What to do if …? Continue driving with added caution. Have the system checked at an authorized Mercedes-Benz Center as soon as possible. Continue driving with added caution. Have the system checked at an authorized Mercedes-Benz Center as soon as possible.
Page 357 ESP ® If the ESP message does not go out: Continue driving with added caution. Have the system checked at an authorized Mercedes-Benz Center as soon as possible. Failure to follow these instructions increases the risk of an accident. ®...
Page 358 Possible solution Place the gear selector lever in position P. ® malfunction messages are Visit an authorized Mercedes-Benz Center as ® soon as possible. ® itself has failed. All other occu- Visit an authorized Mercedes-Benz Center as soon as possible.
Page 359 Listen for scraping noises. Do not exceed a speed of 50 mph (80 km/h). Visit an authorized Mercedes-Benz Center as soon as possible. Do not exceed a speed of 50 mph (80 km/h). Visit an authorized Mercedes-Benz...
Page 360 50 mph (80 km/h) and 75 mph (120 km/h) for more than five minutes. Practical hints What to do if …? Possible solution Visit an authorized Mercedes-Benz Center as soon as possible. Press the vehicle level control button to adjust the vehicle level ( page 230).
Page 361 Notify an authorized Mercedes-Benz Center. If it is intact: Drive immediately to the nearest autho- rized Mercedes-Benz Center. Adjust driv- ing to be consistent with reduced braking responsiveness. Release the parking brake ( page 48).
Page 362 Possible solution Have the brake pads replaced as soon as possible. Risk of accident! Stop the vehicle and no- tify an authorized Mercedes-Benz Center. Do not add brake fluid! This will not solve the problem. Failure to follow these instructions increases the risk of accident.
Page 363 Do not ignore the low engine coolant level warning. Extended driving with the message and symbol displayed may cause serious engine damage not covered by the Mercedes-Benz Limited Warranty. Do not drive without a sufficient amount of coolant in the cooling sys- tem.
Page 364 The engine should not be operated with the coolant temperature above 248°F (120°C). Doing so may cause serious engine damage which is not covered by the Mercedes-Benz Limited Warranty. Practical hints What to do if …? Possible solution Stop the vehicle and turn off the engine.
Page 365 Mercedes-Benz Limited Warranty. Observe the coolant temperature gauge in the instrument cluster ( page 24). Drive immediately to the nearest autho- rized Mercedes-Benz Center. Adjust driv- ing to be consistent with reduced braking responsiveness.
Page 366 Observe the coolant temperature display. Have the fan replaced as soon as possi- ble. Have cruise control or Distronic* checked by an authorized Mercedes-Benz Center. Continue driving with added caution. Visit an authorized Mercedes-Benz Cen- ter as soon as possible.
Page 367 Practical hints What to do if …? Display ADD 1.0 QT. OIL AT FILLING STATION (Canada: 1.0 LITER ENGINE OIL LEVEL STOP, ENGINE OFF ENGINE OIL LEVEL REDUCE OIL LEVEL Possible cause The engine oil level is too low. There is no oil in the engine. You have added too much engine oil.
Page 368 Have the measuring system checked by an authorized Mercedes-Benz Center. The engine oil level warnings should not be ignored. Extended driving with the symbol displayed could result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty.
Page 369 The message will disappear. Close the hood ( page 288). Remove the SmartKey from the starter switch. Visit an authorized Mercedes-Benz Cen- ter as soon as possible. Remove the SmartKey from the starter switch. Replace the battery ( page 392).
Page 370 Operate the vehicle with the SmartKey in the starter switch if necessary. Take the SmartKey with KEYLESS-GO* out of the vehicle. Visit an authorized Mercedes-Benz Cen- ter as soon as possible. Visit an authorized Mercedes-Benz Cen- ter as soon as possible.
Page 371 The lamp sensor is malfunctioning. The headlamps switch on automatically. Possible solution Visit an authorized Mercedes-Benz Cen- ter as soon as possible. Visit an authorized Mercedes-Benz Cen- ter as soon as possible. Replace the bulb as soon as possible.
Page 372 Practical hints What to do if …? Possible solution Replace the bulb as soon as possible. Bi-Xenon* headlamp: Visit an authorized Mercedes-Benz Center as soon as possible. Halogen headlamp: Replace the bulb as soon as possible. Bi-Xenon* headlamp: Visit an authorized Mercedes-Benz Center as soon as possible.
Page 373 Practical hints What to do if …? Display STANDING LIGHT, L CHECK LIGHT STANDING LIGHT, R CHECK LIGHT STANDING LIGHT, L CHECK LIGHT SUBSTITUTE LAMP ON STANDING LIGHT, R CHECK LIGHT SUBSTITUTE LAMP ON TAIL LIGHT, LEFT CHECK LIGHT SUBSTITUTE LAMP ON TAIL LIGHT, RIGHT CHECK LIGHT SUBSTITUTE LAMP ON...
Page 374 Replace the bulb as soon as possible. Replace the bulb as soon as possible. Replace the bulb as soon as possible. Visit an authorized Mercedes-Benz Cen- ter as soon as possible. Visit an authorized Mercedes-Benz Cen- ter as soon as possible.
Page 375 This display appears if button t or s on the multifunction steering wheel is pressed and the vehicle is not equipped with a telephone. Possible solution Visit an authorized Mercedes-Benz Center as soon as possible. Close the tilt/sliding sunroof ( page 212). Close the tilt/sliding sunroof ( page 212).
Page 376 Check the fuel cap ( page 284). If it is not closed properly: Close the fuel cap. If it is closed properly: Have the fuel system checked by an au- thorized Mercedes-Benz Center. Close the trunk lid. Add washer fluid ( page 296).
Page 377 Practical hints What to do if …? Tire inflation pressure monitor messages Display TIRE PRES. MONITOR REACTIVE AFTER CORRECTING PRESSURE TIRE PRESSURE DISPLAY ONLY AVAILABLE WHEN IGNITION IS ON TIRE PRES. MONITOR REACTIVATED Warning! Do not drive with a flat tire. A flat tire affects the ability to steer or brake the vehicle.
Page 378 Remove any extra wheel sensors from the ve- hicle. As soon as the causes of the malfunction have been removed, the tire inflation pressure moni- tor automatically becomes active again. Have the tire inflation pressure monitor checked by an authorized Mercedes-Benz Center. Have the wheels checked.
Page 379 Carefully bring the vehicle to a halt, avoid- ing abrupt steering and braking maneu- vers. Observe the traffic situation around you. Change the damaged wheel ( page 403). Have the damaged wheel repaired or re- placed at an authorized Mercedes-Benz Center.
Page 380 Observe the traffic situation around you. Check the tires. If no damage visible, check and correct tire inflation pressure as required. Change the damaged wheel ( page 403). Have the damaged wheel repaired or re- placed at an authorized Mercedes-Benz Center.
Page 381 Observe the traffic situation around you. Change the wheel ( page 403). Have the damaged wheel repaired or re- placed at an authorized Mercedes-Benz Center. Carefully bring the vehicle to a halt. Check the tires. If no damage visible, check and correct tire inflation pressure as required ( page 308).
Page 382 Observe the traffic situation around you. Change the wheel ( page 403). Have the damaged wheel repaired or re- placed at an authorized Mercedes-Benz Center. Carefully bring the vehicle to a halt. Check the tires. If no damage visible, check and correct tire inflation pressure as required ( page 308).
Page 383 Observe the traffic situation around you. Change the wheel ( page 403). Have the damaged wheel repaired or re- placed at an authorized Mercedes-Benz Center. Carefully bring the vehicle to a halt. Check the tires. If no damage visible, check and correct tire inflation pressure as required ( page 308).
Page 384 Observe the traffic situation around you. Change the wheel ( page 403). Have the damaged wheel repaired or re- placed at an authorized Mercedes-Benz Center. Carefully bring the vehicle to a halt. Check the tires. If no damage visible, check and correct tire inflation pressure as required ( page 308).
Page 385: Where Will I Find
Practical hints Where will I find ...? First aid kit The first aid kit is located in the storage compartment under the front passenger seat. 1 Lid 2 Buttons Removing the first aid kit Press buttons 2 together and fold lid 1 down.
Page 386 To prevent damage, always disengage trunk floor handle from trunk lid and lower trunk floor before closing the trunk lid. The vehicle tool kit includes: One interchangeable slot/Phillips screwdriver One towing eye bolt One wheel bolt wrench with socket wrench One alignment bolt One pair of gloves One fuse extractor...
Page 387 Practical hints Where will I find ...? Warning! The jack is designed exclusively for jacking up the vehicle at the jack take-up brackets built into both sides of the vehicle. To help avoid personal injury, use the jack only to lift the vehicle during a wheel change.
Page 388 Spare wheel S 55 AMG, S 65 AMG and vehicles with Sport Package* In case of a flat tire, you may temporarily use the spare wheel when observing the following restrictions: Do not exceed a vehicle speed of 50 mph (80 km/h). Drive to the nearest tire repair facility to have the flat tire repaired or re- placed as appropriate.
Page 389: Unlocking/Locking In An Emergency
Practical hints Unlocking/locking in an emergency Unlocking the vehicle If you are unable to unlock the vehicle with the SmartKey or KEYLESS-GO*, open the driver’s door and the trunk using the me- chanical key. Unlocking the driver’s door and/or the trunk with the mechanical key will trig- ger the anti-theft alarm system.
Page 390: Locking The Vehicle
Unlocking the trunk A minimum height clearance of 6 ft. (1.85 m) is required to open the trunk lid. The trunk lid lock is located next to the handle above the rear license plate recess. 1 Unlocking and opening Insert the mechanical key into the trunk lid lock until it stops.
Page 391: Fuel Filler Flap
Practical hints Unlocking/locking in an emergency Fuel filler flap In case the central locking system does not release the fuel filler flap, you can open it manually. 1 Release knob Open the trunk. Remove the trim inside the trunk on the right-hand side.
Page 392: Opening/Closing In An Emergency
Opening/closing in an emergency Tilt/sliding sunroof You can open or close the tilt/sliding sun- roof manually should an electrical malfunc- tion occur. The tilt/sliding sunroof drive is located be- hind the lens of the interior overhead light. 1 Lens Pry off lens 1 using a flat blade screw- driver ( page 384).
Page 393: Replacing Smartkey Batteries
SmartKey with KEYLESS-GO* are dis- charged, the vehicle can no longer be locked or unlocked. It is recommended to have the batteries replaced at an autho- rized Mercedes-Benz Center. Warning! Batteries contain poisonous and corrosive substances. Therefore keep the batteries out of reach of children.
Page 394: Smartkey With Keyless-Go
4 Battery 5 Contact spring Remove the batteries 4 in the direc- tion of arrow. Using a lint-free cloth, insert new batteries 4 under the contact spring 5 with the positive terminal (+) side facing up. Return battery compartment 3 ( page 392) into housing until it locks into place.
Page 395: Replacing Bulbs
Have headlamps checked and readjusted at regular intervals and when a bulb has been replaced. See an authorized Mercedes-Benz Center for headlamp ad- justment. If the headlamps or front fog lamps are fogged up on the inside as a result of...
Page 396: Bulbs
H7-55 W High beam flasher Vehicles with Bi-Xenon headlamps*: Low beam and high beam use the same D2S-35W lamp. Do not replace the Bi-Xenon bulbs yourself. See an au- thorized Mercedes-Benz Center. Practical hints Replacing bulbs Rear lamps Lamp Type...
Page 397 Your hands should be dry and free of oil and grease. If the newly installed bulb does not come on, visit an authorized Mercedes-Benz Center. Have the LEDs and bulbs for the following lamps replaced by an authorized Mercedes-Benz Center.
Page 398: Replacing Bulbs For Front Lamps
Replacing bulbs for front lamps Before you start to replace a bulb for a front lamp, do the following first: Turn the exterior lamp switch to M ( page 50). Open the hood ( page 287) (except for side marker lamps). 1 Headlamp cover for fog lamp 2 Headlamp cover for high beam halogen headlamp bulb, parking and standing...
Page 399 Practical hints Replacing bulbs Halogen headlamp Press the tab on cover 3 and remove cover. Pull connector 7 off of the lamp. Release the retaining springs and take out the bulb. Insert the new bulb in the socket so that the base is in the recess on the lower left.
Page 400: Replacing Bulbs For Rear Lamps
Parking and standing lamp bulb Press the tab on cover 2 and remove cover. Pull out the bulb socket 5 with the bulb. Pull the bulb out of the bulb socket 5. Insert a new bulb in the bulb socket 5. Reinstall the bulb socket 5.
Page 401 Practical hints Replacing bulbs Tail lamp unit Passenger side 1 Black socket: Backup lamp 2 Red socket: Driver’s side: Tail, parking and rear fog lamp Passenger side: Tail and parking lamp 3 Red socket: Tail, standing and parking lamp 4 White socket: Turn signal lamp Driver’s side: Turn the locking knob and move the trim to the side.
Page 402: Replacing Wiper Blades
Replacing wiper blades To avoid damage to the hood, the wiper arms should only be folded forward when in the vertical position. Wiper blades in vertical position Removing wiper blades Turn SmartKey in starter switch position 1. Turn combination switch to wiper setting II ( page 52).
Page 403: Installing Wiper Blades
Make certain that the wiper blades are properly installed. Improperly installed wiper blades may cause windshield damage. For your convenience, we recommend that you have this work carried out by an authorized Mercedes-Benz Center.
Page 404: Flat Tire
Flat tire Preparing the vehicle Park the vehicle as far as possible from moving traffic on a hard surface. Turn on the hazard warning flashers. Turn the steering wheel so that the front wheels are in a straight ahead position. Set the parking brake.
Page 405 Practical hints Flat tire Preparing the vehicle Take vehicle tool kit tray and vehicle jack out of trunk. Take the spare wheel out of wheel well ( page 384). Lifting the vehicle Prevent the vehicle from rolling away by blocking wheels with wheel chocks (not included) or other sizeable ob- jects.
Page 406 Take the two-piece wheel wrench out of the vehicle tool kit tray. Assemble wheel wrench. On wheel to be changed, loosen but do not yet remove the wheel bolts (ap- proximately one full turn with wrench). The tube openings are located directly be- hind the front wheel housings and in front of the rear wheel housings.
Page 407 Damaged wheel hub threads should be re- paired immediately. Do not continue to drive under these circumstances! Contact an au- thorized Mercedes-Benz Center or call Roadside Assistance. Incorrect wheel bolts or improperly tight- ened wheel bolts can cause the wheel to come off.
Page 408 Unscrew the alignment bolt, install last wheel bolt and tighten slightly. Warning! Use only genuine equipment Mercedes-Benz wheel bolts. Other wheel bolts may come loose. Do not tighten the wheel bolts when the ve- hicle is raised. Otherwise the vehicle could fall off the jack.
Page 409: Battery
Have the battery checked regularly by an authorized Mercedes-Benz Center. Refer to Maintenance Booklet for main- tenance intervals or contact an autho- rized Mercedes-Benz Center for further information. Warning! With a disconnected battery you will no longer be able to turn the...
Page 410: Disconnecting The Battery
Warning! Never charge a battery while still installed in the vehicle unless the accessory battery charge unit approved by Mercedes-Benz is being used. Gases may escape during charg- ing and cause explosions that may result in paint damage, corrosion or personal injury.
Page 411: Reconnecting The Battery
Practical hints Battery Reconnecting the battery Turn off all electrical consumers. Connect the positive lead and fasten its cover 2. Connect negative lead 3. Never invert the terminal connections. The battery, its filler caps and the vent tube must always be securely installed when the vehicle is in operation.
Page 412: Jump Starting
Only use 12-volt battery to jump start your vehicle. Jump starting with a more powerful battery could damage the ve- hicle’s electrical system, which will not be covered by the Mercedes-Benz Lim- ited Warranty. Only use jumper cables with sufficient cross-section and insulated terminal clamps.
Page 413 Do not turn on the lights under any circumstances. Remove the jumper cables first from negative terminals 2 and 4 and then from positive terminals 1 and 3. You can now turn on the lights. Have the battery checked at the near- est authorized Mercedes-Benz Center.
Page 414: Towing The Vehicle
Towing the vehicle Mercedes-Benz recommends that the vehi- cle be transported with all wheels off the ground using flatbed or appropriate wheel lift/dolly equipment. This method is pref- erable to other types of towing. Use flatbed or wheel lift/dolly equip- ment with SmartKey in starter switch turned to position 0.
Page 415 Practical hints Towing the vehicle To be certain to avoid a possibility of damage to the drivetrain, however, we recommend the drive shaft be discon- nected at the rear axle drive flange (ve- hicles with 4MATIC: disconnected at the front and rear axle drive flanges) for any towing beyond a short tow to a nearby garage.
Page 416: Installing Towing Eye Bolt
When towing the vehicle with all wheels on the ground, please note the follow- ing: With the automatic central locking acti- vated and the SmartKey in starter switch position 2, or KEYLESS-GO* start/stop button ( page 35) in position 2, the vehicle doors lock if the left front wheel as well as the right rear wheel are turning at vehicle speeds of approximately 9 mph (15 km/h) or...
Page 417: Fuses
Fuse chart Spare fuses Special fuse extractor Warning! Only use fuses approved by Mercedes-Benz and which have the specified amperage. Us- ing other fuses may cause an overload and lead to a fire, or cause damage to electrical components and/or systems.
Page 418: Fuse Boxes In Passenger Compartment
Fuse boxes in passenger compartment There are two fuse boxes in the in passen- ger compartment. One fuse box is located in the dashboard. An additional fuse box is located in the rear passenger compart- ment. Fuse box in dashboard The fuse box is located in the dashboard on the front passenger side.
Page 419: Fuse Boxes In Engine Compartment
Practical hints Fuses Fuse boxes in engine compartment There are three fuse boxes located in the engine compartment in front of the firewall (dividing wall between engine compart- ment and passenger compartment): one box on the driver’s side two boxes on the front passenger side Fuse box, driver’s side 1 Cover 2 Slide...
Page 420: Technical Data
Technical data Parts service Warranty coverage Identification labels Layout of poly-V-belt drive Engine Rims and tires Electrical system Main dimensions and weights Fuels, coolants, lubricants, etc.
Page 421: Parts Service
The “Technical data” section provides the necessary technical data for your vehicle. All authorized Mercedes-Benz Centers maintain a stock of genuine Mercedes-Benz parts required for mainte- nance and repair work. In addition, strate- gically located parts distribution centers provide quick and reliable parts service.
Page 422: Warranty Coverage
Emission System Warranty Emission Performance Warranty California, Maine, Massachusetts, and Vermont Emission Control Systems Warranty Replacement parts and accessories are covered by the Mercedes-Benz Parts and Accessories warranties, copies of which are available at any authorized Mercedes-Benz Center. Technical data Warranty coverage...
Page 423: Identification Labels
Technical data Identification labels 1 Certification label (below driver’s door latch) 2 Vehicle Identification Number (VIN) (below right rear passenger seat) 3 Engine number (engraved on engine) 4 VIN, visible (lower edge of windshield) 5 Emission control information label, includes both federal and California certification exhaust emission standards 6 Vacuum line routing diagram label...
Page 424: Layout Of Poly-V-Belt Drive
Layout of poly-V-belt drive S 350/S 430/S 430 4MATIC/S 500/ S 500 4MATIC 1 Automatic belt tensioner 2 ABC tandem pump (pump for power-steering assistance and ABC chassis) 3 Air conditioning compressor 4 Crankshaft 5 Coolant pump 6 Generator (alternator) 7 Idler pulley S 55 AMG The S 55 AMG has two poly-V-belts (belt one...
Page 425: Engine
Poly-V-belt 2380 mm The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies and special equipment. Premium fuel required. Performance may vary with fuel octane rating. S 430 (220.070, 220.170) S 430 4MATIC (220.183)
Page 426 Belt one: 1289 mm Belt two: 2462 mm The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies and special equipment. Premium fuel required. Performance may vary with fuel octane rating.
Page 427: Rims And Tires
ABS or ® . Tires specially developed for your vehicle and tested and approved by Mercedes-Benz can be identified by finding the following on the tire’s side- wall: MO = Mercedes-Benz Original equipment tires...
Page 428 See an authorized Mercedes-Benz Center for more infor- mation.
Page 429: Same Size Tires
All-season tires 225/55 R17 97H M+S 2, 3 Winter tires 225/55 R17 97H M+S. For use with snow chains contact an authorized Mercedes-Benz Center. Radial-ply tires For more information, see “Winter tires” ( page 327). S 600 (without Sport Package*...
Page 430 245/45 R18 100V XL (Extra Load) M+S. 245/45 R18 96H M+S. For use with winter tires only. For use with snow chains contact an authorized Mercedes-Benz Center. Must not be used with snow chains. Radial-ply tires For more information, see “Winter tires” ( page 327).
Page 431: Mixed Size Tires
Technical data Rims and tires Mixed size tires S 430, S 500, S 600 ( with Sport Package*) Front axle: AMG light alloy rims 8.5 J x 18 EH2 Wheel offset 1.73 in (44 mm) Summer tires 245/45 R18 100Y XL (Extra Load) 245/45 R18 96Y Rear axle:...
Page 432: Spare Wheel
Spare wheel S 350 S 430, S 430 4MATIC, S 500, S 500 4MATIC (without Sport Package*) Rims (light alloy) 7.5 J x 17 H2 Wheel offset 2.0 in (51 mm) Summer tires All-season tires 225/55 R17 97H M+S Radial-ply tires S 430, S 430 4MATIC, S 500, S 65 AMG S 500 4MATIC (with Sport...
Page 433: Electrical System
Technical data Electrical system Model S 350 S 430, S 430 4MATIC, S 500, S 500 4MATIC Generator (alternator) 14 V/150 A Starter motor 12 V/1.7 kW Battery 12 V/95 Ah Spark plugs Bosch F 8 DPP 332 NGK PFR 5 R-11 Electrode gap 0.039 in (1.0 mm) Tightening torque...
Page 434: Main Dimensions And Weights
Main dimensions and weights Main dimensions Model S 350 (220.067) S 430 (220.070) Overall vehicle length 198.3 in (5038 mm) Overall vehicle width 73.0 in (1855 mm) Overall vehicle height 57.2 in (1454 mm) Wheelbase 116.7 in (2965 mm) Track, front 62.0 in (1574 mm) Track, rear 62.0 in (1574 mm)
Page 435: Fuels, Coolants, Lubricants, Etc
2.1 US qt. (2.0 l) 0.63 US qt. (0.6 l) Please refer to the Factory Approved Ser- vice Products pamphlet, or inquire at your Mercedes-Benz Center. Fuels, coolants, lubricants, etc. Approved engine oils MB Automatic Transmission Fluid Hypoid gear oil SAE 85 W 90...
Page 436 Model Transfer case S 430 4MATIC S 500 4MATIC Hydraulic system for ADS or ABC All models Power steering All models Front wheel hubs All models Brake system All models Cooling system S 350 S 430, S 430 4MATIC S 500, S 500 4MATIC S 55 AMG S 600 S 65 AMG...
Page 437 Technical data Fuels, coolants, lubricants, etc. Model Fuel tank All models including a reserve of All models except S 55 AMG, S 65 AMG including a reserve of S 55 AMG, S 65 AMG Air conditioning system All models Windshield washer S 350 S 430, S 430 4MATIC Windshield washer and...
Page 438: Engine Oils
Therefore, the brake fluid must be replaced every two years, preferably in the spring. Only brake fluid approved by Mercedes-Benz is recommended. Your au- thorized Mercedes-Benz Center will pro- vide you with additional information.
Page 439: Premium Unleaded Gasoline
Technical data Fuels, coolants, lubricants, etc. Premium unleaded gasoline Warning! Gasoline is highly flammable and poisonous. It burns violently and can cause serious injury. Whenever you are around gasoline, avoid inhaling fumes and skin contact, extin- guish all smoking materials. Never allow sparks, flame or smoking materials near gasoline! To maintain the engine’s durability and...
Page 440: Gasoline Additives
Mercedes-Benz vehicles listed in the Fac- tory Approved Service Products Pamphlet are not covered by the Mercedes-Benz Limited Warranty.
Page 441 The replacement interval published in the Maintenance Booklet is only applicable if MB 325.0 anticorrosion/antifreeze solu- tion or other Mercedes-Benz approved products of equal specification (see Factory Approved Service Products pam- phlet) are used to renew the coolant con- centration or bring it back up to the proper level.
Page 442 Anticorrosion/antifreeze quantity Model S 350 S 430, S 430 4MATIC S 500, S 500 4MATIC S 600 (main cooling system) S 600 (low temperature cooling system) S 55 AMG S 65 AMG (main cooling system) S 65 AMG (low temperature cooling system) Approx.
Page 443: Windshield And Headlamp Washer System
Technical data Fuels, coolants, lubricants, etc. Windshield and headlamp washer system Both the windshield and headlamp washer systems are supplied from the windshield washer fluid reservoir. The washer fluid reservoir has a capacity of approximately: 3.2 US qt. (3.0 l) in vehicles without headlamp cleaning system* 7.4 US qt.
Page 444: Technical Terms
The sensor system for the front pas- senger seat prevents deployment of the passenger front air bag if a BabySmart compatible child seat is installed. See an authorized Mercedes-Benz Center for availability. ( page 323) BabySmart is a trademark of Siemens Automo- tive Corp.
Page 445 Bi-xenon headlamps produce low beam and high beam. (Customer Assistance Center) Mercedes-Benz customer service cen- ter, which can help you with any ques- tions about your vehicle and provide assistance in the event of a break- down.
Page 446 Distronic* A driving convenience cruise control system which helps the driver maintain a pre-selected speed: If there is no vehicle directly ahead, the system operates in the same way as conventional ->cruise con- trol. If a slower moving vehicle is ahead, Distronic will reduce your vehicle speed to the extent permitted by re- duced throttle and up to 20% brak-...
Page 447 Technical terms (Global Positioning System) Satellite-based system for relaying geographic location information to and from vehicles equipped with special re- ceivers. Employs DVD digital maps for navigation. (Gross Vehicle Weight) ( page 323) GVWR (Gross Vehicle Weight Rating) ( page 324) Instrument cluster The displays and indicator/warning lamps in the driver’s field of vision, in-...
Page 448 Engine speeds within the red marking of the tachometer dial. Avoid this en- gine speed range, as it may result in se- rious engine damage that is not covered by the Mercedes-Benz Limited Warranty. Parktronic system (Parking assist)* System which uses visual and acoustic signals to assist the driver during park- ing maneuvers.
Page 449 Technical terms Program mode selector switch Used to switch the automatic transmis- sion between standard operation S and comfort operation C. S55 AMG and S65 AMG with steering wheel gearshift control and manual shift program: in addition to S and C (see above), you can use M for manual operation.
Page 450 Telematics* A combination of the terms “telecom- munications” and “informatics.” Tightening torque Force times lever arm (e.g. a lug wrench) with which threaded fasteners such as wheel bolts are tightened. (Tire Identification Number) ( page 325) Tire load rating ( page 325) Tire ply composition and material used ( page 325) Tire speed rating...
Page 452: Index
ABC 232, 443 Messages in display 351 Setting vehicle level 230, 233 ABS 25, 79, 443 Malfunction indicator lamp 340 Messages in display 353 Warning lamp 340 Accelerator position, automatic transmission 177 Accessory weight 323 Accident In case of 54 Activating Air conditioner (cooling) 202 Air conditioning 202...
Page 453 Index ADS 229, 443 Air bag off indicator lamp 348 Air bags 61 BabySmart air bag deactivation system 73, 443 Children 62 Front 65 Passenger 65 Safety guidelines 64 Side impact 66 Window curtain 66 Air conditioning Turning off 202 Turning on 202 Air pressure 323 Air pressure see Tire inflation pressure...
Page 454 Automatic headlamp mode 132 Automatic lighting control Activating 137 Deactivating 137 Automatic locking when driving 112 Automatic shift program Automatic transmission 179 Automatic transmission 173 Accelerator position 177 Automatic shift program 179 Emergency operation (Limp Home Mode) 185 Fluid level 293 Gear ranges 178 Gear selector lever position 173, 175 Gear shifting malfunctions 185...
Page 455 Index Bulbs, replacing 394 Additional turn signals 395 Backup lamps 395 Brake lamps 395 Fog lamps 395 Front lamps 395 High beam 395 High mounted brake lamp 395 License plate lamps 395, 400 Low beam 395 Parking and standing lamps 395 Parking lamps 395, 399 Rear fog lamp 395, 400 Rear fog lamps 399...
Page 456 Cleaning Cup holder 337 Distronic* system sensor cover 335 Engine 334 Gear selector lever 337 Hard plastic trim items 337 Headlamps 186 Headliner and shelf below rear window 337 Instrument cluster 337 Leather upholstery 338 Light alloy wheels 337 Ornamental moldings 334 Paintwork 333 Parktronic* system sensor 335 Plastic and rubber parts 338...
Page 457 Index Convenience submenu 169 Activating easy-entry/exit feature 170 Adjusting drive-dynamic seat* 171 Setting key-dependency 169 Setting parking position for exterior rear view mirror 170, 172 Coolant 294 Adding 294 Checking level 294 Messages in display 362, 363 Temperature 283 Temperature gauge 141 Warning lamp 363 Coolant level Checking 294...
Page 458 Dialing A number (telephone) 154 Difficulties While driving see Problems while driving 54 Digital clock 25 Digital speedometer 148 Direction of rotation (tires) 300 Discharged battery Jump starting 411 Disconnecting Vehicle battery 409 Displays Digital speedometer 148 Distronic* 220 Messages 290 Service indicator 329 Showing malfunctions 159 Vehicle status messages 349...
Page 459 Index Driving Abroad 281 General instructions 43, 273 Hydroplaning 277 In winter 279 Problems 54 Safety systems 79 Through standing water 280 With Distronic* 227 Driving abroad 281 Driving instructions 273 Driving off 276 Driving safety systems 4MATIC 84 ABS 79 BAS 80 ®...
Page 460 Viscosity 445 Engine oil level see Oil level 286 Entry position Messages in display 368 ® 81, 445 Four wheel electronic traction system ® with ESP Switching off 82 Switching on 83 Synchronizing 356 Warning lamp 344, 345 ETD 445 Safety guidelines 64 ETD (Emergency tensioning device) 69 Exterior lamp switch 131...
Page 461 Index Fuel tank Filler flap 284 Fuels, coolants, lubricants etc. 434 Functions (control system) 145, 147 Resetting 161 Fuse box 417, 418 Fuse chart 385 Fuses 416 Auxiliary fuse box in trunk 417 Fuse box in engine compartment 418 Fuse box in passenger compartment 417 Fuse chart 385 Fuse extractor 385...
Page 462 Height adjustments Vehicle level 230, 233 High beam 50 Replacing bulbs 395 High beam flasher 135 High beam headlamps Messages in display 370 Switching on 135 High mounted brake lamp 395 High-performance brake system (S 65 AMG only) 275 Hood 287 Closing 288 Message in display 368 Opening 287...
Page 463 Index Key see SmartKey 57, 58 Key, mechanical 388 Key, SmartKey Checking the batteries 95 Locking 58 Key-dependency memory Settings 169 KEYLESS-GO* 446 Activating ignition with 36 Locking 58 Locking the vehicle 101 Loss of SmartKey with KEYLESS-GO 102 Messages in display 368 Starting the engine 47 Turning off engine 57 Kickdown 177, 446...
Page 464 Lighter see Cigarette lighter 250 Lighting 131 Automatic headlamp mode 132 Combination switch 135 Courtesy lighting 139 Daytime running lamp mode 133 Door entry lamps 139 Exterior lamp switch 131 Front fog lamps 134 High beam flasher 135 High beams 135 Instrument cluster illumination 140 Interior 137 Locator lighting 133...
Page 465 Index Maintenance System (U.S. vehicles) 446 Manual headlamp mode 132 Manual operations Closing the power tilt/sliding sunroof 391 Fuel filler flap 390 Interior lighting control 137 Locking the vehicle 389 Opening the power tilt/sliding sunroof 391 Power tilt/sliding sunroof 391 Unlocking the driver’s door 388 Manual shift program S 55 AMG and S 65 AMG...
Page 466 Mph or km/h in speedometer 163 Multicontour backrest* 122 Multifunction display 143, 447 Selecting language 164 Standard display 147 Multifunction display messages ABC 351 ABS 353 Airmatic 358 Brake fluid 361 Brake pads 361 Check engine 342, 343 Coolant 363 Coolant level 362 Distronic* 354 Doors 365...
Page 467 Index One-touch gearshifting 180 Canceling gear range limit 180 Downshifting 180 Upshifting 180 Opening Ashtray 249 Cup holder 249 Doors from the inside 102 Fuel filler flap 284 Fuel filler flap manually 390 Glove box 243 Hood 287 Power tilt/sliding sunroof 212 Power windows 208 Side windows 209 Storage compartment in the center...
Page 468 Parking position Exterior rear view mirrors 130, 170, 172, 187 Parktronic system* 235, 447 Parktronic* Cleaning sensors 335 Malfunctioning 238 Warning indicators 236 Parts service 420 Passenger compartment 281 Fuse box in 417 Interior lighting 137 Interior rear view mirror 41 Parcel net in front passenger footwell 247 Passenger safety see Occupant...
Page 469 Index ® PRE-SAFE ® PRE-SAFE see Preventive occupant safety 70 Preventive occupant safety ® (PRE-SAFE ) 70 Problems While driving 54 With vehicle 17 Product information 9 Production options weight 324 Program mode selector switch 448 Proper use of the vehicle 16 PSI 324 PULSE function (Massage function) 123 Quick search...
Page 470 Reinstalling vehicle battery 409 Remote control SmartKey 92 SmartKey with KEYLESS-GO* 96 Remote controls Integrated 265 Remote door unlock With Tele Aid 261 Removing Vehicle battery 409 Wheel 406 Wiper blades 401 Replacing Backup lamp bulbs 399 Battery (SmartKey with KEYLESS-GO*) 393 Brake fluid 437 Brake lamp bulbs 399...
Page 471 Index Seat ventilation* Switching off 127 Switching on 127 Seating capacity 302 Seats 114 Adjusting 37 Adjusting lumbar support 123 Adjusting shoulder support 123 Easy entry/exit feature 114 Heater 125 Massage function 123 Multicontour backrest* 122 Rear power seat bench* 117 Rear seats 117 Securing cargo Cargo tie-down hooks 240...
Page 472 Setting front passenger seat position from rear* 118 Settings Calling up Distronic* 156, 221 Convenience functions 169 Factory, SmartKey 94 Individual (SmartKey) 169 Lighting (control system) 164 Menus and submenus 145 Resetting all (control system) 160 Resetting in the submenu 161 Selective 94, 100 Settings menu Functions in 160...
Page 473 Index Speed Setting current 216 Setting to last stored speed in Distron- ic* (“Resume” function) 224 Speed settings Cruise control 217 Distronic* 223, 224 To last stored speed (“Resume” func- tion) in Cruise control 217 Speedometer Displays 220 Settings units 163 Speedometer display mode Selecting 163 Sporty driving style 232...
Page 474 Suspension tuning For regular driving style 232 For sporty driving style 232 Setting 232 Switching off Automatic central locking (control system) 168 Engine 57 ® Hazard warning flasher 136 Headlamps 57 Switching on Automatic central locking (control system) 168 ® Front fog lamps 134 Front lamps 131 Hazard warning flasher 136...
Page 475 Index Temperature Display mode 163 Setting units in display 163 Tires 307 Tie-down hooks (Trunk) 240 Tightening torque 449 Tightening torque (Wheel bolts) 407 Tilt/sliding sunroof Stopping 214 Synchronizing 214 TIN 325 Tire Vehicle maximum load on 325 Tire and Loading Information 301 Tire and loading terminology 323 Tire care and maintenance 298 Tire Identification Number see TIN...
Page 476 Trunk Auxiliary fuse box 417 Closing 105 Closing from the inside automatically* 105 Lighting 138, 139 Lock button, KEYLESS-GO* 101 Message in display 375 Opening 103 Opening from inside vehicle 104 Opening with SmartKey 95 Parcel net 247 Tie-down hooks 240 Trunk lid 103, 105 Trunk lock 389 Unlocking with SmartKey 95...
Page 477 Index Useful features 241 Ashtrays 249 Cigarette lighter 250 Document holder 241 Garage door opener 263 Heated steering wheel* 252 Storage compartments 242 Tele Aid 254 Telephone* 253 Vanity mirror in the rear 242 Vanity mirror in the sun visor 241 Vacuum line routing diagram label 422 Vanity mirror in the rear 242 Vanity mirror in the sun visor 241...
Page 478 Ventilated storage compartment 203 Ventilation Storage compartment 203 VIN (Vehicle Identification Number) 449 Voice control system* 449 Hands-free microphone 29 Warning indicators Parktronic* 236 Warning lamps see Lamps, indicator and warning Warning sounds Distance warning function* 226 Distronic* 220 Drivers seat belts 67 Parking brake 49 Warranty coverage 421 Washing the vehicle 332...
